Instruction Manual
Wireless micro DAB Hi-Fi
UX-D327B
Before using this appliance, read all safety instructions carefully rst in the Safety Warnings booklet and keep
them for future reference.
1
Safety Warnings
DAB all-in-one Hi-Fi
Ventilation
• To prevent the risk of electric shock or
re hazard due to overheating, ensure
that curtains and other materials do not
obstruct the ventilation vents.
• A minimum distance of 5 cm around the
unit should be maintained to allow for
sucient ventilation.
• Do not install or place this unit in a
bookcase, built-in cabinet or in another
conned space. Ensure the unit is well
ventilated.
Safety
• Always disconnect the unit from the mains
supply before connecting/disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
during a lightning storm.
• In the interests of safety and to avoid
unnecessary energy consumption,
never leave the unit switched on while
unattended for long periods of time, e.g.
overnight, while on holiday or while out of
the house. Switch it o and disconnect the
mains plug from the mains socket.
Mains Cable
• Make sure the unit or unit stand is not
resting on top of the mains cable, as the
weight of the unit may damage the mains
cable and create a safety hazard.
• If the mains cable is damaged it must be
replaced by the manufacturer, its service
agent, or similarly qualied persons in
order to avoid a hazard.
Use only power supplies listed in
the user instrucitons.
The mains plug is used as
disconnect device, the disconnect
device shall remain readily
operable.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely aect
the operating performance of the unit,
and cause a distorted picture or sound.
Batteries
• Batteries used in the remote control for this
unit are easily swallowed by young children
and this is dangerous.
• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit
onto a third party make sure to include this
manual.
• Check that the voltage marked on the
rating label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about it working normally,
or if it is damaged in any way – switch o,
withdraw the mains plug and consult
your dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
• This unit is designed for indoor, domestic
use only.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing.
No objects lled with liquids, such as vases,
should be placed on the unit. Do not
operate the unit with wet hands, near
water or other liquid.
• If you spill any liquid into the unit, it can
cause serious damage. Switch it o at the
mains immediately. Withdraw the mains
plug and consult your dealer.
2
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the unit. Seek
medical advice if you believe a cell has
been swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
• Do not expose the battery to direct
sunlight or sources of excessive heat.
• Attention should be drawn to the
environmental aspects of battery disposal.
• Do not ingest the battery. Chemical Burn
Hazard.
• The remote control supplied with this
product contains a coin/button cell battery.
• If the coin/button cell battery is swallowed,
it can cause severe internal burns in just 2
hours and can lead to death.
• Keep new and used battery away from
children.
• If the battery compartment does not close
securely, stop using the product and keep
it away from children.
• If you think batteries might have been
swallowed or placed inside any part of the
body, seek immediate medical attention.
Supervision
• Children should be supervised to ensure
that they do not play with the unit and the
remote control.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in
a fatal electric shock.
Class 1 Laser Product
CLASS 1
LASER PRODUCT
• This unit
utilises a laser.
Use of controls,
adjustments or
performance of procedures other than
those specied herein may result in
hazardous radiation exposure.
• Before moving the unit, ensure the disc
tray is empty.
• Always remove the disc when the unit is
not in use.
• Failure to do so will risk severely damaging
the disc and the unit.
• Do not stack devices, heat from other
devices may aect the performance of
the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
unit’s enclosure that may be of
sucient magnitude to constitute
a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains
socket before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.
This unit is designed for indoor use only.
This equipment is a Class II or double
insulated electrical appliance. It has been
designed in such a way that it does not
require a safety connection to electrical
earth.
AC voltage: This symbol indicates that the
rated voltage marked with the symbol is
AC voltage.
DC voltage: This symbol indicates that
the rated voltage marked with the
symbol is DC voltage.
To prevent the
spread of re, keep
candles or other
open ames away
from this product
at all times.
3
Useful Information and Licences
Visit Partmaster.co.uk today for the easiest way to buy electrical
spares and accessories. With over 1 million spares and accessories
available we can deliver direct to your door the very next day. Visit www.partmaster.co.uk or
call 0344 800 3456 (UK customers only). Calls charged at National Rate.
The symbol on the product or its packaging indicates that this product
must not be disposed of with your other household waste. Instead, it is
your responsibility to dispose of your waste equipment by handing it over
to a designated collection point for the recycling of waste electrical and
electronic equipment. The separate collection and recycling of your waste
equipment at the time of disposal will help conserve natural resources and
ensure that it is recycled in a manner that protects human health and the
environment.
For more information about where you can drop o your waste for
recycling, please contact your local authority, or where you purchased your
product.
Notes for Battery Disposal
The batteries used with this product contain chemicals that are harmful to
the environment. To preserve our environment, dispose of used batteries
according to your local laws or regulations. Do not dispose of batteries with
normal household waste.
For more information, please contact the local authority or your retailer
where you purchased the product.
All trademarks are the property of their respective owners and all rights are acknowledged.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by Currys Group Limited is under license. Other trademarks
and trade names are those of their respective owners.
(Safety-JVC DAB Hi-Fi System-250425V6)
This product is distributed and warranted exclusively by Currys Group Limited.
“JVC” is the trademark of JVCKENWOOD Corporation,
used by Currys Group Limited under license.
UK Representative and Responsible Person
Currys Group Limited (No. 504877)
1 Portal Way, London, W3 6RS, UK
https://www.currys.co.uk
EU Representative and Responsible Person
Currys Ireland Limited (No. 259460)
3rd Floor Oce Suite, Omni Park SC,
Santry, Dublin 9, Republic of Ireland
https://www.currys.ie
UK & EU Contact details: business.standards@currys.co.uk
Contents
Safety Warnings ..........................................................................Safety Warnings booklet
Unpacking .............................................................................................................................4
Product Overview ................................................................................................................5
Main Unit ......................................................................................................................................................... 5
Remote Control ............................................................................................................................................6
Preparation ...........................................................................................................................7
Battery Replacement for the Remote Control ..................................................................................7
Remote Control Operation Range .........................................................................................................8
Connections ..........................................................................................................................9
Connecting the FM Aerial .........................................................................................................................9
Speaker Connection ...................................................................................................................................9
Connecting Mobile Devices .................................................................................................................. 10
Connecting to the Mains Supply ........................................................................................................ 10
Basic Operation ..................................................................................................................11
Switching ON / OFF ...................................................................................................................................11
ECO-Power Mode .......................................................................................................................................11
Selecting Modes .........................................................................................................................................11
Adjust the Speaker Level Settings and Eects ...............................................................................12
System Settings .................................................................................................................. 12
System Reset ................................................................................................................................................12
Software Version ........................................................................................................................................12
Clock Operation .................................................................................................................13
Manually Setting the Clock ....................................................................................................................13
Time Display ................................................................................................................................................13
Setting the Sleep Timer ...........................................................................................................................13
DAB Operation ...................................................................................................................14
Selecting DAB mode .................................................................................................................................14
First Time Auto Scan .................................................................................................................................14
Full Scan.........................................................................................................................................................14
To Select and Listen to the Found Stations ......................................................................................14
Manual Tuning ............................................................................................................................................14
DRC (Dynamic Range Compression) ..................................................................................................15
Pruning Radio Stations ............................................................................................................................15
Presetting Stations ....................................................................................................................................15
Recalling Preset Stations ........................................................................................................................ 16
DAB Display Modes ...................................................................................................................................17
FM Radio Operation ...........................................................................................................18
Tuning in a Station .................................................................................................................................... 18
Scan Settings .............................................................................................................................................. 18
Audio Settings............................................................................................................................................ 18
Presetting Stations ....................................................................................................................................19
Recalling Preset Stations .........................................................................................................................19
CD/MP3 Operation ............................................................................................................ 20
Compatible Disc Types ........................................................................................................................... 20
Playback ........................................................................................................................................................ 20
To Skip Search or Search and Play ...................................................................................................... 20
Selecting an Album (MP3) ..................................................................................................................... 20
Repeat Playback ........................................................................................................................................ 21
Programme Play ........................................................................................................................................ 21
Using the USB .................................................................................................................... 22
AUDIO IN (AUX IN) Operation .......................................................................................... 22
Bluetooth® Operation ....................................................................................................... 23
Maintenance ...................................................................................................................... 24
Cleaning the Unit ...................................................................................................................................... 24
Handling Discs ........................................................................................................................................... 24
Cleaning Discs ............................................................................................................................................ 24
Storing Discs ............................................................................................................................................... 24
Hints and Tips .................................................................................................................... 25
Product Fiche and Specifications .................................................................................... 26
4
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new JVC product.
We recommend that you spend some time reading this instruction manual
in order to fully understand all the operational features it oers. You will
also nd some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Speakers x 2Main Unit
FM Aerial
Remote Control /
AAA Battery x2
• If items are missing, or damaged please contact Partmaster (UK only). Tel: 0344 800 3456 for assistance.
• If you require additional assistance:
For UK, please call our UK Call Centre on 0344 561 1234.
For Ireland, please call our Ireland Call Centre on 0818 810575.
3.5 mm to 3.5 mm
Stereo Audio Cable
Safety & Instruction Manual Quick Start Guide
Instruction
Manual
Safety
Manual
Quick Start Guide
5
Product Overview
Main Unit
Front View
Rear View
1. Standby Button
2. Display
3. VOLUME+/– Dial
4. LINE IN (AUX IN) Socket
5.
USB Socket
6.
Play/Pause Button
7.
Stop/Menu Button
• Press to Stop playback.
• Press and hold to enter the Menu.
8.
Button
9.
/ Button
10.
/
Button
11.
Open/Close Button
12. SPEAKER OUT (6Ω ) L/R Sockets
13. FM ANTENNA Socket
1
2
3
4
5
6 7 8 9 10 11
12
13
6
Remote Control
1. Standby Button
2. REPEAT/MENU Button
3. INTRO Button
4.
/ AUTO Button
5. ALBUM+/ALBUM– Button
6.
/ Button
7. TUNE– Button
8. EQ Button
9. CD Button
10. USB/LINE IN Button
11. Number Pad
12. PRESET/PROG Button
13.
Open/Close Button
14. SHUFFLE/INFO Button
15. VOL+ Button
16. OK/
Button
17.
/ Button
18. VOL– Button
19. TUNE+ Button
20.
Mute Button
21.
Source Button
22. DAB/FM Button
23.
Bluetooth Button
24. CLOCK/SLEEP Button
1
2
3
13
20
19
22
23
21
24
15
18
17
16
4
6
5
7
8
9
11
10
14
12
7
2. Insert two AAA size batteries (included). Make sure the
(+) and (–) ends of the batteries match the (+) and (–)
ends indicated in the battery compartment.
Preparation
Battery Replacement for the Remote Control
1. Press and slide the back cover to open the battery
compartment of the remote control.
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause re,
personal injury or damage to property.
• Install the battery correctly by following the polarity (+ and –) indications in the battery compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in accordance with local
regulations.
Handling the Remote Control
• Be aware of your ngernails when removing the battery cover and the battery.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive heat.
• Remove the battery from the remote control when not in use for a long period of time, as corrosion or
battery leakage may occur and result in physical injury, and/or property damage, and/or re.
• When the battery is exhausted, the remote control will not function.
3. Close the battery compartment cover.
8
Remote Control Operation Range
• Point the remote control to the unit no more than 6 meters from
the remote control sensor and within 60° horizontally and 20°
vertically of the front of the unit.
• Please note that the operating distance may vary depending on
the brightness of the room.
Remote sensor
• Make sure that there is no obstacle between the infrared remote sensor of the unit and remote
control. If you install the unit on rack, etc., the remote controllable range may decrease depending on
the thickness or colour of glass door of rack.
• Do not expose the infrared remote sensor to direct sunlight or other strong light, such as inverter
uorescent light.
30°
30°
Max. 6 m
9
Connections
Connecting the FM Aerial
Fully extend the FM aerial. Connect the supplied FM aerial to the AERIAL socket on the rear
of the unit.
Speaker Connection
Connect the speaker cables at the back of the speakers to the SPEAKER OUT (6Ω ) L/R
sockets at the rear of the unit.
• Do not overtighten, this could damage the aerial.
• To avoid noise, keep aerial away from the unit, the
connecting cables and the mains cable.
Rear View of the Main Unit
Rear View of the Main Unit
Rear View of the
Right Speaker
Rear View of the
Left Speaker
10
Connecting Mobile Devices
Connect the LINE IN (AUX IN) socket on the front of the main unit to the headphone jack on
a mobile device with an 3.5 mm to 3.5 mm stereo audio cable illustrated below.
LINE IN
3.5 mm to 3.5 mm
stereo audio cable
(included)
Front View of the Main Unit
To the mains
socketRear View of the Main Unit
Connecting to the Mains Supply
• Ensure all audio connections of the unit are connected before connecting to the mains power socket.
• Make sure the mains plug is rmly inserted into the mains socket.
• To switch the unit o completely, remove the mains plug from the mains socket.
• Please turn the unit o completely to save energy when not in use.
• Use the mains cable as the disconnect device. The disconnect device shall remain readily operable.
Unwind the mains adapter cable to its full length. Connect the mains plug to the mains
socket.
Mobile Devices
11
Basic Operation
Switching ON / OFF
When you rst connect the unit to the AC power, the unit will be in Standby mode. The
STANDBY indicator will light up red.
• Press
on the unit or remote control to switch the unit on. The display will show
“HELLO” and the STANDBY indicator will switch o. Then, the system will switch to the
last selected source.
• Press
on the unit or remote control to switch the unit back to standby mode. The
display will show “GOOD BYE” and the standby indicator will light up red. The clock will
be displayed. The unit will switch to ECO-Power mode.
• To switch the unit o completely, remove the mains plug from the mains socket.
• Please turn the unit o completely to save energy when not in use.
ECO-Power Mode
The unit features an ECO-Power / Standby mode. It automatically turns to Standby mode
after 15 minutes if the unit is idle in LINE IN, BT (Bluetooth), DISC or USB mode or the
external unit is disconnected, switched o or the volume is too close to mute.
Selecting Modes
Press the button on the unit or remote control to switch between DAB, FM, LINE IN, BT
(Bluetooth), DISC or USB mode. The selected mode will show on the display.
Alternatively, you can directly press the followings buttons on the remote control to switch to your
desired mode:
• to switch to BT (Bluetooth) mode.
• CD to switch to DISC mode.
• USB/LINE IN to switch to USB/LINE IN mode.
• DAB/FM to switch to DAB/FM mode.
12
Adjust the Speaker Level Settings and Eects
Adjusting the Volume
To increase or decrease the volume, turn the VOLUME+/– dial on the unit or press the
VOL+/– button on the remote control.
Mute Sound
If you wish to turn the sound o, press button. Press button again, or turn the
VOLUME+/– dial on the unit, or press VOL+/– button to resume normal listening.
Preset Equalizer
You can adjust the sound reproduced simply by choosing from 5 preset equalizers.
During play, press the EQ button on the remote control repeatedly to select: FLAT / JAZZ /
CLASSIC / ROCK / POP.
System Settings
Make sure that the unit is in DAB or FM mode for system settings.
System Reset
If you want to delete all your stations and settings, you can return your radio back to the
default setting by running a System Reset.
1. In DAB or FM mode, press and hold
on the unit or press REPEAT/MENU on the
remote control, and then press
/ or / on the unit, or TUNE+/TUNE– on
the remote control to select <SYSTEM>. Press
on the unit or OK/
on the remote
control to conrm.
2. Press
/ or / on the unit, or TUNE+/TUNE– on the remote control to select
<RESET>. Press
on the unit or OK/
on the remote control to conrm.
3. Press
/ or / on the unit, or TUNE+/TUNE– on the remote control to select Y,
and then press
on the unit or OK/
on the remote control to conrm.
After system reset, all tuned stations, preset stations and alarm settings will be erased then your radio will
switch back on.
Software Version
This information may be requested when dealing with technical support issues.
1. In DAB or FM mode, Press and hold
on the unit or press REPEAT/MENU on the
remote control, and then press
/ or / on the unit, or TUNE+/TUNE– on
the remote control to select <SYSTEM>. Press
on the unit or OK/
on the remote
control to conrm.
2. Press
/ or / on the unit, or TUNE+/TUNE– on the remote control to select
<SW VER>. Press on the unit or OK/ on the remote control to conrm.
13
Clock Operation
Manually Setting the Clock
Manual setting the clock can only be done in Standby mode.
1. In Standby mode, press and hold CLOCK/SLEEP button.
2. Press
/ or /
button to set 12 HOUR/24 HOUR format.
3. Press the OK/
button, hour indicator will blink.
4. Press
/ or /
button
to set the hour.
5. Press the OK/
button, minute indicator will blink.
6. Press
/ or /
button to set the minute.
7. Press the OK/
button to conrm.
8. Press
/ or /
button to select between SYNC-ON or SYNC-OFF for clock
synchronisation.
• To exit timer setting mode without storing, press the button.
• If no button is pressed in approx 90 seconds, the unit exits clock setting mode automatically.
• If a power failure occurs or the unit is disconnected from the mains, the clock setting will be lost.
Time Display
While the unit is in ON mode, press and hold CLOCK/SLEEP button to display the clock.
Setting the Sleep Timer
Use the sleep timer to turn the system o after a certain number of minutes in play mode.
By setting the sleep timer, you can fall asleep to music and know that your system will turn
o by itself rather than play all night.
1. While the unit is in ON mode, press CLOCK/SLEEP on the remote control repeatedly
to view the dierent timer settings. The number of minutes shown will display in this
sequence:
SLEEP 120 SLEEP 90
SLEEP OFF SLEEP 15 SLEEP 30
SLEEP 60 SLEEP 45
2. The system is now set to turn o after the number of minutes you have set.
3. When the sleep timer is activated, “SLEEP” will show on the display.
4. Press CLOCK/SLEEP to show the reminding time till the unit switches o minutes and
return back to previous screen.
5. To cancel the sleep timer, press CLOCK/SLEEP repeatedly until “SLEEP OFF” shows on
the display.
14
DAB Operation
Selecting DAB mode
• Press the button repeatedly on the unit or remote control, or DAB button on the
remote control to select DAB mode.
First Time Auto Scan
If the unit is connected to the mains power and then switched on to DAB mode for the rst
time, the unit will automatically start scanning. During the scan the display will show a slide
bar that indicates the progress of the scan and the amount of stations that have been found
so far.
Once the scan has nished, the unit will select the rst alphanumerically found station. To
explore the found stations, press
/ or / and then press on the unit, or OK/
on the remote control to conrm.
Full Scan
The full scan will search for the entire DAB Band III channels. After the scan has nished, the
rst alphanumerically found station will be automatically selected.
• Using the remote control
1. Press
/AUTO button to activate auto scan. The display will show a progressing slide
bar.
Or
1. Press REPEAT/MENU button. The display will show FULL SCAN. Press OK/
button the
remote control to start auto scan.
• Using the unit
1. Press and hold
button. The display will show FULL SCAN. Press button to start
auto scan. The display will show a progressing slide bar.
2. All the stations that have been found will be stored automatically.
To Select and Listen to the Found Stations
Press / or / on the unit, or TUNE+/TUNE– button on the remote control.
Manual Tuning
As well as the auto tune function, you can manually tune the receiver. This can help you
when aligning your aerial or when adding stations that were missed while auto tuning.
1. Press and hold
on the unit or press REPEAT/MENU on the remote control, and then
press / or / on the unit, or TUNE+/TUNE– on the remote control to select
MANUAL. Press on the unit or OK/ on the remote control to conrm.
2. Press
/ or / on the unit, or TUNE+/TUNE– on the remote control to cycle
through the DAB channels, which are numbered from 5A to 13F.
15
DRC (Dynamic Range Compression)
If you are listening to music with high dynamic range in a noisy environment, you may wish
to compress the audio dynamic range.
1. During DAB mode, press and hold
on the unit or press REPEAT/MENU on the remote
control and then press / or / or TUNE+/TUNE– on the remote control to
select <DRC>. Press the on the unit or OK/ on the remote control to conrm.
2. Press
/ or / or TUNE+/TUNE– on the remote control to select <OFF/LOW/
HIGH> and press
on the unit or OK/ button on the remote control to conrm.
Pruning Radio Stations
You may remove all unavailable stations from the list.
1. Press and hold
on the unit or press REPEAT/MENU on the remote control and then
press / or / or TUNE+/TUNE– on the remote control to select <PRUNE>.
Press on the unit or OK/ on the remote control to conrm.
2. Press
/ or / or TUNE+/TUNE– on the remote control to select <PRUNE Y>.
Press on the unit or OK/ on the remote control to conrm, or select <PRUNE N>
to cancel.
Presetting Stations
You can store up to 20 of your favourite stations to the memory. This will enable you to
access your favourite stations quickly and easily.
To store a preset, you must rst be listening to the station that you would like to save.
• Using the Remote Control
1. Press and hold PRESET/PROG on the remote control. The display will show “## EMPTY”.
2. Press TUNE+ or TUNE– to select your desired preset station number.
3. Press OK/
button to conrm.
4. The station will be stored and the screen will then show “STORED“.
OR
• Using the Main Unit
Press and hold PRESET/PROG on the remote control to enter preset menu.
1. Press
/ or / to select your desired preset station number.
2. Press
to conrm.
3. The station will be stored and the screen will then show “STORED“.
16
Recalling Preset Stations
To recall a preset, you must rst have stored preset stations in the unit.
• Using the Remote Control
Press
/ or / to select your desired preset station.
OR
Simply recall the preset station by pressing 0-9 on the remote control.
OR
1. Press PRESET/PROG to enter the preset menu.
2. Press TUNE+ or TUNE– to select your desired preset station number.
3. Press OK/
button to conrm.
• Using the Main Unit
Press PRESET/PROG on the remote control to enter the preset menu.
1. Press
/ or / to select your desired preset station number.
2. Press
to conrm.
The stored stations will be saved into the memory and power o will not erase it. Storing a new station
into a preset location will erase the previously stored station in that location.
17
DAB Display Modes
Press SHUFFLE/INFO on the remote control, the display will switch through the following
display modes.
The information of each display mode is displayed on the lower segment of the display.
DLS (Dynamic Label Segment)
Dynamic label segment is a scrolling message that
the broadcaster may include with their transmissions.
The message usually includes information, such as
programme details etc.
Signal Strength
This shows a slide bar to indicate the signal strength,
the stronger the signal, the longer the bar will be from
left to right.
Programme Type
This describes the “style” or “genre” of the programme
that is being broadcast.
Ensemble
This displays the name of the multiplex that contains
the station you are listening to. A multiplex is a
collection of radio stations that are bundled and
transmitted on one frequency. There are national and
local multiplexes. Local ones contain stations that are
specic to that area.
DAB – unlike normal radio, groups together several radio
stations and transmits them on one frequency.
Channel
This displays the chanel of the present station, such as
“5A“.
Frequency
This displays the frequency of the present station, such
as “220.352” (MHz).
Signal Error
This displays a number showing the error rate. If the
number is 0, it means the signal received is error free
and the signal strength is strong. If the error rate is high,
it is recommended to re-orient the aerial or re-position
the unit.
Audio Bit Rate
The display will show the digital audio bit rate being received.
Time
This displays the current time provided automatically by the broadcaster.
Date
This displays the current date provided automatically by the broadcaster.
DLS
Signal Strength
Ensemble
Frequency
Programme Type
Signal Error
Time
Audio Bit Rate
Date
18
FM Radio Operation
• Make sure that you have correctly connected and fully extended the antenna.
• The search may not stop at a station with a very weak signal.
• If reception is still poor, try to adjust the FM aerial location.
Press the button repeatedly on the unit or remote control, or press FM button on the
remote control to select the FM source. The word “FM” will be showed on the display.
Tuning in a Station
Auto Tuning
Press /AUTO button on the remote control to start auto tuning. Press /AUTO button
again to stop the auto tuning.
The search may not stop at a station with a very weak signal.
Manual Tuning
Press and hold / or /
button on the unit or TUNE+ or TUNE– on the remote
control to start the forward or reverse scanning. The display will show the frequency being
searched. Once a station has been found, the scanning will stop automatically. Continue to
change the frequency until you nd the station you want.
With FM radio it may be necessary to ne tune each station by pressing TUNE+ or TUNE– button
repeatedly. Each press will adjust the frequency by 0.05MHz. If reception is still poor adjust the position of
the aerial or try moving the radio to another location.
Scan Settings
By default, FM scans stop at any available station. This may result in a poor signal-to-noise
ratio (hiss) from weak stations.
1. Press and hold
on the unit or REPEAT/MENU on the remote control and then press
/ or / or TUNE+/TUNE– on the remote control to select <SCAN SET>. Press
on the unit or OK/ on the remote control to conrm.
2. Press
/ or / or TUNE+/TUNE– on the remote control to select <ALL> or
<STRONG>. Press on the unit or OK/ on the remote control to conrm.
Audio Settings
By default, all stereo stations are reproduced in stereo. For weak stations, this may result in a
poor signal-tonoise ratio (hiss).
1. Press and hold
on the unit or REPEAT/MENU on the remote control and then press
/ or / or TUNE+/TUNE– on the remote control to select <AUD SET>. Press
on the unit or OK/ on the remote control to conrm.
2. Press
/ or / or TUNE+/TUNE– on the remote control to select <STEREO> or
<ALL>. Press on the unit or OK/ on the remote control to conrm.
19
Presetting Stations
You can store up to 20 of your favourite stations to the memory. This will enable you to
access your favourite stations quickly and easily.
To store a preset, you must rst be listening to the station that you would like to save.
• Using the Remote Control
1. Press and hold PRESET/PROG on the remote control. The display will show “## EMPTY”.
2. Press TUNE+ or TUNE– to select your desired preset station number.
3. Press OK/
button to conrm.
4. The station will be stored and the screen will then show “STORED“.
OR
• Using the Main Unit
Press and hold PRESET/PROG on the remote control to enter preset menu.
1. Press
/ or / to select your desired preset station number.
2. Press
to conrm.
3. The station will be stored and the screen will then show “STORED“.
Recalling Preset Stations
To recall a preset, you must rst have stored preset stations in the unit.
• Using the Remote Control
Press
/ or / to select your desired preset station.
OR
Simply recall the preset station by pressing 0-9 on the remote control.
OR
1. Press PRESET/PROG to enter the preset menu.
2. Press TUNE+ or TUNE– to select your desired preset station number.
3. Press OK/
button to conrm.
• Using the Main Unit
Press PRESET/PROG on the remote control to enter the preset menu.
1. Press
/ or / to select your desired preset station number.
2. Press
to conrm.
The stored stations will be saved into the memory and power o will not erase it. Storing a new station
into a preset location will erase the previously stored station in that location.
20
CD/MP3 Operation
Compatible Disc Types
Disc Types Disc Logo Recorded Content
CD-R (CD Recordable - Audio/MP3)
AUDIO / MP3
CD-RW (CD-Rewritable - Audio/MP3)
AUDIO / MP3
AUDIO-CD (Compact Disc Digital Audio)
AUDIO
• Some recorded les may not be able to be played due to the type and format of disc or condition of
the recording.
• If you are having trouble playing a certain disc, it is recommended to use USB input instead for best
MP3 playback.
Press button on the unit or remote control repeatedly or press CD button on the remote
control to select the DISC source. The word “DISC” will be showed on the display.
Playback
1. In DISC mode, press button on the unit or remote control to open the disc tray.
2. Place the disc with the label side up into the CD compartment, and then press the
button on the unit or remote control to close the tray.
3. After closing the disc tray, the unit will read the disc and play it automatically.
• If there is no disc or the disc can’t be read, “NO DISC” will show on the display.
• If in stop mode, please press the
button to start playing the disc.
4. Press to pause the playback, the time elapsed indicator will ash. To resume
playback, press again.
5. Press
/AUTO to stop the disc playing. Press button if you want to remove the disc.
To Skip Search or Search and Play
• Press once or more to skip to beginning of the current track or the previous track.
• Press
once or more to skip forward to the next track.
• Press and hold
/ to search for the position that you intend to start playing.
Release to resume normal playback.
Selecting an Album (for MP3 disc)
• Press ALBUM+/ALBUM– to select the next/previous album, and play the rst track of
this album.
21
Repeat Playback
ONE and ALL Repeat Play
• CD Disc
Press the REPEAT/MENU button repeatedly to set the function.
First press : To repeat the same track, the display will show “REP ONE”.
Second press : To repeat playing all tracks on a disc, the display will show “REP ALL”.
Third press : To cancel the repeat playing, the display will show “OFF”.
MP3 Disc
Press the REPEAT/MENU button repeatedly to set the function.
First press : To repeat the same track, the display will show “REP ONE”.
Second press : To repeat playing album, the display will show “REP FOLD”.
Third press : To repeat playing all tracks on a disc, the display “REP ALL” will stay lit.
Fourth press : To cancel the repeat playing, the display will show “OFF”.
Random Play
Press the SHUFFLE/INFO button. The display will show “RANDOM”, and then start
random play.
Press the SHUFFLE/INFO button twice. The display will show “OFF”, and cancel
random play.
Programme Play
You can program up to 20 tracks to play in any desired order.
1. Make sure the disc is inserted and in STOP mode.
2. Press PRESET/PROG button to enter the programme mode. The display will show “01
PR 01” (for CD) or “001 PR 01” (for MP3).
3. Press ALBUM+/ALBUM– button to select desired folder (for MP3 disc or USB).
4. Press
/ or /
to select the desired track number.
5. Press PRESET/PROG button to store.
6. Repeat steps 3-4 to program more tracks.
7. Once it is completed, press the
button to start programme play.
8. Press
/AUTO once to stop the programme play. Press /AUTO twice to clear
programme.
Opening the CD tray and closing it again will cancel the programme and erase the memory.
22
Using the USB
By connecting a USB mass storage device (including
USB ash memory, USB ash players or memory cards)
to this unit, you can enjoy the device’s stored music
through the unit.
1. Insert the USB device’s USB plug into the
socket at the front of unit.
2. Press
button on the unit or remote control or
press USB/LINE IN on the remote control to select
the USB source. The word “USB” will be showed on
the display.
3. Press ALBUM+/ALBUM– button to select next/
previous album, and play the rst track.
4. Other playback features are the same as if you
were playing an CD.
• The player supports the USB music le format of MP3 only.
• If your USB device is loaded with MP3 les but the display keeps showing ‘NO SONG” on the display,
the format of your USB device might not be compatible with the unit.
• The unit can support USB devices with up to 32 GB of memory.
• The unit may not be compatible with all USB devices, this is not an indication of a problem with the
unit.
AUDIO IN (AUX IN) Operation
1. While in ON mode, press button on the unit or remote control or press USB/LINE IN
on the remote control to select the LINE IN source. The words “LINE IN” will be shown
on the display.
2. Operate your audio device directly for playback features.
3. Turn the VOL+/VOL– dial on the unit or press the VOL+/VOL– buttons on the remote
control to adjust the volume to your desired level.
23
Bluetooth® Operation
Pairing the unit with a Bluetooth® device to listen to music:
1. Press the
button on the unit or remote control or directly press the Bluetooth
button on the remote control to select the BT (Bluetooth) mode.
2. Activate your Bluetooth® device and select the search mode. “UX-D327B” will appear on
your Bluetooth® device list.
3. Select “UX-D327B” and enter “0000” for the password if necessary. If connection is
successful, and the unit will make a beep sound twice.
4. To disconnect the Bluetooth® function,
• Switch to another function on the unit;
• Disable the function from your Bluetooth® device. The unit will make a beep sound;
• Press and hold
Bluetooth button on the remote control. The unit will make a beep
sound twice.
If your Bluetooth
® device supports A2DP, play music via your device.
If your Bluetooth
® device supports AVRCP, use supplied remote control to control play.
• To pause / resume playback, press
.
• To skip to a track, press
/ or / .
• Turn the VOL+/VOL– dial on the unit or press the VOL+/VOL– buttons on the remote
control to increase or decrease the volume.
• The operational range between the unit and the device is approximately 10 metres.
• Before connecting a Bluetooth® device to the unit, ensure you know the device’s capabilities.
• Compatibility with all Bluetooth® devices is not guaranteed.
• Any obstacle between the device and the unit can reduce operational range.
• Keep this player away from other electronic devices that may cause interference.
• If no other Bluetooth® devices pairs with this unit within 2 minutes, the unit will recover to its previous
connection.
• The player will also be disconnected when your device is moved beyond the operational range.
24
Maintenance
Cleaning the Unit
Ensure the unit is fully unplugged from the mains socket before cleaning.
• To clean the units, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray aerosol at or near the unit.
Handling Discs
• Do not touch the playback side of the disc.
• Do not attach paper or tape to the disc.
Playback side
Cleaning Discs
• Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc
from the centre outwards with a soft cloth. Always keep the disc clean.
• If you cannot wipe o the dust with a soft cloth, wipe the disc lightly with a slightly
moistened soft cloth and nish with a dry cloth.
• Do not use any type of solvent such as thinner, benzine, commercially available
cleaners or antistatic spray. They may damage the disc.
Storing Discs
• Do not store discs in places subjected to direct sunlight or near heat sources.
• Do not store discs in places subjected to moisture and dust such as a bathroom or near
a humidier.
• Storing discs vertically in a case, stacking discs or placing objects on discs outside of
their cases may cause warping.
25
Hints and Tips
If a problem does occur, it may often be due to something very minor. The following table
contains various tips. If you require additional assistance
• For UK, please call our UK Call Centre on 0344 561 1234.
• For Ireland, please call our Ireland Call Centre on 0818 810575.
General
Problem Solution
No power. • Ensure the mains plug is connected.
• Make sure that you select the ON mode.
The remote control is
not function.
• Use the remote control near the unit.
• Point the remote control at the remote sensor on the unit.
• Replace the battery in the remote control with a new one.
• Remove any obstacles between the remote control and
the unit.
No sound from the unit. Please try either one of the solutions below:
• Make sure that the unit is not muted. Press the
or the
VOL+/VOL– on the remote control, or turn the VOL+/
VOL– dial on the unit to resume normal listening.
• Press on the unit or on the remote control to switch
the unit to standby mode. Then press the button again to
switch the unit on.
• Unplug the unit from the mains socket, then plug them
again. Switch on the unit.
The unit does not
respond when pressing
any buttons.
• The unit may freeze up during use. Switch the unit o and
then on again at the mains socket to reset the unit.
CD
Problem Solution
Disc in place but the unit
won’t play.
• Make sure you’ve selected CD mode.
• Make sure the disc label is facing up.
• Make sure the disc is clean.
• PAUSE mode may be activated, deactivate it.
• Disc may be damaged or dirty; check and clean the disc.
Disc skips • Make sure the unit is on a secure spot. Vibrations or
jarring can cause the disc to skip.
Radio
Problem Solution
Poor radio reception. • Electrical interference in your home can cause poor
reception. Move the unit away from them (especially those
with motors and transformers).
Desired station not
found.
• Weak signal. Search manually.
26
Bluetooth®
Problem Solution
I cannot nd
“UX-D327B” on my
Bluetooth® device.
• Ensure the Bluetooth® function is activated on your
Bluetooth® device.
• Ensure you have paired your unit with the Bluetooth®
device.
If any functional abnormality is encountered, unplug the unit from the mains socket and reconnect it
again.
Product Fiche and Specifications
Brand JVC
Model UX-D327B
System Section
Power Supply 100 - 240 V ~ 50/60 Hz
Power Consumption 20 W
Working Environment - Temperature -10 ~ +35 °C
Working Environment - Relative Humidity 5% ~ 90%
Bluetooth® Bluetooth® Version Bluetooth® 5.0
Maximum power
transmitted
Class 2, 4.07 dbm
Frequency bands 2.4 GHz - 2.480 GHz
Ecodesign Information
Information
on Power
Consumption
Power
consumption of
another low power
consumption
condition
when the unit
is operating at
standby mode
with USB port
power supply.
0.45W
Network
Standby Power
Consumption
N/A
27
Time interval for Power management
function switches the unit automatically
into standby mode
The unit should switch to another
condition (when the unit is operating at
standby mode with USB power supply)
automatically when not providing main
functions for 15 minutes.
Power consumption in network standby
if all wired network ports are connected
and all wireless network ports are
activated
N/A
How to activate wireless network port No wireless network port
How to deactivate wireless network port No wireless network port
How to deactivate wireless network port No wireless network port
Speakers Section
Impedance 6 Ω
Output RMS Power 2 x 5 W
Speaker Box Dimension (W) × (D) × (H) 128 mm × 225 mm × 125 mm
Compact Disc Section
Optical Pickup 3 - Beam Laser
Frequency Response 100 Hz – 10 kHz
Radio Section
Frequency Range DAB 174.928 – 239.200 MHz (Band III)
FM 87.5 – 108 MHz
USB Section
USB Memory Stick
Memory Size
Up to 32 GB
USB Output (For playback only, charging
is not recommended and may not be
compatible)
5V
500 mA
Features and specications are subject to change without prior notice.
For the latest version of the Safety and Instruction Manual, please visit the ocial
website below (other websites may not contain the full and most updated version):
https://www.currys.co.uk/services/repairs-maintenance/product-service-manuals.html
(IB-UX-D327B-250526V10)
For Help and Support Call
UK: 0344 561 1234
Ireland: 0818 810575
Declaration of Conformity (RED)
Hereby, Currys Group Limited declares that the radio
equipment type [UX-D327B] is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://www.currys.co.uk/
Declaration of Conformity (RER)
Hereby, Currys Group Limited declares that the radio
equipment type [UX-D327B] is in compliance with Radio
Equipment Regulations 2017 (S.I. 2017/1206).
The full text of the UK declaration of conformity is
available at the following internet address:
https://www.currys.co.uk/
This product is distributed and warranted exclusively by Currys Group Limited.
“JVC” is the trademark of JVCKENWOOD Corporation,
used by Currys Group Limited under license.
