USER MANUAL
HOW-TO
THANK
YOU!
Thank You for Purchasing from
Made in China
NOTE:
modify this information without prior notification.
For any questions regarding assembly, please watch the video on the
product page or contact our customer service. Our customer service will
To continuously improve its products, reserves the right to
Thank you for using products in your home!
Evaporative Air Cooler
SWING TIMER COOL SPEED ON/OFF
1
SECTION A
Instruction
Notice:
The machine may produce some special smells for the first
time. This is normal, and smells will disappear after several
hours of running.
Evaporative cooling:
Evaporative cooling is a very economical way of cooling. Air
can be cooled through the evaporator medium; fresh, cool air
makes our body feel cool. Be sure to open doors and win-
dows when you use the indoor space. I If you use it in an en-
closed space, it will increase the environmental temperature,
therefore affecting the cooling effect. The best way to use the
evaporative air cooler is to place it in front of the vents of
doors and windows, which are placed in the ventilation
passage to draw in fresh air and maintain airflow.
Warning: To reduce the risk of electric shock or fire, you can't
use the "SCR fan speed controller" on this machine.
All maintenance must be performed with power discon-
nected.
To avoid the risk of electric shock, the power plug has to be
connected to the grounded sockets and connected to the
grounding fault automatic protection device.
Don't let an unsound, incomplete behavior person (includ-
ing a child) contact and use the product; unless there is a
normal person supervising or guiding, don't let children
play with the product.
Assembly is EASY!
WE WANT
YOU TO
ENJOY LIFE
AT
GO TO THE PRODUCT LISTING PAGE
FOR AN INSTRUCTIONAL VIDEO!
Safety rules:
1.
2.
3.
2
SECTION B
Mounting Casters
3
SECTION C
Control Panel
Notice:
The product has 4 pieces of 2 inches of casters, which
include 2 pieces of casters with brakes and 2 pieces of
casters without brakes. Please take out the casters and
screw them on the bottom of the water tank. Please sepa-
rate casters with brakes and without brakes on each side.
- Electronic remote control
- Remote control
SWING TIMER COOL SPEED ON/OFF
5
Warning: You must unplug the product before any repair or
maintenance.
As in the picture: open the
top lid and add water or ice.
Unscrew the back side panel
and push it up.
Pull the back panel out and
down, then take off the back
panel.
Spin counterclockwise the
cooling pad pin, then take off
the cooling pad to clean.
4
SECTION D
Repair and Maintenance
SECTION E
Troubleshooting
- Clean cooling pad
Fault Reasons/Solutions
1. Machine doesn't
work.
The power cord is not connected
properly.
4. Doesn't swing.
Please confirm the "SWING" switch
is turned "ON".
5. Fan leaking.
Please check if the drain plug is tight
or not.
The power switch is not turned on.
Please confirm the power switch is
turned "ON".
2. Water pump
doesn't work.
The water pump is not turned on.
Please confirm thewater pump
switch is turned "ON".
The water level is too low. Please
add water and turn on "COOL".
The water pump is broken. Please
change water pump.
3. Fan doesn't work.
The power switch is not turned on.
Please confirm power switch is
turned "ON".
If it's connected to ground protec-
tion, please check if the ground pro-
tection is short circuited or not.
Check if the power cord is connect-
ed correctly or not.
SECTION F
Warranty
6 7
The VIVOHOME warranty program is our commitment to you.
We are committed to providing you with a high-quality prod-
uct that meets your needs and expectations. To demonstrate
our confidence in the durability and performance of our
products, we offer the following warranty.
This warranty program applies to any orders, purchases,
receipts, or use of any products sold by VIVOHOME and is
valid for a period of 1 year from the date of purchase. Howev-
er, please note that this warranty period is only valid for the
original order. If you receive a replacement order during the
warranty period, it will not include a separate warranty
period.
WARRANTY COVERAGE
This warranty does not cover damage resulting from misuse,
accident, unauthorized modification, or any other circum-
stances not directly related to the manufacturing and design
of the product, including but not limited to:
Parts lost during use.
Normal wear and tear of products or parts.
Incorrect installation (such as using the wrong voltage) or
assembly.
Exceeding the bearing capacity of the product.
Use under extremely harsh conditions.
WARRANTY EXCLUSIONS
VIVOHOME will provide technical support, replacement,
refund, or other solutions based on the nature of the issue. If
you wish to return the original package for any reason, please
contact us for confirmation before proceeding. You can
expect to receive a response within 48 hours.
Thank you for choosing VIVOHOME. We are committed to
ensuring the quality and satisfaction of your purchase. If you
have any questions or need assistance, please do not hesitate
to contact our customer service team.
If you find any defects that affect the use of the product or if
the product stops working and cannot be repaired during the
warranty period, please contact our customer service team at
our email or via Amazon & app’ s direct messaging service as
soon as possible. Provide the following information to expe-
dite the process:
HOW TO MAKE A WARRANTY CLAIM
Order number
Images and/or videos illustrating the issue
A detailed description of the problem
●
●
●
●
●
●
●
●
Improper cleaning or maintenance.
Damage caused by any reason other than the intended
use of the product.
Indirect loss or damage caused by the product.
●
●
●
