Hui Zhou Gaoshengda Technology Co., LTD WXT7GZ1601
PAGE 1
Version 1.0
WIFI+BT Module
IEEE 802.11 a/b/g/n/ac/ax 1T/1R
Model Number: WXT7GZ1601
Product Descrition
The WXT7GZ1601 is a complete 2.4GHz/5GHz WIFI module. This module provides a high level of integration with
IEEE 802.11ax MAC/ base band /radio and Bluetooth 5.0.The WLAN operation supports 20MHz,40MHz channels
for data rates up to 600Mbps. It fully complies with IEEE 802.11 a/b/g/n/ac/ax feature rich wireless connectivity
at high standards,delivers reliable,cost-effective, throughput from an extended distance.
Product Features
◆ Complies with IEEE 802.11b/g/n/ax for 2.4GHz，IEEE 802.11a/n/ac/ax for 5GHz
◆ Bluetooth v5.0
◆ One transmit and One receive path(1T1R)
◆ Works with all existing network nfrastructure.
◆ Capable of up to 128-Bit WEP Encryption.
◆ Freedom to roam while staying connected.
◆ UP to 600 Mbps High-Speed Transfer Rate in 802.11ax mode of operation.
◆ Operating Systems：Linux, Windows.
◆ Low power consumption.
◆ Easy to install and configure.
◆ USB interface.
◆ ROHS compliant
Product Specification
Model
WXT7GZ1601
Product Name
WIFI+BT Module
Standard
802.11 a/b/g/n/ac/ax
Interface
USB
Data Transfer Rate
Up to 600Mbps
Modulation Method
GFSK,π/4-DQPSK,8DPSK(bluetooth)
DQPSK,DBPSK,CCK(802.11b)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11g)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11n)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11a)
QPSK,BPSK,16QAM,64QAM,256QAM with OFDM (802.11ac)
QPSK,BPSK,16QAM,64QAM,256QAM,1024QAM with OFDMA (802.11ax)
Frequency Band
BLUETOOTH
2402~2480 MHz
WIFI
2.4G: 2412~2462 MHz
5G: 5150~5350MHz, 5470~5725MHz，5725~5850MHz
Operation Mode
Infrastructure
Security
WEP, TKIP, AES, WPA, WPA2
Operating Voltage
3.3V±10%
Current Consumption
＜1000mA
Antenna Type
WIFI:PIFA,BT:PCB
Operating
Temperature
-10 ~ 70°C ambient temperature
Storage Temperature
-40 ~ 85°C ambient temperature
Humidity
10 to 90 % maximum (non-condensing)
Hui Zhou Gaoshengda Technology Co., LTD WXT7GZ1601
PAGE 2
Version 1.0
NOTICE:
◆please keep this product and accessories attached to the places which children can't touch;
◆do not splash water or other liquid onto this product, otherwise it may cause damage;
◆do not put this product near the heat source or direct sunlight, otherwise it may cause
deformation or malfunction;
◆please keep this product away from flammable or naked flame;
◆please do not repair this product by yourself. Only qualified personnel can be repaired.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
2.2
This module has been assessed against the following FCC rule parts: CFR 47 FCC Part 15 C (15.247, DTS
and DSS) and CFR 47 FCC Part 15 E (NII). It is applicable to the modular transmitter
2.3
This radio transmitter 2AC23-WXT7G has been approved by Federal Communications Commission to operate
with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in
this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for
use with this device.
The concrete contents to check are the following three points.
１) Maximum antenna gains are shown in item 2.7 below.
２) Should be installed so that the end user cannot modify the antenna
３) Feed line should be designed in 50ohm
Fine-tuning of return loss etc. can be performed using a matching network.
The antenna shall not be accessible for modification or change by the end user.
2.4
The module complies with FCC Part 15.247 / Part 15.407 and apply for Single module approval.
2.5
Trace antenna designs: Not applicable, the antenna conector for this module are integrated into the module. Use of
external antennas or antennas integrated into the host circuit board are not an option.
Hui Zhou Gaoshengda Technology Co., LTD WXT7GZ1601
PAGE 3
Version 1.0
2.6
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2.7
The following antennas have been certified for use with this module.
Only antennas of the same type with equal or lower gain may also be used with this module.
Other types of antennas and/or higher gain antennas may require the additional authorization for operation. The
installer should use unique antenna connector and Antenna types not included in this list that have a gain
greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. The
manufacturer of module will inform installer to meet with the FCC part 15.203 in the warning part.
Antenna Specification list below:
Antennas:
2.4G
5G
PIFA antenna & 1.72 dBi
PIFA antenna & 2.57 dBi
BT Antenna:
TYPE
GAIN
PCB antenna
2.75 dBi
2.8
Please notice that if the FCC identification number is not visible when the module is installed inside another
device, then the outside of the device into which the module is installed must also display a label referring to the
enclosed module. This exterior label can use wording such as “Contains FCC ID: 2AC23-WXT7G”; any similar
wording that expresses the same meaning may be used.
2.9
Testing of the host product with all the transmitters installed – referred to as the composite investigation test- is
recommended, to verify that the host product meets all the applicable FCC rules. The radio spectrum is to be
investigated with all the transmitters in the final host product functioning to determine that no emissions exceed
the highest limit permitted for any one individual transmitter as required by Section 2.947(f). The host
manufacturer is responsible to ensure that when their product operates as intended it does not have any
emissions present that are out of compliance that were not present when the transmitters were tested
individually.
If the modular transmitter has been fully tested by the module grantee on the required number of channels,
modulation types, and modes, it should not be necessary for the host installer to re-test all the available
transmitter modes or settings. It is recommended that the host product manufacturer, installing the modular
transmitter, perform some investigative measurements to confirm that the resulting composite system does not
exceed the spurious emissions limits or band edge limits (e.g., where a different antenna may be causing
additional emissions).
The testing should check for emissions that may occur due to the intermixing of emissions with the other
transmitters, digital circuitry, or due to physical properties of the host product (enclosure). This investigation is
especially important when integrating multiple modular transmitters where the certification is based on testing
each of them in a stand-alone configuration.
2.10
Any company of the host device which install this modular should perform the test of radiated & conducted
emission and spurious emission etc. according to FCC Part 15C: 15.247 and 15.209 & 15.207, part 15 E
Hui Zhou Gaoshengda Technology Co., LTD WXT7GZ1601
PAGE 4
Version 1.0
15.407,15B class B requirement, only if the test result comply with FCC part 15C: 15.247 and 15.209 & 15.207,
part 15 E 15.407,15B class B requirement. Then the host can be sold legally.
The host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not
covered by the modular transmitter grant of certification. If the grantee markets their product as being Part 15
Subpart B compliant (when it also contains unintentional-radiator digital circuity), then the grantee shall provide
a notice stating that the final host product still requires Part 15 Subpart B compliance testing with the modular
transmitter installed.
2.11
The host manufacturer is recommended to use FCC KDB 996369 D04 Module Integration Guide recommending as
"best practice" RF design engineering testing and evaluation in case non-linear interactions generate additional
non-compliant limits due to module placement to host components or properties.
2.12
This module is stand-alone modular. If the end product will involve the Multiple
simultaneously transmitting condition or different operational conditions for a stand-alone
modular transmitter in a host, host manufacturer have to consult with module manufacturer
for the installation method in end system.
Hui Zhou Gaoshengda Technology Co., LTD WXT7GZ1601
PAGE 5
Version 1.0
Notice to OEM integrator
Must use the device only in host devices that meet the FCC RF exposure category of mobile, which means the
device is installed and used at distances of at least 20cm from persons.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The end user manual shall include FCC Part 15 compliance statements related to the transmitter as show in
this manual(FCC statement).
Host manufacturer is responsible for compliance of the host system with module installed with all other
applicable requirements for the system such as Part 15 B
Host manufacturer is strongly recommended to confirm compliance with FCC requirements for the transmitter
when the module is installed in the host.
The use condition limitations extend to professional users, then instructions must state that this information
also extends to the host manufacturer’s instruction manual.
Host manufacturer is strongly recommended to confirm compliance with FCC
requirements for the transmitter when the module is installed in the host.
Must have on the host device a label showing Contains FCC ID: 2AC23-WXT7G
Both FCC ID is not to be placed on the host at the same time and only hosts going into the US can use the FCC
ID
