1. Watch wireless charging
position
2. Mobile phone wireless
charging position
3. Earbuds case wireless
charging position
4. 140°(Max.) foldable design
5. 180°(Max.) foldable design
6. 180°(Max.) foldable design
7. Power input port
8. LED Indicator
TRIO FLEX
USB-C TO USB-C 4FT
USER MANUAL
PD POWER ADAPTER
Input: 100-240V~50/60Hz
User Guide
TRIO FLEX
GT-MGA-2
Model
Package Contents
Product Diagram
How to Use
Step1: Please open the 3-in-1 foldable wireless charger and pull out the watch
wireless charging position;
Step2: Please connect one end of the USB-C cable to product power input
port, the other end to a power adapter;
Step3: Please place your devices to corresponding wireless charging
positions for charging.
Note:
Specifications
If you're experiencing interrupted or slow charging, check the following:
1. The back of your phone should not have any metal, pop sockets, or credit
cards.
2. If you're using an iphone 12 or below version or a other branded phone,
please put the phone in the center of the charging surface (this lets the
charging coil in your phone line up with the one inside the wireless
charger).
3. Phone cases should be no thicker than 6mm for effective charging.
4. Check whether the adapter is QC3.0/ PD3.0 fast charger.
If you are using the recommended wireless charger with the QC3.0/ PD3.0
adapter and have removed any potential charging obstructions, but are still
experiencing issues, please try following steps:
1. Replacing
the cable connecting to your wireless charger.
2. Unplug the adapter and reinsert it.
3. Please feel free to contact our support team for solving problem.
Trouble Shooting
Compatible Devices
Compatible Devices
Model
iPhone17 Series (Pro, Pro Max, etc.)
iPhone16 Series (Pro, Pro Max, etc.)
iPhone15 Series (Pro, Pro Max, etc.)
iPhone14 Series (Pro, Pro Max, etc.)
1. Please use the power supply voltage as specified (AC 100-240V).
2. Please use a mobile phone case with a thickness of less than 6MM.
3. If you need to clean the charger, please make sure it is not connected
power supply.
4. Applies to iphone 12 series and above mobile phones perfectly.
5. Wireless foldable charging supports a maximum output of 15W.
6. Due to the magnetic attraction, there may be imprints in the joint area of
wireless charger, which can be wiped off with an alcohol cotton pad.
7. It is recommended that uses with the included power adapter and USB-C
charging cable for better charging performance.
8. Do not disassemble, repair, modify on your own and do not drop this
product.
9. Do not use or store this product in highly humid or moist places, direct
sunlight, dense dust, or in high temperatures such as in a car under the sun
or near a heater.
10. This product is non-waterproof.
11. Keep out of reach of children.
12. If any abnormality like smoking, odor, deformation,
etc. occurs in this
product, stop using it immediately.
Cautions
FCC Warning Statement
‐‐ Reorient or relocate the receiving antenna.
‐‐ Increase the separation between the equipment and receiver.
‐‐Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
‐‐ Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to
Made in China
Model
Input
Output
Transmission Distance
Fast Charging Protocol Supported
GT-MGA-2
9.0V 3.0A(27.0W),
12.0V 3.0A(36.0W)
3.0W（for Watch)
5.0W (for Earphone charging case)
15.0W Max. (for Mobile phone)
≤ 6mm
QC2.0/ QC3.0/ PD/ Qi2.0
①
②
③
⑦
④
⑤
⑥
⑧
WEEE Compliance
DO not to dispose of product as unsorted municipal waste and to collect such
WEEE separately, for proper treatment, recovery and recycling, please take
this product(s) to designated collection points where it will be accepted free
of charge. Please contact your local authority for further details of your
nearest designated collection station.
06
the following two conditions: (1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference
that may cause undesired operation.
NOTE: This device and its antenna(s) must not be co-located or operation in
conjunction with any other antenna or transmitter.
Indicator Status
Indicator Status
Blue Light On for 3 Seconds and Off
Breath Blue Light
Constant Blue Light
Quick Flash Blue Light
Off
Charging Status
Connecting the Power Supply
Charging
Being Fully Charged
Foreign Object Detection
Function
Stand by
Smart Watch
Earbuds
Apple Watch 2 - 11, UItra, etc.
All Airpods/Earbuds with wireless charging case
Smart Phone
Please place your charging
devices centrally.
02 03 04 0501
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment. This
equipment has been tested and found to comply with thelimits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installd and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.If this
equipment does cause harmful interference toradio ortelevisionreception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan
uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperated
withaminimumdistanceof20cmbetweentheradiatorandyourbody.
70mm
100mm
