25W
9V/3A,12V3A,15V3A
60*70*70mm
25W
Indicator light
The charging area for the watch
can be retracted by pressing and releasing.
Input interface.
Charging instructions.
1. Power up: Use an adapter with a voltage of 9V, 12V, or 15V to power the product.
2. Place the device: Simply place the device you want to charge in the corresponding
location and start the charging process.
Indicator instructions.
Pattern Indicator
Power on
Idle
Charging
Detected foreign object.
The indicator light blinks three times and then goes out
The indicator light is off
The indicator light remains on
The indicator light blinks.
Notes:
This product is compatible with devices featuring built-in wireless charging capabilities.
For non-magnetic phone models, please add a magnetic ring before using this product.
Input compatibility: QC3.0, PD3.0 protocols (recommended PD45W).
When the input exceeds 12V = 3A, the maximum charging power for a phone is 25W.
When the input exceeds 15V = 3A, it can simultaneously charge a phone at 25W, a headset at 5W, and a watch at 2.5W.
The maximum charging power for iPhone series is 25W, for Samsung phones it is 15W, and for Huawei/Android
phones it is 5W.
Do not place the wireless charger too close to magnetic strips or chips (e.g., ID cards, bank cards) to prevent
the magnetic cards from becoming invalid.
Use a 9V adapter for powering the device.
(Using a 5V adapter may result in interrupted charging due to insufficient power.)
Since the wireless charger generates some energy losses during the transmission of power, a portion of the energy
is converted into heat.
Mild heating during charging is normal.
The wireless charger is equipped with a temperature sensor.
If the temperature during charging becomes excessively high, the charging process will automatically stop, and
charging will resume once the charging device or the wireless charger has cooled down.
Avoid excessively squeezing or bumping the device.
Keep the surface of the charger dry and do not place the product in a fire or humid environment.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) this device may not cause harmful interference, and 2)
this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Radiation Exposure Statement
This device complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment.
The FCC certification of this device refers to RF exposure testing performed in typical
operating conditions, where a person is no closer than 20 centimeters from the
device surface at all times, except for non-repetitive patterns with transient time
intervals in the order of a second. Only in the stated conditions, the device is shown
to fully comply with the FCC RF Exposure requirements of KDB 447498.
