FCC Warning
说明书尺寸：414x95mm 折叠尺寸：69x95mm
80g书写纸 双面印刷，折页
QUICK START
GUIDE
Wireless Power Bank
Magnetic wireless
charging part
Battery level
display
Charging：Battery rises, units digit flashes. Steady at 100%.
Discharging：Battery drops, steady display. Green fast-charge icon
for fast output.Flash below 5% low power.
Active Wireless Charging：Steady battery display; green fast-charge icon
for fast charge.
Wireless Charging Error：Wireless charge shut down, battery display steady.
Restore after FOD cleared.
Low-Current Mode：Long press ~2s after power on to enter: units digit scrolling.
Exit by double click or long press.
Low voltage protection: 0 current, indicators off.
Overvoltage protection: battery display flashes.
Type-Cport
Power Button
Function Introduction
Light display mode
Wireless charging
Wireless Power Bank
Material
Battery Capacity
Battery Energy
Wireless Output
Operating Temperature
Product Dimensions
Product Weight
Product Name
Model
Input
Output
Combined Output
Rated Capacity
Product Specifications
Packing List
Power Bank*1/User Manual*1/Type-C data cable*1
PC+ABS （UL94-V0)
5000mAh
5000mAh 3.85VDC/19.25Wh
15W (Max)
0℃-40℃
58.5*76*15mm
120g
P50
5V 3A/9V 1.67A(15W)
5V 3A/9V 2.22A/12V 1.67A(30W)
5V 3A (Max)
3200mAh (5V 3A)
Do not disassemble the battery. Keep away from fire and high
temperatures. Please pay attention to environmental protection.
Operating Environment
Do not use after being immersed in water.
※If consumers use a power adapter for power supply, they should
purchase a matching power adapter that has obtained CCC certification
and meets standard requirements.
Supports Type-C wired charging
Support Qi-enabled device
Wired Charging
Please read this manual carefully before using this charging
device. Fully charge the device before first use.
To avoid electric shock, do not operate this device with wet hands,
and do not use it in high-intensity or harsh environments.
Please only use a grounded power supply or a standard power
adapter that meets the specified parameters to power the device.
Precautions
Power Button
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:(1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without
restriction.
Model:P50 FCC ID:2AVSB-P50
Manufacturer:Shenzhen Mgctech Co.,Ltd.
