Assembly Manual.

This is the main product document for model BK688244.

The file format is pdf, 20 pages, you can download this manual here .

background
ASSEMBLY MANUAL & PARTS LIST MANUEL DE MONTAGE & LISTE DE PIECES
RETAIN FOR FUTURE REFERENCE VEUILLEZ CONSERVER POUR REFERENCE ULTERIEURE
[email protected]
1-800-265-2150
20084-E59 REV D 09/20
REGAL S590 PRO IR
9589-44
9589-47
background
HARDWARE INCLUDED / MATERIAL INCLUS / EQUIPOS INCLUIDO
TOOLS REQUIRED / OUTILS NECESSAIRES / HERRAMIENTAS NECESARIAS
Y-12865 (26) S21124 (8)
S21125 (4) Y-12222 (2)
S21235 (2) Y-12223 (2)
Y-29304 (6) Y-11560 (4)
S21233 (2) Y-11793 (4)
7/16 [11 mm]
#3 ROBERTSON
#2 ROBERTSON
background
1
(8) (4) (2)
2
(4)
background
3
(2) (2)
4
(4)
background
5
(2) (2) (2)
6
(6)
background
7
8
(2)
background
9
10
(2)
background
11
(2) (2)
A
B
B
A
background
12
(2) (2) (4)
A
A
A
B
B
B
C
C
C
C
C
background
13
(4) (4)
background
14
background
15
background
16
(2) (2)
17
(2) (2)
background
18
background
19
background
20
(2) (2)
background
21
background
22
(1) (1)
background
23
background
24
