Strength Training Equipment
User Manual
Model: [AM9]
Thank you for choosing our AM9 Strength Training equipment. To
ensure safe and effective use of the product, please read this manual
carefully before use and keep it properly for future reference.
1. I. Product Introduction
Appearance: This smart fitness equipment adopts a foldable design, supports 180°
unfolding, easy for storage and carrying.
1.Folded State (Schematic diagram, Unit: mm)
Figure 1: Overall outline (left) and side view schematic (right) of the product in folded state
2.Unfolded State (Schematic diagram, Unit: mm)
Figure 2: Top view (left) and usage posture schematic (right) of the fully
unfolded product
Press and hold the power key to power on. After power-on, the motors on both sides will
2
automatically retract the pull ropes. Please ensure the pull ropes are not entangled by
other objects. Do not operate at this moment. After the pull ropes are fully retracted, the
motors on both sides will feed out a small section of pull rope. Then you can start using
the fitness equipment.
During use of the fitness equipment, the pull ropes on both sides may be elongated
slightly. If it affects your exercise, restart the fitness equipment to restore the pull ropes to
the initial length.
Display Operation Instructions
1、 Power key: Press and hold to power on / power off
2、 Battery level indicator
3、 Bluetooth connection indicator light
4、 Strength increase key: Each press increases strength by 1KG. After power-on, it
defaults to adjusting the left motor strength. To adjust the right motor strength, short press
the SYNC key. When the right number flashes, press + / – key to adjust the right motor
strength.
5、 Strength decrease key: The operation logic is consistent with the strength increase
key.
6、 SYNC key: Strength synchronization key / Left-right motor strength switching key
When the strength of the two motors is different, press and hold this key, both motors will
synchronize to the higher strength value.
Short press once, the right strength number will flash, then you can press + / – to adjust
the right motor strength; short press again to switch to adjust the left motor strength.
M Mode switch key: The highlighted letter represents the current mode; other letters
3
are gray.
C — Constant Strength Mode: The motor outputs strength according to the set value.
B — Rowing Mode: Pulling strength is about 1.2 times of retracting strength.
I — Incremental Mode: Starts from 1KG, increases by 1KG per pull up to max 20KG.
W — Decremental Mode: Starts from 20KG, decreases by 1KG per pull down to 1KG and
keeps this strength.
FC — Eccentric Mode: Retracting strength is approximately equal to pulling strength.
8. Left / Right motor current strength display (e.g. 12 means 12KG). Left and right
strength can be set the same or different.
9. Total exercise time (MIN)
10. Calorie consumption (KCAL)
11. Total pulling count (COUNT)
II. Accessories Introduction
4
Name
Specification
Description
Standard
Accessories
Handheld Grip
2pcs
Adapter
1pcs
Extension Strap
2pcs
Hanger for wall board
2pcs
Expansion Screw
1set
Wall Board
1pcs
User Manual
1pcs
Optional
Accessories
Slide Rail Assembly
1 set (Opt)
Including slide rail
rods, slide rail
fixings, expansion
screws, wood
mounting brackets,
movable latches
and fixing screws.
Foot Ring Buckle
2 pcs(Opt)
-
Barbells
3 pcs(Opt)
Maximum tensile
force: 60kg
Waist Belt
1 pcs(Opt)
-
Pilates Strap
2 pcs(Opt)
-
5
III. Hazardous Substances Description
In accordance with China Management Measures for Restriction of
Hazardous Substances in Electrical and Electronic Products (RoHS) and
relevant standards, the content of hazardous substances in this product is as
follows:
Part
Name
Lead(
Pb)
Mercur
y(Hg)
Cadmiu
m(Cd)
Hexavalen
t
Chromium
(Cr(VI))
Polybrom
inated
Biphenyl
s(PBB)
Polybrom
inated
Diphenyl
Ethers(P
BDE)
Access
ories
○
○
○
○
○
○
Metal
Fasten
ers
×
○
○
○
○
○
Circuit
Board
×
○
○
○
○
○
Battery
×
○
○
○
○
○
Charge
r
×
○
○
○
○
○
Wire /
Conne
ctor
×
○
○
○
○
○
Display
/ Lamp
Parts
×
×
○
○
○
○
This table is compiled in accordance with SJ/T11364.
○ : Indicates that the content of the hazardous substance in all homogeneous
materials of the part is below the limit specified in GB/T 26572-2011.
× : Indicates that the content of the hazardous substance in at least one
homogeneous material of the part exceeds the limit specified in GB/T
26572-2011. There is no mature alternative technology in the industry at
present, which complies with EU RoHS environmental protection
requirements.
6
The number in the environmental protection mark indicates the
environmental service life is 5 years under normal use. No leakage or mutation
of hazardous substances will occur during this period.
IV. Product Parameters
Item
Parameter
Motor Rated Power
400W (Dual Motor)
Single-side Maximum Force
20 kg
Double-side Maximum Force
40 kg
Lithium Battery Capacity
2500 mAh
Adapter Charging Voltage/Current
29.4V ⎓ 1.5A
Device Noise
≤55 dB
Working Temperature
-10℃~40℃
Storage Temperature
0℃~40℃
Relative Humidity
≤75%
Pull Rope Maximum Tensile Force
100 kg
Executive Standard
GB 17498.1, GB 4706.1
V. Safety Warnings and Disclaimer
⚠ Warning: Please read this manual carefully before using the fitness equipment.
Improper use may cause property loss, safety accidents and personal injury. The final
interpretation right belongs to Dongguan Aomeiruike.
By using this fitness equipment, you agree to all terms of this disclaimer and take full
responsibility for all risks.
1. Read Before Use
Read all warnings and instructions and obtain proper operating guidelines before
using the device.
2. Health Assessment
7
Prior to starting any exercise program, complete a physical examination or fitness
assessment. Consult a physician especially if you have a history of cardiovascular
diseases or joint injuries.
3. Exercise Safety
During exercise, ensure moving parts of the equipment do not restrict your movement.
Keep hair and clothing away from all moving components.
4. Pre-use Inspection
Inspect the device before each use: check for frayed pull cords, abnormal motor noise
and cracked housing. Stop use immediately and contact maintenance staff if any
damage or abnormality is found.
5. Damage Handling
If the device, power cord or any component is worn, broken or damaged, replace the
defective parts right away or discontinue use until repairs are completed.
6. Children & Vulnerable Persons
This product is not a toy and is not intended for users under 18 years of age. Keep the
product away from children and exercise extra caution when operating it around
children. Children aged 8 and above, as well as persons with physical, sensory or
intellectual impairments, shall use this product only under supervision and guidance
after fully understanding potential hazards.
7. Dedicated Charger
Only use the original dedicated charger supplied with this product. Do not use any
other chargers.
8. Charging Environment
Do not charge the product in humid areas such as bathrooms. Keep the charging area
away from bathtubs and heat sources (heaters, open flames). Charging is permitted
indoors only.
9. Optimal Charging Temperature
The ambient temperature for charging shall be between 0℃ and 40℃. Excessively
high or low temperatures may damage the battery.
10. Storage Requirements
When not in use, store the fitness equipment in a safe, dry and cool place. Prevent it
from falling from heights.
11. Pull Cord Protection
Keep sharp objects away from the pull cord to avoid cuts, wear and breakage.
12. Power Cord
If the power cord is damaged, replace it only with a dedicated cord or assembly
obtained from the manufacturer or authorized service center.
13. Wireless Connection
8
This product is equipped with a Bluetooth module only, with no Wi-Fi module installed.
This manual provides an overview of the product’s general functions and usage
instructions.
Disclaimer
This fitness equipment is only for indoor exercise, not for medical rehabilitation or
industrial traction.
Any injury or loss caused by disassembly, modification or using non-original
accessories shall be borne by the user.
Stop exercise immediately if you feel dizziness, chest tightness or joint pain.
VI. Executive Standards
This product complies with:
GB 17498.1 --Stationary fitness equipment Part 1: General safety requirements and
test methods
GB 4706.1 -- Household and similar electrical appliances – Safety – General
requirements
For any questions about the fitness equipment, please contact customer service.
Warranty terms refer to the warranty card.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could
void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
