Medisana TM 700 Thermometer

Classication: Type BF applied part Read the instructions carefully

Manufacturer LOT number

The CE-mark refers to the EC-directive 93/42/EEC. The product was designed and manufactured in conformance with

the following European norms: EN 80601-2-56 (Medical thermometers), EN ISO 15223, EN 60601-1 (Electrical safety for

medical items). In accordance with our policy of continual product improvement, we reserve the right to make technical

and optical changes without notice.

Warranty and repair terms

Please contact your dealer or the service centre in case of a claim under the warranty. If you have to return the unit,

please enclose a copy of your receipt and state what the defect is.

a. All damage which has arisen due to improper treatment, e.g. nonobservance of the user instructions.

b. All damage which is due to repairs or tampering by the customer or unauthorised third parties.

c. Damage which has arisen during transport from the manufacturer to the consumer or during transport to the

service centre.

d. Accessories which are subject to normal wear and tear.

5. Liability for direct or indirect consequential losses caused by the unit are excluded even if the damage to the unit is

accepted as a warranty claim.

GB Thermometer TM 700 Operating Instructions. Please read carefully!

SAFETY INFORMATION

• Important Information! Retain for future use! Read the instruction manual carefully before using this device, es-

• Do not place the thermometer near extreme heat. There is a danger of explosion of the battery!

• The device must be tested for accuracy (calibrated) after 2 years. Please send the complete device to the service

centre.

• If the thermomter is not going to be used for a long period, remove the battery.

• Do not shake, bend or tap the thermometer. Do not drop it. It is not shock-resistant.

• Protect the device from direct sunlight, extremely high or low temperatures, high humidity, dirt and dust.

• Do not open up the device. If a fault occurs, please do not try to repair the unit yourself. Discontinue further use of the

unit. Contact your dealer and only have repairs carried out by the service.

• The device complies with the EN 60601-1-2 standard for electromagnetic compatibility. It is subject to particular pre-

cautions in regard to electromagnetic compatibility. Please note, that portable and mobile HF communication systems

need to replace the battery. To do this, remove the battery compartment cover and lift the compartment approx. 1

cm out of the thermometer. Use a suitable tool, e.g. the tip of a ballpoint pen, to carefully lever out the battery. Insert

the new battery with the „+“ sign facing upwards. Push the battery compartment back into the thermometer and

replace the compartment cover.

Change the unit of measure

You can measure the temperature in ° Celsius or in ° Fahrenheit.

Please proceed as follows to select the unit of measure:

1. The device has to be switched off.

2. Press and hold the ON/OFF-button for approx. 4 seconds

to change the current setting.

compartment

cover

0297

Cleaning and Disinfection

The medisana thermometer TM 700 is waterproof, making it easy to clean and disinfect. Clean the thermom-eter

before and after each use using a cloth moistened in a mild solution containing alcohol. You may also soak the

thermometer in a suitable disinfectant solution. Your dealer will be happy to recommend suitable cleaning products and

household waste, but at a battery collection station at a recycling site or in a shop. Consult your municipal

authority or your dealer for information about disposal.

Technical Specications

Name and model:

Power supply:

Battery service life:

Measuring range:

Measuring accuracy:

Memory:

Operating conditions:

Press the ON/OFF-button to switch the unit on. All display symbols will appear shortly and a signal tone will be emitted,

followed by the last measured temperature. If the temperature is below 32°C (90°F), “Lo” is displayed - if the tempera-

ture is above 42,9°C (109.9°F), “Hi” is displayed. The medisana thermometer TM 700 is now ready to take a

temperature reading. Position the sensor tip in oral, axillary or rectal position:

ORAL READINGS:

Place the sensor tip of the thermometer under the tongue and close your mouth. Breathe through your nose while taking

the reading in order to avoid inaccurate results.

RECTAL READINGS:

Many patients nd rectal measurement uncomfortable, but it delivers precise results. To quickly and reliably determine

body temperature, carefully insert the sensor tip approx. 1 cm into the rectum.

measure the body temperature on the armpit, the measurement duration should be at least 10 minutes in order to get a

reliable result. If the reading is > 37,8°C (100°F), the thermometer will indicate fever alarm by announcing mutiple beep

sounds (short beeps).

The thermometer will switch off automatically ten minutes after taking the reading. To prolong the life of the battery,

however, you should switch off the thermometer manually by pressing the ON/OFF-button.

medisana thermometer TM 700

Button cell 1,5V

(type GP-192 or LR 41)

approx. 200 hours

32,0°C - 42,9°C (90.0°F - 109.9°F)

approx. 13,9 x 2,2 x 1,3 cm

approx. 11 g (incl. battery)

48606

40 15588 48606 7

48606_TM 700_manual_GB_202208_L4

medisana GmbH

Carl-Schurz-Str. 2, 41460 NEUSS, GERMANY
