Instruction Manual
Accessories List
Product Introduction
Indicator Light Status
Nut
Indicator Light
type-c Po
Magnetic Wireless Charging Area for Mobile Phones
Air cooling control button
(Low Speed / High Speed / O)
Single press the key
(Cycle through low wind
/ high wind / o modes)
Air cooling control button
Rear Schematic
Diagram
Clip Mount
Ball Joint
A ir Vent Clip
Wireless Car Charger
Operation Instructions
Product SpecicationsAdapter Selection
Made in China
Mode Indicator Light
Power-On
Standby
Air cooling ON
Air cooling OFF
Foreign Object Detected /
Protection State
Blue light steady on
Green light steady on
Light o
Blue and green lights ash alternately once,
then the blue light stays steady on
Blue light ashing
Over-temperature /
Over-current State
Blue light ashing
1
3
2
70*78mm
Air cooling function description
e air cooling system runs for 5 seconds during power-on self-test; it will shut down
automatically if no device is detected. Air cooling operates continuously while the device is
charging. Air cooling stops when the mobile phone is fully charged or the FOD foreign
object detection alarm is triggered.
FCC Warning Statement
FCC Warning Statement
Changes or modications not expressly approved by the pay responsible for compliance
could void the user’s authority to operate the equipment. is equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant to Pa 15 of the
FCC Rules. ese limits are designed to provide reasonable protection against harmful
inteerence in a residential installation. is equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful inteerence to radio communications. However, there is no guarantee
that inteerence will not occur in a paicular installation. If this equipment does cause
harmful inteerence to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to t to correct the inteerence by one
or more of the following measures:
‐‐ Reorient or relocate the receiving antenna.
‐‐ Increase the separation between the equipment and receiver.
‐‐ Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
‐‐ Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
e antennas used for this transmitter must be installed to provide a separation distance
of at least 20 cm from all persons and must not be co‐located for operating in conjunction
with any other antenna or transmitter.
is device complies with Pa 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1)is device may not cause harmful inteerence.
(2)is device must accept any inteerence received, including inteerence that may
cause undesired operation.
Name:
Wireless Car
Charger
Product Dimensions (Bare Unit)
68mm*68mm*45mm
USB-C Input:
12V⎓3A,15V⎓3A
Operating Frequency:
110-365KHz
Mobile Phone Output:
25W
Eective Wireless Charging
Distance (for Mobile Phones):
≤3mm
Conversion Eciency:
60%-80%
Material:
ABS + Silicone
When using a PD 30W car charger adapter, the maximum output
power for mobile phones is 15W.
When using a PD car charger adapter rated 36W or above,
the maximum output power for mobile phones is 25W.
❶Put the nut into the ball joint, inse the clip mount into the ball joint
and tighten with the nut.
❷Place the air vent clip on the car air vent vane and tighten to lock it in
place.
❸Plug in the Type-C charging cable, the indicator light will turn on.
Place your iPhone on the magnetic wireless charging area to sta
charging.
Main Unit × 1
Instruction Manual × 1
Type-C Charging
Cable (1m) × 1
Air Vent Clip × 1 Nut × 1
Frequently Asked Questions
(1)Please ensure that your mobile phone suppos wireless charging.
(2)Please connect to a power source using the original charging cable before use.
(3) Please make sure there are no metallic materials, magnetic objects, credit cards or pop
sockets between your phone and phone case.
Why is this charger not working?
Why is fast charging not working?
(1)Please use a PD 36W or higher car charger adapter. e maximum power is 25W,
and the refrigeration function can be activated.
(2) Please connect to a power source with the original charging cable before use.
70mm
78mm
70mm
78mm
