Product Introduction
Technical Data
Release The Maximum Channel Latch
Maximum Channel Latch
PE5215-C Rechargeable Transmitter Instruction
81102010084600A
Screen
Channel
"
+
"
Channel
"
-
"
UP Button
STOP Button
DOWN Button
Side
Insert the tips into
the hole to enter the
learning state
01
Mounting Bracket
Bottom
Use the "+" or "-" channel button
to select the maximum channel
(except the teamwork channel“00”).
Hold down the "+" and "-" channel buttons
at the same time, the screen will start flashing
the current channel until 'AA' is displayed.
The screen displays "AA" as successful
Except for the teamwork
channel “00”,hold down the “+”
and ”-“ channel buttons.
The display starts flashing the current channel
and let go until “16” is displayed
When "16" is displayed,
the operation succeeds.
•
Product Model： PE5215-C
•
Working Temperature： -20~+60℃
•
Working Current： ≤20 mA
•
Standby Current： ≤15 uA
•
Operating Distance： ≥35 m
•
Frequency： 433.92 MHz
•
Battery Capacity： 250 mAh
•
Power Supply： Rechargeable lithium battery
PE5215-C
Front
Pairing Button
Charging Port
Charging Instruction
Warning
1. Keep the Transmitter away from moisture and impact to extend the service life.
2. Press any button for more than 10 seconds, the Transmitter will stop sending wireless signals.
3. The 00 channel can control all channels,and the code matching function cannot be realized when using this channel.
0202
① Please find the charging
port at bottom.
④
The display is off when the
battery is charged to 100%.
Please disconnect the power.
② Charge by USB cable to
connect to power.
③
The display shows "--" and flashes
during charging. It takes about
0.5h- 1h to get fully charged.
Note: When the display starts flashing, it means the battery is running low. Please put it on charge in time.
Simplified EU Declaration Of Conformity
The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as follows:
Hereby, Zhejiang General Light Curtain Co., Ltd declares that the radio equipment type Rechargeable Transmitter is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.poyaltech.com/eu-declaration-of-conformity
Importer Company Name: XXXXXX
Importer Company Address: XXXXXXXXXX
Manufacturer Company Name: Zhejiang General Light Curtain Co.,LTD.
Manufacturer Company Address: Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, Hang Zhou City, Zhe Jiang Province, China
FCC Warning
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may causeb undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
