Use both hands to pry the cover apart on both sides.
As shown in the following figure, install the paper roll with the thermal
side facing outward.
Move the paddle switch up and adjust the paper limiter according to the
width of the paper roll. After adjustment, press down the paddle switch
and lock the paper limiter.
Pull out a small piece of paper and close the lid.
Product Introduction
Packing List
Paper Loading Instruction
Indicator Status
Paper Loading Instruction
Flash: Firmware upgrade in progress
Slow flashing: charging
Always on: Printer ready/Bluetooth connected
successfully/Bluetooth disconnected
/Bluetooth lost
Constant brightness: abnormal
(paper shortage/cover opening/TPH overheating)
Slow flashing: low battery
Product Introduction
White
Light
White
Light
On/Off
Long press the power button for 3 seconds to turn it on/off.
If you need to charge, please use a USB Type-C to Type-A cable and connect the
power adapter (self provided, adapter output not higher than 5V/1A) to the printer
for charging.
When the battery level is low, the indicator light will flash (white, flashing once per
second). Please charge in a timely manner. If you continue printing, the printer may
automatically shut down.
Battery charging
Note: You can use a power adapter or computer USB for power supply, and
the adapter is not included when shipping. If consumers use a power
adapter for charging, they should purchase and use a power adapter that
has obtained CCC certification and meets the standard requirements.
Printer
Tear Bar
Type-C Charging Port
Reset Hole
Power Button
Indicator Light
Abnormal
State
Basic State
Appearance and Components
The actual content inside
the box shall be based on
the actual object.
Quick Start Guide
01
02
03
04
Edit the labels as needed, click "Next" after editing, and then print.
Connect Printing
Open the Hancode app and click on "My" - "Connect Device".
Check the list of "Bluetooth devices", find "HM-T260L-XXXX", and click to connect.
Click "New" - "New Label". Set the label width and height based on the actual size
of the label paper.
APP Download
Scan QR code to download the app:
“HereLabel” APP“HerePrint” APP
Thermosensitive Layer
Charging
through PC
Charging through
power adapter
HM-T260L
Online WeChat Customer Service
(Warranty/After Sales/Technical Support)
FCC WARNING
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help. To
maintain compliance with FCC’s RF Exposure guidelines, This equipment
should be installed and operated with minimum distance between 20cm
the radiator your body: Use only the supplied antenna.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
