3-IN-1 CHARGING STATION
USER MANUAL
Product Function Introduction
Applicable mobile phones : iphone12/13/14/15/16 /17series
Wireless Earbuds : Airpods pro,Airpods 2/3/4[Wireless Version], Other Qi
Wireless Earbuds
Iwatch : support Apple Watch 1 -10 generation wireless charging
Matters Needing Attention
1 . Do not place the product in water or near the fire source , so as not to
cause malfunction of the charging equipment and mobile phone.
2 . Do not drop the device from a high place to avoid damage to the device
due to falling to the ground.
3 . If you need to clean the charger, make sure it is not connected to the
power supply.
4 . Please use 25W or above PD adapter or the PD adapter that comes with
the product.
Specification
Input voltage : 15V/3A,9V/3A
Phone output : Max 25W
TWS output : 5W
Watch output : 5W
Frequency : 115-205KHz(5W,7.5W,
10W,15W EPP) 360KHz(25W MPP)
Receiving distance : 0-4mm
Conversion rate : ≥80%
Appliccable temperature:0-35°
Magnetic Wireless charger x1
Type-C quick charge cable x1
User manual x1
45W PD adapter x1
Package Include
LED Indicator Status Description
1. Connected to power supply : blue light flashes 3 times and turns off after 30s
2. Standby : light off
3. Quick charging : blue light stays on for 60 seconds and then turns off
4. Charging exception alert : blue light keeps flashing.
1. Please use a qualified PD protocol or QC protocol power charger, otherwise
it may cause unstable charging or abnormal flicker;
2. If you need to use a protective case for your iPhone 12/13/14/15/16 during the
charging, please use one with Mag safe;
3. Do not use a mobile phone protective shell with metal back or a mobile phone
protective shell with a thickness greater than 4mm;
4. The receiving coil of a mobile phone that supports wireless charging is
generally located at the center of the mobile phone.
Precautions
Please place the center of the mobile phone at the center of the charging
board to get a better charging experience;
5. Do not put metal debris or magnetic cards on the charging board, which
may cause metal hair, magnetic card damage, charger damage or other
abnormalities;
6. If the receiving coil or the transmitting board is overheated and the charging
stops during the use, please remove the charging device, wait for it to cool
down, and try charging again.
7. Do not pull the power cord violently to avoid the power cord from breaking or
falling off.
8. Please do not disassemble the product or put it into fire or water to avoid
short circuits and leakage.
9. The standard temperature of wireless charger QI is 130°F, but our product
temperature is controlled within 130°F. The charger will cut off the current
when it is abnormally hot. Please contact us if any damage occurs.
Q6定制说明书，正面两页，背面两页
Manufacturer :Shenzhen USV Technology Co.,Ltd
Wireless charging for
iwatch devices
Wireless Charging for
Airpods or Earbuds
Wireless charging area for
iphone 12/13/14/15/16/17 series
