Performance Characteristics
1.Power Supply: Use an adapter that meets safety standards to power the device.
2.Foreign Metal Objects: Ensure there are no foreign metal objects between the
wireless charger and the mobile phone while charging to prevent accidental heating
of the metal objects.
3.Magnetic Cards: Do not place magnetic cards, such as bank or bus cards,
in the charging area to avoid damage.
4.Charging Distance: To obtain a better wireless charging experience,
use only within the product's maximum charging distance.
5.Compatibility: This product is designed for iPhones with magnetic wireless
charging functions and is compatible only with iPhone 12 and newer models.
For optimal Qi2 15W charging, the device must be an iPhone 12 or later, running
iOS 17 or newer.
1.Qi2.0 MPP Standard: Supports iPhone's latest Qi 2.2 MPP magnetic
charging standard .
2.Wireless Charging: Supports up to 25W wireless charging.
3.Magnetic Design: It features a ring-shaped magnetic design to ensure
the phone is tightly adsorbed and aligns the charging coil easily.
4.Easy Installation: The unique metal buckle design for easy fixing, and
the embedded design allows it to integrate seamlessly with furniture.
320.00 mm
240.00 mm
GF-13Pro
Embedded 25W Wireless Charger
User Manual
Product Introduction
Manufacturer: GCteq Wireless (Shenzhen) Co., Ltd.
Website: http://www.gcteq.com
Product Warranty Instructions
Wireless charger product after-sales service strictly in accordance with
Law of the PRC on the Protection of the Rights and Interests of
Consumers, and Product Quality Law of the People's Republic of China
Adopted to provide After-sales service.
The services are as follows:
1. Within 7 days from the next day after purchase (sign for), if this
product has performance failure, you can enjoy free return or exchange
service after being tested and determined by the after-sales service
center;
2. Within 15 days from the next day after you purchase (sign for), if this
product has performance failure, you can enjoy free exchange or repair
service after being tested and determined by the after-sales service
center;
3. Within 1 year from the next day after you purchase (sign for), if this
product has performance failure, you can enjoy free repair service after
being tested and determined by the after-sales service center.
Non warranty regulations
In one of the following cases, we don't offer three guarantees and only
charging maintenance will be provided:
1. Damage caused by improper use, maintenance and storage of consumers;
2. Damage caused by unauthorized service provider;
3. There is no valid invoice or proof of purchase;
4. Damage caused by majeure.
Common product faults
Phenomenon
Cause
Troubleshooting
This mark is the product pollution control mark, the number of which
represents the environmental service life. In this period of time, under
normal conditions of use harmful substances will not cause greater
pollution to the environment or damage to human life and property.
Name of parts
Hazardous substance
Elec tr on ic compon en ts
Plas ti c ca sing
Elec tr op lated alu mi nu m
allo y pa rt s
Non- el ec troplat ed m et al parts
Doub le f ac ed adhesi ve t ap e
Synt he ti c cork
Sili co n pa rts
Lead
(Pb)
Merc ur y
(Hg)
Cadm iu m
(Cd)
Hexa va le nt
-Chr om iu m
(Cr(VI))
Poly br om inated
-Bip he ny ls
(PBB)
Poly br om inated
diph en yl ethers
(PBDE)
This form is in term of Stipulation SJ/T 11364
O It means that the content of the harmful substance in a part of the part is lower than the limit
requirements specified in GB/T 26572.
X It means that the content of the harmful substance in a part of the part exceeds the limit
requirements specified in GB/T 26572.
Specification
Installation
Precautions
Please read and follow the following precautions carefully before
installing and using this product:
Wireless charging
not working
1. Power supply doesn't
meet requirements.
2. Poor contact in power
interface.
1. Use an adapter that meets
requirements.
2. Ensure secure connection
of power port.
Wireless charging
slow
1. Product body temperature
too high.
2. Misaligned wireless charging
area.
1. Let the product cool to room
temperature.
2. Place the phone in the center
of the charging area for better
alignment.
Hazardous Substance Declaration
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
FCC STATEMEN
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. During the operation of device a distance of 15 cm surrounding the device and
20 cm above the top surface of the device must be respected.
T :
Checked
Certificat ed of qualification
Introduction
Dimensions
25W magnetic wireless charging
1. The hole size of the wooden board is φ15mm (as shown below);
2. Align the product with the mounting hole and tighten the
nut at the bottom of the wooden board.
LED indicator light
Nut
200mm
DC female connector
φ15mm
3. Connect the tail wire of the wireless charging device to
the adapter.
Product Name
Model
Embedded 25W Wireless Charger
Input power
DC12V 3A
Wireless charging output
25W Max
GF-13Pro
Input interface
DC female connector
Wireless charging protection
over-temperature protection,
over-voltage protection,
over-current protection, FOD
Communication standard
Certification
Qi2.2 MPP protocol standard
CE,FCC,Rosh
wireless charging status
Standby
Indicator light display
Charging
Green light stays on
extinguish
FOD
Green light flashing
Charging indicator light
