USER MANUAL
Handheld Pool Vacuum
THANK
YOU!
Thank You for Purchasing from
Made in China
NOTE:
To continuously improve its products, reserves the right to
modify this information without prior notification.
For any questions regarding assembly, please watch the video on the
product page or contact our customer service. Our customer service will
Thank you for using products in your home!
USER MANUAL
HOW-TO
Handheld Pool
Vacuum
CONTENTS
Introduction and Safety..............................................1
Operation ...........................................................................3
Commissioning ...............................................................5
Maintenance .....................................................................9
Technical Data
...............................................................10
Warranty
............................................................................11
Assembly is EASY!
WE WANT
YOU TO
ENJOY LIFE
AT
GO TO THE PRODUCT LISTING PAGE
FOR AN INSTRUCTIONAL VIDEO!
USER MANUAL
HOW-TO
Handheld Pool
Vacuum
CONTENTS
Introduction and Safety..............................................1
Operation ...........................................................................3
Commissioning ...............................................................5
Maintenance .....................................................................9
Technical Data
...............................................................10
Warranty
............................................................................11
Assembly is EASY!
WE WANT
YOU TO
ENJOY LIFE
AT
GO TO THE PRODUCT LISTING PAGE
FOR AN INSTRUCTIONAL VIDEO!
1 2
SECTION A
Introduction and Safety
SAFETY INFORMATION
Please read the instructions for use carefully and observe the
information they contain. By referring to these instructions,
familiarize yourself with the appliance, learn how to use it
correctly, and note the safety precautions to be taken.
Take the appropriate steps to ensure that children have no
access to the appliance.
The user of the appliance is responsible for any third parties
in the work area.
Before using the appliance for the first time, an electrician
must ensure that the necessary electrical protection mea-
sures have been taken.
1.
2.
3.
4.
The Pool Cleaner must not be used when people are in the
water.
This appliance can be used by children aged 8 years and
above and by persons with reduced physical, sensory, or
mental capabilities, if they have been given supervision and
instruction concerning safe use and understand the hazards
involved. Children should not play with the appliance.
Cleaning or user maintenance should not be done without
supervision.
If the equipment is damaged, it must be replaced by
VIVOHOME, or repaired by qualified persons in order to
avoid a hazard.
1.
2.
3.
Use the appliance only for the purposes specified in these
instructions for use.
You are responsible for safety in the work area.
When charging, ensure that appliance is plugged into a
socket in a place where there is no risk of flooding and
which is protected against moisture.
The operator is responsible for any local safety and installa-
tion regulations. (Ask your electrician for advice.)
If the Pool Cleaner fails, any repair work necessary must be
performed only by an electrician.
Never let the appliance run dry and never operate it with
fully closed intake power. The manufacture’s warranty shall
lapse if the pump is damaged due to it being allowed to
run dry.
Water temperature range: 4° C (39.2° F)-35° C (95° F).
Please turn off the cleaner before charging.
To avoid unnecessary harm, hairs, body, or clothes should
keep away from the dirt sucker, because it has a suction
force when it works.
Do not dismantle the cleaner arbitrarily.
Please use the original charger to charge the cleaner.
Please place the cleaner indoors in a well-ventilated, clean,
and dry condition when charging.
If there is any damage to the charger, please stop charging.
If there is any damage to the power cord, it must be
replaced by the manufacturer or authorized personnel to
avoid dangers.
Please ensure that the cleaner and charger are dry before
charging.
The cleaner is specially designed for the underwater envi-
ronment, rather than a universal cleaner.
Please avoid using the cleaner to clean sharp objects; other-
wise, the cleaner and filter net will be damaged.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
CAUTION!
1 2
SECTION A
Introduction and Safety
SAFETY INFORMATION
Please read the instructions for use carefully and observe the
information they contain. By referring to these instructions,
familiarize yourself with the appliance, learn how to use it
correctly, and note the safety precautions to be taken.
Take the appropriate steps to ensure that children have no
access to the appliance.
The user of the appliance is responsible for any third parties
in the work area.
Before using the appliance for the first time, an electrician
must ensure that the necessary electrical protection mea-
sures have been taken.
1.
2.
3.
4.
The Pool Cleaner must not be used when people are in the
water.
This appliance can be used by children aged 8 years and
above and by persons with reduced physical, sensory, or
mental capabilities, if they have been given supervision and
instruction concerning safe use and understand the hazards
involved. Children should not play with the appliance.
Cleaning or user maintenance should not be done without
supervision.
If the equipment is damaged, it must be replaced by
VIVOHOME, or repaired by qualified persons in order to
avoid a hazard.
1.
2.
3.
Use the appliance only for the purposes specified in these
instructions for use.
You are responsible for safety in the work area.
When charging, ensure that appliance is plugged into a
socket in a place where there is no risk of flooding and
which is protected against moisture.
The operator is responsible for any local safety and installa-
tion regulations. (Ask your electrician for advice.)
If the Pool Cleaner fails, any repair work necessary must be
performed only by an electrician.
Never let the appliance run dry and never operate it with
fully closed intake power. The manufacture’s warranty shall
lapse if the pump is damaged due to it being allowed to
run dry.
Water temperature range: 4° C (39.2° F)-35° C (95° F).
Please turn off the cleaner before charging.
To avoid unnecessary harm, hairs, body, or clothes should
keep away from the dirt sucker, because it has a suction
force when it works.
Do not dismantle the cleaner arbitrarily.
Please use the original charger to charge the cleaner.
Please place the cleaner indoors in a well-ventilated, clean,
and dry condition when charging.
If there is any damage to the charger, please stop charging.
If there is any damage to the power cord, it must be
replaced by the manufacturer or authorized personnel to
avoid dangers.
Please ensure that the cleaner and charger are dry before
charging.
The cleaner is specially designed for the underwater envi-
ronment, rather than a universal cleaner.
Please avoid using the cleaner to clean sharp objects; other-
wise, the cleaner and filter net will be damaged.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
CAUTION!
3 4
DURABILITY
The maximum temperature of the medium to be pumped in
continuous operation should not exceed +35°C (95°F).
This pool cleaner is not to be used to clean combustible,
gaseous or explosive fluids.
1.
2.
1.
2.
APPLICATIONS
Scope of Application:
Small-scale swimming pool, fishpond, bathing pool, and
landscaped pool.
Medium:
Swimming pool water, clear water, and rain.
OPERATION INSTRUCTIONS
To assemble a complete machine, the handle and dirt sucker
should be installed into the pump in order as the figure shows.
SECTION B
Operation
DESCRIPTION
SECTION B
Operation
VH1351
Handle
Switch
Charging Interface
Main Pump Casing
Filter Net Ring
Dirt Sucker
Locking Handle
Outlet
SECTION B
Operation
SECTION B
Operation
Remark: The image shown here is indicative only. If there is any
inconsistency between the image and the actual product, the
actual product shall govern.
Telescoping
Tube
Mesh Bag*4
Battery
Charger
3 4
DURABILITY
The maximum temperature of the medium to be pumped in
continuous operation should not exceed +35°C (95°F).
This pool cleaner is not to be used to clean combustible,
gaseous or explosive fluids.
1.
2.
1.
2.
APPLICATIONS
Scope of Application:
Small-scale swimming pool, fishpond, bathing pool, and
landscaped pool.
Medium:
Swimming pool water, clear water, and rain.
OPERATION INSTRUCTIONS
To assemble a complete machine, the handle and dirt sucker
should be installed into the pump in order as the figure shows.
SECTION B
Operation
DESCRIPTION
SECTION B
Operation
VH1351
Handle
Switch
Charging Interface
Main Pump Casing
Filter Net Ring
Dirt Sucker
Locking Handle
Outlet
SECTION B
Operation
SECTION B
Operation
Remark: The image shown here is indicative only. If there is any
inconsistency between the image and the actual product, the
actual product shall govern.
Telescoping
Tube
Mesh Bag*4
Battery
Charger
5 6
SECTION B
Operation
SECTION C
Commissioning
Dirt Sucker Pump Handle
Push down the switch to turn on the cleaner. The distance be-
tween the priming water level and the horizontal surface should
be 30cm.
When cleaning the filter net, please open the locking handle
and the upper and lower hasps attached to the filter net. Take
out the waste from the filter net and rinse it.
Switch
Priming Water Level
is 30cm deep.
SECTION B
Operation
SECTION C
Commissioning
Upper Hasp
Lower Hasp
Wrench
Filter Net
INSTALLING THE TELESCOPING TUBE
Attach the telescoping tube by squeezing the spring buttons
and inserting it into handle of the pool cleaner body. Ensure the
buttons pop into the holes. Adjust the length of the shaft by
unlocking, extending and locking each section accordingly.
CAUTION! Do not overextend and vigorously stretch telescoping
tube when adjusting the length to avoid damage.
"Click"
Mesh Bag Installation
"Click"
Snaping the Locking Handle
5 6
SECTION B
Operation
SECTION C
Commissioning
Dirt Sucker Pump Handle
Push down the switch to turn on the cleaner. The distance be-
tween the priming water level and the horizontal surface should
be 30cm.
When cleaning the filter net, please open the locking handle
and the upper and lower hasps attached to the filter net. Take
out the waste from the filter net and rinse it.
Switch
Priming Water Level
is 30cm deep.
SECTION B
Operation
SECTION C
Commissioning
Upper Hasp
Lower Hasp
Wrench
Filter Net
INSTALLING THE TELESCOPING TUBE
Attach the telescoping tube by squeezing the spring buttons
and inserting it into handle of the pool cleaner body. Ensure the
buttons pop into the holes. Adjust the length of the shaft by
unlocking, extending and locking each section accordingly.
CAUTION! Do not overextend and vigorously stretch telescoping
tube when adjusting the length to avoid damage.
"Click"
Mesh Bag Installation
"Click"
Snaping the Locking Handle
7 8
SECTION B
Operation
SECTION C
Commissioning
Connect the charger with the cleaner as the figure shows. The
specification of the charger: Input 100-240V, 50/60Hz, 0.8A;
Output 21V-1.5A. During the charging process, if the indicator
light turns red, it means the battery is charging; if the indicator
light turns green, it means the cleaner is fully charged. Before
the first use, please charge the cleaner for 1.5 hours. After being
fully charged, the cleaner can work for 50-60 minutes.
Charger
SECTION C
Commissioning
TROUBLESHOOTING GUIDE
Warning: To avoid dangers, all the installation including repair
and replacement of components should be conducted by
authorized service personnel. Before operating the cleaner,
please turn off the device and unplug it.
Problem Reasons Solutions
Fail to
clean the
waste
Waste gets
out from
the front
parts
Waste
gets out
from the
filter net
The battery runs
out
The impeller is
damaged
Recharge the cleaner, and it can
work for 50-60 minutes after
being fully charged.
Correspond with VIVOHOME to
repair or replace the impeller.
The impeller is
blocked
Turn off the cleaner and check
the impeller. Please correspond
with professional personnel to
clean the blockage in the
impeller.
The filter bag is
full
Clean the waste in the filter bag.
Check Valve is
damaged
Change the check valve.
The filter net is
damaged
Change the filter net.
Handle/ext
ension
pole fails
to connect
The connective
V-Cord is
damaged
Change the V-Cord.
Cleaner
fails to be
charged
The battery is
damaged
Correspond with VIVOHOME to
replace the battery. Warning!
To avoid damaging the cleaner,
please purchase the original
lithium battery to replace.
The charger is
damaged
Correspond with VIVOHOME to
replace the charger. Warning!
To avoid damaging the cleaner
caused by the charger, please
purchase the original charger to
replace it.
7 8
SECTION B
Operation
SECTION C
Commissioning
Connect the charger with the cleaner as the figure shows. The
specification of the charger: Input 100-240V, 50/60Hz, 0.8A;
Output 21V-1.5A. During the charging process, if the indicator
light turns red, it means the battery is charging; if the indicator
light turns green, it means the cleaner is fully charged. Before
the first use, please charge the cleaner for 1.5 hours. After being
fully charged, the cleaner can work for 50-60 minutes.
Charger
SECTION C
Commissioning
TROUBLESHOOTING GUIDE
Warning: To avoid dangers, all the installation including repair
and replacement of components should be conducted by
authorized service personnel. Before operating the cleaner,
please turn off the device and unplug it.
Problem Reasons Solutions
Fail to
clean the
waste
Waste gets
out from
the front
parts
Waste
gets out
from the
filter net
The battery runs
out
The impeller is
damaged
Recharge the cleaner, and it can
work for 50-60 minutes after
being fully charged.
Correspond with VIVOHOME to
repair or replace the impeller.
The impeller is
blocked
Turn off the cleaner and check
the impeller. Please correspond
with professional personnel to
clean the blockage in the
impeller.
The filter bag is
full
Clean the waste in the filter bag.
Check Valve is
damaged
Change the check valve.
The filter net is
damaged
Change the filter net.
Handle/ext
ension
pole fails
to connect
The connective
V-Cord is
damaged
Change the V-Cord.
Cleaner
fails to be
charged
The battery is
damaged
Correspond with VIVOHOME to
replace the battery. Warning!
To avoid damaging the cleaner,
please purchase the original
lithium battery to replace.
The charger is
damaged
Correspond with VIVOHOME to
replace the charger. Warning!
To avoid damaging the cleaner
caused by the charger, please
purchase the original charger to
replace it.
9 10
MAINTENANCE INSTRUCTIONS
SECTION B
Operation
SECTION D
Maintenance
SECTION B
Operation
SECTION E
Technical Data
The pool cleaner is basically maintenance free. To ensure a
long service life,we recommend regular checks and care.
Warning! Before every servicing, switch off the pool cleaner.
If the pool cleaner is not going to be used for a long time or
has to be removed for the winter months, rinse it out with
water, empty it completely and allow it to dry.
If there is a risk of frost, the pool cleaner must be emptied
completely.
After long stoppages, make sure the rotor turns correctly by
briefly switching the pool cleaner on and off.
DISPOSAL
1.
2.
3.
4.
5.
Please do not dispose of power tools that are no longer
usable along with your regular household waste. Instead,
choose an environmentally friendly method of disposal. If
there are recycling facilities available in your area, make sure
to utilize them. For advice on recycling, you can consult with
your local government authority.
Recycling packaging materials helps reduce our reliance on
landfills and raw materials. The reuse of recycled materials
aids in mitigating environmental pollution. If recycling facili-
ties are accessible in your community, we encourage you to
recycle packaging materials. Should you need advice on
recycling, you can seek assistance from your local govern-
ment department.
1.
2.
Property Value
Power rating 40W
Nominal voltage DC18V
Battery capacity 2AH
Max. flow rate 4200L/H
Particulate matter <25mm
Max. water temperature 35°C
Moisture protection IPX8
Battery charging time 90min
Battery life 50-60min
9 10
MAINTENANCE INSTRUCTIONS
SECTION B
Operation
SECTION D
Maintenance
SECTION B
Operation
SECTION E
Technical Data
The pool cleaner is basically maintenance free. To ensure a
long service life,we recommend regular checks and care.
Warning! Before every servicing, switch off the pool cleaner.
If the pool cleaner is not going to be used for a long time or
has to be removed for the winter months, rinse it out with
water, empty it completely and allow it to dry.
If there is a risk of frost, the pool cleaner must be emptied
completely.
After long stoppages, make sure the rotor turns correctly by
briefly switching the pool cleaner on and off.
DISPOSAL
1.
2.
3.
4.
5.
Please do not dispose of power tools that are no longer
usable along with your regular household waste. Instead,
choose an environmentally friendly method of disposal. If
there are recycling facilities available in your area, make sure
to utilize them. For advice on recycling, you can consult with
your local government authority.
Recycling packaging materials helps reduce our reliance on
landfills and raw materials. The reuse of recycled materials
aids in mitigating environmental pollution. If recycling facili-
ties are accessible in your community, we encourage you to
recycle packaging materials. Should you need advice on
recycling, you can seek assistance from your local govern-
ment department.
1.
2.
Property Value
Power rating 40W
Nominal voltage DC18V
Battery capacity 2AH
Max. flow rate 4200L/H
Particulate matter <25mm
Max. water temperature 35°C
Moisture protection IPX8
Battery charging time 90min
Battery life 50-60min
11 12
SECTION F
Warranty
The VIVOHOME warranty program is our commitment to you.
We are committed to providing you with a high-quality product
that meets your needs and expectations. To demonstrate our
confidence in the durability and performance of our products,
we offer the following warranty.
This warranty program applies to any orders, purchases, receipts,
or use of any products sold by VIVOHOME and is valid for a
period of 1 year from the date of purchase. However, please note
that this warranty period is only valid for the original order. If
you receive a replacement order during the warranty period, it
will not include a separate warranty period.
WARRANTY COVERAGE
This warranty does not cover damage resulting from misuse,
accident, unauthorized modification, or any other circumstances
not directly related to the manufacturing and design of the
product, including but not limited to:
Parts lost during use.
Normal wear and tear of products or parts.
Incorrect installation (such as using the wrong voltage) or
assembly.
Exceeding the bearing capacity of the product.
Use under extremely harsh conditions.
WARRANTY EXCLUSIONS
●
●
●
●
●
VIVOHOME will provide technical support, replacement, refund,
or other solutions based on the nature of the issue. If you wish
to return the original package for any reason, please contact us
for confirmation before proceeding. You can expect to receive a
response within 48 hours.
Thank you for choosing VIVOHOME. We are committed to en-
suring the quality and satisfaction of your purchase. If you have
any questions or need assistance, please do not hesitate to con-
tact our customer service team.
If you find any defects that affect the use of the product or if the
product stops working and cannot be repaired during the war-
ranty period, please contact our customer service team at our
email or via Amazon & app’ s direct messaging service as soon as
possible. Provide the following information to expedite the
process:
HOW TO MAKE A WARRANTY CLAIM
Order number
Images and/or videos illustrating the issue
A detailed description of the problem
●
●
●
Improper cleaning or maintenance.
Damage caused by any reason other than the intended use
of the product.
Indirect loss or damage caused by the product.
●
●
●
11 12
SECTION F
Warranty
The VIVOHOME warranty program is our commitment to you.
We are committed to providing you with a high-quality product
that meets your needs and expectations. To demonstrate our
confidence in the durability and performance of our products,
we offer the following warranty.
This warranty program applies to any orders, purchases, receipts,
or use of any products sold by VIVOHOME and is valid for a
period of 1 year from the date of purchase. However, please note
that this warranty period is only valid for the original order. If
you receive a replacement order during the warranty period, it
will not include a separate warranty period.
WARRANTY COVERAGE
This warranty does not cover damage resulting from misuse,
accident, unauthorized modification, or any other circumstances
not directly related to the manufacturing and design of the
product, including but not limited to:
Parts lost during use.
Normal wear and tear of products or parts.
Incorrect installation (such as using the wrong voltage) or
assembly.
Exceeding the bearing capacity of the product.
Use under extremely harsh conditions.
WARRANTY EXCLUSIONS
●
●
●
●
●
VIVOHOME will provide technical support, replacement, refund,
or other solutions based on the nature of the issue. If you wish
to return the original package for any reason, please contact us
for confirmation before proceeding. You can expect to receive a
response within 48 hours.
Thank you for choosing VIVOHOME. We are committed to en-
suring the quality and satisfaction of your purchase. If you have
any questions or need assistance, please do not hesitate to con-
tact our customer service team.
If you find any defects that affect the use of the product or if the
product stops working and cannot be repaired during the war-
ranty period, please contact our customer service team at our
email or via Amazon & app’ s direct messaging service as soon as
possible. Provide the following information to expedite the
process:
HOW TO MAKE A WARRANTY CLAIM
Order number
Images and/or videos illustrating the issue
A detailed description of the problem
●
●
●
Improper cleaning or maintenance.
Damage caused by any reason other than the intended use
of the product.
Indirect loss or damage caused by the product.
●
●
●
USER MANUAL
Handheld Pool Vacuum
THANK
YOU!
Thank You for Purchasing from
Made in China
NOTE:
To continuously improve its products, reserves the right to
modify this information without prior notification.
For any questions regarding assembly, please watch the video on the
product page or contact our customer service. Our customer service will
Thank you for using products in your home!
