1
BREAD MAKER
T
INSTRUCTION MANUAL
MODEL: BM1352-UL
Read this manual thoroughly before using and save it for future reference
Guangdong Xinbao Electrical Appliances Holdings Co., LTD
ADDRESS: ZHENGHE SOUTH ROAD, LELIU TOWN, SHUNDE DISTRICT,FOSHAN CITY, GUANGDONG PROVINCE, CHINA
STAINLESS STEEL BREAD MAKER
WITH AUTOMATIC FRUIT DISPENSER
INSTRUCTION MANUAL
SKU:VH839
OK
START
STOP
2
CONTENTS
IMPORTANT SAFEGUARDS
KNOW YOUR BREAD MAKER
INTRODUCTION OF CONTROL PANEL
DELAY FUNCTION
KEEP WARM
MEMORY
ENVIRONMENT
WARNING DISPLAY
AUTO ADD INGREDIENT FUNCTION
FOR THE FIRST USE
USING YOUR BREAD MAKER
SPECIAL INTRODUCTION
CLEANING AND MAINTENANCE
INTRODUCTION OF BREAD INGREDIENTS
INGREDIENTS MEASUREMENT
TROUBLE SHOOTING GUIDE
3
IMPORTANT SAFEGUARDS:
Before using the electrical appliance, the following basic precautions should always be
followed:
1. READ ALL INSTRUCTIONS.
2. Before using check that the voltage of wall outlet corresponds to that shown on the
rating plate.
3. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or it is dropped or damaged in any manner. Return the appliance to
manufacturer or the nearest authorized service agent for examination, repair or electrical
or mechanical adjustment.
4. Do not touch hot surfaces.
5. To protect against electric shock, do not immerse cord, plugs, or housing in water or
other liquid.
6. Unplug from outlet when not in use, before putting on or taking off parts, and before
cleaning.
7. Do not let cord hang over edge of table or hot surface.
8. The use of accessory attachments not recommended by the appliance manufacturer may
cause injuries.
9. Do not place on or near a hot gas or electric burner, or in a heated oven.
10. Do not touch any moving or spinning parts of the machine when baking.
11. Never switch on the appliance without properly placed bread pan filled with
ingredients.
12. Never beat the bread pan on the top or edge to remove the pan as this may damage the
bread pan.
13. Metal foils or other materials must not be inserted into the bread maker as this can give
rise to the risk of a fire or short circuit.
14. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised.
15. Keep the appliance and its cord out of reach of children less than 8 years.
16. Never cover the bread maker with a towel or any other material, heat and steam must
4
be able to escape freely. A fire can be caused if it is covered by, or comes into contact
with combustible material.
17. Do not operate the appliance for other than its intended use.
18. Always use the appliance on a secure, dry level surface.
19. Do not use outdoors.
20. This appliance has been incorporated with a grounded plug. Please ensure the wall
outlet in your house is well earthed.
21. This appliance is intended to be used in household and similar applications such as:
– Staff kitchen areas in shops, offices and other working environments;
– Farm houses;
– By clients in hotels, motels and other residential type environments;
– Bed and breakfast type environments.
22. The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
23. Do not operate the unit without bread pan placed in the chamber to avoid damaging the
appliance.
KNOW YOUR BREAD MAKER
(Product may be subject to change without prior notice)
Housing
Control
panel
LCD
Lid
Bread
pan
Housing
Control
panel
LCD
Lid
Bread
pan
5
ok
Kneading
blade
Hook
Measuring
Cup
Measuring Spoon
Ingredient Box
View Window
Drawer
ok
Kneading
blade
Hook
Measuring
Cup
Measuring Spoon
Ingredient Box
View Window
Drawer
6
INTRODUCTION OF CONTROL PANEL
(The silkscreen may be subject to change without prior notice.)
AFTER POWER-UP
As soon as the bread maker is plugged into the power supply, LCD will be illuminated
while a beep will be heard. If has not any operation, LCD will be extinguished after 20s;
The default setting of 900g and MEDIUM. “BASIC” are displayed on LCD.
START / STOP
For starting and stopping the selected baking program
To start a program, touch the “START/STOP” button once. the program starts. Enter
working status (if delay function is used, the time starts to count down, the appliance will
start to work when the remaining time equal to finish time set for this menu.). when unit
starts, only the selected one-level, second-level menu burn steady，others menus won’t be
displayed, time begin to count down. After enter the operation, unit will pause by pressing
“START/STOP” button once, and renew by pressing it again, if press “START/STOP”
button more than 2s, the program will be reset, a beep will be heard, program back to
standby status, default to select the one-level menu when starting, other menus burn
Under one-level menu
status, press this button
to enter second-level
menu. P
ress it each
time, can enter next
second-
level menu
which
can be set, it
circulates in order,
press this button for 2s,
it will back to
one-level menu;.
Set/display delay time
Set/display working time
If add ingredient
Warm
Baking
Inner circle is knead 1,
Outer circle is knead 2
Upper arrow is rise 1
Lower arrow is rise 2
Loaf size: 500g/750g/900g
Setting knob: under
one-
level menu status:
right-
rotate the Setting
knob, menu circulates by
the order of from up to
down, from left to right,
the direction is in reverse
if left-
rotate the Setting
knob; under second-level
menu status, related
function can be adjusted
under the selected menu.
7
steady。
To stop the program, touch the “START/STOP” button for approx. 3 seconds until a beep
confirms that the program has been switched off.
PAUSE
After procedure starts up, touch “START/STOP” button once to interrupt at any time,
the operation will be paused but the setting will be memorized, the working time will be
flashed on the LCD. Touch “START/STOP” button again or within 10 minutes without
touching any button, the program will continue.
MENU
Use setting knob to set different programs. The functions of 25 menus will be explained
below.
1. BASIC: kneading, rising and baking normal bread. You may also add ingredients to
add flavor.
2. FRENCH: kneading, rising and baking with a longer rise time. The bread baked in this
menu usually will have a crisper crust and light texture.
3.WHOLE WHEAT: kneading, rising and baking of whole wheat bread. This setting has
longer preheating time to allow the grain to soak up the water and expand. It is not
advised to use the delay function as this can produce poor results.
4.SWEET: kneading, rising and baking the sweat bread. For baking the crisp and sweet
bread.
5.LOW SUGAR BREAD: Low sugar bread: kneading, rising and baking, with low sugar
6.RICE BREAD :Rice bread: Kneading, rising, and baking,the proportion of protein and
amino acid is higher than basic bread, and is more easier to digest.
7.RICE FLOUR BREAD: Kneading, rising and baking. The size is same as basic bread,
flavor and taste are better.
8.QUICK: kneading, rising and baking loaf with baking soda or baking powder. Bread
baked on this setting is usually smaller with a dense texture
9.ITALIAN BREAD: Kneading, rising and baking, taste is more soft and with a dense
texture.
10.GLUTEN FREE BREAD: kneading, rise and baking gluten-free bread. You may also
add ingredients to add flavor.
11.PIZZA DOUGH: Kneading, rising dough, remove the dough and shaping it to make
Pizza.
12.ITALIAN DOUGH: Kneading dough, remove the dough and shaping it to make
8
dessert
13.DOUGH RISE: Kneading, rising dough, Remove the dough and shaping it to make
bread rolls, pizza, steamed bread, etc.
14.FERMENT/DEFROST: only heat with low temperature, the rising time can be set by
yourself in the stated scope
15.Yogurt: only heat with low temperature, the rising time can be set by yourself in the
stated scope
16.Pickled vegetables: Making Pickled vegetable
paste is to make the chili powder more condensed, the taste more better.
17..DOUGH: kneading and rising, but without baking. Remove the dough and shaping it
to make bread rolls, pizza, steamed bread, etc.
18.JAM: boiling jams and marmalades, mash up fruit or vegetables before putting them in
bread pan
19.BAKE: only baking, no kneading and rising. Also used to increase the baking time on
selected settings
20.ROAST NUT:Before roast nut, note select out the hard impurity completely, reduce
the abrasion
21.MEAT FLOSS: Meat floss is nutritious, delicious and easy to carry, etc.
22.RICE VINEGAR: Making rice vinegar
23. CAKE:kneading, rising and baking. Rise with soda or baking powder.
24.ITALIAN CAKE:different original design according to your desire.
25.DO IT YOURSELF: The making process contain knead/rise/bake/warm and many
period, user can set the working time for every period by himself, the program is mainly
used for the user who is familiar with making bread to set working time as per himself
taste, to get satisfactory result.
COLOR
There are three colors of LIGHT, MEDIUM or DARK for the crust. Rotate Setting knob
to select your desired color. Exceptionally, it is inactive for the programs of QUICK,
PIZZA DOUGH, ITALIAN DOUGH, DOUGH RISE, FREMENT/DEFROST,
YORGUAT, PICKLED VEGE, DOUGH, JAM, BAKE, ROAST NUT, MEAT FLOSS,
RICE VINEGAR, CAKE and ITALIAN CAKE
Note: select your desired color by rotating Setting knob
LOAF SIZE
There are three loaf sizes of 500g , 750g and 900g for selection. Please note the total
operation time may vary with the different loaf size. Exceptionally, it is inactive for the
9
programs of QUICK, PIZZA DOUGH, ITALIAN DOUGH, DOUGH RISE,
FREMENT/DEFROST, YORGUAT, PICKLED VEGE, DOUGH, JAM, BAKE,
ROAST NUT, MEAT FLOSS, RICE VINEGAR, CAKE , ITALIAN CAKE and DO
IT YOURSELF
Note: select your desired loaf size by rotating Setting knob
DELAY FUNCTION
If want to use delay function, the maximum delay time is 13 hours, rotate the Setting knob
to delay mark, press “OK” button, rotate the Setting knob to increase or decrease delay
time, once press the button, the delay time will be increased at the increment of 10min。
After up to 13hours, it will back to default time, Please note the delay time should
include the baking time of program .
Example: Now it is 8:30p.m, if you would like your bread to be ready in the next morning
at 7 o’clock, i.e. in 10 hours and 30 minutes. Select the menu for color, loaf size and the
time until 10:30 appears on the LCD. Then touch the STOP/START button to activate this
delay program. The dot is flashing and the remaining time will be counted down to show
in the LCD. The fresh bread will be got at 7:00 in the morning. If not to take out the bread
immediately, the keeping warm time of one hour will start.
NOTE:1. This button is not applicable for the programs PIZZA DOUGH, ITALIAN
DOUGH, DOUGH RISE, FREMENT/DEFROST, YORGUAT, PICKLED VEGE,
DOUGH, JAM, BAKE, ROAST NUT, MEAT FLOSS, RICE VINEGAR, CAKE and
ITALIAN CAKE
2.For time delayed baking, do not use any easily perishable ingredients such as eggs, fresh
milk, fruits, onions, etc.
KEEP WARM
Bread can be automatically kept warm for 60 minutes after baking. If you would like to
take the bread out, switch the program off with the START/STOP button.
MEMORY
If the power supply has been broken off in the course of bread making, the process
10
will be continued automatically within 10 minutes, even without touching
“
START/STOP” button. If the break time exceeds 10 minutes the memory cannot be
kept and the bread maker must be restarted, but if the dough is no further than the
kneading phase when the power supply breaks off, touch the “START/STOP”
straight to continue the program from the beginning.
ENVIRONMENT
The machine may work well in a wide range of temperature, but there could be a
difference in loaf size between a very warm room and a very cold room. We suggest the
room temperature should be between 15℃ and 34℃.
WARNING DISPLAY
1. If the display shows “HHH” after the program has been started, the temperature inside
is still too high（accompanied by 5 beep sounds）. Then the program has to be stopped.
Open the lid and let the machine cool down for 10 to 20 minutes.
2. If the display shows“LLL”after pressing the START/STOP button ( except the
programs BAKE), it means the temperature inside is too low（accompanied by 5 beep
sounds）, stop sound by pressing the START/STOP button, open the lid and let the
machine rest for 10 to 20 minutes to return to room temperature.
3. If the display shows “ERR” after you have pressed START/STOP, the thermal resistor
value exceed scope, please check the sensor carefully by Authorized expert.
AUTO ADD INGREDIENT FUNCTION
This machine is capable of adding ingredient automatically for the programs of BASIC,
FRENCH, WHOLE WHEAT, SWEET, LOW SUGAR BREAD, RICE BREAD,
RICE FLOUR BREAD, QUICK, ITALIAN BREAD, GLUTEN FREE BREAD and
DO IT YOURSEL. Before making bread, pull out the ingredient box drawer by holding
the lock device and drawer handle, take the ingredient box out, put the ingredients needed
into the box and then replace the drawer. During operation, the ingredients will be
automatically poured into the bread pan.
FOR THE FIRST USE
The appliance may emit a little smoke and a characteristic smell when turning it on for the
first time. This is normal and will soon stop. Make sure the appliance has sufficient
ventilation.
1. Please check if all parts and accessories are “complete and free of damage”.
11
2. Clean all the parts according to the latter section “Cleaning and Maintenance”.
3. Set the bread maker in baking mode and bake empty for about 10 minutes. After cooling
it down, clean once more.
4. Dry all parts thoroughly and reassemble them, the appliance is ready for use.
USING YOUR BREAD MAKER
1. Lay the appliance on the firm and even surface.
2. Before making bread, weigh the ingredients you need respectively.
3. Place the pan in position, turn it clockwise until it clicks in correct position. Fix the
kneading blade onto the drive shafts. It is recommended to fill holes with heat-resisting
margarine prior to placing the kneaders, this avoids the dough to stick below the
kneaders and the kneaders could be removed from bread easily.
4. Place ingredients into the bread pan. Usually the water or liquid substance should be put
firstly, then add sugar, salt and flour, always add yeast or baking powder as the last
ingredient. (See fig.6)
Note: the maximum quantity of flour and yeast is 600g and 7 g.
5. With finger make a small indentation on one side of the flour. Add yeast to indentation,
ensure it does not come into contacting with the liquid ingredients or salt. Close the lid
gently.
6. Plug the power cord into a wall outlet.
7. Rotate the Setting knob until your desired program is selected.
8. Rotate the Setting knob to select the desired crust color.
9. Rotate the Setting knob to select the desired size (500g ,750g or 900g).
10. Rotate the Setting knob to
icon and press “OK” button, then set the delay time.
This step may be skipped if you want the bread maker to start working immediately.
11. Touch the START/STOP button to start working.
12.For the programs of BASIC, FRENCH, WHOLE WHEAT, SWEET, LOW
水或液体
干的配料
酵母或苏打
Yeast or soda
Dry ingredients
Wa ter or liq uid
Fig.6
12
SUGAR BREAD, RICE BREAD, RICE FLOUR BREAD, QUICK, ITALIAN
BREAD, GLUTEN FREE BREAD and DO IT YOURSEL, put the fruit ingredients
into the ingredient box and then close the pan drawer.
NOTE: During operation, the ingredients in the ingredient box will be automatically
poured into the bread pan.
13. Once the process has been completed 10 beeps sound will be heard. Touch
START/STOP button for approx. 3 seconds to stop the process and take out the bread.
Open the lid with wearing oven mitts, firmly grasp the bread pan handle. Turn the pan
anti-clockwise and gently pull the pan straight up and out of the machine.
NOTE: Before replacing the bread pan, allow it cooling down completely.
14. Use non-stick spatula to gently loosen the sides of the bread from the pan.
CAUTION: The Bread pan and bread may be very hot! Always handle with care and
use oven mitts.
15. Turn bread pan upside down onto a clean countertop and gently shake until bread
falling out onto rack.
16. Remove the bread carefully from the pan and cool for about 20 minutes before slicing.
17. If leaving the room or not to touch START/STOP button at the end of operation, the
bread will be kept warm automatically for one hour.
18. When in not use or after complete operation, unplug the power cord.
CAUTION: Before slicing the loaf, use the hook to remove out the kneading blade
hidden on the bottom of loaf. Never use the hand to remove the kneading blade as the
loaf is hot.
NOTE: If bread has not been completely eaten up, it is advised to store the remained
bread in sealed plastic bag or vessel. Bread can be stored for about three days during
room temperature, if need more days for storage, pack it with sealed plastic bag or
vessel and then place it in the refrigerator, storage time is at most ten days. As bread
made by ourselves without adding preservative, generally the storage time is no longer
than that for bread in market.
SPECIAL INTRODUCTION
1. For Quick program
With Quick program, the bread maker can finish making a loaf within shorter period
13
with baking powder or soda in place of yeast. To obtain perfect quick bread, it is
suggested that all liquid ingredients shall be placed at the bottom of the bread pan and
dry ingredients on the top, but during the initial kneading, some dry ingredients may
collect in the corners of the pan, so in order to avoid flour clumps, you may use a rubber
spatula to help to knead dough.
CLEANING AND MAINTENANCE
Disconnect the machine from the power and let it cool down prior to cleaning.
1. Bread pan: Rub inside and outside with a damp cloth. Do not use any sharp or abrasive
agents for the consideration of protecting the non-stick coating. The pan must be dried
completely prior to installing.
2. Ingredient box: Wash the ingredient box in warm water and dry thoroughly, then
replace to drawer and close the drawer well. Do not use any rough scouring pad or
cleanser on part or finish.
3. Kneading blade: If the kneading blade is difficult to remove from the axle, in such an
event fill the container with warm water and allow it to soak for approx.30minutes.The
kneading blade can then be easily removed for cleaning. Also wipe the blade carefully
with a damp cotton cloth. Please note that the bread pan, kneading blade and ingredient
box are dishwashing safe components.
4. Lid and view window: Clean the lid inside and outside with a slightly damp cloth.
5. Housing: Gently wipe the outer surface of housing with a wet cloth. Do not use any
abrasive cleaner to clean as this would degrade the high polish of the surface. Never
immerse the housing into water for cleaning.
6. Before the bread maker is packed away for storage, ensure that it has completely cooled
down, clean and dry, put the spoon and the kneading blade in the pan, and close the lid.
INTRODUCTION OF BREAD INGREDIENTS
1. Bread flour
Bread flour has high content of high gluten (so it can be also called high-gluten flour
which contains high protein), it has good elastic and can keep the size of the bread from
collapsing after rise. As the gluten content is higher than the common flour, so it can be
used for making bread with large size and better inner fiber. Bread flour is the most
important ingredient of making bread.
2. Plain flour
14
Flour that contains no baking powder, it is applicable for making express bread.
3. Whole-wheat flour
Whole-wheat flour is ground from grain. It contains wheat skin and gluten. Whole-wheat
flour is heavier and more nutrient than common flour. The bread made by whole-wheat
flour is usually small in size. So many recipes usually combine the whole -wheat flour or
bread flour to achieve the best result.
4. Black wheat flour
Black wheat flour, also named as“rough flour”, it is a kind of high fiber flour, and it is
similar with whole-wheat flour. To obtain the large size after rising, it must be used in
combination with high proportion of bread flour.
5. Self-rising flour
A type of flour that contains baking powder, it is used for making cakes specially.
6. Corn flour and oatmeal flour
Corn flour and oatmeal flour are ground from corn and oatmeal separately. They are the
additive ingredients of making rough bread, which are used for enhancing the flavor and
texture.
7. Sugar
Sugar is very important ingredient to increase sweet taste and color of bread. And it is also
considered as nourishment in the yeast bread. White sugar is largely used. Brown sugar,
powder sugar or cotton sugar may be called by special requirement.
8. Ye a st
After yeasting process, the yeast will produce carbon dioxide. The carbon dioxide will
expand bread and make the inner fiber soften. However, yeast fast breeding needs
carbohydrate in sugar and flour as nourishment.
1 tsp. active dry yeast =3/4 tsp. instant yeast
1.5 tsp. active dry yeast =1 tsp. instant yeast
2 tsp. active dry yeast =1.5 tsp. instant yeast
Yeast must be stored in the refrigerator, as the fungus in it will be killed at high
temperature, before using, check the production date and storage life of your yeast. Store it
back to the refrigerator as soon as possible after each use. Usually the failure of bread
rising is caused by the bad yeast.
The ways described below will check whether your yeast is fresh and active.
15
(1) Pour 1/2 cup warm water (45-500C) into a measuring cup.
(2) Put 1 tsp. white sugar into the cup and stir, then sprinkle 2 tsp. yeast over the water.
(3) Place the measuring cup in a warm place for about 10min. Do not stir the water.
(4) The froth should be up to 1 cup. Otherwise the yeast is dead or inactive.
9. Salt
Salt is necessary to improve bread flavor and crust color. But salt can also restrain yeast
from rising. Never use too much salt in a recipe. But bread would be larger if without salt.
10. Egg
Eggs can improve bread texture, make the bread more nourish and large in size, the egg
must be peeled and stirred evenly.
11. Grease, butter and vegetable oil
Grease can make bread soften and delay storage life. Butter should be melted or chopped
to small particles before using.
12. Baking powder
Baking powder is used for rising the Ultra Fast bread and cake. As it does not need rise
time, and it can produce the air, the air will form bubble to soften the texture of bread
utilizing chemical principle.
13. Soda
It is similar with baking powder. It can also used in combination with baking powder.
14. Water and other liquid
Water is essential ingredient for making bread. Generally speaking, water temperature
between 20
0
C and 25
0
C is the best. The water may be replaced with fresh milk or water
mixed with 2% milk powder, which may enhance bread flavor and improve crust color.
Some recipes may call for juice for the purpose of enhancing bread flavor, e.g. apple juice,
orange juice, lemon juice and so on.
INGREDIENTS MEASUREMENT
One of important step for making good bread is proper amount of ingredients. It is strongly
suggested that use measuring cup or measuring spoon to obtain accurate amount,
otherwise the bread will be largely influenced.
1. Weighing liquid ingredients
Water, fresh milk or milk powder solution should be measured with measuring cups.
16
Observe the level of the measuring cup with your eyes horizontally. When you measure
cooking oil or other ingredients, clean the measuring cup thoroughly without any other
ingredients.
2. Dry measurements
Dry measuring must be done by gently spooning ingredients into the measuring cup and
then once filled, leveling off with a knife. Scooping or tapping a measuring cup with more
than is required. This extra amount could affect the balance of the recipe. When measuring
small amounts of dry ingredients, the measuring spoon must be used. Measurements must
be level, not heaped as this small difference could throw out the critical balance of the
recipe.
3. Adding sequence
The sequence of adding ingredients should be abided, generally speaking, the sequence is:
liquid ingredient, eggs, salt and milk powder etc. When adding the ingredient, the flour
can't be wet by liquid completely. The yeast can only be placed on the dry flour. And yeast
can't touch with salt. When you use the delay function for a long time, never add the
perishable ingredients such as eggs, fruit ingredient.
TROUBLE SHOOTING GUIDE
Questions &
Answers on
Bread maker
Problem
Cause
Solution
Smoke comes out of the
baking compartment or of
the vents
The ingredients stick to the
baking compartment or on
the outside of the baking
pan
Pull out the plug and clean
the outside of the baking
pan or the baking
compartment.
The bread goes down in the
middle and is moist on the
bottom
The bread is left too long in
the pan after baking and
warming.
Take the bread out of the
baking pan before the
warming function is over.
It is difficult to take the
bread out of the baking
pan.
The bottom of the loaf is
stuck to the kneading blade
Clean the kneading blade
and shafts after the baking.
If necessary, fill the baking
pan with warm water for
30 minutes, then the
kneading blade can be
easily removed and
cleaned.
The ingredients are not
mixed or the bread is not
baked correctly
Incorrect program setting
Check the selected menu
and the other settings.
The START/STOP button
was touched while the
machine was working
Do not use the ingredients
and start over again
The lid opened several
Never open the lid
17
times while the machine
was working
frequently, unless it is
necessary such as add
ingredients. And make sure
that lid was closed well
after being opened.
Long blackout while the
machine was working
Do not use the ingredients
and start over again.
The rotation of the
kneading blade is blocked
Check that the kneading
blade is blocked by grains,
etc. Pull out the baking pan
and check the driver is
turning. If this is not the
case, send the appliance to
the customer service.
The appliance does not
start. The display shows
“HHH”
The appliance is still hot
after the previous baking
procedure
Pull out the plug, take out
the baking pan and leave it
to cool at room
temperature, then insert the
plug and start again.
Error with the
recipes
The bread rises too fast.
Maybe, too much yeast, too
much flour, not enough
salt.
a/b
or several of these causes
The bread does not rise at
all or not enough.
No yeast at all or too little
a/b
old or stale yeast
e
liquid too hot
c
the yeast has come into
contacting with the liquid
d
wrong flour type or stale
flour
e
too much or not enough
liquid
a/b/g
not enough sugar
a/b
The dough rises too much
and spills over the baking
pan.
If the water is too soft the
yeast ferments more
f
too much milk affects the
fermentation of the yeast
c
The bread goes down in the
middle.
The dough volume is
larger than the pan and the
bread goes down.
a/f
The fermentation is too
short or too fast owing to
the excessive temperature
of the water or the baking
chamber or to the excessive
moisture.
c/h/i
Heavy, lumpy structure
too much flour or not
enough liquid.
a/b/g
not enough yeast or sugar
a/b
too much fruit, wholemeal
or of one of the other
ingredients
b
18
old or stale flour, warm
liquids make the dough rise
too quickly and loaf fall in
before baking
e
no salt or not enough sugar
too much liquid
The bread is not baked in
the center
too much or not enough
liquid
a/b/g
too much humidity
h
recipes with moist
ingredients, e.g. yogurt
g
Open or coarse structure or
too many holes
too much water
g
no salt
b
great humidity, water too
hot
h/i
too much liquid
c
Mushroom-like, unbaked
surface
bread volume too big for
the pan
a/f
too much flour, especially
for white bread
f
too much yeast or not
enough salt
a/b
too much sugar
a/b
sweet ingredients besides
the sugar
b
The slices are uneven or
there are clumps in the
middle
bread not cooled enough
(the vapor has not escaped)
j
Flour deposits on the bread
crust
the flour was not worked
well on the sides during the
kneading
g/i
a) Measure the ingredients correctly.
b) Adjust the ingredient doses and check that all the ingredients have been added.
c) Use another liquid or leave it to cool at room temperature, add the ingredients specified in the
recipe in the right order, make a small ditch in the middle of the flour and put in the crumbled
yeast or the dry yeast, avoid letting the yeast and the liquid come into direct contact.
d) Use only fresh and correctly stored ingredients.
e) Reduce the total amount of the ingredients, do not use more than the specified mount of flour.
Reduce all the ingredients by 1/3.
f) Correct the amount of liquid. if ingredients containing water are used, the dose of the liquid
to be added must be duly reduced.
g) In case of humid weather, remove 1-2 tablespoons of water.
h) In case of warm weather do not use the timing function. Use cold liquids.
i) Take the bread out of the pan immediately after baking and leave it on the grid to cool for at
least 15 minutes before cutting it.
j) Reduce the amount of yeast or of all the ingredient doses by 1/4.
k) Never grease the pan!
l) Add a tablespoon of wheat gluten to the dough.
19
ENVIRONMENT FRIENDLY DISPOL
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working
electrical equipments to
an appropriate
waste disposal center.
suppor[email protected]
Thank You For Purchasing From
VIVOHOME
www.vivo-home.com
To continuously improve its products, VIVOHOME reserves the right to modify this
information without prior notification.
Please contact customer service via
with any questions,
comments, or concerns. Thank you for using VIVOHOME products in your home!
NOTE:
