OWNER’S MANUAL AND SAFETY INSTRUCTIONS
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST
OUTDOOR FIREPIT TABLE
ITEM: 96800
IMPORTANT SAFETY INFORMATION
1
EXPLOSION - FIRE HAZARD: Keep solid combustibles, such as building materials, paper or cardboard,
Provide adequate clearances around air openings into the combustion chamber.
NEVER
such as gasoline, solvents, paint thinner, dust particles or unknown chemicals
DO NOT
materials: two (2) feet from the sides & two (2) feet from the rear, 6 feet from ceiling.
EXPLOSION - FIRE HAZARD:
sunlight, other ignition sources or where temperatures exceed 120 degrees F (49 C).
Propane vapors are heavier than air and can accumulate in low places. If you smell gas, leave the
area immediately.
NEVER
Store the propane cylinder outdoors in a well ventilated space out of reach of children. Never store the
the propane cylinder for outdoor storage.
exist, follow National Fuel Gas Code, ANSI Z223.1. In Canada, installation must conform to local codes.
If no local codes exist, follow the current National standards of CANADA CAN/CGA-B 149.2.
CARBON MONOXIDE HAZARD:
produce carbon monoxide (CO) during the combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of CO if used and maintained in accordance with all warnings
and instructions. DO NOT
fatigue and possibly death. You can’t see it and you can’t smell it. It’s an invisible killer. If these symptoms
are present during operation of this product get fresh air immediately!
2
FOR OUTDOOR USE ONLY.
pit consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life.
DO NOT
appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
CARBON MONOXIDE HAZARD: This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a
camper, tent or home.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operation and maintenance instructions thoroughly before installing or
servicing this equipment.
California Proposition 65 Combustion by-products produced when using this product contain chemicals
known to the State of California to cause cancer, birth defects, and other reproductive harm.
BURN HAZARD:
seriously damaged.
SERVICE SAFETY:
Use as a heating appliance only. Never alter in any way or use with any device.
CAUTION indicates an imminently hazardous situation which, if not avoided, may result in minor or
moderate personal injury, or property damage.
normally added to help detect leaks and can be described as a “rotten egg”smell. The odorant can
fade over time so leaking gas is not always detectable by smell alone.
Propane gas is heavier than air and leaking propane will sink to the lowest level possible. It can ignite by
original leak. Use only propane gas set up for vapor withdrawal.
Store or use propane gas in compliance with local ordinances and codes or with ANSI/NFPA 58. Turn off
propane when not in use.
DO NOT
Replace any guard or protective device removed for servicing the appliance prior to placing back in
service.
cleaning may be required as necessary. It is imperative that the control compartment, burners, and
circulating air passageway of the appliance be kept clean.
SAVE THESE WARNINGS
3
Features
• Offering both useful functionality and contemporary appeal, the stylish patio heater features
• Fire pit heater offers an impressive heat output of 50,000 BTUs. Mid-winter merry-making? No
• A
• A nylon weather cover protects the table from the rain when it’s not in use
• Heating your outdoor room with an outdoor heater will extend your outdoor entertaining season
and allow you to enjoy your patio or other outdoor living space for a couple of extra months or
in some cases year round
• Easily access the interior compartment to switch out the propane tank
•
• Add
• Outdoor used only
Technical Information
4
PARTS LIST
Cover
Burner Assembly
Side Panel
Back Panel
Front Panel
Left Leg
Right Front Leg
Right Back Leg
Door
Metal Stand
Foot Pad
Control Panel
A
D
F
K
E
J
C
I
B
L
G
H
5
1. Attach the side panel (C) ,back panel (D) and
front panel (E) to the left leg (F) , right front leg
(G) and right back leg (H) using 12 pcs M6x12
screws (AA).
HARDWARE NEEDED:
2. Attach the metal stand (J) , to the front panel
(E) and back panel (D) using 12 pcs M6x12
screws (AA).
Attach the door (I) to the left leg (F) using
1pc M6x12 screw (BB).
HARDWARE NEEDED:
HARDWARE NEEDED:
3.
ASSEMBLY
AA
AA
AA
BB
Bolt M6x12
x12pcs
CC
CC
CC
M6 washer
x12pcs
AA Bolt M6x12
x2pcs
CC M6 washer
x2pcs
BB Bolt M6x16
x1pc
ASSEMBLY
D
D
F
F
E
E
J
I
G
H
Attach the control panel (L) to the front panel
(E) using 2pcs M6x12 screws (AA).
ASSEMBLY
AA
AA Bolt M6x12
x2pcs
(A)cover
to the table top (B), attach the
4 foot pads (K) to the right front leg (G) , right
back leg (H) and left leg (F) .
CC M6 washer
x2pcs
6
HARDWARE NEEDED:
4.
6.
5.
ASSEMBLY
A
F
K
E
B
L
G
7
7. Connect the hose and regulator to the cylinder. The
propane gas and cylinder are sold separately. Use a
standard 20lb. propane cylinder only. Use this heater only
with a propane vapor withdrawal supply system. Storage
of an appliance indoors is permissible only if the cylinder is
disconnected and removed from the appliance. A cylinder
must be stored outdoors in a well ventilated area out of
reach of children. A disconnected cylinder must have dust
caps tightly installed and must not be stored in a building,
garage or any other enclosed area. The maximum outlet
gas supply pressure” 250psi, the minimum inlet gas supply
pressure: 5psi.
The minimum hourly rating of 10000 BTU is required for a
heater for automatic operation at ratings less than full input
rating.
The pressure regulator and hose assembly supplied with
the appliance must be used. The installation must conform
with local codes, with national fuel gas code ANS Z223.1/
NFPA54, natural gas and propane installation code CSA
V149.1, or propane and handling code B149.2.
8
ASSEMBLY
A dented, rusted or damaged propane cylinder may be hazardous
and should be checked by the cylinder supplier. NEVER use a
propane cylinder with a damaged valve connection.
The propane cylinder must be constructed and marked in
U.S. Department of Transportation (DOT), or the standards for
cylinders, spheres and tubes for transportation of dangerous
goods and commission, CAN/CSA-B339.
The cylinder must have a connection device compatible with the
connection for the appliance. The cylinder must also include a
collar to protect the cylinder valve. NEVER connect an unregulated
propane cylinder to the heater. Attach the regulator to the cylinder.
Complete attachment. Install cylinder.
DO NOT store a spare LP gas cylinder under or near this
appliance.
NEVER sill the cylinder beyond 80% full.
Place the dust cap on the cylinder valve outlet whenever the
cylinder is not in use. Only install the type of dust cap on the
cylinder valve that is provided with the cylinder valve. Other type
of caps or plugs may result in leakage of propane.
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE. RESIDENTIAL USE ONLY.
LEAK CHECK
• Perform all leak tests outdoors.
•
• NEVER leak test while smoking
• DO NOT
all connections have been leak
tested and do not leak.
1. Make 2-3oz of leak check solution (one part dish soap and three parts water)
2. Apply several drops of solution where the hose attaches to the regulator.
3. Apply several drops of solution where the regulator connects to the cylinder.
4.
5. Turn the cylinder ON.
If NO bubbles appear at any connection, the connections are secure.
NOTE: Whenever gas connections are loosened or removed, you must perform a complete leak test.
9
OPERATION
CARBON MONOXIDE HAZARD: For outdoor use ONLY. NEVER use inside the house or other
or enclosed areas to avoid endangering your life.
CAUTION: DO NOT attempt to operate until you have read and understand all General Safety Information
in this manual and all assembly is complete and leak checks have been performed.
BEFORE TURNING THE GAS SUPPLY
1.
any other enclosed area.
2
liquids.
3. Ensure that there is no obstruction to air ventilation. Be sure all gas connections are tight and there are
no leaks.
4. Be sure the cylinder cover is clear of debris. Be sure any component removed during assembly or servicing
is replaced and fastened prior to starting.
BEFORE LIGHTING
1.
2. Inspect the hose assembly for evidence of excessive abrasion, cuts or wear. Suspected areas should
be leak tested. If the hose leaks, it must be replaced prior to operation. Only use the replacement hose
LIGHTING
1. Turn the control knob to the OFF position.
2. Fully open the LP cylinder valve. Note: for initial start or after any cylinder change, hold the control knob
IN for 2 minutes to purge air from gas lines before proceeding.
3.
depressing and turning the control knob counter-clockwise until the heater lights. ( You should hear a clicking
noise).
4
then release the control knob. If you want to lower the temperature, push in the control knob and turn
counter-clockwise to the LOW position.
NOTE: If the burner fails to remain lit, all valves should be closed and a waiting period of at least 5 minutes
should pass before attempting to light.
OPERATION
10
ignition.
WHEN FIRE PIT IS ON
this manual.
RE-LIGHTING
1. Turn the control knob to OFF.
2. Repeat the lighting steps as described above.
SHUTTING DOWN THE FIRE PIT
1. To extinguish burner, depress the control knob and continue to turn it clockwise to OFF.
2. Turn the cylinder valve clockwise to OFF and disconnect regulator when the heater is not in use.
SHUTTING DOWN THE FIRE PIT
I am familiar with entire owner’s manual and understand all precautions noted.
All components are properly assembled, intact and operable.
No alterations have been made.
All gas connections are secure and do not leak.
Wind velocity is below 10MPH.
Fire pit is outdoors and outside of any enclosure.
There is adequate fresh air and ventilation.
Fire pit is away from windows, air intake openings, sprinklers or other water sources.
Fire pit is at least 24” away from any combustible materials.
Fire pit is on a hard, level surface.
All burner passages are clear.
All air circulation passages are clear.
OPERATION
AFTER OPERATION:
STORAGE: Between uses
11
OPERATION and MAINTENANCE
1. Gas control is in the OFF position.
2. The Gas tank valve is OFF.
3. Disconnect the Gas line.
regular basis.
KEEP EXTERIOR SURFACES CLEAN:
corrosive cleaning agents.
1. While cleaning your unit, be sure to keep the area around the burner dry at all times. DO NOT submerge
the control valve assembly. If the gas control is submerged, DO NOT use it. It must be replaced. DO NOT
2.
possible blockage include:
Fire pit does not reach the desired temperature.
Fire pit glow is excessively uneven.
Fire pit makes popping noises.
for use. Clean the burner holes using a heavy duty pipe cleaner. Compressed air may help clear away
smaller particles.
deposits develop.
NOTE: In a salt air environment (like near the ocean), corrosion occurs more quickly than normal. Frequently
check for corroded areas and repair them promptly.
TIP:
surfaces only. DO NOT apply to the burner.
Turn the control knob OFF
Disconnect LP source and move to a secure, well-ventilated location outdoors.
.
NEVER leave the LP cylinder exposed to direct sunlight or excessive heat.
SERVICE:
CAUTION:
OPERATION and MAINTENANCE
13
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
TROUBLESHOOTING AND WARRANTY
PLEASE READ THE FOLLOWING CAREFULLY
PRODUCT MADE IN CHINA
