Issue Department：Bedding Division Date：
2025-4-16
System Instruction
Author：
Alexandria
Instruction of RF7421
Edition： 1.1
Page 1 of 5
1 / 5
Instruction of RF7421
Figure 1 button ofremoteItem
REMOTE CONTROL
Issue Department：Bedding Division
Date：
2025-4-16
System Instruction
Author：
Alexandria
Instruction of RF7421
Edition：
1.1
Page 2 of 5
2 / 5
1.1 AntiSnore button 1
Press the ANTI SNORE button, and the bed will move to the ANTI SNORE position.
1.2 LIGHT button 2
Click this button to turn on/off lighting.
1.3 TV button 3
Press this button to recline the bed to the position.
1.4 ZeroG button 4
Press the zeroG button, and the bed will move to the zeroG position. Hold the zeroG button for 5
seconds until the backlight blinks, and the control box will set the current position as the zeroG
position.
1.5 TV button 5
Press the TV button, and the bed will move to the TV position. Hold the TV button for 5 seconds
until the backlight blinks, and the control box will set the current position as the TV position.
1.6 M1 button 6
Click M1 button, the bed moves to M1 position,press and hold it for 5s until backlight flashes,
the control box set the current position as M1 position.
1.7 Child Lock button 7
Press and hold CHILD LOCK button for 5s until backlight flashes, then the lock/unlock is complete.
1.8 M2 button 8
Press the M2 button, and the bed will move to the M2 position. Hold the M2 button for 5
seconds until the backlight blinks, and the control box will set the current position as the M2
position.
1.9 HEAD UP button 9
press and hold this button, head actuator moves out, stop when released.
1.10 FOOT UP button 10
press and hold this button, foot actuator moves out, stop when released.
Issue Department：Bedding Division
Date：
2025-4-16
System Instruction
Author：
Alexandria
Instruction of RF7421
Edition：
1.1
Page 3 of 5
3 / 5
1.11 HEAD DOWN button 11
press and hold this button, head actuator moves in, stop when released.
1.12 FOOT DOWN button 12
press and hold this button, foot actuator moves in, stop when released.
1.13 FLAT button 13
Press this button to recline the bed to a flat position.
1.14 Head and Foot UP button 14
press and hold this button, head+foot actuator moves in, stop when released.
1.15 Head and Foot Down button 15
press and hold this button, head + foot actuator moves in, stop when released.
1.19 ON/OFF button 16
Click here to turn the massage on or off.
1.17 MASSAGE TIMER button 17
When the massage function is activated, press the button to switch the massage duration
(10-20-30min-Off).
1.18 UNDER BED LIGHT button 18
click this button to turn on/off under bed lighting.
1.16 HEAD MASSAGE button 19
Click here to select the head massage intensity up.
1.20 MODE button 20
Click here to select the massage mode.
1.21 FOOT MASSAGE button 21
Click here to select Foot Massage.
Issue Department：Bedding Division
Date：
2025-4-16
System Instruction
Author：
Alexandria
Instruction of RF7421
Edition：
1.1
Page 4 of 5
4 / 5
1.1 Matching Code button 9 and button 11
Press and hold this key to perform the pairing code operation.
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 0cm
between the radiator and your body.
Issue Department：Bedding Division
Date：
2025-4-16
System Instruction
Author：
Alexandria
Instruction of RF7421
Edition：
1.1
Page 5 of 5
5 / 5
ISED Statement
‐ English: This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
‐ French:Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont
conformes aux CNR exempts de licence d’Innovation, Sciences et Développement économique
Canada. Le fonctionnement est soumis aux deux conditions suivantes :
(1) Cet appareil ne doit pas causer d’interférences.
(2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de
provoquer un fonctionnement indésirable de l’appareil.
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance 0cm between the
radiator & your body.
Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement
non contrôlé.
Cet équipement doit être installé et utilisé avec une distance minimale de 0 cm entre le
radiateur et votre corps.
