Home Healthcare
Wireless Communicaon Gateway
INSTRUCTIONS FOR USE
Altaneos S.R.L.
Chaussée Verte, 93B | 4470 Saint-Georges | Belgium
www.altaneos.com | [email protected]
Tel : +32 4 233 37 03
D01031-001
Gate2Care and its accessories
Funcon Buon &
Mulcolor LED indicator
USB-C
Power Entry
SIM Card Cover
Mains Wall-Plug Adapter
(shown with US Plug)
EU, US and UK
Interchangeable Plugs
1. Introducon
Gate2Care is a wireless communicaon gateway. It is intended to
establish the communicaon between a wireless sensor (using the
Bluetooth® technology) in a Home Healthcare Environment and a
digital system located in the Internet (using either WiFi® or GSM/LTE
networks).
The device doesn’t require the use of a Smartphone or any other
connected device to be used. Gate2Care has been provided to you by a
professional Home Healthcare company as part of a complete kit
including one or several sensors.
This Instrucon for Use document focuses only on essenal
informaon for the Gate2Care device (intended use, safety,
performance), while the day-to-day use of the device is documented
on a separated guide provided separately and depending on the
specic Home Healthcare system you are using.
2. Quick start guide
• Unpack the device.
• Place the device in any room (indoor use only).
• Posion can be horizontal or vercal.
• Select the right Mains plug (EU, US or UK) and place it on the
Wall-Plug Mains Adapter.
• Plug the USB-C connector of the Adapter in the device.
• Plug the Adapter into the Mains outlet.
• The device is no powered and the mulcolor LED indicator
starts blinking.
3. Funcon Buon
The use of the illuminated buon depends on the specic Home
Healthcare system you are using. See addional documentaon
provided for details.
4. Mulcolor LED indicator
The meaning (color and blinking) of the LED indicator depends on the
specic Home Healthcare system you are using. See addional
documentaon provided for details.
5. Power Supply and Internal baery
Gate2Care is provided with an internal baery allowing the device to
connue running for some me if the Mains Adapter is disconnected.
If Mains Adapter is disconnected, the LED indicator will provide
specic indicaon and specic warning will be sent to the data
management system on the Internet. The behavior depends on the
specic Home Healthcare system you are using. See addional
documentaon provided for details.
The normal use of Gate2Care requires that the Mains Adapter is
connected to a Mains wall outlet and to Gate2Care. The internal
baery is provided as a backup power only.
Important Note:
If a dierent USB-C Mains adapter is used, its specicaons must be
at least equivalent to those of the adapter supplied with the
product. It must also be a Limited Power Source (LPS) type adapter.
6. Technical Specicaons
General
Trademark
Gate2Care
Device model reference
P00681-001
Adaptor model reference
PEAMW12I-10-USBC
Power Supply – Adapter
Nominal input voltage of the adapter
90-265 V AC
Nominal input frequency of the adapter
50-60 Hz
Nominal output voltage of the adapter
5V DC
Nominal output power of the adapter
12W
Power Supply – Device
Nominal input voltage of the device
5 V DC
Nominal output power of the adapter
7.5W
Internal rechargeable baery
Li-Polymer 3.7V 1000mAh
Internal non-rechargeable baery
Lithium Coin Cell CR1225
Classicaon
Mode of operaon
Connuous
Insulaon class of adapter
II
Ingress protecon code
IPX0
Physical characteriscs
Dimensions
98x98x42mm
Weight
142g
Operang Condions
Temperature
+10°C to +40°C
+50°F to +104°F
Relave humidity
55-85%
Altude
< 2000m
Storage Condions
Temperature
-20°C to +40°C
-4°F to +104°F
Relave humidity
55-85%
Altude
< 2000m
7. Integrated Radio Interfaces
Radio Interface
Technical Specicaons
WiFi
2.4 GHz WiFi (802.11 b/g/n)
2412-2472 MHz
20/40MHz BW
DSSS & OFDM Modulaons
Channel spacing 5 MHz
Onboard PCB antenna 3.26dBi
Transmit Power 19.9dBm EIRP
Bluetooth
2.4 GHz Bluetooth 5
2402-2480 MHz
GFSK Modulaon
Channel Spacing 2 MHz
Onboard PCB antenna 3.26 dBi
Transmit Power 10dBm EIRP
LTE Cat 1bis
LTE-FDD bands: B1/B2/B3/B4/B5/B7/B8/B12/
B13/B18/B19/B20/B25/B26/B28/B66/B71
LTE-TDD bands: B34/B38/B39/B40/B41
Maximum Output Power: +23dBm±2.7dB
(LTE Power Level 3)
Antenna peak gain:
698~824MHz: 0.40dBi
824~960MHz: 1.60dBi
1710~2170MHz: 3.50dBi
2300~2400MHz: 3.60dBi
2500~2690MHz: 2.10dBi
GNSS Receiver
GPS/Galileo/GLONASS/Beidou L1 Compable
1559-1609 MHZ Operang Frequency Range
Antenna peak gain: 0.7dBi
NFC Tag
ISO15963 NFC Tag – 13.56 MHz
8. CE Marking
This is a class B product. In a domesc environment, this product may
cause radio interference, in which case the user may be required to
take adequate measures.
EU Declaraon of Conformity
Altaneos hereby declares that the device is in compliance with the
essenal requirements and other relevant provisions of direcves
2014/53/EU, 2011/65/EU and (EU)2015/863.
RF Exposure Informaon
This device meets the EU requirements (2014/53/EU Arcle 3.1a) on
the limitaon of exposure of the general public to electromagnec
elds by way of health protecon.
9. FCC Statement (USA)
FCC ID: 2BUWO-00687001
This device complies with Part 15 of the FCC Rules. Operaon is subject to the
following two condions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operaon.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protecon against harmful interference in a residenal
installaon. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instrucons, may
cause harmful interference to radio communicaons. However, there is no
guarantee that interference will not occur in a parcular installaon. If this
equipment does cause harmful interference to radio or television recepon,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separaon between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
This equipment complies with FCC’s radiaon exposure limits set forth for an
uncontrolled environment under the following condions :
1. This equipment should be installed and operated such that a minimum
separaon distance of 20cm is maintained between the radiator (antenna) and
user’s/nearby person’s body at all mes.
2. This transmier must not be co-located or operang in conjuncon with
any other antenna or transmier.
Changes or modicaons not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
10. IC Statement (Canada)
CAN ICES-3 (B)/NMB-3(B)
This equipment complies with RSS102’s radiaon exposure limits set forth for
an uncontrolled environment under the following condions:
1. This equipment should be installed and operated such that a minimum
separaon distance of 20cm is maintained between the radiator (antenna) and
user’s/nearby person’s body at all mes.
2. This transmier must not be co-located or operang in conjuncon with
any other antenna or transmier.
Cet équipement est conforme aux limites d’exposions de la CNR102
applicables pour un environnement non contrôlé aux condions suivantes:
1. Cet équipement devra être installé et fonconner de telle manière
qu’une distance minimale de séparaon de 20 cm soit maintenue entre la
pare rayonnante (l’antenne) et l’ulisateur / les personnes à proximité à tout
moment.
2. Cet émeeur ne doit pas être co-localisé ou opérer en conjoncon avec
toute autre antenne ou émeeur.
This device contains licence-exempt transmier(s)/receiver(s) that comply with
Innovaon, Science and Economic Development Canada’s licence-exempt
RSS(s). Operaon is subject to the following two condions:
1. This device may not cause interference.
2 This device must accept any interference, including interference that may
cause undesired operaon of the device.
L’émeeur/récepteur exempt de licence contenu dans le présent appareil est
conforme aux CNR d’Innovaon, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L’exploitaon est
autorisée aux deux condions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d’en compromere le fonconnement.
