Right Speaker
Le Joystick
Select Buon
Right Joystick
= Buon
LB BuonRB Buon
Vol + / - Buons
Microphone
Le Speaker
Active Cooling
Air Intake
Home Buon
RT Trigger LT Trigger
Active Cooling
Air Outlet
RC Buon
LC Buon
Power Buon with
Fingerprint
Power
Indicator
Micro SD Card Slot
Type-C Po (Charging / DP / Data po)
D-Pad
Sta Buon
AYA Buon
ABXY Buons
Storage Expansion
The AYANEO Pocket S mini is equipped with a Micro SD card
expansion slot. Open the dust cover at the boom of the device
to install or replace the Micro SD card.
AYANEO Pocket S mini suppos WLAN network. When you need to connect to the network through WLAN, set the
" " and enter the seings menu home page, > "Internet". Select the network and
enter the password, then click "Connect" to join the WLAN network.
To connect to a Bluetooth device, go to the main seings menu and select "Connected Devices" > "Pair with New
Device". Once the device search is complete, click on the desired Bluetooth device from the list to initiate the con-
nection.
Connected Devices > Pair with New Device
Pair new deviceconnected devicesb
Network and internet
Mobile, Wi-Fi, hotspot
To use the ngerprint recognition feature, you must rst set up "Screen Lock" to enable and congure the nger-
print functionality. Seings " " > Security " " > Screen Lock, where you can choose to set a paern, PIN, or
password. Aer that, under the security options, select " ", and enter your password or PIN to conrm security.
Once you have conrmed your security credentials, follow the prompts to register your ngerprint.
In the power-o state, press and hold the power buon " " for about 3 seconds and then release to power on
the AYANEO Pocket S mini.
In the power-on state, press and hold the power buon " " for about 2 seconds to bring up the menu. Select
" " to shut down the AYANEO Pocket S mini, or select " " to resta the AYANEO Pocket S mini.
In the power-on state, press the power buon " " to put the AYANEO Pocket S mini into sleep mode.
In sleep mode, press the power buon " " to wake up the AYANEO Pocket S mini. If a security screen lock has
been set, you will need to draw the paern, enter the password, or PIN to unlock and access the system inteace. If
both security screen lock and ngerprint recognition are congured, you can simply touch the power buon to
complete ngerprint recognition, which will quickly wake up and enter the system inteace.
Note: Aer a power-o and resta, or aer a resta while the device is powered on, you will need to re-verify the
security screen lock before you can use ngerprint unlock to access the screen.
Volume Control
You can use Vol + / - Buons control volume function. Alternatively, you can go to " " > " " to
adjust the media volume, notication volume, alarm volume, etc. accordingly.
Pull-down Menu
To access the pull-down menu, swipe down from the top of the screen for the rst time to quickly toggle seings
such as WLAN and Bluetooth. Swipe down again to display the full pull-down quick menu. You can adjust the screen
brightness by sliding the brightness slider, and peorm other quick seings congurations.
Service and Suppo
When you submit a valid claim under the warranty service policy, AYANEO will, at its discretion, repair, replace, or
refund your AYANEO Pocket S mini. The warranty rights you have are in addition to the rights provided by local
consumer law. When you make a claim under this warranty policy, you may be required to provide detailed informa-
tion about your purchase receipt.
For more suppo and troubleshooting information, please visit www.ayaneo.com
Cleaning
Please use a lint free cloth to clean AYANEO Pocket S mini. Do not let the opening of the body get damp. Do not use
aerosol sprays, solvents, or abrasives for cleaning.
Electromagnetic Inteerence (EMI)
The AYANEO Pocket S mini contains components with magnets and emits electromagnetic elds from radio waves,
which may inteere with medical devices, pacemakers, debrillators, or other medical equipment. Maintain a safe
distance between medical devices and the AYANEO Pocket S mini. Consult your physician and the medical device
manufacturer for information on your medical devices. If you suspect that the AYANEO Pocket S mini is inteering
with your pacemaker, debrillator, or other medical devices, stop using the AYANEO Pocket S mini.
Warranty
AYANEO warrants the hardware products and accessories included with your purchase against defects in materials
and workmanship under normal use for one year from the date of original retail purchase. This warranty does not
cover normal wear and tear or damage caused by accidents or misuse. For service, visit the AYANEO store or an
authorized AYANEO service provider. Available service options may depend on the country or region where the
service is requested and may be limited to the country or region of original sale. There may be a charge for call and
international shipping fees, depending on your location.
Baery and Charge
Please use the ceied adapter correctly for charging to ensure safety compliance. Do not use adapters without
safety ceication as they may damage internal components and pose unpredictable risks.
When plugging in a USB Type-C cable to a power source, avoid prolonged skin contact with the plug to prevent
discomfo or injury.Do not aempt to replace the AYANEO Pocket S mini baery on your own, as this may damage
the baery, leading to overheating which could cause res and personal injury.
The lithium-ion baery of the AYANEO Pocket S mini should be serviced or recycled by AYANEO or authorized ser-
vice providers. Self replacement of baeries may pose a risk of explosion.
Please follow local environmental regulations for baery disposal. The baery should only be replaced by AYANEO or
an authorized AYANEO service provider. Using incorrect baery models for replacement poses a risk of explosion.
Network / Bluetooth
Text Input
When you need to input text, simply tap on the text input eld to automatically bring up the on-screen keyboard,
and use the touch input to type your text.
Sleep Mode
Fingerprint Recognition
Power On / Power O / Resta
Sound and vibration
Volume, vibration, Do Not Disturb
1. The maximum operating ambient temperature of the product is 35°C.
2. If consumers use a power adapter for power supply, they should purchase and use a power adapter that has obtained CCC ceication and
meets the standard requirements.
3. Replacing with a baery pack of the wrong model poses a risk of re or explosion.
4. Do not place the baery pack in extremely high temperature or extremely low pressure environments, or subject the baery pack to
mechanical extrusion or cuing, as this may cause an explosion or leakage of ammable liquids or gases.
Caution: Please do not listen at high volume for extended periods, as there is a risk of hearing damage.
Warranty Service
AYANEO provides a warranty for the hardware products and accessories included, eective for one year from
the date of original retail purchase. The warranty does not cover normal wear and tear or damage caused by
accidents or improper usage. To request service, please visit the ocial AYANEO website or an authorized
service provider. Available service options may depend on the country or region where the service request is
made and may be limited to the original country or region of sale. Additional charges, such as phone or
international shipping fees, may apply.
When you submit a valid claim under the warranty service policy, AYANEO will, at its discretion, provide repair,
replacement, or refund services for your AYANEO Pocket Fit. Your warranty rights are supplementary to those
provided by local consumer laws. When submiing a claim under this warranty policy, you may be required to
provide detailed purchase proof.
● Environmental Protection and Recycling
Do not disassemble the product yourself. It must be disposed of separately from household waste. Please follow
local environmental regulations for recycling.
● Protection
Avoid dropping, crushing, or bumping the device, as it may cause physical damage.
● Accessory Variations
Some accessories may vary depending on the purchased conguration and country or region.
● Medical Device Inteerence
The internal components of the AYANEO Pocket Fit contain magnets and electromagnetic elds that may
inteere with medical devices, pacemakers, debrillators, or other medical equipment. Please maintain a safe
distance between the AYANEO Pocket Fit and medical devices.
Consult your physician and medical equipment manufacturer for information. If you suspect the AYANEO Pocket
Fit inteeres with your pacemaker, debrillator, or other medical equipment, stop use immediately.
Names and Contents of Hazardous Substances in the Product
This table is compiled according to SJ/T11364 regulations.
〇: Indicates that the content of the hazardous substance in all homogeneous materials of the
pa is below the limit requirement specied in GB/T26572.
X: Indicates that the content of the hazardous substance in at least one homogeneous material
of the pa exceeds the limit requirement specied in GB/T26572.
Note: This product applies an environmentally friendly design concept and eectively controls hazardous
substances. The "X" indicates that the hazardous substance is primarily due to the limitations of
technological development, making substitution of the hazardous substance impossible.
Environmental Protection Use Period
The symbol indicates the period (ten years) during which the hazardous substances contained in electronic and
electrical products will not leak or undergo abrupt changes under normal use conditions. During this period, the
use of these electronic and electrical products will not cause severe pollution to the environment or cause
serious harm to the user’s health and propey.
Power Cables
Metal Pas
Plastic Pas
PCB Components
Pa Name
(Pb)
(Hg)
(Cd)
Hazardous Substance
(Cr(VI)) (PBB) (PBDE)
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to computer
or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Specific Absorption Rate (SAR) information: This device meets the government's
requirements for exposure to radio waves. The guidelines are based on standards that
were developed by in dependent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons regardless of age or health.
FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg
averaged over one gram of tissue. Device types: device has also been tested against this
SAR limit. This device was tested for typical body-worn operations with the back of the
Tablet computer kept 0mm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain an 0mm separation distance
between the user's body and the back of the Tablet computer.
The use of belt clips, holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF Exposure requirements, and should be
avoided.
