Horse Riding Machine
User Manual
Please read this User Manual carefully
before use of this product
Thank you for your purchase of this product.To ensure properoperation of
the product,please read this USER MANUAL carefullybefore using,and pay
special attention to the precautions.
Please keep this USER MANUAL properly for further reference.
Contents
>Safety and precautions.........................................1
>Structure explanation...........................................2
>Use method....................................................5-7
>Storage and maintenance.......................................8
>Product and solutions...........................................9
Problems and solutions
PROBLEMS
REASONS AND SOLUTIONS
Press ON/OFF key,the
machine can not be
started
-The plug is not in place.Please
insert the piug
-The power switch may off,Please
turn on the power
-Press the ON/OFF key,forget to
press the Manual or Auto key
The movement slow or
Quick
The gravity is not balanced, please
attention the sitting position,Please
follow the direction as mentions
befoer
The swing around is not
the same
-The gravity on one side not in the
middle,please follow the direction as
mentions before
-If any questions more,please contact
with the supplier
Sound like phew or Da-da
is heard during working
Normal sound generated by the
motor of from the abrasion between
mechanical units
The unusual sound Please stop immediately
Hip pain
If the hip too ache,please stop use
and contact with the supplier
During use
process,appear sick or
swirl ect
Please use right posture,shorten the
time to get used that
Display explanation
3
Preparation
4
9
Safety and precautions
Storage and maintenance
Environment for u s e
Do not us e the p roduct in humid or dusty environmen t to av oid
electric shock o r breakdown o f the mechanical pa rts.
Do not us e the p roduct when indoor temperature is o ver 40
degree.
Do not us e the p roduct in the open air or un der the direct
sunlight.
Please put the prod uct on the mat of the flat floor.
People under these conditions as below are not suggested
to use the product:
It is strongly a dvise to consult your doctor before use.
Patients who are under treatme nt or feel not good.
Patients with malignant tumor.
Pregnant women or women in m enstrual pe riod.
People with heart disease. Osteo porosis pat ients.
People with heart pacema ker or other medical electronic
instrument implanted.
People with artificial limb.
People who are sensitive to vi bration and strenuous exercise.
Warning
Unauthorized dismantle,disassembly or renovation is not
allowed to prevent electrical shock or any malfunctions. Please
contact manufacturer or local dealer immediately if there is
any service work needed.
Stop using the product under the below conditions, then power
off and remove the plug form power supply.
Water or other liquid accidentally splashed onto the product
or controller.
Any accessory is found damaged or internal component is
exposed.
Power failure.
Thundering of lighting weather.
Surface cleaning
Before cleaning,ensure the power cord is turnedoff,and the
attaching plug is pulled out of the sockrt.
Please use dry and gentle cloth to clean.Please do notuse
cheemistry to clean.
If have oil dirty,please wipe with nentral lotion thesolubility is
3%-5%,then use the cotton cloth to clean.
!
Notice
Do not clean the product with corrosive detergentsuch as
benzene or thinner,as it may cause fading,corrosion or crock on
the product.
Do not splash water into the product to avoid short circuit.
When maintain,please pull off the piug or may cause electric
shock.
Forbid use wet hand to pull or insert out the power card.
Compliance matters
Put your hands on the handle with light strength,do not be
too hard.
If use in the unreasonable methods on the forward and
backward or ocerweight,the machine will break down.
1
8
Structure explanation
Use method
Seat cushion
Handle
Control the fast board
Foot pedal connection
Plug
Right foot pedal
Left foot pedal
Support tube
Moving wheel
Power switch
Foot pedal
Left
Right
Foot pepal connection
Product specification
Commodity name
Power
N.W/G.W
Rated voltage
Horse riding machine
200W
28/33KG
90V-110V
200V-240V
AC
AC
Max user weight
Product size(LxWxH)
Packing size(LxWxH)
Fitting
150KG
79x37x76.5CM
86x42.5x80.5CM
Foot pedalx2
Foot pedalcouplingx2
Gesturin
It can let you stay at home also can experience the pleasure of riding
horse in the open air. Through the frequency of Horse Riding Machine，
and go with kinds of body gestures, it will make your body and mind
relaxed and harmonize qi and blood and improve your health.
Raise arms to both sides
and then put your arms
down 30-degree to your
hips.Repeat lifting and
droping your arms, it can
exercise biceps effectively.
Main exercise: Biceps
Raise arms to both sides and until the upper arm is parallel to
the ground. In the exercising process, keep the elbow, upper
arm and the shoulder are parallel to the ground. Keep this
posture and then twist the waist to get exercise.
Main exercise: Deltoid,the trapezius muscle and
supraspinatus.
Keep your upper body upright,
back straight ,legs curled back
wards and hold your wrists with
your hands. It can train the
ability of balance control and
also exercise abdominal
muscles and back muscles.
Main exercise: Abdominal
muscles and back muscles.
Sit sideways on the Horse Riding Machine with one hand holding the handle
and the other hand holding the mat. Keep your back straight and follow the
rhythm of the machine to relax your upper body.
Main exercise: Abdominal
muscles and back muscles.
Lift the arms to both sides and keep the upper arm perpendicular
to your body and the elbow to form a 90-degree angle. Fold your
arms in the middle of your body and open
your arms parallel to your shoulders.
Main exercise: Biceps
Hold the machine handle with both hands,keep your back straight and
keep your body leaning back and follow the machine to move.
Main exercise: relax the muscles of the body effectively.
2
7
ON
P
+
-
OFF
MODE
TIME
ON/OFF Key
Time Key
Mode Key
MODE
TIME
Speed+
Speed
-
On/ Off key, when the machine is in standby mode, press the key,
then the machine start running, when the machine is in running
mode, press the key, then the machine stops running.
Program: Auto-program mode key When the machine is in standby
mode, choose any auto-program from P1,P2 and P3, press on/off
key, the machine will run according to the corresponding program you
choosed. This key is not valid in the manual mode.
Time: When the machine is in standby mode, press this key, then
press+ / - key to adjust the using time, then press on/ off key to start
the machine, the key is valid in the manual mode only, it is not valid
in auto- program mode..
When the machine is under running mode, press +/- key to increase
/decrease the speed, when the machine is under standby mode,
press +/- key to increase/decrease the time.
LCD DISPLAY WINDOW
SPEED +
SPEED
-
Safety Switch
In addition to equipped with traditional switch，we specially
add adsorptional safety switch. Whenever you remove the
safety switch，machine would be stopped and it has dual
insurance function.
Equipment method
1.Lift this product, use the front wheel to pull,push ,move.
Do not hold the handle to move.
Do not move standing on the power cord.
Please care of your waist sprain when move the machine.
2.Put on the mat,then put the machine on.
Mat adhesive surface should face down.
The use space around at least 60cm front and bank,80cm
left and right.(Please see picture below.)
Even if use the mat,the floor aslo has the possibility to
scratch.
Please use the thick mat!
!
Attention
If do not use the mat, the floor
may scratch.
60cm
60cm
80cm
80cm
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
--
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
--
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
--
-
-
-
-
--
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Equipment method
Display explanation
3
6
5. Ri d i ng o n the s e at
Befor e riding p lease do n o t touch c ontrol p anel.
Do n o t step o n the foot p edal to r i d e.
6.Sit o n the cushio n to c o n firm the l e ngth o f foot p edal.
Bend you k n ees s l ight,a n d put your f oot o n the foot p edal.
If f e el n o t comfo r t able,p l e ase s top t h e mach i n e and get
down immedi a t ely.
The f ront e nd o f the p edal w ith t o se t o boot.
Put t he f o o t acco r d ing t o the diff e rent s ffe c t of t h e p o s ition.
Foot pedal application method and movement effect
Dose not use the foot
pedal,use the leg
department free motion.
Put the foot on the
foot pedal.
The foot dose not
use pedal,put the
foot on the ground.
(Main exercise inside muscle)
Dose not use the foot pedal the
situation,please dismount the
foot pedal.
Front end foot
Can cause the body to
reduce the movement.
7.Ready movement
Do ready exercise before use the machine,to
avoid the muscle injure by overload exercise.
Preparation before Exercising
1.Connect the power supply.
2.Press the "ON" button to
check whether the red light
is on or not.
3.After connecting, if the red
light doesn't work, please
check the circuit carefully.
4.Installating the pedal and it has
left pedal and right pedal.
Basic installment
May modilate velocity4 lengths
Use method
4
5
Use method
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions :
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help
The device must not be co-located or operating in conjunction with any other antenna or transmitter.
FCC RF Radiation Exposure Statement Caution:
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
