INSTALLATION GUIDE
Darord
Models: KBF430C
KBF430MB
KBF430SS
Karran USA Tel: 866.452.7726 www.karran.com [email protected]
COMPONENT LIST QTY
1 - Faucet Body 1
2 - O-Ring 1
3 - Rubber Washer 1
4 - Metal Washer 1
5 - Mounng Hardware 1
6 - Screw 2
1
4
5
6
1
3
2
3
2
3-15/16”
3-5/8”
5-7/8”
2-1/8”
7-11/16”
4-15/16”
1-1/4” to 1-3/8”
5
4
7
6
1 - Color Buon
2 - Screw
3 - Handle
4 - Cover
5 - Nut
6 - Cartridge
7 - Faucet Body
8 - Base Body
9 - Base
10 - O-Ring
11 - Rubber Washer
12 - Metal Washer
13 - Mounng Hardware
14 - Screw
15 - Water Lines
16 - Aerator Cover
17 - Aerator
18 - Gasket
