Quick Start Guide
– 1 –
E092026-CS-R01
www.edge-core.com
Portable IoT Gateway
Pi7a
System Status
Press
Restart
5s Press with Pin
Reset
USB-C 5 VDC
1 2 3
HaLow Link Status
Blinking: No Link Weak Signal Link Medium Signal Link Strong Signal Link
Battery Charging
System Ready Battery Medium
Battery Low
On Slow Blink Fast Blink
(<60%, Configurable) (<20%, Configurable)
Battery Replacement
2 x 3.7 V / >2500 mAh
Li-ion 18650 Batteries
1 2 3 4
5 6 7 8
Restart/Reset
Press & Hold
Power On/Off
Quick Start Guide
– 2 –
Hardware Specifications Safety and Regulatory Information
FCC Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and
receiver
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician
for help
FCC Caution:
Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
For product available in the USA/Canada market, only channel
1~11 can be operated. Selection of other channels is not possible.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This device has been tested and meets applicable limits for Radio
Frequency (RF) exposure.
The local Specific Absorption Rate (SAR) quantifies the user’s
exposure to the electromagnetic waves of the equipment
concerned. The maximum permitted SAR is 1.58 W/kg.
Carry this device at least 10 mm away from your body to ensure
exposure levels remain at or below the as-tested levels.
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Cet appareil contient des émetteurs / récepteurs exempts de licence
qui sont conformes au (x) RSS (s) exemptés de licence d’Innovation,
Sciences et Développement économique Canada. L’opération est
soumise aux deux conditions suivantes:
(1) Cet appareil ne doit pas provoquer d’interférences.
(2) Cet appareil doit accepter toute interférence, y compris les
interférences susceptibles de provoquer un fonctionnement
indésirable de l’appareil.
Enclosure
Size (WxDxH) 76 x 25 x 164 mm (2.99 x 0.98 x 6.46 in.)
Weight x.xx kg (x.xx lb)
Temperature Operating: -20° C to 50° C (-4° F to 122° F)
Storage: -30° C to 70° C (-22° F to 158° F)
Humidity Operating: 0% to 95% (non-condensing)
Waterproof Rating IP56
Network Interfaces
Ports USB-C: Power input
2.4 GHz Radio IEEE 802.11b/g/n/ac/ax
HaLow Radio IEEE 802.11ah
Bluetooth Radio IEEE 802.15.1
Radio Frequencies 2.4–2.4835 GHz (US, Canada, ETSI, Japan, TW)
HaLow (FCC): 902–928 MHz
HaLow (CE): 863–868 MHz
HaLow (JP): 920.6–928 MHz
HaLow (TW): 920–925 MHz
Power Specifications
USB-C Input
Power
5 VDC, 1 A
Regulatory Compliances
Radio EN300 328 V2.2.2 (2019-07)
EN300 220-1 V3.1.1 (2017-02)
EN300 220-2 V3.1.1 (201702)
47 CFR FCC Part 15.247
IC RSS-247 Issue 4 and RSS-Gen Issue 5
RSS-247 Issue 4 July. 2025
RSS-Gen, Issue 5 April 2018, Amendment 2
(February 2021)
NCC LP0002 (2024-02-06)
MIC Certification Rule, Article 2 Paragraph 1
Item 18
MIC Certification Rule, Article 2 Paragraph 1
Item 19
Terminal equipment design certification, Article
3, Article 4, Article 6, Article 9, and Article 34
regulations
Emissions EN 301 489-1 V2.2.3 (2019-11) Class B
EN 301 489-17 V3.3.1 (2024-09)
47 CFR FCC Rules and Regulations Part 15
Subpart B, Class B Digital Device
ICES-003, Issue 7 Class B
CNS 15936 Class B
Safety Low Voltage Directive IEC 62368-1:2018; and/
or EN IEC 62368-1:2020+A11:2020; and/or
BS EN IEC 62368-1:2020+A11:2020
CNS 15598-1
RoHS CNS 15663
Note:
Purchased 18650 batteries must be rated at least
3.7 V / 2500 mAh.
Note:
Purchased batteries must have a protruding
positive terminal (button top), and it is recommended that
they comply with applicable safety standards.
Note:
The operating temperature during battery charging
must follow the specifications of the battery purchased by
the end user.
Quick Start Guide
– 3 –
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This device has been tested and meets applicable limits for Radio
Frequency (RF) exposure.
Cet appareil a été testé et respecte les limites applicables en
matière d’exposition aux radiofréquences (RF).
The local Specific Absorption Rate (SAR) quantifies the user’s
exposure to the electromagnetic waves of the equipment
concerned. The maximum permitted SAR is 1.58 W/kg.
Le débit d’absorption spécifique (DAS) local quantifie l’exposition
de l’utilisateur aux ondes électromagnétiques de l’équipement
concerné. Le DAS maximal autorisé est de 1.58 W/kg.
Carry this device at least 10 mm away from your body to ensure
exposure levels remain at or below the as-tested levels.
Maintenez cet appareil à une distance minimale de 10 mm de votre
corps afin de garantir que les niveaux d’exposition restent inférieurs
ou égaux aux niveaux testés.
CE Statement
This equipment complies with EU radiation exposure limits set forth
for an uncontrolled environment. This equipment should be
installed and operated with minimum distance xx cm between the
radiator and your body.
All operational modes:
2.4 GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40),
802.11ac (VHT20), 802.11ac (VHT40), 802.11ax (HE20), 802.11ax
(HE40)
BLE 2.4 GHz: 802.15.1
HaLow: 802.11ah
The frequency and maximum transmitted power limit in EU are
listed as below:
2400–2483.5 MHz: 20 dBm
863–868 MHz: 14 dBm
The abbreviations of the countries, as prescribed in above table,
where any restrictions on putting into service or any requirements
for authorization of use exist.
CE Mark Declaration of Conformance for EMI and Safety (EEC)
This information technology equipment is in compliance with the
Directive 2014/53/EU and Directive 2014/35/EU.
The Declaration of Conformity (DoC) can be obtained from
Edgecore.
Antenna List
Japan VCCI Statement
Warnings and Cautionary Messages
警告及注意訊息
NCC Statement
NCC 警語
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均
不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射
頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象
時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，
指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法
通信或⼯業、科學及醫療用電波輻射性電機設備之干擾。
AT BE BG CH CY CZ
DE DK EE EL ES FI
FR HR HU IE IS IT
LI LT LU LV MT NL
NO PL PT RO SE SI
SK TR UK
No. Model No. Application Material/Type Peak Gain
1 120G00000298A HaLow Metal, PIFA 900MHz: 1.56 dBi
2 142000004535A Wi-Fi/BLE
2.4G
PIFA 3.6 dBi
Warning:
This product does not contain any serviceable
user parts.
警告：
本產品不包含使用者可自行維修的零件。
– 4 –
快速入⾨指南
www.edge-core.com
Portable IoT Gateway
Pi7a
USB-C 5 VDC
重啟 重置
按 用別針按壓 5 秒
1 2 3
閃爍：無連結
弱訊號鏈路
中等訊號鏈路
強訊號鏈路
Battery Low
(<20%, Configurable)
開
慢眨眼
快速眨眼
系統就緒
電池中型
60%????
2 x 3.7 V / >2500 mAh
鋰離子18650電池
1 2 3 4
5 6 7 8
按住
電源開/關
系統狀態
HaLow 連結狀態
電池充電
重啟/重置
電池更換
開
系統就緒
電池中型
(<60%，可配置) (<20%，可配置)
電池電量低
慢閃爍 快速閃爍
快速入⾨指南
– 5 –
硬體規格 安全和監管訊息
FCC Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and
receiver
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician
for help
FCC Caution:
Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
For product available in the USA/Canada market, only channel
1~11 can be operated. Selection of other channels is not possible.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This device has been tested and meets applicable limits for Radio
Frequency (RF) exposure.
The local Specific Absorption Rate (SAR) quantifies the user’s
exposure to the electromagnetic waves of the equipment
concerned. The maximum permitted SAR is 1.58 W/kg.
Carry this device at least 10 mm away from your body to ensure
exposure levels remain at or below the as-tested levels.
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Cet appareil contient des émetteurs / récepteurs exempts de licence
qui sont conformes au (x) RSS (s) exemptés de licence d’Innovation,
Sciences et Développement économique Canada. L’opération est
soumise aux deux conditions suivantes:
(1) Cet appareil ne doit pas provoquer d’interférences.
(2) Cet appareil doit accepter toute interférence, y compris les
interférences susceptibles de provoquer un fonctionnement
indésirable de l’appareil.
外殼
尺寸（寬 x 深 x
高）
76 x 25 x 164 mm (2.99 x 0.98 x 6.46 in.)
重量
x.xx kg (x.xx lb)
溫度 操作：-20° C 至 50° C （-4° F 至 122° F）
儲存：-30° C 至 70° C (-22° F 至 158° F)
濕度 操作：0% 至 95%（無冷凝）
防水等級
IP56
網路介⾯
連接埠 USB-C: 電源輸入
2.4 GHz 無線電
IEEE 802.11b/g/n/ac/ax
HaLow 無線電
IEEE 802.11ah
藍牙無線電
IEEE 802.15.1
無線電頻率 2.4–2.4835 GHz (美國、加拿大、ETSI、日本、
台灣)
HaLow (FCC): 902–928 MHz
HaLow (CE): 863–868 MHz
HaLow (JP): 920.6–928 MHz
HaLow (TW): 920–925 MHz
電源規格
USB-C 輸入電源
5 VDC, 1 A
符合法規
無線電
EN300 328 V2.2.2 (2019-07)
EN300 220-1 V3.1.1 (2017-02)
EN300 220-2 V3.1.1 (201702)
47 CFR FCC Part 15.247
IC RSS-247 Issue 4 and RSS-Gen Issue 5
RSS-247 Issue 4 July. 2025
RSS-Gen, Issue 5 April 2018, Amendment 2
(February 2021)
NCC LP0002 (2024-02-06)
MIC Certification Rule, Article 2 Paragraph 1
Item 18
MIC Certification Rule, Article 2 Paragraph 1
Item 19
Terminal equipment design certification, Article
3, Article 4, Article 6, Article 9, and Article 34
regulations
輻射
EN 301 489-1 V2.2.3 (2019-11) Class B
EN 301 489-17 V3.3.1 (2024-09)
47 CFR FCC Rules and Regulations Part 15
Subpart B, Class B Digital Device
ICES-003, Issue 7 Class B
CNS 15936 Class B
安全性
Low Voltage Directive IEC 62368-1:2018; and/
or EN IEC 62368-1:2020+A11:2020; and/or
BS EN IEC 62368-1:2020+A11:2020
CNS 15598-1
RoHS CNS 15663
附註：
所購18650電池的額定電壓必須至少為3.7V/容量
2500mAh。
附註：
購買的電池必須有突出的正極（凸頭），並建議符
合適用的安全標準。
附註：
電池充電期間的⼯作溫度必須符合最終用戶所購買
電池的規格。
快速入⾨指南
– 6 –
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This device has been tested and meets applicable limits for Radio
Frequency (RF) exposure.
Cet appareil a été testé et respecte les limites applicables en
matière d’exposition aux radiofréquences (RF).
The local Specific Absorption Rate (SAR) quantifies the user’s
exposure to the electromagnetic waves of the equipment
concerned. The maximum permitted SAR is 1.58 W/kg.
Le débit d’absorption spécifique (DAS) local quantifie l’exposition
de l’utilisateur aux ondes électromagnétiques de l’équipement
concerné. Le DAS maximal autorisé est de 1.58 W/kg.
Carry this device at least 10 mm away from your body to ensure
exposure levels remain at or below the as-tested levels.
Maintenez cet appareil à une distance minimale de 10 mm de votre
corps afin de garantir que les niveaux d’exposition restent inférieurs
ou égaux aux niveaux testés.
CE Statement
This equipment complies with EU radiation exposure limits set forth
for an uncontrolled environment. This equipment should be
installed and operated with minimum distance xx cm between the
radiator and your body.
All operational modes:
2.4 GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40),
802.11ac (VHT20), 802.11ac (VHT40), 802.11ax (HE20), 802.11ax
(HE40)
BLE 2.4 GHz: 802.15.1
HaLow: 802.11ah
The frequency and maximum transmitted power limit in EU are
listed as below:
2400–2483.5 MHz: 20 dBm
863–868 MHz: 14 dBm
The abbreviations of the countries, as prescribed in above table,
where any restrictions on putting into service or any requirements
for authorization of use exist.
CE Mark Declaration of Conformance for EMI and Safety (EEC)
This information technology equipment is in compliance with the
Directive 2014/53/EU and Directive 2014/35/EU.
The Declaration of Conformity (DoC) can be obtained from
Edgecore.
Antenna List
Japan VCCI Statement
Warnings and Cautionary Messages
警告及注意訊息
NCC Statement
NCC 警語
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均
不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射
頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象
時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，
指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法
通信或⼯業、科學及醫療用電波輻射性電機設備之干擾。
AT BE BG CH CY CZ
DE DK EE EL ES FI
FR HR HU IE IS IT
LI LT LU LV MT NL
NO PL PT RO SE SI
SK TR UK
No. Model No. Application Material/Type Peak Gain
1 120G00000298A HaLow Metal, PIFA 900MHz: 1.56 dBi
2 142000004535A Wi-Fi/BLE
2.4G
PIFA 3.6 dBi
Warning:
This product does not contain any serviceable
user parts.
警告：
本產品不包含使用者可自行維修的零件。
