TRAILER COUPLER
MODEL: SS-TC-10B
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: SS-TC-10B
Have product questions? Need technical support? Please feel free to
contact us:
TechnicalSupport and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TRAILER COUPLER
- 2 -
SAFETY INSTRUCTIONS
1. Safety chains must be used.
2. Be sure to take good protection during welding work.
3. Be sure to check that the bolts are tight.
4. Be sure to match the corresponding trailer ball.
5. After towing for 50 miles, check coupler for tightness on ball. Always
check tighness before towing. Be sure coupler handle is in locked
position.
6. Do not exceed the gross trailer weight capacity.
MODEL AND PARAMETERS
Model
SS-TC-10B
Capacity
7000lbs
Ball Size
2inch
Applicable Channel
2inch
Mounting Angle
50°
Color
Black
- 3 -
STRUCTURE DIAGRAM
1.Ball Socket 2.Handle 3.Safety Pin 4.Jack Mounting Hole
1
2
3
4
- 4 -
COMPONENTS
No.
Name
Qty
1
Trailer Coupler
1
3
User Manual
1
OPERATION
To open, pull the coupler handle and rotate. Place coupler on ball. When
ball is completely nested in ball socket. Release the coupler handle until
handle is in locked position. Plug in the safety latch.
After towing for 50 miles, check coupler for tightness on ball. Always check
tighness before towing. Be sure coupler handle is in locked position.
Remove the safety pin.
- 5 -
Installation:
The welding must be firm and reliable.
Φ2.32in
Φ3.5in
Holes:3-3/8-16
- 6 -
MAINTENANCE
1. Please check that the bolts are tight before each use.
2. Do not overload.
3. Pay attention to rust prevention.
MADE IN CHINA
