OUTDOOR RATED DUAL ZONE WINE COOLER
RWC1
America's Best Value in Outdoor Kitchen Equipment
INSTRUCTION MANUAL
BEFORE USE PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Renaissance Cooking Systems
Product Warranty
RCS is proud to provide the industries most
comprehensive warranty program.
All RCS refrigeration and sink products are warrantied to be free
from manufacturer defects for 5 years to the original owner.
For service assistance, please reach out to us at the email address
below. You may also check our website for lots of great information
on using, servicing, or cooking on your new RCS grill.
This warranty excludes normal surface corrosion, discoloration,
surface scratches and surface rust which may occur. Improper
maintenance, salt spray, chemicals, pesticides will affect the look and
integrity of the components of this grill. RCS will not be responsible
for any damage caused as a result of not following owner’s manual
instructions. This non-transferrable warranty is limited to the
replacement of original (one-time) defective parts, does not include
shipping and labor to remove or install replacement parts, if
necessary. The owner must retain and submit their original receipt
with any warranty claim to receive warranty parts. The warranty
applies to the original owner only. Coverage is for residential use
only, no commercial applications apply. No registration required.
For more information, questions or assistance please contact us at:
RCSGasGrills.com ~ [email protected]
14
Problem
Possible Causes
The room temperature
is higher than normal.
A large amount of food
has been placed in the
fridge.
The door is being
The fridge turns itself
on and off frequently.
opened too often.
The door was not closed
completely.
The door is not
hermetically sealed.
It isn't connected to a
Solution
Move the fridge to a
cooler place.
Let the fridge run for a
while so it reaches the
set temperature.
Do not open the door
more often than
necessary.
Close door properly.
Check the door seal and
clean or replace if it does
not provide a proper
seal.
Plug in the fridge.
power supply.
Turn on the lighting by
The interior lighting
The lighting is turned
pressing the lighting
off.
button on the control
doesn't work.
panel.
The circuit breaker is Turn the circuit breaker
tripped, or a fuse has
back on, or replace the
been blown.
fuse.
The fridge is vibrating
The fridge is not
Level the fridge with the
or shaking a lot during
properly leveled.
adjustable feet or
operation. casters.
As the refrigerant flows through the fridge, you may
hear rattling or gurgling noises. Both are normal.
When temperature fluctuation occurs, the expansion
and contraction of the inner walls of the fridge may
cause popping or crackling noises, which are also
The fridge is making
normal.
too much noise.
The fridge is not
Level the fridge with the
properly leveled.
adjustable feet or
casters.
3
SAFETY INFORMATION & WARNINGS
Your safety and the safety of others is very important.
We have provided many important safety messages in this
manual and on your appliance. Always read and obey all safety
messages. This is the Safety Alert Symbol. The symbol alerts
you to potential hazards that can kill or injure you and others.
All safety messages will follow the Safety Alert Symbol and
either the word DANGER or WARNING.
DANGER means that failure to heed this safety statement may result in severe
personal injury or death.
WARNING means that failure to heed this safety statement may result in
extensive product damage, serious personal injury, or death.
All safety messages will alert you about the potential hazard, tell you how to
reduce the chance of injury, and let you know what can happen if the
instructions are not followed.
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so please read the manual carefully. To reduce the
risk of fire, electrical shock or injury when using the appliance, follow basic
precautions, including the following:
DANGER
• Plug into a grounded 3 prong outlet, do not remove grounding prong, do not
use an adapter, and do not use an extension cord.
• It is recommended that a separate circuit serving only your appliance be
used. Do not use outlets that can be turned off by a switch or pull chain.
• Never clean appliance parts with flammable fluids. These fumes can create a
fire hazard or explosion.
• Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
• Do not connect or disconnect the plug when your hands are wet.
• Unplug the appliance or disconnect power before cleaning or servicing.
Failure to do so can result in electrical shock or death.
4
• Do not attempt to repair or replace any part of your appliance unless it is
specifically recommended in this manual.
WARNING
FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR
MODEL
• Use two or more people to move and install the appliance. Failure to do so
can result in injury.
• To ensure proper ventilation for your appliance, the front of the unit must
be completely unobstructed.
• Choose a well-ventilated area with temperatures above S0
°
F (~1Q
0
C) and
below 110
°
F (~43
°
C}.
• The appliance should not be located next to ovens, grills or other sources of
high heat.
• The appliance must be installed with all electrical, water, and drain
connections {if applicable) in accordance with state and local codes. A
standard electrical supply {110 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and
ordinances, is required.
• Do not kink or pinch the power cord of the appliance.
• It is important that the appliance be leveled in order to work properly. You
may need to make several adjustments to the feet or wheels to level it.
• All installations must be in accordance with local plumbing code
requirements {if applicable).
• Make certain that the pipes are not pinched, kinked or damaged during
installation. (If Applicable)
• Never allow children to operate, play with or crawl inside the appliance.
• Do not use solvent-based cleaning agents or abrasives on the interior. These
cleaners may damage or discolor the interior.
• Use this appliance only for its intended purpose as described in this
instruction manual.
• Keep fingers out of the "pinch point" areas. Clearances between the door
and cabinet are necessarily small. Be careful closing the door when children
are nearby.
13
TROUBLESHOOTING
You can solve many common problems easily, saving you the cost of time spent
communicating with customer service. Try the suggestions below to see if the
problem you're facing has a simple solution.
Problem
Possible Causes
Solution
It isn't connected to a
Plug in the fridge.
power supply.
The fridge isn't
The fridge isn't turned
Turn on the fridge.
on.
working.
The circuit breaker is Turn the circuit breaker
tripped, or a fuse has
back on, or replace the
been blown.
fuse.
The temperature is not Check the set
set correctly.
temperature.
The ambient
temperature could
Set to a lower
require a lower
temperature.
temperature setting.
The door is being
Do not open the door
more often than
opened too often.
necessary.
The door was not closed
Close door properly.
completely.
The fridge isn't cold
Check the door seal and
The door is not
clean or replace if it does
enough.
hermetically sealed.
not provide a proper
seal.
The condenser is too
Clean the condenser
dirty.
when necessary.
The ventilation opening
Clear any obstructions
is blocked or too dusty.
and clean the dust.
6
ASSEMBLY & INSTALLATION
BEFORE USING YOUR FRIDGE
Remove the exterior and interior packing.
Before plugging in the fridge, let it stand upright for approximately
24 hours.
Doing this will reduce the possibility of a malfunction in the cooling system
from handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Install the handle on the door, if it is not already attached
I INSTALLING THE FRIDGE
This fridge is designed to be either built-in or freestanding.
Note: This appliance may be used for the storage of medicine and other
medical products.
Place your fridge on a floor that is strong enough to support it when it is fully
loaded. To level the unit, adjust the front leveling legs, or the screws on the
wheels.
Make sure that the air vent at the front of the appliance is never covered or
blocked in any way.
Note: It is recommended that you do not install the appliance near an oven,
radiator or other heating source. Any nearby heat sources may increase
electrical consumption. Do not install in a location where the temperature will
fall below S0
°
F (~10
°
C) or above 110
°
F (~43
°
C). For best performance, do not
install the fridge behind a cabinet door or block the vent in the front.
Avoid installing the fridge anywhere with excessive moisture.
Plug the fridge into a properly grounded wall outlet. Do not plug the fridge into
a power strip or extension cord.
11
CLEANING & MAINTENANCE
I CLEANING YOUR FRIDGE
• Turn off the power, unplug the fridge, and remove all items, including
shelves.
• Wash the inside surfaces with a solution of warm water and baking soda
(about 2 tablespoons of baking soda per 4 cups of water).
• Wash the shelves with a mild detergent solution.
• Wring excess water out of the sponge or cloth before cleaning the area
where the controls are located, or any place on or near electrical parts.
• Wash the outside of the fridge with warm water and a mild liquid detergent.
Rinse well and wipe dry with a clean, soft cloth.
• Use an approved stainless steel cleaner to clean the door frame and handle.
Do not use steel wool or a steel brush on the stainless steel.
CAUTION:
Failure to unplug the idge during cleaning could result in electrical shock or
other peonal injury.
I POWER FAILURE
Most power failures are corrected within a few hours and they should not
affect the temperature of your fridge, as long as you avoid opening the door. If
the power is going to be o for a longer period of time, it is recommended that
you transfer all perishable/sensitive contents to a functional fridge or cooler.
To prevent odor and mold growth, leave the door open slightly, blocking it
open if necessary. Lay a towel down below the open front of the fridge in case
any frost buildup melts and drains out.
I VACATION TIME
Short vacations: Leave the fridge running during vacations that are shorter
than three weeks.
Long vacations: If the fridge will not be used for a month or more, remove all
items and turn it off. Clean and dry the interior thoroughly. To prevent odor
and mold growth, leave the door open slightly, blocking it open if necessary.
Lay a towel down below the open front of the fridge in case any frost buildup
melts and drains out.
10
RW
C
1
1 2
3
4
5
Upper zone display
Lower zone display
1 Switching the cooler on/o
6
Key:
1 - Power button
2 - Upper zone
·+· button
3 - Upper zone
·-· button
4 - Lower zone
#
+
#
button
5 - Lower zone
·-· button
6 - Light button
Press and hold the power buon for 6 seconds to switch the wine cooler ON
/
OFF.
2 mperature sengs
The preset temperature is 8 °((46 °F) in the upper zone and 12 °((54 °F) in the
lower zone.
Press the+ or - buons for the appropriate zone unl required temperature shows
in the display.
The display shows set temperature when the cooler is on.
change the temperature display from Celsius to Fahrenheit or Fahrenheit to
Celsius, press and hold key 4+5 buon for 2 seconds. The display will show the
set value, °C
/
°
F.
3 Light
Press the light buon to switch the light ON or OFF.
turn the light ON when door opens, press the light buon for 6 seconds, the
display will show "OP", which means door control funcon is ON.
turn the light funcon OFF, press the light buon for 6 seconds, the display will
show "CL", which means the door control function is OFF.
4 Lock/unlock display
Press power button and + button at the same time for one second to lock
/
unlock
all buons on the panel.
5 Door alarm
The wine cooler is equipped with an alarm that will sound if the door is le open
for more than 60 seconds. Close door or press any key to mute the alarm.
6 Defrosng
The wine cooler will defrost automatically every 4 hours for 20 minutes. During
defrost, the compressor stops, but the fan will keep running.
I
ELECTRICAL CONNECTION
WARNING
7
Improper use of the grounded plug can result in electrical shock.
This fridge should be properly grounded for your safety. The power cord of this
fridge is equipped with a three-prong plug which fits with a standard three
prong wall outlet to minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third (ground) prong from
the power cord supplied. For personal safety, this appliance must be properly
grounded.
This appliance requires a standard 110 Volt AC 60Hz three-prong grounded
electrical outlet. Ensure that the wall outlet and circuit been checked by a
qualified electrician and confirmed to be properly grounded.
If only a 2-prong wall outlet is available, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
To prevent accidental injury, the cord should be secured behind the appliance
and not left exposed or dangling.
This fridge should always be plugged into its own individual electrical outlet
which has a voltage rating that matches the rating label on the appliance. This
will allow the best performance and also prevent overloading house wiring
circuits that could cause a fire hazard from overheating. Never unplug the
fridge by pulling on the power cord. Always grip the plug head firmly and pull
straight out from the receptacle. Immediately repair or replace all power cords
that have become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length or at either end.
When moving the appliance, be careful not to damage the power cord.
8
I EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly
recommended that you do not use an extension cord with this appliance.
However, if you must use an extension cord, it is absolutely necessary that it be
a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a
grounding type plug and outlet and that the electrical rating of the cord be 110
volts.
I INSTALLING THE STAINLESS STEEL HANDLE
To install the handle, follow the instructions below:
1.
Remove the rubber gasket from the right side of the inside of the door
(you don't need to remove the whole gasket, just the side that covers the
openings for the screws).
2.
Remove the screws from the included bag. Feed the screws through the
holes from the inside until they poke through to the outside front of the
door frame.
3.
Align the handle with the two screws, then tighten the screws into the
handle using a screwdriver until the handle is both flush and secured
tightly against the door frame. DO NOT over-tighten the screws, as you
may cause damage to the door frame.
Door handle
Screw
9
OPERATING INSTRUCTIONS
It is recommended that you install appliance in a place where the ambient
temperature is between 16
°
C(~61
°
F) - 32
°
C(~9Q
°
F). If the ambient temperature
is above or below recommended temperature, the performance of the unit
may be aected. For example, placing your unit in extremely cold or hot
condions may cause interior temperatures to uctuate. The operaon
temperature range may not be reached.
