11
LANG GRIDDLES
Plate Thickness 1”
Plate Depth 23” & 30”
extra
-
deep
Plate Width 24” - 72”
BTU/ft. 27,000 6.0
Embedded Yes
Thermostat
Electric Snap
-
Action or Solid State
Set Temperature +/- 15
o
F or +/- 4
o
F
Chrome Option Yes
Warranty 3 Year parts and labor
Grooved Griddle Option Yes ($1,100 per 12”)
GAS MODELS
kW/ft.
ELECTRIC
MODELS
STAR ULTRA
-
MAX® GRIDDLES
Plate Thickness 1”
Plate Depth 24”
Plate Width 24” - 72”
BTU/ft.
30,000 - 40,000 4.35
Embedded Yes
Thermostat Mechanical Snap
-
Action
Set Temperature +/- 15
o
F
Chrome Option Yes
Warranty 3 Year parts and labor
GAS MODELS
kW/ft.
ELECTRIC
MODELS
Plate Thickness 1”
Plate Depth 20
1/2
”
Plate Width 15” - 48”
BTU/ft.
28,300 3.0 (208V)
Embedded
Yes
Thermostat Modulating
Set Temperature +/- 30
o
F
Chrome Option Yes
Warranty 2 Year parts and labor
kW/ft.
ELECTRIC
MODELS
STAR
-
MAX® GRIDDLES
GAS MODELS
4.0 (240V)
Plate Thickness
3
/
4
”
Plate Depth 20
1/2
”
Plate Width 24” - 48”
BTU/ft.
20,000 3.0 (208V)
Embedded
No
Thermostat Mechanical Snap
-
Action
Set Temperature +/- 40
o
F
Chrome Option No
Warranty 1 Year parts and labor
kW/ft.
ELECTRIC
MODELS
TOASTMASTER GRIDDLES
4.0 (240V)
GAS MODELS
Why Chrome
?
12
STAR
|
LANG
|
TOASTMASTER CUSTOMER SERVICE 800-264-7827
GRIDDLES
1” VS. 3/4” THICK PLATES
Plate thickness helps drive surface temperature performanc
e
and consistency. 1” thick griddle plates will retain more heat
for faster recovery, and allow thermostat probes to be mounted
deep within the plate for improved performance. 3/4” plates
have bottom
-
mounted temperature probes only.
PLATE DEPTH
Deeper griddle plates offer more cooking area and usable
space. Balance your specific production needs with size
constraints in the kitchen. Different depths available on
select model families.
PILOT SAFETY
Direct Spark Ignition lights
the burner as demanded by the
thermostat, eliminating the need for a standing pilot burner.
This feature requires electric power.
CHROME SURFACE
In addition to their exceptional mirror finish,
chrome plates do not require seasoning
with
oil, clean up faster, reduce kitchen heat load
,
and nearly eliminate flavor transfer.
5 YEAR CHROME
SURFACE WARRANTY
!
GROOVING
Grooved gr
iddle plates allow sear marks typical
ly
associated with charbroilers, without the need
for another piece of equipment. Grooving can be
modified to your specifications and needs. The
grooving option only available on Lang griddles.
Easy to clean • Cooler working environment
Exceptional release qualities • Reduced flavor transfer
No seasoning required • Looks spectacular in the kitchen!
OUR CHROME GRIDDLE PLATES
LEAD THE INDUSTRY
Full 1” thick T1 Armor
-
grade steel plate coated
with 2 mil thick Hexavalent chrome is the most
durable chrome griddle in the marketplace today.
GRIDDLES
13
langworld.com/marine
-
price
-
list
SOLID STATE THERMOSTAT
Electronic controls with thermocouples embedded in the plate material
react instantly to surface temperature change, cycling the burner more
frequently for more consistent performance. Temperature control ranges
from 150-450°F with a surface temperature control ±4°F to set point.
MECHANICAL SNAP-ACTION THERMOSTAT
MECHANICAL controls cycle the burner completely ON-or-OFF as demanded by surface
temperature changes. Controls are heat, water and grease resistant, with no power
required. Temperature control ranges from 150-550°F for embedded probes with a
surface temperature control ±15°F to set point.
EMBEDDED THERMOSTAT
Embedded thermostat reacts more quickly to changes on the
cooking surface providing better performance than probes on
the bottom of the plate.
ELECTRIC SNAP-ACTION THERMOSTAT
Electric powered controls cycle the burner completely ON-or-OFF as demanded by surface
temperature changes. Temperature control ranges from 150-450°F for embedded probes with
a surface temperature control ±15°F to set point.
MODULATING THERMOSTAT
MECHANICAL diaphragm and probe controls the burner. Controls are heat, water
and grease resistant, and require no power. Temperature control ranges from 150-
450°F for embedded probes with a surface temperature control ±30°F to
set point, ±40°F for bottom mounted.
