Refrigerator
use
&
care
A23801503/B (October 2025)
Introduction ......................................................2
Important Safety Information .................... 3
Features .............................................................. 6
Installation .........................................................7
Door Removal ................................................. 10
Water Supply Connection ..........................13
Controls and Settings ...................................15
Ice Maker ......................................................... 20
Storage Features .......................................... 24
Storing Food and Saving Energy ..........30
Normal Operating Sounds ..........................31
Filter Replacement .......................................32
Care and Cleaning ....................................... 34
Troubleshooting ........................................... 36
Limited Warranty .......................................... 41
2
INTRODUCTION
Doors
Door seals completely to cabinet on
all sides
Leveling
Refrigerator is level side-to-side and
slightly elevated in front to assist
with door and drawer closing (front
should be higher than back)
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to
refrigerator (WARNING: Potable
water supply only.)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser
operates correctly
Final Checks
Shipping material removed
Fresh food and freezer
temperatures set
Registration card sent in
Installation Checklist
9
Serial Number Location
Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it o cial! Be sure to register
your product.
Keep your product info here so it’s easy
to fi nd.
Model Number
Serial Number
Purchase Date
3
WARNING
WARNING indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Defi nitions
This is the safety alert symbol. It is used
to alert of potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
IMPORTANT SAFETY INFORMATION
WARNING
Please read all instructions before using
this refrigerator.
DANGER
DANGER Risk of fi re or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigerator.
Do not puncture refrigerant tubing.
DANGER Risk of fi re or explosion.
Flammable refrigerant used. To be
repaired only by trained service personnel.
Use only manufacturer-authorized service
parts. Any repair equipment used must
be designed for fl ammable refrigerants.
Follow all manufacturer repair instructions.
Do not puncture refrigerant tubing.
CAUTION
CAUTION Risk of fi re or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fi re or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
4
IMPORTANT SAFETY INFORMATION
Proper Disposal of your Appliance
Risk of child entrapment
Child entrapment and su ocation are not
problems of the past. Junked or abandoned
refrigerators or freezers are still dangerous
– even if they will sit for “just a few days”.
When disposing of an old refrigerator or
freezer, please follow the instructions below
to help prevent accidents.
We strongly encourage responsible
appliance recycling/disposal methods.
Check with the utility company or visit
energystar.gov/recycle for more information
on recycling an old refrigerator.
Before disposing of an old appliance:
• Remove doors.
• Leave shelves in place so children may
not easily climb inside.
• Have refrigerant removed by a
qualifi ed service technician.
Child Safety
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the refrigerator is
unpacked. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause su ocation.
Safety Instructions
• DO NOT store or use gasoline, or
other fl ammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
fl ammability and other hazards.
• DO NOT operate the refrigerator in
the presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts,
and also destroy fi nishes if they
come in contact with other
appliances or furniture.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
5
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Electrical information
• The refrigerator must be plugged
into its own dedicated 115 Volt, 60
Hz., 15 Amp, AC only electrical outlet.
The power cord of the appliance
is equipped with a three-prong
grounding plug for protection against
electrical shock hazards. It must
be plugged directly into a properly
grounded three prong receptacle.
The receptacle must be installed in
accordance with local codes and
ordinances. Consult a qualifi ed
electrician. Do not use an extension
cord or adapter plug.
• If the power cord is damaged, it
should be replaced by an authorized
service technician to prevent any risk.
• Never unplug the refrigerator by
pulling on the power cord. Always
grip the plug fi rmly, and pull straight
out from the receptacle to prevent
damaging the power cord.
• Unplug the refrigerator before
cleaning and before replacing a light
bulb to avoid electrical shock.
• Performance may be a ected if
the voltage varies by 10% or more.
Operating the refrigerator with
insu cient power can damage the
compressor. Such damage is not
covered under the warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the refrigerator
from being turned o accidentally.
WARNING
When positioning the appliance, ensure
the supply cord is not trapped or
damaged.
WARNING
Do not locate multiple portable socket-
outlets or portable power supplies at
the rear of the appliance.
IMPORTANT SAFETY INFORMATION
6
FEATURES
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.
*Optional Accessory Shown
A Ice and Water Dispenser**
B Custom-Flex
Zone Controls
C Flipper Mullion
D Door Bin
E Fresh Food Ice Maker
F Flip Shelf
G Auto CrispSeal™ Drawers
H Adjustable Hinges
I Reversible Custom-Flex
Zone Slide Shelf with
Wine Rack Feature**
Q Slide-Under Shelf
R Freezer Ice Maker*
S Freezer Slide Shelf
with Ice Container
T Freezer Slide Shelf
U Freezer Drawer
V Dairy Compartment
W Full Width Adjustable
Door Bin
X Fast Adapt Door Bin
Y Fixed Door Bin
J Custom-Flex™
Zone Drawer**
K Anti-tip Leg
L Flipper Mullion Guide
M
PureAir Ultra II
®
Air Filter
N Full Width Shelf
O SnackZone™ Storage
Compartments (Recessed
below Crispers)
P
PureSource Ultra
®
II
Water Filter
JD
D
D
D
D
D
I
I
H H
G G
N
C
E
L
M
P V
Q W
X
O
R
S
T
U
KK
A
B
**Switches between Refrigerator and Freezer
F
Y
7
NOTE
If the refrigerator is placed with the
door hinge side against a wall, allow
additional space so the door can be
opened wider.
INSTALLATION
CAUTION
Do Not install the refrigerator where
the temperature will drop below 55°F
(13°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside
the refrigerator.
This Use & Care Manual provides general
installation and operating instructions for
this model. We recommend using a service
or kitchen contracting professional to
install the refrigerator. Use the refrigerator
only as instructed in this Use & Care
Manual. Before starting the refrigerator,
follow these important fi rst steps.
Location
Tools Necessary:
Phillips Head
or
Quadrex Head
Screwdriver
(OR)
OR
8 mm Socket
Wrench
Adjustable
Wrench
OR
Ǫ Fixed
Wrench
ANDAND
10 mm
Wrench
WARNING
This appliance is intended to be used
in household and similar applications
such as:
• a kitchen/kitchenette
• a pantry room
• a basement
• an enclosed garage
• other interior residential-type
environments
WARNING
Installation
Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top ⅜" (9.5 mm)
Back 1" (25.4 mm)
• Choose a place near a grounded, non-
GFCI, electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher, or other heat sources.
• You must install the refrigerator on a
fl oor level and strong enough to support
a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic
ice maker.
8
NOTE
After adjusting the screw, you might
need to swing the door to check for
proper alignment.
Door opening
Position the refrigerator to allow easy
access to a counter when removing
food. For the best use of refrigerator
drawers and freezer baskets, position the
refrigerator where you can fully open both.
3. Ensure both doors are bind-free with
their seals touching the cabinet on
all 4 sides and the cabinet is stable.
Cabinet Leveling & Refrigerator
Door Alignment (if necessary)
Guidelines for fi nal positioning of refrigerator:
• Firmly rest all 4 corners of the cabinet on
the fl oor.
• Slightly elevate the front to ensure the
doors close and seal properly.
• Align and level the doors with each other.
You can meet most of these conditions by
raising or lowering the adjustable anti-tip legs.
To level the cabinet using the anti-tip legs:
1. Slightly open freezer compartment.
2. Lower anti-tip legs until they are both
touching the fl oor. Use a pair of pliers
to adjust.
Door
Door
12.25 in
8.75 in
1 in
1 in
56.75 in
25.4 mm
.37 in
9.5 mm
.37 in
9.5 mm
To raise unit: turn leg clockwise.
To lower unit: turn leg counterclockwise.
To make fi nal door height adjustments:
1. Open the lower doors to make the
middle hinge visible.
2. Insert the 10 mm wrench (included)
into the shaft of the middle hinge.
To lower door: turn the adjustment
screw clockwise.
To raise door: turn the adjustment
screw counterclockwise.
INSTALLATION
9
INSTALLATION
Bottom Doors Alignment
In a few cases the doors might not align
vertically. To correct this condition a
snap ring shim is supplied with the door
alignment kit (in the literature pack). To
assemble it, lift the lower door slightly to
access the door hinge pin and insert the
snap ring as illustrated.
Flipper Mullion
Adjust the fl ipper mullion for proper
connection with the mullion guide by
ensuring the fl ipper mullion is folded and
perpendicular to the fresh food door. If
the mullion guide is not in the correct
position, it could prevent the door from
closing completely.
WRONG
10
NOTE
Use care while pulling the water tube
from the door to be sure the tube does
not kink. To prevent damage to the
water line, be sure to install the water
line in a protective spring after reinstall-
ing the doors.
NOTE
You will pull approximately 4 ft of water
tube from the refrigerator door.
DOOR REMOVAL
Getting through narrow spaces
If the refrigerator will not fi t through an
entrance area, you can remove the doors.
Check fi rst by measuring the entrance.
To prepare for removing the doors:
1. Make sure you unplug the electrical
power cord from the wall outlet.
2. Remove any food from the door
shelves and close the doors.
To remove the refrigerator doors:
1. Open the doors to 90°.
2. Remove all 4 Phillips
TM
screws from
top hinge cover and lift up.
5. Unscrew the plastic clamps that hold
the cables and tubes and then gently
pull up on the water line to remove
them from door.
3. Trace lightly around the door’s top
hinges with a pencil. This makes
reinstallation easier.
4. Disconnect electrical harnesses
running from door to hinge cover on
both doors.
CAUTION
Be sure to set the doors aside in a
secure position where they cannot fall
and cause personal injury, or damage to
the doors.
11
IMPORTANT
Make sure the water line tubing goes
through the hole at the top of the
dispenser pocket. A metal wrap on the
tubing prevents damage from the hinge
rubbing against it. Fix this back around
the tube in the proper location upon
reinstallation (just as long as the tube is
protected from the hinge).
NOTE
When reinserting the water tube and
replacing the top hinge cover, use care
to be sure the tube does not kink.
1. Remove three 8 mm bolts from both
top hinges. Lift the doors up o the
lower hinges and carefully set aside.
x2
DOOR REMOVAL
Once both doors are in place, ensure
they are aligned with each other and
level (Reference INSTALLATION for more
details), and replace the top hinge cover.
2. To reinstall the doors, reverse
the procedure.
To remove bottom doors
1. Fully open the bottom doors in order
to remove the bottom hinge cover.
2. Remove the screw and the bottom
hinge cover.
3. Disconnect the switch connector
and detach the wires from the guide.
12
DOOR REMOVAL
4. Make sure you removed the top doors.
5. With the bottom doors closed, remove
the center hinge unscrewing the 3
screws fi xing them to the cabinet.
6. Carefully remove the door by
opening it and pushing it upward.
Center Hinge Removal
7. Repeat this procedure for both
bottom doors.
NOTE
To gain access to center hinge, unscrew
the 3 hinge screws and remove the hinge.
8. To reinstall the doors, reverse
the procedure.
13
WATER SUPPLY CONNECTION
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the refrigerator from
electrical power before connecting a
water supply line to the refrigerator.
NOTE
Check with local building authority for
recommendations on water lines and
associated materials prior to installing
refrigerator. Depending on local/state
building codes, we recommend Smart
Choice
®
water line kit 5304437642 with
a 6ft. (1.8 meters) braided Stainless
Steel Water Line for homes with exist-
ing valves. Please refer to
Frigidaire.com for more information.
CAUTION
To Avoid Property Damage:
• We recommend using Copper or
Stainless Steel braided tubing for
the water supply line. We do not
reommend using water supply tubing
made of ¼" plastic. Plastic tubing
greatly increases the potential for
water leaks, and the manufacturer
will not be responsible for any
damage if you use plastic tubing for
the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
water softener can damage the ice
maker. If a water softening system is
present, maintain the softener and
ensure it is working properly.
IMPORTANT
Ensure the water supply line connections
comply with all local plumbing codes.
To install the water supply line, you will
need the following:
• Basic Tools: adjustable wrench,
fl at-blade screwdriver, and Phillips
TM
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100psi.
• A water supply line made of ¼"
(6.4mm) OD, copper or braided
stainless steel tubing. To determine
the length of tubing needed, measure
the distance from the inlet water
tube at the back of the refrigerator
to the cold water pipe. Then add
approximately 7ft (2.1m.), so you
can move the refrigerator
for cleaning.
• A shuto valve to connect the water
supply line to the household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fi tting or
use thread seal tape.
• A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the ice maker
inlet valve.
NOTE
Expect the fi rst ice harvest within fi rst
24hours of unit operation. To prevent any
issues concerning ice production, please
ensure that all water lines are primed. See
Priming the water supply system in the
ICE MAKER section.
IMPORTANT
The refrigerator’s water supply system
includes several tubing lines, a water fi l-
ter, and a water valve. To ensure the wa-
ter dispenser works properly, you must
completely fi ll this system with water
when you fi rst connect the refrigerator
to the household water supply line.
NOTE
The water dispenser has a built-in de-
vice that shuts o the water fl ow after
2 minutes of continuous use. To reset
this shuto device, simply release the
dispenser paddle.
14
WATER SUPPLY CONNECTION
To Connect the Water Tube to
Household Water Supply
1. Disconnect the
refrigerator
from the
electrical
power source.
2. Place the end
of the water
supply line
into a sink
or bucket.
Turn ON the
water supply
and fl ush the
supply line until
the water is
clear. Turn OFF the water supply at
the shuto valve.
3. Open the locking
clips and grab
the water line
coming from
the refrigerator.
Remove the
plastic cap
from the water
inlet fi tting and
discard the cap.
6. Replace the connected tubes into
the clips and lock the clips back
in place to keep the tubing in the
right position.
7. Turn ON the water supply at the
shuto valve and tighten any
connections that leak.
8. Reconnect the refrigerator to an
electrical power source.
9. Turn on the ice maker.
10. Purge air from the ice and water
dispenser system by operating
the water dispenser for 3-4 minutes.
This requires dispensing several
glasses of water.
4. If you use (recommended) stainless
steel braided tubing - the nut and
ferrule are already assembled on
the tubing. Slide the compression
nut onto the water inlet fi tting and
fi nger tighten.
5. Using two ½" wrenches (one to hold
the household water line nut and the
other to hold the water inlet fi tting
nut), tighten a half turn with wrench.
DO NOT overtighten.
Water
inlet
fitting
Plastic
tubing
to
water
valve
6 ft. (1.8 Meters) Stainless
Steel water line from
household water supply line
Connection to Household Water Supply
with 1/4" compression
fitting
Plastic
Cap
Remove
plastic cap
from water
inlet fitting
Water Inlet
Brass
Fitting
¼ inch
plastic tube
to water
valve
To
household
water
supply
To
unit
water valve
Place ½" wrench
here. Do not turn.
Place ½" wrench
here. Turn
clockwise.
15
CONTROLS AND SETTINGS
Awake Mode Display
Awake Mode
To change from sleep mode (on) to awake mode (o ), simultaneously press and hold
Crush and for 5 seconds. The display shows the current temperature/ice maker
status. An audible tone confi rms the selection is set.
Sleep Mode Display
Sleep Mode
As a default, the display goes to sleep after a short time. If you press any icon, the
display awakens. After a short time, it goes back to sleep. When in sleep mode, wake
up the display to confi rm the ice maker is On/O . You can turn sleep mode o to
have the display on full time (awake mode). When sleep mode is O , the display is
always illuminated. To turn sleep mode On/O , simultaneously press and hold Crush
and
for 5 seconds. An audible tone confi rms the selection is set.
NOTE
When the refrigerator temperature is adjusting and the adjusting temperature icon
is on, the sleep mode is disabled until the unit reaches the desired temperature.
16
Appliance Control Display Settings
10
1
2
3
4
5
6
7
98
11 12
13
14
15
16
17
1
Freeze Boost (on/o )
Prior to grocery shopping,
activate Freeze Boost to lower the
temperature and freeze food faster.
Freeze Boost remains active for up
to 12 hours before automatically
deactivating or manually exiting by
pressing Freeze Boost to turn the
function o . This will reset the freezer
to the previous temperature setting.
2
Cold Drink Timer
Quickly chills a drink inside the
freezer compartment. To enable,
touch the Cold Drink Timer key.
A time value will appear on the
freezer temp display (in minutes)
and can be changed using the +/-
buttons. A tone will sound when the
time has been input. Range is from
20-45 minutes in 5 minute intervals.
Drinks will freeze if temperature
setting is too low or timer setting is
too long.
3
Ice Maker On/O
Press and hold for 3 seconds to turn
ice maker on/o . When indicator is
lit, ice maker is on. When ice maker
is OFF, ice maker OFF indicator is
lit. When ice maker is in the OFF
state, it will stop making ice. When
sleep mode is enabled, wake the
display to confi rm ice maker is on/
o (see Sleep Mode). While o , ice
dispensing can continue as long as
there is ice in the bucket. When ice
maker is o and ice is dispensing,
indicator above ice maker button
and ice maker OFF will both blink.
4
The lock button can be used to lock
the display preventing it from being
used in certain situations. Press
and hold for 3 seconds to enable/
disable. While in the locked state,
no changes can be made to settings
on the display. Dispensing ice and
water will be disabled. The indicator
will fl ash and an audible warning
tone is played.
5
Power Outage
In the event of a power failure,
the power outage alert will be
illuminated once power has been
restored and a tone will sound.
Press any button to silence the tone.
WARNING
When using the cold drink timer, be
sure to remove drinks from the freezer
compartment when the alarm sounds.
Carbonated drinks may explode if left
in freezer for too long.
CONTROLS AND SETTINGS
17
CONTROLS AND SETTINGS
7
Door Open illuminates whenever
you open the doors. If you leave a
door open for 5 minutes or more,
an alarm sounds and the display
illuminates until you shut the doors.
Press any button to mute the alarm
temporarily. Check to make sure no
food is blocking the doorway.
8
Replace Water Filter illuminates
every 6 months or when you need
to replace the fi lter. Replace the
fi lter and then press and hold
Reset Water Filter for 3 seconds
to deactivate the warning on the
display. See FILTER REPLACEMENT
for more information.
9
Replace Air Filters illuminates every
6 months or when you need to
replace the fi lter. Replace the fi lter
and then press and hold Reset Air
Filters for 3 seconds to deactivate the
warning on the display. See FILTER
REPLACEMENT for more information.
10
Press Water to select water. An
indicator light illuminates above the
active feature. Press the paddle to
dispense water.
11
Press Cube to select cubed ice. An
indicator light illuminates above the
active feature. Press the paddle to
dispense cubed ice.
12
Press Crush to select crushed ice.
An indicator light illuminates above
the active feature. Press the paddle
to dispense crushed ice.
13
°F/°C
To toggle between Fahrenheit (°F)
and Celsius (°C), simultaneously
press and hold + and — for 5
seconds on the refrigerator side of
the appliance display control.
14
Chill Boost
Prior to grocery shopping,
activate Chill Boost to lower the
temperature and cool food faster.
Chill Boost remains active for up
to 6 hours before automatically
deactivating or manually exiting
by pressing Chill Boost to turn the
function o . This resets the freezer
to the previous temperature setting.
15
Reset Air Filters
After replacing the fi lter, press and
hold for 3 seconds to reset.
16
Reset Water Filter
After replacing the fi lter, press and
hold for 3 seconds to reset.
17
Toggles dispenser light On and
O . Press and hold for 5 seconds
to turn on the ambient lighting,
located under the fresh food doors.
Press and hold again for 2 seconds
to turn this feature o .
NOTE
When in Sleep mode, the display will
not illuminate. Touch any key to wake
the display.
6
Adjusting Temp illuminates when
you press either + or — to change
temperature setting on the
appliance display and will remain
illuminated until the the refrigerator
and freezer reach the desired
temperatures inside.
Freezer temp
Control temperatures range from
-6°F / -21°C to 6°F / -15°C.
Refrigerator temp
Control temperatures range from
34°F / 1°C to 44°F / 7°C. This
unit is designed to operate at
37°F Refrigerator/0°F Freezer.
Temperatures should stabilize within
24 hours of installation.
18
Alarms
Power Outage
In the event of a power failure, the power
outage alert illuminates once power has
been restored and a tone sounds. Press
any button to silence the tone.
Door Open
If you have left a door open for 5 minutes
or more, an alarm sounds and the door
open indicator illuminates on the display.
You can turn o the alarm by closing the
door or pressing any key. The appliance
control display returns to normal opera-
tions after you close the door.
High Temperature
In the event of a high temperature condi-
tion, an alarm sounds. The appliance
control display reads HI on whichever
compartment the alert is detected in and
an alarm sounds over 10 seconds until you
acknowledge the alert. You can turn o
the alarm by closing the door or pressing
any key.
Flapper (Dispenser Models Only)
If the fl apper (or ice chute door) is held
open by a jammed ice cube when you
select Cube or Crush, an alarm sounds
and the current selection blinks on the
dispenser control. The alarm resets when
you remove the ice cube.
NOTE
The unit should stabilize temperatures
within 24 hours of installation.
Air Port
NOTE
The recommended settings for a prod-
uct installed in a kitchen is 37˚F for the
fresh food compartment and 0˚F for
the freezer.
IMPORTANT
If food is freezing in the fresh food
compartment, increase the temperature
setting by 1 or 2 degrees. Wait 24 hours
for temperature to stabilize.
IMPORTANT
Food placed within 1 inch in front of
the air ports may cause food to freeze.
Ensure air ports are not blocked.
Setting Temperatures
CONTROLS AND SETTINGS
19
CONTROLS AND SETTINGS
NOTE
While in Sabbath Mode, neither the
lights, the dispenser, nor the display will
work until you deactivate Sabbath Mode.
The refrigerator stays in Sabbath Mode
after power failure recovery. You must
deactivate it with the buttons on the ap-
pliance control display.
NOTE
Although you have initiated the Sab-
bath Mode, the ice maker complets
the cycle it has already started. The
ice cube compartment remains cold
and you can make new ice cubes with
standard trays.
Sabbath Mode
The Sabbath Mode is a feature that disables
portions of the refrigerator and its controls
in accordance with observance of the
weekly Sabbath and religious holidays
within the Orthodox Jewish community.
Turn Sabbath Mode ON and OFF by
simultaneously pressing and holding both
— (freezer side) and + (refrigerator side) for
5 seconds. Other than the High Temp alarm,
no audible sounds occur until you exit
the Sabbath Mode. The appliance control
display shows Sb while in Sabbath mode.
In the Sabbath Mode, the High Temp alarm
is active for health reasons. For example,
if you leave the door ajar it activates the
High Temp alarm. The refrigerator functions
normally once you close the door, without
any violation of the Sabbath/holidays. The
High Temp alarm sounds when the cabinet
temperature is outside the safe zone for 20
minutes. The alarm silences itself after 10
minutes while High Temp stays lit until you
exit the Sabbath Mode.
For further assistance, guidelines
for proper usage and a complete
list of models with the Sabbath
feature, please visit the web at
star-k.org.
NOTE
You must manually turn o the optional
freezer ice maker to comply with sab-
bath mode.
20
ICE MAKER
NOTE
The water dispenser has a built-in de-
vice that shuts o the water fl ow after
2 minutes of continuous use. To reset
this shuto device, simply release the
dispenser paddle.
CAUTION
We recommend a water supply
pressure between 30psi and 100psi.
The system may malfunction with
excessive pressure.
Ice Maker Operation and Care
After you have properly installed the
refrigerator and it has cooled for several
hours, the ice maker produces ice within
24hours. The ice maker fi lls the ice bin
from the rear. Dispense some ice to force
the ice forward in the bin. This allows the
bin to fi ll completely.
Ice Maker and Storage Bin Capacity
The ice maker should produce 3.2 to 3.7
lbs of ice per 24 hours, depending on the
usage conditions. The fresh food ice bin
holds about 4 lbs of ice.
Turning the Fresh Food Ice
Maker On and O
NOTE
After the initial 26 ounces (750 ml), the
water remains room temperature until
the tank refi lls and has enough time
to chill the next 26 ounces (750 ml) of
water. It may take up to 8 hours to chill.
Using the Ice Maker
After Installation
Before making ice for the fi rst time, be
sure to prime the water supply system. Air
in new plumbing lines can result in 2 or 3
empty ice maker cycles. Furthermore, if you
do not fl ush the system, the fi rst ice cubes
may be discolored or have an odd fl avor.
Priming the Water Supply System
Dispenser
1. Begin fi lling the system by pressing
and holding a drinking glass against
the dispenser.
2. Keep the glass in this position until
water comes out of the dispenser. It
may take about 1 ½ minutes.
3. Continue dispensing water for
3-4 minutes (or after you have
dispensed 1½ gallons) to fl ush the
system and plumbing connection of
any impurities, stopping to empty
the glass as necessary.
IMPORTANT
The ice maker is turned on at the factory
so it can work as soon as you install
the refrigerator. If you cannot connect
a water supply, set the ice maker’s On/
O feature to O ; otherwise, the ice
maker’s fi ll valve may make a loud chat-
tering noise when it attempts to operate
without water.
Ice production is controlled by the ice
maker’s On/O feature on the appliance
control display. Pressing the On/O
feature turns the ice maker on and o .
21
ICE MAKER
IMPORTANT
Occasionally, you may notice unusu-
ally small ice cubes in the bucket or in
dispensed ice. This could occur in nor-
mal operation of the ice maker. If this
happens frequently, it may indicate low
water pressure or the water fi lter needs
to be replaced. As the water fi lter nears
the end of its useful life and becomes
clogged with particles, less water is
delivered to the ice maker during each
cycle. Remember, if it’s been 6 months
or longer or you have dispensed more
than 200 gallons (757 liters) since last
changing the water fi lter, replace it with
a new one. You may have to change the
fi lter more frequently if you have poor
quality household water.
CAUTION
Properly maintain the water supply
to the refrigerator if it is softened.
Chemicals from a water softener can
damage the ice maker.
Ice maker/dispenser tips
If refrigerator is not connected to a water
supply or the water supply is turned o ,
turn o the ice maker as described in the
previous section.
The following sounds are normal when
the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• If you need a large quantity of ice
at one time, it is best to get cubes
directly from the ice bin.
• Ice cubes stored too long may
develop an odd fl avor. Empty the ice
bin as explained below.
• When dispensing cubed ice, it is
normal to have a small quantity
of little pieces along with the
whole cubes.
• To avoid splashing, dispense ice into
the container before adding liquids.
• It is normal for ice to fi ll to the top of
the ice bin.
Cleaning the Ice Bin
Regularly clean the ice maker and ice bin,
especially prior to vacation or moving.
1. Turn o the ice maker.
2. Remove the ice bin by lifting it
upward and pulling it straight out.
3. Empty and carefully clean the ice
bin with mild detergent. Do not use
harsh or abrasive cleaners. Do not
place it in the dishwasher. Rinse with
clear water.
4. Allow the ice bin to dry completely
before replacing it into the
compartment.
5. Replace the ice bin. Turn the ice
maker on.
IMPORTANT
Turning o the ice maker simply dis-
ables ice making. You can still dispense
existing ice and water.
NOTE
The ice maker also has a built-in plastic
signal arm that automatically stops ice
production when the ice bin is full. Do
not use this signal arm to manually stop
the ice maker.
NOTE
We recommend you turn the ice maker
o if you will not use the refrigerator
for an extended period of time.
22
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin and dispenser
mechanism.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
IMPORTANT
When removing or replacing the ice
bin, avoid rotating the auger in the ice
bin. If you accidentally rotate the auger,
realign the auger by turning it in 45°
turns (see below) until the ice bin fi ts
into place with the drive mechanism.
If you do not properly align the auger
when replacing the ice bin, the refrig-
erator will not dispense ice. The fresh
food door also may not close properly
causing warm air to leak into the fresh
food compartment.
Remove and empty the ice bin if:
• An extended power failure (1 hour
or longer) causes ice cubes in the
ice bin to melt and refreeze together
after power is restored, jamming the
dispenser mechanism.
• You use the ice dispenser. Ice cubes
will freeze together in the bin,
jamming the dispenser mechanism.
Removing Ice Bin
(1) Lift
Upward
(2) Pull Bin
Straight Out
Remove the ice bin by (1) lifting upward
and (2) pulling straight out. Then
shake to loosen the cubes or clean as
explained above.
Adjusting Ice Bin Auger
Auger
ICE MAKER
23
ICE MAKER
Ice Maker Operation and Care
After you have properly installed the
refrigerator, the ice maker can produce
ice within 24hours. When using the ice
maker for the fi rst time, and in order
for it to work properly, you need to
clear air from the water tubing and the
fi lter. Furthermore, if you do not fl ush
the system, the fi rst ice cubes may be
discolored or have an odd fl avor. Once
the ice maker begins making ice, allow
the bin to fi ll completely, and then discard
the fi rst FULL bin of ice.
Ice Maker and Storage Bin Capacity
This ice maker should produce between 2
and 2.5 lbs of ice per 24 hours depending
on usage conditions. The ice bin will hold
about 6 lbs of ice.
Turning the Ice Maker On and O
Press or slide the power button to turn
the ice maker on/o . The button and LED
illuminate when active. (A - power button,
B - test button)
varies by model
A
B
A
B
Freezer Ice Maker
(optional accessory)
NOTE
The ice maker will only produce the ad-
vertised production rate if the product
is set at 0°F.
CAUTION
Properly maintain the water supply
to the refrigerator if it is softened.
Chemicals from a water softener can
damage the ice maker.
Ice Maker Tips
• The following sounds are normal
when the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Ice cubes stored too long may
develop an odd fl avor. Empty the
ice bin. (See To remove freezer ice
container: in STORAGE FEATURES).
NOTE
The freezer ice maker fi lls in the center
of the ice bin. Occasionally move the
ice to the borders to allow the bin to fi ll
completely.
Ordering Optional Freezer
Ice Maker
Order the optional freezer ice maker at
Frigidaire.com, by calling 1-800-374- 4432
or through the dealer from which you
purchased the refrigerator.
24
STORAGE FEATURES
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to
sudden temperature change. Allow
the glass shelves to stabilize to room
temperature before cleaning. Do not
wash in the dishwasher.
You can easliy adjust shelf positions in
the fresh food compartments as needed.
The shelves have mounting brackets that
attach to slotted supports at the rear of
each compartment.
Change the Position of a Shelf
1. Remove all food from the shelf.
2. Lift the front edge up and pull the
shelf out.
3. Replace by inserting the mounting
bracket hooks into the desired
support slots.
4. Lower the shelf and lock it
into position.
To adjust the fl ip shelf:
1. Remove food from the shelf.
2. Lift the right side edge of the shelf
upward and push to the left toward
the ice maker.
Flip Shelf
Drawers
The refrigerator includes a variety of
storage drawers.
Auto CrispSeal Drawer
Crispers are designed for storing fruits,
vegetables, and other fresh produce.
Crispers have an auto humidity control
at the rear of each crisper under the
humidity control cover.
To remove the auto humidity control
membrane for cleaning:
1. Reach to back of the humidity
control cover.
2. Place fi ngers between the humidity
control and the back wall, pulling up
on the cover.
3. Pull the cover toward the front of
the cabinet and remove.
4. Remove the humidity membrane
from the housing by lifting it up and
sliding it over.
5. Clean the humidity membrane with
hot soapy water. Thoroughly dry it
before replacing.
6. Replace the membrane in the
housing and unit by reversing the
steps above.
Slide-Under Shelf
To adjust the slide-under shelf:
Push the front half
shelf backward
toward the rear of
the cabinet until
the rear half shelf
drops down. Then
gently continue
pushing the front
half shelf back and under the rear half shelf.
25
STORAGE FEATURES
Removing Auto CrispSeal Drawer
Removing Auto Humidity
Control Membrane
Opening SnackZone
Recessed Snack Drawers
SnackZone - Recessed Snack Drawers
These drawers are ideal for storing deli
meats and cheeses.
To open: slide back the cover to allow
access to the drawers.
To remove the Auto CrispSeal drawer
for cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove
the drawer.
NOTE
We do not recommend replacing the
auto-humidity membrane unless it
becomes damaged or ruined. If the
membrane becomes soiled, you can
wash it with soap and water. Ensure the
membrane is dry before replacing it in
the unit.
26
IMPORTANT
Do not use the Custom-Flex Zone to store fresh pro-
duce as these items may freeze and cause damage to
the fruits and leafy vegetables stored in the drawer.
CAUTION
Do not store glass bottles in the Custom-Flex Zone
when the temperature setting is in Freezer, Meat/
Seafood, or Cold Drink modes. The glass may
break and shatter, causing physical harm and injury.
1
2
3
4
5
6
Using Your Custom-Flex Zone Controls
1
The Custom-Flex Zone automatically defaults to a locked state to prevent any
unwanted use. To change the Custom-Flex Zone’s settings, you must fi rst unlock
it. To unlock, press and hold UNLOCK for 3 seconds. It automatically locks after
10 seconds without any interaction.
Refrigerator:
2
Choosing Chilled Wine sets the zone temperature to 45°F (7°C). A tone sounds
to confi rm choice.
3
Choosing Deli/Snacks sets the zone temperature to 37°F (3°C). A tone sounds
to confi rm choice.
4
Choosing Cold Drinks sets the zone temperature to 32°F (0°C). A tone sounds
to confi rm choice.
5
Choosing Meat/Seafood sets the drawer temperature to 28°F (-2°C). A tone
sounds to confi rm choice. Use this setting for short-term storage. Place any meat
to be kept longer than 2 days in the freezer.
Freezer:
6
To change the Custom-Flex Zone temperature when in the freezer temp setting,
use the appliance control display on the front door. Changing the temp on the
display changes both the Custom-Flex Zone AND the freezer temp settings.
NOTE
Temp Adjust stays lit until reaching the new set temp.
Custom-Flex Zone
You can adjust the Custom-Flex Temp Zone from
-6° F to 45° F, giving you versatility and control of
your appliance.
STORAGE FEATURES
27
STORAGE FEATURES
Custom-Flex Zone
To remove Custom Flex-Zone shelves
and drawers:
1. Open doors completely to gain
access to shelves/drawers.
2. Pull the shelf/drawer to the stopper.
Lift the shelf/drawer up and pull it to
remove it from the cabinet.
3. Reverse the steps to reinstall the
shelf/drawer.
You can mount the middle drawers in
the freezer and Flex-Zone in up to 3
height positions and can also invert them
90° allowing bottles to be stored in the
Flex-Zone.
Shelves in 3 Height Positions and Inverted
Possible Shelf Confi guration Example
To remove the Wine Rack Mat:
1. Unhook the rack from the shelf.
2. Pivot as shown in the image and
remove the silicone mat.
IMPORTANT
You can remove and clean the Wine
Rack Mat with tap water.
IMPORTANT
The Wine Rack Mat helps to keep the
bottles from sliding o when opening
the Custom-Flex Zone drawers.
28
Adjustable Door Bins
Doors
Storage bins
The doors use a system of modular
storage bins. You can remove all of these
bins for easy cleaning. Adjust the bins
as needed.
Use the door bins to store jars, bottles,
cans, and large drink containers. You can
also quickly select frequently used items.
Adjustable door bins
Move the adjustable door bins to suit
individual needs.
To adjust the collapsible door bin:
1. Make sure the bin is securely seated
on rail in the door.
2. Grab one side of the bin and place the
other hand on the adjustable side.
3. Pull on the side of the bin until the
bin is adjusted to the desired width.
To move the door bin side to side:
1. Tilt the bin up so the back of the
bin is o the door but the hook is
still engaged.
2. Slide the bin along the rail to the
desired position.
3. Lower the bin back into place.
To move the door bin up or down:
1. Lift the bin up disengaging the hook.
2. Move the bin to the desired
rail location.
3. Push the bin hook into the rail
engaging the hook.
STORAGE FEATURES
29
STORAGE FEATURES
IMPORTANT
Make sure all the wheels on the back of
the shelves are aligned on their respec-
tive tracks for proper function. If the
shelf is not aligned properly, the door
will not operate properly.
IMPORTANT
If you do not correctly assemble the ice
container with the slider shelf, it will not
close properly and may damage the
freezer ice maker. Check to make sure
door closes properly after removing the
ice container. If you leave a door ajar,
frosting or condensation may collect in
the freezer.
To remove freezer ice container:
1. Open the doors completely to gain
access to the drawers.
2. Pull the freezer drawer to its most
forward position.
3. Lift up the front side of the ice
container and pull it out of the
drawer.
4. Allow the ice container to dry
completely before replacing it in the
freezer. Reverse the steps to reinstall
the ice container.
30
STORING FOOD AND SAVING ENERGY
Ideas for storing foods
Fresh food storage
• Keep the fresh food compartment
between 34°F and 44°F with an optimum
temperature of 37°F.
• Avoid overcrowding the refrigerator
shelves, which reduces air circulation and
causes uneven cooling.
• Avoid placing food in front of air ports.
(See CONTROLS AND SETTINGS.)
Fruits and vegetables
• Store fruits and vegetables in crispers,
where trapped moisture helps preserve
food quality for longer time periods.
• Do not wash items until you are ready to
use them. Remove excess water before
placing them inside the unit.
• Wrap any items with strong odors or high
moisture content.
Meat
• Wrap raw meat and poultry separately
and securely to prevent leaks and
contamination of other foods or surfaces.
• Use the Custom-Flex Temp Zone to store
meat/poultry for short-term storage.
Freeze any meat to be kept longer than
2 days.
Frozen food storage
• Keep the freezer compartment at 0°F
or lower.
• A freezer operates most e ciently when
it is at least ⅔ full.
Packaging foods for freezing
• To minimize food dehydration and
quality deterioration, use aluminum foil,
freezer wrap, freezer bags, or airtight
containers. Force as much air out of
the packages as possible and seal them
tightly. Trapped air can cause food to
dry out, change color, and develop an o
fl avor (freezer burn).
• Wrap fresh meats and poultry with
suitable freezer wrap prior to freezing.
• Do not refreeze meat that has
completely thawed.
Loading the freezer
• Prior to grocery shopping, activate
Freeze Boost so newly purchased
food designated for the freezer will be
preserved as quickly as possible.
• Activating Freeze Boost also will help
the freezer more e ciently maintain the
selected temperature after placing new
purchases with pre-existing frozen foods.
• Avoid adding too much warm food to
the freezer at one time. This overloads
the freezer, slows the rate of freezing,
and can raise the temperature of
frozen foods.
• Leave a space between packages, so cold
air can circulate freely, allowing food to
freeze as quickly as possible.
Ideas for saving energy
Installation
• Locate the refrigerator in the coolest part
of the room, out of direct sunlight, and
away from heating ducts or registers.
• Do not place the refrigerator next to
heat-producing appliances such as a
range, oven, or dishwasher. If this is not
possible, a section of cabinetry or an
added layer of insulation between the
2 appliances will help the refrigerator
operate more e ciently.
• Level the refrigerator so the doors
close tightly.
Temperature settings
• Refer to CONTROLS AND SETTINGS for
procedures on temperature settings.
Food storage
• Avoid overcrowding the refrigerator or
blocking cold air vents. Doing so causes
the refrigerator to run longer and use
more energy.
• Cover foods and wipe containers dry
before placing them in the refrigerator.
This cuts down on moisture build-up
inside the unit.
• Organize the refrigerator to reduce door
openings. Remove as many items as
needed at one time and close the door as
soon as possible.
• Do not place a hot container directly
on a cold shelf. Remember, such an
extreme temperature change may
damage the glass.
31
NORMAL OPERATING SOUNDS
Understanding the Sounds
Coming from the Refrigerator
High-e ciency refrigerators may
introduce unfamiliar sounds. These
sounds normally indicate you are correctly
operating the refrigerator. Some surfaces
on fl oors, walls, and kitchen cabinets may
make these sounds more noticeable.
The following is a list of major
components in the refrigerator and the
sounds they can cause:
A Evaporators Refrigerant through the
evaporators may create a boiling or
gurgling sound.
B Evaporator fans Sounds of air being
forced through the refrigerator by
the evaporator fans may be heard.
C Defrost heaters During defrost
cycles, water dripping onto the
defrost heaters may cause a hissing
or sizzling sound. After defrosting, a
popping sound may occur.
D Automatic ice maker When ice has
been produced, sounds of ice cubes
falling into the ice bin may be heard.
Ice maker fan, water valve activation,
and refrigerant gas fl uid may create
sounds from its operation.
E Electronic control & automatic
defrost control These parts can
produce a snapping or clicking sound
when turning the cooling system on
and o .
F Condenser fan Sounds of air being
forced through the condenser may
be heard.
G Compressor Modern, high-e ciency
compressors run much faster than
previous models. The compressor
may have a noticeable hum or
pulsating sound during operation.
H Water valves Make a buzzing
sound each time they open to fi ll
the ice maker.
I Drain pan (not removable) Sounds
of water dripping into the drain pan
during the defrost cycle may be heard.
J Condenser May create minimal
sounds from forced air.
G
L
K Motorized damper May produce a
light humming during operation.
L Ice dispenser When dispensing ice, a
snapping, clicking, or popping sound
may be heard.
NOTE
Energy e cient foam in the refrigerator
is not a sound insulator.
NOTE
During automatic defrost cycle, a red
glow in the back wall vents of the
freezer compartment is normal.
32
FILTER REPLACEMENT
Do not use with water that is
microbiologically unsafe or of unknown
quality without adequate disinfection
before or after the system. Systems
certifi ed for cyst reduction may be used
on disinfected waters that may contain
fi lterable cysts.
Test & certifi cation results:
• Rated Capacity - 125 gallons/473 L
for PureSource Ultra II ice and
water fi lter
• Rated service fl ow - .65 gallons
per minute
• Operating Temp: Min. 33°F, Max.
100°F
• Maximum Rated Pressure - 100 lbs/in
2
• Recommended Minimum Operating
Pressure: 30lbs/in
2
More about the Advanced Water Filter
Certifi ed by IAPMO R&T against NSF/ANSI
Standards 42, 53, 401, CSA B483.1 and
NSF/ANSI/CAN 372 in PureSource Ultra II
systems for reduction of the claims on the
Performance Data Sheet*.
*Find the
Performance Data Sheet
located in the Guides and Manuals
section for your specifi c water fi lter on
Frigidaire.com.
PureSource Ultra II Water Filter
If you have not used the refrigerator
for a period of time (during moving
for example), change the fi lter before
reinstalling the refrigerator. Order
replacement fi lters online at Frigidaire.
com, by calling 1 (800) 374-4432
or through the dealer from which
the refrigerator was purchased. We
recommend replacing fi lters at least once
every 6 months.
Here is the product number to request
when ordering:
PureSource Ultra II™ Water Filter
EPTWFU01
The refrigerator is equipped with a water
fi ltering system. This system fi lters all
dispensed drinking water, as well as the
water used to produce ice. The water
fi lter is located at the top right side of the
fresh food compartment.
Change the water fi lter every 6 months to
ensure the highest possible water quality.
Replace Water Filter on the appliance
control display indicates when to replace
the fi lter after a standard amount of water
(125 gallons/473 L for PureSource UltraII)
has fl owed through the system.
Removing and replacing your water fi lter
To Remove: Pull the cover forward and
the cover will drop down and allow access
to the fi lter.
To Reinstall: Push the cover up toward
the liner, and then push toward the rear of
the cabinet. The fi lter cover will snap back
into place.
NOTE
When ordering replacement fi lters,
please reorder the same fi lter type that
is currently in the refrigerator.
33
PureAir Ultra II Air Filter
To ensure optimal fi ltering of refrigerator
odors, change the air fi lter every 6
months (Replace Air Filter on the
appliance control display indicates
replacing the fi lter after 6 months).
Ordering your replacement air fi lter
To order replacement fi lters, please visit
our online store at Frigidaire.com, by
calling toll-free at 1 (800) 372-4432, or by
visiting the dealer where you purchased
your unit. We recommend replacing fi lters
at least once every 6 months.
Here is the product number to request
when ordering:
PureAir Ultra II™ Air Filter PAULTRA2
Replacing your air fi lter
The air fi lter is located in the top center of
the fresh food compartment.
FILTER REPLACEMENT
It is not necessary to turn the water
supply o to change the fi lter. Be ready
to wipe up any small amounts of water
released during the fi lter replacement.
(Instructional video of procedure can be
found on Frigidaire.com.)
1. Pull forward and then push down on
front edge of fi lter cover. Cover will
tilt down and expose water fi lter.
2. Remove the old fi lter by rotating it
counterclockwise (to the left) 90
degrees to release it.
3. Slide the old fi lter cartridge straight
out of the housing and discard it.
4. Unpackage the new fi lter cartridge
and remove any protective caps
from fi lter before installing. Slide it
into the fi lter housing as far as it will
go with the grip end vertical.
5. Push lightly inward on the fi lter
while rotating it clockwise (to the
right). The fi lter will then pull itself
inward as it is rotated. Rotate the
fi lter 90 degrees until it stops and
the grip end is horizontal. A very
light click may be heard as the fi lter
locks into place.
6. Press a drinking glass against the
water dispenser while checking for
any leaks at the fi lter housing. Any
spurts and sputters that occur as
the system purges air out of the
dispenser system are normal.
7. Continue dispensing water for
3-4 minutes. It may be necessary
to empty and refi ll the container
several times.
8. To reset fi lter alert, press and hold
the Reset Water Filter on the
display for 3 seconds. Tone will
sound once it has been reset.
9. Replace fi lter cover by pushing up
and snapping into place.
1. Remove the air fi lter cover by
squeezing the top and bottom of
the cover together and removing it
from liner.
2. Remove the old fi lter and discard it.
3. Unpack the new fi lter and snap it into
the fi lter cover. You should install the
open face (carbon media) of the fi lter
facing outward in the cover.
4. Replace the air fi lter cover by
squeezing the sides and snapping it
back into place.
5. Press and hold Reset Air Filters on
the appliance control display for 3
seconds. When the indicator turns
o , you have reset the status.
34
IMPORTANT
When storing or moving refrigerator in freezing temperatures, be sure to completely drain
the water supply system. Failure to do so could result in water leaks when the refrigerator is
put back into service. Contact a service representative to perform this operation.
CAUTION
• Pull the refrigerator straight out to move it. Shifting it from side to side may damage
fl ooring. Be careful not to move the refrigerator beyond the plumbing connections.
• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces with wet or
damp hands.
CARE AND CLEANING
Care and Cleaning Tips
Keeping the refrigerator clean maintains its appearance and prevents odor build-up. Wipe up
any spills immediately and clean the freezer and fresh food compartments at least twice a year.
• Always unplug the electrical power cord from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do not use razor blades or other sharp instruments
which can scratch the appliance surface.
• Do not remove the serial plate. Removal of the serial plate voids the warranty.
• Before moving refrigerator, raise the anti-tip brackets so the rollers will work correctly. This
will prevent the fl oor from being damaged.
Refer to the guide on the next page for details on caring and cleaning specifi c areas
of refrigerator.
• Never use metallic scouring pads, brushes, abrasive cleaners, or strong alkaline solutions
on any surface.
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
NOTE
Do not use abrasive cleaners such as window sprays, scouring cleansers, fl ammable fl uids,
cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum prod-
ucts on plastic parts, interior doors, gaskets, or cabinet liners. Do not use scouring pads or
other abrasive cleaning materials.
NOTE
When setting temperature controls to turn o cooling, power to lights and other electrical
components will continue until the power cord is unplugged from the wall outlet.
35
Vacation and moving tips
Occasion Tips
Short
Vacations
• Leave refrigerator operating during vacations of 3 weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn automatic ice maker o and empty ice bucket, even if only away a few days
.
Long
Vacations
• Remove all food and ice if leaving for one month or more.
• Turn the cooling system o (see CONTROLS AND SETTINGS for the location of
On/O ) and disconnect the power cord.
• Turn the water supply valve to closed.
• Clean the interior thoroughly.
• Leave both doors open to prevent odors and mold build-up. Block the doors
open if necessary.
Moving
• Unplug the unit.
• Remove all food and ice.
• If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching the surface.
CARE AND CLEANING
Care & Cleaning Tips
Part What To Use Tips and Precautions
Interior &
Door Liners
• Soap and water
• Baking soda and water
Use two tablespoons of baking soda in one quart
of warm water. Be sure to wring excess water
out of sponge or cloth before cleaning around
controls, light bulb or any electrical part.
Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.
Drawers & Bins • Soap and water Use a soft cloth to clean drawer runners
and tracks.
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature
before immersing in warm water.
Exterior &
Handles
• Soap and water
• Non Abrasive
Glass Cleaner
Do not use commercial household cleaners
containing ammonia, bleach or alcohol to
clean handles. Use a soft cloth to clean smooth
handles or exterior. DO NOT use a dry cloth to
clean smooth doors.
Exterior &
Handles
(Stainless Steel
Models Only)
• Soap and water
• Stainless Steel
Cleaners
Never use CHLORIDE or cleaners with bleach
to clean stainless steel.
Clean stainless steel front and handles with
non-abrasive soapy water and a dishcloth.
Rinse with clean water and a soft cloth. Use
a non-abrasive stainless steel cleaner. These
cleaners can be purchased at most home
improvement or major department stores.
Always follow manufacturer’s instructions.
Do not use household cleaners containing
ammonia or bleach.
NOTE: Always clean, wipe and dry with the
grain to prevent scratching. Wash the rest of
the cabinet with warm water and mild liquid
detergent. Rinse well, and wipe dry with
a clean soft cloth. Stainless steel cleaning
supplies can be purchased from Frigidaire.com
36
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
TROUBLESHOOTING
Concern Potential Cause Common Solution
Automatic Ice Maker
Ice maker is
not making
any ice.
• Ice maker is turned o .
• Refrigerator is not
connected to water line
or water valve is not
open.
• The water supply line is
kinked.
• The water fi lter is not
seated properly.
• The water fi lter may be
clogged with foreign
material.
• Refer to Ice Maker and Controls and
Settings.
Fresh Food Ice Maker: Press and
hold the ice maker button on the
appliance control for 3 seconds
to turn the ice maker on. The LED
indicator illuminates to indicate the
ice maker is on.
Freezer Ice Maker: Press or slide the
power button to turn the ice maker
on. The button and LED illuminate
when active.
• Connect the unit to the household
water supply and ensure the water
valve is open.
• Ensure that the supply line does not
kink when the refrigerator is pushed
into place against the wall.
• Remove and re-install the water
fi lter. Be sure to seat it fully into the
locked position.
• If water dispenses slowly or not at
all, or if the fi lter is six months old or
older, it should be replaced.
Ice maker is
not making
enough ice.
• Ice maker is producing
less ice than expected.
• The water fi lter may be
clogged with foreign
material.
• The water supply line is
kinked.
• Water pressure is
extremely low. Cut-o
and cut-on pressures are
too low (well systems
only).
• Reverse osmosis system
is in regenerative phase.
• The fresh food ice maker will
produce approximately 3.2 to
3.7 pounds of ice every 24 hours
depending on usage conditions. The
freezer ice maker will produce 2 to
2.5 pounds of ice every 24 hours
depending on usage conditions.
• If water dispenses slower than
normal, or if the fi lter is six months
old or older, it should be replaced.
• Ensure that the supply line does not
kink when the refrigerator is pushed
into place against the wall.
• Have someone turn up the cut-o
and cut-on pressure on the water
pump system (well systems only).
• It is normal for a reverse osmosis
system to be below 20 psi during
the regenerative phase.
37
TROUBLESHOOTING
Concern Potential Cause Common Solution
Automatic Ice Maker (continued)
Ice cubes
are freezing
together.
• Ice cubes are not being
used frequently enough
or interruption of power
for prolonged time.
• Ice cubes are hollow
(shells of ice with water
inside). The hollow
cubes break open in
the bin and leak their
water onto existing ice,
which causes it to freeze
together.
• Remove ice container and discard ice.
The ice maker will produce fresh supply.
Ice should be used at least twice weekly
to keep the cubes separated.
• This generally occurs when the
ice maker does not get enough
water. This is usually the result of
a clogged water fi lter or restricted
water supply. Replace the water
fi lter and if the condition still occurs,
check to see if the water valve is not
turned on all the way or if there is a
kinked water supply line.
Dispenser (Ice & Water)
Dispenser
will not
dispense
ice.
• There is no ice in the bin
to be dispensed.
• The refrigerator doors
are not completely
closed.
• Dispenser paddle has
been pressed too long
and the dispenser motor
has overheated.
• See the Ice maker is not making
any ice.
• Be sure the refrigerator doors are
completely closed.
• The motor overload protector will
reset in about three minutes and
then ice can be dispensed.
Ice
dispenser is
jammed.
• Ice has melted and
frozen around auger
due to infrequent
use, temperature
fl uctuations, and/or
power outages.
• Ice cubes are jammed
between ice maker and
back of ice container.
• Remove ice container, thaw,
and empty the contents. Clean
container, wipe dry, and replace in
proper position. When new ice is
made, dispenser should operate.
• Remove ice cubes that are jamming
the dispenser.
Dispenser
will not
dispense
water.
• Water fi lter not seated
properly.
• Water fi lter is clogged.
• Household water line
valve is not open.
• Remove and reinstall the water fi lter.
For PureSource Ultra II, be sure to
rotate it to the right until it stops
and the grip end is vertical.
• Replace fi lter cartridge. Be sure to
rotate it to the right until it stops
and the grip end is vertical.
• Open household water line valve.
See CONCERN column under
Automatic Ice Maker.
38
Concern Potential Cause Common Solution
Dispenser (Ice & Water) (continued)
Water
not cold
enough.
• As warmer tap water
goes through the
fi lter and enters the
water supply system,
the chilled water is
pushed through to the
dispenser. Once the
chilled water is used up,
it will take several hours
to bring the freshly
replaced water to a
cooler temperature.
• Add ice to cup or container before
dispensing water.
Note: Only fi rst 26 ounces are chilled.
Water has
an odd
taste and/or
odor.
• Water has not been
dispensed for an
extended period of time.
• Unit not properly
connected to cold
water line.
• Filter needs to
be replaced.
• Draw and discard 10-12 glasses of
water to freshen the supply.
• Connect unit to cold water line that
supplies water to the kitchen faucet.
• Replace water fi lter per instructions
in this manual.
Opening/Closing Of Doors/Drawers
Door(s) will
not close.
• Door was closed too
hard, causing other door
to open slightly.
• Refrigerator is not level.
It rocks on the fl oor
when moved slightly.
• Refrigerator is touching
a wall or cabinet.
• Food/packaging is
obstructing the door
from closing.
• Flipper mullion on left
fresh food door is not in
the correct position.
• Close both doors gently.
• Adjust leveling legs. Ensure fl oor is
level and solid, and can adequately
support the refrigerator. Contact a
carpenter to correct a sagging or
sloping fl oor.
• Ensure fl oor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping fl oor.
• Make sure there is no food/
packaging blocking the doorway.
• Ensure the fl ipper mullion is in
the correct position to allow the
door to close. See Flipper Mullion
in INSTALLATION.
Drawers are
di cult to
move.
• Food is touching shelf
on top of drawer.
• Track that drawers slide
on is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly installed
on track.
• Clean drawer, rollers, and track. See
CARE AND CLEANING.
TROUBLESHOOTING
39
TROUBLESHOOTING
Concern Potential Cause Common Solution
Running of Refrigerator
Compressor
does not
run.
• Refrigerator is in defrost
cycle.
• Plug at electrical outlet
is disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• This is normal for a fully automatic
defrost refrigerator. The defrost
cycle occurs periodically, lasting
about 30 minutes.
• Ensure plug is tightly pushed into
outlet.
• Check/replace fuse with a 15 amp
time-delay fuse. Reset circuit
breaker.
• Check house lights. Call local
electric company.
Refrigerator
seems to
run too
much or too
long.
• The variable speed
compressor is designed
to run 100% of the
time except during the
defrost cycle. At times
it will run faster, such as
after a defrost cycle.
• It is normal for the compressor to
run continuously except during
defrost mode.
Digital Temperature Setting Display
Digital
temperature
displays an
error.
• Electronic control
system has detected a
performance problem.
• Contact Electrolux Customer Care
for assistance with any errors or
codes fl ashing in the display by
calling 1-800-374-4432.
Water/Moisture/Frost Inside Refrigerator
Moisture
collects on
inside of
refrigerator
walls.
• Weather is hot and
humid.
• Flipper mullion
• The rate of frost buildup and
internal sweating increases.
• Adjust fl ipper mullion. (See Flipper
Mullion in INSTALLATION.)
Water
collects on
bottom side
of drawer
cover.
• Vegetables contain and
give o moisture.
• It is not unusual to have moisture on
the bottom side of the cover.
• Both crispers contain an automatic
humidity control, which should
adjust automatically to the varying
levels of moisture inside the
drawer without creating additional
condensation or drying out the air
inside the crisper drawer, works with
various types of produce. If excess
moisture is noticed, check to verify
humidity membrane is not damaged
and replace as necessary.
Water
collects in
bottom of
drawer.
• Washed vegetables and
fruit drain while in the
drawer.
• Dry items before putting them in
the drawer. Water collecting in
bottom of drawer is normal.
40
TROUBLESHOOTING
Concern Potential Cause Common Solution
Water/Moisture/Frost Outside Refrigerator
Moisture
collects on
outside of
refrigerator
or between
doors.
• Weather is humid. • This is normal in humid weather.
When humidity is lower, the
moisture should disappear.
Food/Drinks in Fresh Food Compartment/Custom-Flex Drawer
Food is
freezing.
• Temperature setting is
too low.
• Temperature sensor is
covered by food (right
side of fresh food area).
• Food is covering the
air ports.
• Move the setting to a higher degree.
• Allow space for air fl ow to
the sensor.
• Allow space between the air ports
and the food.
41
LIMITED WARRANTY
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Your appliance is covered by a one year limited warranty. For one year from your date
of delivery, Electrolux will pay all costs for repairing or replacing any parts of this
appliance that prove to be defective in materials or workmanship when such appliance
is installed, used and maintained in accordance with the provided instructions.
Exclusions
If You Need Service
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot
be readily determined.
2. Product that has been transferred from its original owner to another party or
removed outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any Appliance or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or
workmanship, or for appliances not in ordinary household use or used other than
in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to
use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of
trim, cupboards, shelves, etc., which are not a part of the appliance when it is
shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air fi lters, water fi lters,
other consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday
service calls, tolls, ferry trip charges, or mileage expense for service calls to
remote areas, including the state of Alaska.
12. Damages to the fi nish of appliance or home incurred during installation, including
but not limited to fl oors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use
of parts other than genuine Electrolux parts or parts obtained from persons other
than authorized service companies; or external causes such as abuse, misuse,
inadequate power supply, accidents, fi res, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY
SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN.
CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS
THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES
RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR
ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE.
This warranty only applies in the USA and Canada. In the USA, your appliance is
warranted by Electrolux Major Appliances North America, a division of Electrolux
Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada
Corp. Electrolux authorizes no person to change or add to any obligations under this
warranty. Obligations for service and parts under this warranty must be performed
by Electrolux or an authorized service company. Product features or specifi cations as
described or illustrated are subject to change without notice.
Keep your receipt, delivery slip, or some other appropriate payment record to
establish the warranty period should service be required. If service is performed, it is
in your best interest to obtain and keep all receipts. Service under this warranty must
be obtained by contacting Electrolux at the addresses or phone numbers below.
Frigidaire.com
1-800-374-4432
Frigidaire.ca
1-800-265-8352
owner support
accessories
service
Our home is your home. Visit us if you
need help with any of these things:
registration
(See your registration card
for more information.)
welcome home
