PE 3000 Series Button Transmitter Instruction
•
Standby Current： ≤1uA
•
Operating Distance： ≥35m
•
Working Current：
•
Working Temperature：
Mounting Bracket
81102010067600A
Use the "-" or "+" channel button
to select the maximum channel
(except the group channel "00").
Hold down the "-" and "+" channel buttons
at the same time, the screen will start flashing
the current channel until "AA" is displayed.
The screen displays "AA" as successful.
Except for the group
channel "00", hold down the "-"
and "+" channel buttons.
The display starts flashing the current channel
and let go until "15" is displayed.
The screen displays "15" as successful.
Indicator Light
UP Button
STOP Button
Preferred Limit
STOP Button
Channel “-”
Preferred Limit
STOP Button
Preferred Limit
DOWN Button
Indicator Light
UP Button
Jog Down
Jog Up
Pairing
Button
DOWN Button
Switch Button
Indicator Light
UP Button
DOWN Button
Channel “+”
STOP Button
Channel “-”
Preferred Limit
Screen
UP Button
DOWN Button
Channel “+”
Single-Channel
(Tubular Motor)
Two-Channel
（Tubular Motor）
Five-Channel
（Tubular Motor）
Fifteen-Channel
（Tubular Motor）
01
•
Power：
•
Battery： AAA Battery × 2
•
Frequency： 433.92MHz
• ERP: -22.35dBm
3V
≤20mA
-20~+60℃
Release The Maximum Channel Latch
Maximum Channel Latch
Technical Data
Product Introduction
02
① Slide down to
open the battery compartment.
④ Slide the rear cover back.② Remove the old batteries
and properly dispose
of the used ones.
③ Place the new batteries
in the compartment.
Battery Replacement
Warning
1. Keep the transmitter away from moisture and impact to extend the service life.
2. If it is found that transmitter needs to be closely controlled or the button is not too sensitive and
the indicator light blinks and darkens, the battery needs to be replaced.
3. Press any button for more than 10 seconds, the transmitter will stop sending wireless signals.
4. Please dispose of used batteries properly.
5. The 00 channel can control all channels, and the code matching function cannot be realized when using this channel.
Simplified EU Declaration Of Conformity
Importer Company Name: XXXXXX
Importer Company Address: XXXXXXXXXX
Manufacturer Company Name: Zhejiang General Light Curtain Co.,LTD.
The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as follows:
Hereby, Zhejiang General Light Curtain Co., Ltd declares that the radio equipment type Button Transmitter is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.poyaltech.com/eu-declaration-of-conformity
Manufacturer Company Address: Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, Hang Zhou City, Zhe Jiang Province, China
FCC Warning
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may causeb undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
