Smart Button ZB2
Smart Button ZB2 ×1 Micro-USB Charging
Cable ×1
Quick Start Guide ×1
Quick Start Guide
1 2
3
Smart Button ZB2
Quick Start Guide
Specifications
Factory Reset
Setting up your Smart Button ZB2
Package Contents
Model Number
Wireless Connectivity
Frequency
Temperature Range
Input
3RSB01085Z
Zigbee 3.0
2.4 GHz
0℃~40
℃
5V 500mA
Press and hold buttons 1 and 2 for 10 seconds until the device
beeps three times, indicating that it is in pairing mode.
Note: When charging, please connect the button to a power
adapter (not included) using the Micro-USB charging cable
provided in the package. The Smart Button ZB2 will be fully
charged until it beep twice.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules.
Follow instructions to set up your compatible Zigbee hub.
Use the Micro-USB charging cable included in the package to
connect the button to a power adapter (not included) to
active the Smart Button ZB2.
You can also press and hold buttons 1 and 2 for 10 seconds,
the Smart Button ZB2 will be activated once it beeps three
times. The device will automatically enter pairing mode.
Note: It will exit pairing mode automatically if not
successfully paired within 3 minutes, to put it into pairing
mode again, press and hold buttons 1 and 2 for 10 seconds
until the device beeps three times, indicating that it is in
pairing mode.
After the pairing is completed, the device will beep once. you
can create routines in the corresponding smart home App or
platform to control other connected devices. THIRDREALITY
Smart Button ZB2 features three buttons (button 1 & button 2
& button 3), each supporting three control settings: Pressed,
Double Pressed and Held.
1.
2.
3.
4.
Scan the QR code to view details
How to check if the device is fully charged
The Smart Button ZB2 will be fully charged until it beep twice.
Device won’t power on
Recharge the battery, ensure it powers on properly, and note
that low temperatures may reduce performance.
Cannot charge / No charging response
Use the original charger, check the charging port, and wait a
few minutes in case of over-discharge protection.
1.
2.
3.
Troubleshooting
https://bit.ly/488mkj9
FCC Regulatory Conformance
01 02
05
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in the exposure condition
without restriction.
06
For limited warranty, please visit
https://thirdreality.com/faq-help-center/
For customer support, please contact us at
info@3reality.com or visit www.thirdreality.com
For questions on other platforms, visit the corresponding
platform's application/support platform.
