ASSEMBLY INSTRUCTIONS
Replacement Canopy for the Roof Style Gazebo 184DGZ1-PU-25
Canopy Model # 184DGZ1-PU-25-CPY
L1
L2
1. With a free-standing ladder, remove the original vent
cover and main canopy from the frame.
2. Put the ladder at the center of the frame. Gently place the
main canopy L2 over the roof frame. Pull the canopy down to
each corner until all corner roof tubes t well into corner
pockets on the canopy.
IMPORTANT:
The corner roof tubes should be placed into the corner
pockets prior to placing the middle roof tubes into the middle
pockets. This will help to place the canopy onto the roof with
ease.
3.Use the pockets in the middle of each side to cover each
middle roof tube.
4. From under the main canopy gently put the vent cover over
corner roof tubes. Attach the nettings of the vent cover L1 to
the main canopy L2 with the hook and loop straps on them.
Part Descripton Quantity
L1 Vent Cover 1
L2 Main Canopy 1
Call between 8:30am to 4:30pm C.S.T.
(Monday to Friday)
Linya Outdoor Living, LLC
P.O. Box 423
Ripon WI 54971
TEL: (833) 807-3550
Customer Service:
Customer-Service@Linyaoutdoor.com
Please contact our customer service department if
you have any questions.
