VRT 82821 BV
VRT 82821 DV
Cordless Stick
Vacuum Cleaner
User Manual
01M-8813433200-4418-01
01M-8813453200-4418-01
EN
CONTENTS
1 Important safety and
environmental instructions 8
1.1 General safety ........................................................8
2 Part assembling 11
Elbow and flexible hose ............................................11
3 Use 11
3.1 Charging Indicator.................................................11
4 Cleaning and maintenance 12
4.1 Cleaning and care ..................................................12
4.2 Hepa filter ...............................................................12
5 Information 13
5.1 Compliance with the WEEE Directive and
disposal of the waste product ...............................13
5.2 Compliance with RoHS Directive....................13
5.3 Package information .......................................... 13
5.4 Information on waste batteries .....................13
5.5 Storage......................................................................13
5.6 Handling and transportation .......................... 13
EN
OPERATION CLEANING AND CARE
119
8
10
3
4
7 5
1
6
12 13 14 15 16
2
*
*
*
*
*
*
*
*
* Not ALL accessories available on ALL models.
1
4
5
8
11
7
6
9
12
2 3
10
ON/OFF
OFF
VRT 82821 DV
OFF
VRT 82821 BV
VRT 82821 BV
A
VRT 82821 BV
B
VRT 82821 DV
13
14
15
16 17 18
OFF
19
22
20 21
23
24
25
26 27 28
29
30 31
1
2
24h
NEW
Please read this manual
first!
Dear Customer,
Thank you for selecting a Beko product.
We hope that you get the best results
from your appliance which has been
manufactured with high quality and
state-of-the-art technology. For this
reason, please read this user manual and
all other provided documents carefully
before using the appliance and keep it
as a reference for future use. If you hand
over the appliance to someone else, give
the user manual as well.
This appliance has been produced in environmentally-friendly, state-of-the-art facilities.
This product does not contain PCB’S.
Follow the instructions by paying
attention to all the information and
warnings in the user manual.
Meanings of the symbols
Following symbols are used in various
sections of this manual:
C
Important information and useful
advices regarding the usage.
A
WARNING:
Warnings for
dangerous situations concerning the
safety of life and property.
Protection class for electric shock.
1. Switch button
2. Dust cup release button
3. Metal tube release button
4. Electrical turbo brush
5. Machine body
6. Battery pack
7. Dust cup
8. Two-in-one brush
9. Charging dock (VRT 82821 BV)
10. Wall hook (VRT 82821 DV)
11. Power supply plug
12. Elbow (VRT82821BV)
13. Crevice
14. Mini turbo brush (VRT82821BV)
15. Flexible hose (VRT82821BV)
16. Dust brush (VRT82821BV)
Technical data
Rated input power :
180W (VRT82821BV)
100W (VRT82821DV)
Input :
100 - 240 V~ 50-60Hz 0.8 A (max)
Output :
26.0V
0.6A
Charging time :
3-4 hours
Running time max. power
VRT82821DV : 22 min.
VRT82821BV : 12 min.
Running time min. power to up to:
40 min.
Technical and design modifications reserved.
The values which are declared in the markings affixed
on your appliance or the other printed documents
supplied with it represent the values which were
obtained in the laboratories pursuant to the pertinent
standards. These values may vary according to the
usage of the appliance and ambient conditions.
8 / 14 EN
Cordless Stick Vacuum Cleaner / User Manual
8 / EN
This section contains safety
instructions that will help protect
from risk of personal injury or
property damage.
Failure to follow these instructions
invalidates the granted warranty.
1.1 General safety
• This appliance complies with
international safety standards.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
• If the adapter or the appliance
itself is damaged, do not use it.
Contact an authorised service.
• Your mains power supply should
comply with the information
supplied on the rating plate of the
appliance.
• Do not use the appliance with an
extension cable.
• Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges.
• Do not touch the appliance or its
plug when it is plugged if your
hands are damp or wet.
• Do not pull the power cable when
unplugging the appliance.
• Do not vacuum flammable
materials and when vacuuming
cigarette ash, make sure that it
has cooled down.
• Do not vacuum water or other
liquids.
• Protect the appliance from rain,
humidity and heat sources.
• Never use the appliance in or
near places where combustible or
inflammable ambience or places
are present.
• Unplug the appliance before
cleaning and maintenance.
• Do not immerse the appliance
or its power cable in water for
cleaning.
• Do not attempt to dismantle the
appliance.
1 Important safety and environmental instructions
Cordless Stick Vacuum Cleaner / User Manual
9 / 14 EN
9 / EN
• Use the original parts or
parts recommended by the
manufacturer only.
• Do not clean the particles such as
cement, plaster and compressed
paper in order to prevent the filter
from being clogged and the motor
being damaged.
• Use the appliance only with the
adapter supplied with.
• Do not use the appliance without
filters; otherwise it can get
damaged.
• If you keep the packaging
materials, store them out of the
reach of children.
• This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use
of the appliance by a person
responsible for their safety
• Children should be supervised to
ensure that they do not play with
the appliance
• The appliance is only to be used
with the power supply unit
provided with the appliance.
1 Important safety and environmental instructions
• The adapter must be removed
from the socket-outlet and the
battery pack must be removed
from the appliance before cleaning
or maintaining the appliance
• If the adapter is damaged, it must
be replaced by the manufacturer
or its agent or similarly qualified
person in order to avoid hazard.
• Keep fingers, hair and loose
clothing from moving parts and
openings whilst using the vacuum
cleaner
• The battery must be removed
from the appliance before it is
scrapped;
• The appliance must be
disconnected from the supply
mains when removing the battery;
• Please dispose of used batteries
according to local laws and
regulations.
• This appliance contains batteries
that are only replaceable by skilled
persons.
•
WARNING:
For the purposes
of recharging the battery, only
use the detachable supply unit
DK20C-260060H-B provided with
this appliance.
• Please remove and insert the
batteries according to UM.
10 / 14 EN
Cordless Stick Vacuum Cleaner / User Manual
10 / EN
• Rechargeable batteries are to
be removed from the appliance
before being charged;
• Different types of batteries or
new and used batteries are not to
be mixed.
• Batteries are to be inserted with
the correct polarity.
• Exhausted batteries are to be
removed from the appliance and
safely disposed of.
• If the appliance is to be stored
unused for a long period, the
batteries should be removed.
• The supply terminals are not to be
short-circuited.
• Only use with ZB1852 battery.
1 Important safety and environmental instructions
Cordless Stick Vacuum Cleaner / User Manual
11 / EN
2 Part assembling
Elbow and flexible hose
The elbow and flexible hose are extension tools,
one end is inserted into the suction port , the other
end is connected with the accessories, which can
clean corners or narrow spaces
3.1 Charging Indicator
Working Charging
Fully
charged
Lower
power
Persistent
white light
Blinking
white light
Persistent
white light
2 minutes
and then
going out.
Blinking red
light
C
• When you receive this product,
please use the charger provided
by our company to recharge the
battery for 3 hours (no need to
charge it full) and the charging
frequency should be every 3
months.
• Do not place the battery on the
charging base for a very long
time. If it is still charging beyond
the normal charging time, stop
it immediately. Otherwise, the
battery may cause heating,
deformation or burning hazard.
• When the battery is not in use for a
long time or it is over-discharged,
you may find the working time is
reduced at the first few times. We
recommend you fully charge the
battery (usually 4.5 hours) and
discharge it. Repeat this action
two times.
3 Use
12 / EN
Cordless Stick Vacuum Cleaner / User Manual
4.1 Cleaning and care
Switch off and unplug the appliance ,before cleaning it.
A
WARNING:
Never use gasoline,
solvent, abrasive cleaning agents,
metal objects or hard brushes to
clean the appliance.
4.2 Hepa filter
• In order to ensure the performance of the
product, we recommend you clean regularly,
and replace one after 3-6 months. (Depending
on usage)
A
WARNING:
Long-term no use,
please keep the battery intact,
stored in a cool dry place, and let the
battery in the semi-state of charge.
Not full or empty. Please enclose
the battery with non-conductive
material to avoid the metal touching
the battery directly, causing the
battery to be damaged.
4 Cleaning and maintenance
Cordless Stick Vacuum Cleaner / User Manual
13 / EN
5 Information
5.1 Compliance with the WEEE
Directive and disposal of the
waste product
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE).This product has been
manufactured with high quality parts and
materials which can be reused and are suitable for
recycling. Do not dispose of the waste product
with normal domestic and other wastes at the end
of its service life. Take it to the collection center for
the recycling of electrical and electronic
equipment. Please consult your local authorities
to learn about these collection centers..
5.2 Compliance with RoHS
Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
5.3 Package information
Packaging materials of the product are
manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials together
with the domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.
5.4 Information on waste
batteries
This symbol on rechargeable batteries/
batteries or on the packaging indicates
that the rechargeable battery/battery
may not be disposed of with regular
house hold rubbish. For certain
rechargeable batteries/batteries, this
symbol may be supplemented by a
chemical symbol. Symbols for mercury
(Hg) or lead (Pb) are provided if the
rechargeable batteries/batteries
contain more than 0,0005 % mercury or more
than 0,004 % lead.
Rechargeable batteries/batteries, including
those which do not contain heavy metal, may not
be disposed of with household waste. Always
dispose of used batteries in accordance with local
environmental regulations. Make enquiries about
the applicable disposal regulations where you live.
5.5 Storage
• If you do not intend to use the appliance for a
long time, store it carefully.
• Pull the appliance’s plug out.
• Keep the appliance out of the reach of children.
5.6 Handling and
transportation
• During handling and transportation, carry
the appliance in its original packaging. The
packaging of the appliance protects it against
physical damages.
• Do not place heavy loads on the appliance or on
the packaging. The appliance may get damaged.
• Dropping the appliance may render it non-
operational or cause permanent damage.
Please see the cover page of the
user manual for initial use, general
use and cleaning sections.
12 months breakdown and repair guarantee
Product Guarantee
Guarantor: Beko plc, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8UF
The guarantee does not in any way diminish your statutory or legal rights.
Your appliance has the benefit of our manufacturer’s guarantee which covers the product for 12 months
from the date of original purchase.
This gives you reassurance that if within that time, your appliance is proven to be defective because of
either workmanship or materials, we will at our discretion either repair or replace your appliance.
The appliance must be correctly installed, located and operated in accordance with the instructions
contained in the user manual.
The guarantor disclaims any liability for accidental or consequential damage.
The Guarantee is subject to the following conditions:
Documentary proof of the original purchase date is provided.
The appliance has been installed and operated correctly and in accordance with our operating and maintenance
instructions.
The appliance is used only on the electricity supply on the rating plate.
The appliance has only been used for normal domestic purposes.
The appliance has not been altered, serviced, dismantled or otherwise interfered with by any person.
The appliance is used in the United Kingdom or Republic of Ireland.
Any parts removed during repair work or any product that has been replaced becomes our property.
The guarantee is not transferrable if the product is resold.
The Guarantee does not cover:
Transit, installation or delivery damage.
Accidental damage.
Misuse or abuse.
Replacement of any consumable item or accessories. These include but are not limited to: plugs, cables, light bulbs,
knobs, filters and flaps.
Repairs or replacements required as a result of unauthorised repairs or inexpert installation that fails to meet the
requirements contained in the user guide or instruction book.
Repairs to products used in commercial or non-residential household premises.
How to obtain after sales service, help or general advice
Please keep your purchase receipt or other proof of purchase in a safe place as you will need to
show us this document if your product requires attention within the guarantee period.
Please also record your product details below, which will allow you to access our services more quickly and
help us identify your product. The model number is printed on the front of the user guide and the serial and
model number is shown on your products rating plate.
Model number
Serial number
Purchased from
Date of purchase
Please call our UK based Customer Service department if you need help or advice from us:
United Kingdom and Northern Ireland: 0845 600 4911 / 0345 600 4911
Republic of Ireland: 01 862 3411
You can also contact us through our website: www.beko.co.uk
www.beko.co.uk
