TWO WAY RADIO(GMRS RADIO)
KG-UV96G
Quanzhou Wouxun Electronics Co., Ltd.
Jiangnan High Technology Industry Park, No.928 Nanhuan Road, Quanzhou, Fujian, China
Scan/RX: 108-136MHz, 136-174MHz, 400-480MHz
TX: 462.5500-462.7250MHz, 467.5500-467.7250MHz
TX/RX: 2402-2480MHz
462 MHz Main Channels:35.25dBm(Conducted)
462 MHz interstitial channels:35.23dBm (ERP)
467 MHz Main Channels: 35.08dBm (Conducted)
467 MHz interstitial channels: 26.93dBm (ERP)
Accord to that antenna length in different regions, only below type
antenna was authorized use in the product.
Antenna Model: ANO-012
Antenna Type: Whip steel antenna Antenna
Gain: 2.15dBi
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
is connected.
— Consult the dealer or an experienced radio/TV technician for help.
— Connect the equipment into an outlet on a circuit different from that to which the receiver
This equipment generates, uses and can radiate radio frequency energy and, if not installed
the user's authority to operate the equipment.
1)Hold the radio in a vertical position in front of face with the microphone (and the other parts of
the radio, including the antenna) at least one inch (2.5 cm) away from the nose. Keeping the
radio at the proper distance is important because RF exposures decrease with distance from the
the antenna. Antenna should be kept away from eyes.
2)When worn on the body, always place the radio in approved clip, holder, holster, case, or
body harness for this product. Use of non-approved accessories may result in exposure levels,
3)Use only manufacturer’s name approved supplied or replacement antennas, batteries, and
accessories. Use of non-manufacturer-name approved antennas, batteries, and accessories
which exceed the General Population/Uncontrolled Exposure environment RF exposure limits.
may exceed the FCC RF exposure guidelines.
Any Changes or modifications not expressly approved by the party responsible for compliancecould
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Your wireless hand-held portable transceiver contains a low power transmitter.This product
sends out radio frequency (RF) signals when the Push-to-Talk(PTT) button is pressed.
The device is authorized to operate at a duty factor not to exceed 50%.
§ 95.1743 Minor GMRS operators.
Operators under the age of 18 will not be held personally responsible, pursuant to § 95.343,
for improper operation of a GMRS repeater or base station. The holder of the individual license
under which the minor operates is solely responsible for any improper operation that occurs
while an individual under the age of 18 is operating the station
4) For a list approved accessories please consult your local dealer for information.
Users must be fully aware of the hazards of the exposure and able to exercise control over their
RF exposure to qualify for the higher exposure limits.
467.6250, 467.6500, 467.6750,467.7000 and 467.7250MHz. In basic terms, a repeater is a
device that is used to increase the range of two way radios.
Repeaters will receive a transmission on one frequency and simultaneously rebroadcast that
transmission on different frequency. Repeaters are often set up in a fixed location and connected
to an antenna that is mounted at a higher elevation to provide better range than is normally
available with radio-to-radio(simplex) communications. Using GMRS repeaters can significantly
increase the range of your radio, but just tuning to one of the repeater channels isn't necessarily
going to work.
You first have to be sure there is a repeater listening on that channel's frequency, and you have to
be within range of that repeater. It is important to keep in mind that a GMRS repeater is not
necessarily intended for public use. They are owned by individuals and are sometimes intended for
have permission or that the owner is fine with public use. The description on the my GMRS website
usually indicates if permission is required and provides a way to get in touch with the owner.
private use or require permission to use. Before connecting to a GMRS repeater, be sure that you
The Radio is pre-configured with 8 GMRS repeater channels: 467.5500, 467.5750, 467.6000,
MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR RADIO
TELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC
RULES AND FEDERAL LAW.
