REFRIGERATOR
A21785802 (April 2021)
Introduction .......................................................2
Important Safety information.....................3
Features ..............................................................6
Installation .........................................................7
Door Removal ...................................................9
Door Handle Installation .............................. 11
Water Supply Connection .......................... 12
controls and settings ................................... 14
Ice Maker .......................................................... 17
Storage Features ........................................... 18
Storing Food and Saving Energy ...........20
Normal Operating Sounds ......................... 21
Filter replacement ........................................ 22
Care and Cleaning .......................................24
Troubleshooting .......................................... 26
Limited Warranty ......................................... 29
2
INTRODUCTION
Welcome to our
family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number ____________________
Serial Number ____________________
Purchase Date ____________________
Serial Number Location
Doors
Handles are secure and tight
Door seals completely to cabinet on
all sides
Leveling
Refrigerator is level side-to-side and
slightly elevated in front to assist
with door and drawer closing (front
should be higher than back)
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected
to refrigerator (Warning: Potable
water supply only.)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Final Checks
Shipping material removed
Fresh food and freezer
temperatures set
Registration card sent in
Installation Checklist
3
IMPORTANT SAFETY INFORMATION
WARNING
WARNING indicates a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
WARNING
Please read all instructions before using
this appliance.
Child Safety
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
Destroy or recycle the carton, plastic
bags, and any exterior wrapping mate-
rial immediately after the refrigerator is
unpacked. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be re-
paired only by trained service person-
nel. Use only manufacturer-authorized
service parts. Any repair equipment
used must be designed for flammable
refrigerants. Follow all manufacturer
repair instructions. Do not puncture
refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
4
WARNING
These guidelines must be followed to
ensure that safety mechanisms in this
appliance will operate properly.
Electrical information
• Plug the appliance into its own ded-
icated 115 Volt, 60 Hz., 15 Amp, AC
only electrical outlet. The power cord
of the appliance is equipped with a
3-prong grounding plug for your pro-
tection against electrical shock haz-
ards. Plug it directly into a properly
grounded 3-prong receptacle. Install
the receptacle in accordance with
local codes and ordinances. Consult a
qualified electrician. Avoid connect-
ing the appliance to a Ground Fault
Interrupter (GFI) circuit. Do not use
an extension cord or adapter plug.
• If the power cord is damaged, an
authorized service technician should
replace it to prevent any risk.
• Never unplug the appliance by pull-
ing on the power cord. Always grip
the plug firmly, and pull straight out
from the receptacle to prevent dam-
aging the power cord.
• Unplug the appliance before cleaning
to avoid electrical shock.
• Performance may be aected if the
voltage varies by 10% or more. Oper-
ating the appliance with insucient
power can damage the compressor.
Such damage is not covered under
your warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the appliance
from being turned o accidentally.
Proper Disposal of your Appliance
Risk of child entrapment
Child entrapment and suocation are not
problems of the past. Junked or aban-
doned appliances are still dangerous –
even if they will sit for “just a few days”. If
you are getting rid of your old appliance,
please follow the instructions below to
help prevent accidents.
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with your utility company or visit ener-
gystar.gov/products/recycle for more infor-
mation on recycling your old appliance.
Before you throw away
your old appliance:
• Remove door.
• Leave shelves in
place so children
may not easily
climb inside.
• Have refrigerant
removed by a
qualified service technician.
IMPORTANT SAFETY INFORMATION
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquid within or in the
vicinity of this appliance. Read Product
Label for warnings regarding flamma-
bility and other hazards.
• DO NOT store explosive substances
such as aerosol cans with a flammable
propellant in this appliance.
• DO NOT operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
with other appliances or furniture.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
5
IMPORTANT
CFC/HCFC Disposal
Your old appliance may have a cooling
system that used CFCs or HCFCs (chlo-
rofluorocarbons or hydrochlorofluoro-
carbons). CFCs and HCFCs are believed
to harm stratospheric ozone if released
to the atmosphere. Other refrigerants
may also cause harm to the environ-
ment if released to the atmosphere.
If you are throwing away your old
appliance, make sure the refrigerant
is removed for proper disposal by a
qualified technician. If you intentionally
release refrigerant, you may be subject
to fines and imprisonment under provi-
sions of environmental legislation.
IMPORTANT
To turn o power to your appliance you
must unplug the power cord from the
electrical outlet.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
IMPORTANT SAFETY INFORMATION
6
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.
FEATURES
*Features may vary according to model
A Anti-Tip Legs
B Ice Maker
C Adjustable Hinges
D Door Bins
E Adjustable Door Bins
F Flipper Mullion
G Water Filter
H Flipper Guide
I Air Filter
J Spillsafe
®
Shelves
K CrispSeal™ Drawers
L Freezer Drawer
M Middle Freezer Drawer
N Freezer Basket
A
C
D
F
G
H
I
B
J
E
D
M
L
A
J
K
E
N
7
This Use & Care Manual provides general
installation and operating instructions for
this model. We recommend using a ser-
vice or kitchen contracting professional to
install the refrigerator. Use the appliance
only as instructed in this Use & Care Man-
ual. Before starting the appliance, follow
these important first steps.
Location
• Choose a place that is near a ground-
ed, non-GFCI, electrical outlet. Do
Not use an extension cord or an
adapter plug.
• If possible, place the appliance out of
direct sunlight and away from the range,
dishwasher, or other heat sources.
• The appliance must be installed on a
floor that is level and strong enough
to support a fully loaded appliance.
• Consider water supply availability for
models equipped with an automatic
ice maker.
Door opening
The appliance should be positioned
to allow easy access to a counter
when removing food. For best use of
refrigerator drawers and freezer baskets,
the appliance should be in a position
where both can be fully opened.
Tools Necessary:
Phillips Head
or
Quadrex Head
Screwdriver
(OR)
OR
8mm Socket
Wrench
Adjustable
Wrench
OR
⅜"
Fixed
Wrench
ANDAND
6mm
Allen Wrench
INSTALLATION
CAUTION
Do Not install the appliance where
the temperature will drop below 55°F
(13°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside
the appliance.
NOTE
If your appliance is placed with the door
hinge side against a wall, you may have
to allow additional space for the handle
so the door can be opened wider.
WARNING
This appliance is intended to be used
in household and similar applications
such as:
• sta kitchen areas in shops, oces
and other working environments;
• farm houses and by clients in hotels,
motels and other residential type
environments;
• bed and breakfast type environments;
• catering and similar non-
retail applications.
WARNING
Installation
Allow the following clearances
for ease of installation, proper air
circulation, and plumbing and electrical
connections:
Sides & Top ⅜ inch (9.5 mm)
Back 1 inch (25.4 mm)
8
3. Ensure both doors are bind-free with
their seals touching the cabinet on all
four sides and the cabinet is stable.
Flipper Mullion
Adjust Flipper Mullion for proper
connection with the mullion guide by
ensuring the flipper mullion is folded and
perpendicular to the fresh food door. If
the mullion guide is not in the correct
position, it could prevent the door from
closing completely.
WRONG
INSTALLATION
Most of these conditions can be met
by raising or lowering the adjustable
anti-tip legs.
To level the cabinet using the anti-tip legs:
1. Slightly open freezer drawer.
2. Lower anti-tip legs until they are
both touching the floor. Use a pair
of pliers to adjust.
To raise unit: turn leg clockwise.
To lower unit: turn
leg counterclockwise.
Cabinet Leveling & Door
Alignment (if necessary)
Guidelines for final positioning of appliance:
• All 4 corners of the cabinet must rest
firmly on the floor.
• The front should be slightly
elevated to ensure that doors close
and seal properly.
• Doors should align with each other
and be level.
9
DOOR REMOVAL
Getting through narrow spaces
If refrigerator will not fit through an
entrance area, doors can be removed.
Check first by measuring the entrance.
To prepare for removing the doors:
1. Make sure the electrical power cord
is unplugged from the wall outlet.
2. Remove any food from the door
shelves and close the doors.
To remove the refrigerator doors:
1. Open doors to 90°.
2. Trace lightly around the door’s top
hinges with a pencil. This makes
reinstallation easier.
3. Disconnect electrical harness
running from door to hinge cover.
4. Remove three 8 mm bolts from both
top hinges. Lift doors up o lower
hinges and carefully set aside..
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury, or damage to the
doors or handles.
Lower Hinge Removal
Once both doors are in place, ensure they
are aligned with each other and level (See
INSTALLATION for more details), and
replace the top hinge cover.
5. To gain access to lower hinge, drawer
will need to be extended. Unscrew the
3 lower hinge screws and slide the
hinge inward.
6. To reinstall doors, reverse procedure.
10
DOOR REMOVAL
1. Open drawer and fully extend.
2. Remove the freezer drawer.
3. Remove the freezer basket.
4. Inside the cabinet, press the 2 tabs
on both sides to release the sliders.
5. Remove the drawer with brackets
and sliders.
Removing Freezer Drawer
Reinstalling Freezer Drawer
1. Place drawer with brackets and
sliders inside the cabinet and click
into place.
2. Replace the basket.
CAUTION
Drawer is heavy. Use caution when lifting.
NOTE
For additional instructions, see
STORAGE FEATURES.
11
Door Handle
Mounting Instructions
1. Remove handles from
carton and any other
protective packaging.
2. Position fresh food
handle end caps over
upper and lower pre-
installed shoulder bolts
(A) that are fastened
into door, ensuring the
holes for the set screws
are facing toward the
opposite door.
3. While holding handle
firmly against door,
fasten upper and lower
Allen set screws (B) with
supplied Allen wrench.
4. Repeat steps 2 and 3 to
install opposite handle.
Ensure the holes for the
set screws are facing
toward the first door.
5. Position freezer drawer
handle end caps over left
and right pre-installed
shoulder bolts (A) that
are fastened to the
door, ensuring the holes
for the set screws are
facing down.
6. While holding handle
firmly against door,
loosely tighten right
Allen set screw (B)
with supplied Allen
wrench until there is
no gap between handle
and door.
7. Still holding the handle
firmly to the door, firmly
tighten left Allen set
screw (B) with supplied
Allen wrench.
8. Return to the right Allen
set screw (B) and firmly
tighten with supplied
Allen wrench.
Mounting Freezer Drawer Handle
Mounting Refrigerator Handles
DOOR HANDLE INSTALLATION
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
NOTE
When tightening the Allen set screws, it is imper-
ative to apply force to the longer arm of the Allen
wrench supplied in the handle packaging.
NOTE
Tighten all set screws so the screw is below the surface
of the handle. Draw the handles tight to doors/drawer
with no gaps. Opening the opposite door while tight-
ening the Allen screw makes installation easier.
The door handle may loosen over time or if it was
installed improperly. If this happens, tighten the set
screws on the handles.
12
WATER SUPPLY CONNECTION
IMPORTANT
Ensure the water supply line connections
comply with all local plumbing codes.
To install the water supply line, the
following are needed:
• Basic Tools: adjustable wrench, flathead
screwdriver, and Phillips
TM
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100psi.
• A water supply line made of ¼in.
(6.4mm) OD, copper or stainless
steel tubing. To determine the length
of tubing needed, measure the dis-
tance from the ice maker inlet valve
at the back of the refrigerator to the
cold water pipe. Then add approxi-
mately 6ft. (1.8m.), so you can move
the refrigerator out for cleaning.
• A shuto valve to connect the water
supply line to the household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
• A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the ice maker
inlet valve.
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the refrigerator from
electrical power before connecting a
water supply line to the refrigerator.
CAUTION
To Avoid Property Damage:
• Use Copper or Stainless Steel braided
tubing for the water supply line. Do
not use water supply tubing made of
¼ in. plastic. Plastic tubing greatly
increases the potential for water
leaks, and the manufacturer will not
be responsible for any damage if you
use plastic tubing for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning water
softener can damage the ice maker.
If you use a water softening system,
ensure the softener is maintained and
working properly.
NOTE
Check with local building authority for
recommendations on water lines and
associated materials prior to installing
refrigerator. Depending on local/state
building codes, Frigidaire recommends
you use Smart Choice
®
water line kit
5304437642 with a 6ft. (1.8 m.) Stain-
less Steel Water Line on homes with
existing valves. Please refer to Frigid-
aire.com for more information.
13
WATER SUPPLY CONNECTION
To Connect Water Tube to
Household Water Supply
1. Disconnect
refrigerator from
electrical power
source.
2. Place end of water
supply line into
sink or bucket.
Turn ON water
supply and flush
supply line until
water is clear. Turn
OFF water supply at shuto valve.
3. Open the locking
clips and grab
water line
coming from
the refrigerator.
Remove plastic
cap from water
inlet fitting and
discard cap.
To
household
water
supply
To
unit
water valve
Place 7/16" wrench
here. Do not turn.
Place 1/2" wrench
here. Turn
clockwise.
4. If using (recommended) stainless
steel braided tubing - the nut and
ferrule are already assembled on the
tubing. Slide compression nut onto
water inlet fitting and finger tighten.
5. Using ½" and
7
/
16
" wrenches (one to
hold the household water line nut
and the other to hold the water inlet
fitting nut), tighten a half turn with
wrench. DO NOT overtighten.
6. Replace the connected tubes into
the clips and lock clips back in
place to keep the tubing in the right
position.
7. Turn ON water supply at shuto
valve and tighten any connections
that leak.
8. Reconnect refrigerator to electrical
power source.
9. Ensure ice maker is turned ON.
10. Purge air from Ice and Water Dispenser
System by operating the water
dispenser for 3-4 minutes. This will
require dispensing several glasses of
water.
Water
inlet
fitting
Plastic
tubing
to
water
valve
6 ft. (1.8 Meters) Stainless
Steel water line from
household water supply line
Connection to Household Water Supply
with 1/4" compression
fitting
Plastic
Cap
Remove
plastic cap
from water
inlet fitting
Water Inlet
Brass
Fitting
¼ inch
plastic tube
to water
valve
14
CONTROLS AND SETTINGS
1
Temperature Control Choose the
compartment by pressing to
change the temperature in that
compartment. Adjust the
temperature with the — /+ keys.
Refrigerator
Compartment
Freezer
Compartment
6
1
2
3 4 5
7
8
9
2
Control Lock Press to lock the
appliance control display. When
locked, other key functions are
disabled. This prevents accidentally
changing settings when cleaning.
Lock the internal appliance control
display for child safety and cleaning.
3
Reset Air Filter will illuminate when
it is time to replace the air filter. See
the FILTER REPLACEMENT section
for instructions on how to replace the
air filter. After changing the air filter,
reset the alert by pressing and holding
Reset Air Filter for 3 seconds.
4
Prior to grocery shopping, we
recommend you activate Freeze
Boost to freeze your food faster It
will remain active for up to 24 hours
before automatically deactivating
or you manually exit. Press Freeze
Boost to turn the function o. This
will reset the freezer to the previous
temperature setting.
5
Reset Water Filter will illuminate
when it is time to replace the
water filter. See the FILTER
REPLACEMENT section for
instructions on how to replace
the water filter. After changing
the water filter, reset the alert by
pressing and holding Reset Water
Filter for 3 seconds.
6
Air Filter automatically lights up
when the it’s time to change the air
filter, typically after 6 months.
7
Water Filter automatically lights
up when the it’s time to change the
water filter, typically after 6 months.
8
Ice Maker Press and hold for 3
seconds to turn the ice maker on/
o. When the indicator is lit, the
ice maker is on. When the indicator
is not lit, the ice maker is OFF and
will stop making ice. While o, ice
dispensing can continue as long as
there is ice in the bucket. When ice
maker is o and ice is dispensing,
the indicator will blink.
9
°F/°C toggles the temperature
mode between Fahrenheit and
Celsius. Press and hold Freeze
Boost and + for 5 seconds. A tone
will confirm the change.
Fahrenheit Celsius
15
CONTROLS AND SETTINGS
IMPORTANT
If food is freezing in the fresh food
compartment, increase the temperature
setting 1 or 2 degrees.
IMPORTANT
Food placed within 1 in. in front of the
air ports may cause food to freeze.
NOTE
The recommended settings for a prod-
uct installed in a kitchen is 37˚F for the
fresh food compartment and 0˚F for
the freezer.
NOTE
Unit should stabilize temperatures
within 24 hours of installation.
Alarms
High Temperature
If the temperature
increases, the HIGH
TEMP alarm will sound
every 10 seconds until
you press any key to
mute it. The display will
blink HI in the corre-
sponding compartment until the tempera-
ture reaches an acceptable level.
Door Alarm
When and door is left open for 5 minutes,
an alarm will sound. The alarm is turned
o by closing the door.
16
Sabbath Mode
The Sabbath Mode is a feature that disables portions of the refrigerator and its
controls in accordance with observance of the weekly Sabbath and religious holidays
within the Orthodox Jewish community.
NOTE
While in Sabbath Mode, neither the lights
nor the appliance control display will
work until Sabbath Mode is deactivated.
The refrigerator stays in Sabbath Mode
after power failure recovery. Deactivat-
ed it with the buttons on the appliance
control display.
NOTE
Although the Sabbath Mode has been
initiated, the ice maker will complete
the cycle it had already started. The
ice cube compartment will remain cold
and new ice cubes can be made with
standard trays.
CONTROLS AND SETTINGS
In the Sabbath Mode, the High Temp alarm
is active for health reasons. For example,
if the door is left ajar the High Temp alarm
is activated. The refrigerator will function
normally once the door is closed, without
any violation of the Sabbath/Holidays. The
High Temp alarm is permitted when cabinet
temperature is outside the safe zone for 20
minutes. The alarm silences itself after 10
minutes while the High Temp icon stays lit
until the Sabbath mode is exited.
To activate Sabbath Mode, press and hold
— and Reset Air Filter simultaneously for
5 seconds. Sb will display, and no audible
sounds will occur until you exit Sabbath Mode.
To exit Sabbath Mode, press and hold —
and Reset Air Filter simultaneously for 5
seconds. An audible tone will sound, and the
refrigerator will go back to the state it was in
prior to activating Sabbath Mode.
For further assistance, guidelines for
proper usage and a complete list of
models with the Sabbath feature,
please visit the web at
star-k.org.
Sabbath Mode activated
Sabbath Mode deactivated
17
ICE MAKER
IMPORTANT
On occasion, unusually small ice cubes
may be noticed in the bucket. This could
occur in normal operation of the ice
maker. If happening frequently, it may
be an indication of low water pressure
or the water filter needs to be replaced.
As the water filter nears the end of its
useful life and becomes clogged with
particles, less water is delivered to the
ice maker during each cycle. Remember,
if it’s been six months or longer since
last changing the water filter, replace
it with a new one. Poor quality house-
hold water may require the filter to be
changed more frequently.
Ice maker tips
• If refrigerator is not connected to a
water supply or the water supply is
turned o, turn o the ice maker as
described in the previous section.
• The following sounds are normal
when the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• If a large quantity of ice is needed
at one time, it is best to get cubes
directly from the ice bin.
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
bin as explained in “Cleaning the ice
maker”.
• It is normal to have a small quantity
of little pieces along with the
whole cubes.
• It is normal for ice to fill to the top of
the ice bin.
CAUTION
If the water supply to the refrigerator is
softened, be sure the softener is properly
maintained. Chemicals from a water
softener can damage the ice maker.
Cleaning the ice maker
Clean the ice maker and ice bin at
regular intervals, especially prior to
vacation or moving.
1. Turn o the ice maker.
2. Remove the ice bin by lifting upward
and pulling straight out.
3. Empty and carefully clean the ice bin
with mild detergent. Do not use harsh
or abrasive cleaners. Do not place in
dishwasher. Rinse with clear water.
4. Allow the ice bin to dry completely
before replacing in the freezer.
5. Replace the ice bin. Turn the ice
maker on.
Remove and empty the ice bin if:
An extended power failure (one hour or
longer) causes ice cubes in the ice bin to
melt and refreeze together after power is
restored.
Removing Ice Bin
Remove the ice bin by (1) lifting upward and
(2) pulling straight out, then shake to loosen
the cubes or clean as explained above.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
18
STORAGE FEATURES
Shelf positions can easily be adjusted in
the fresh food compartments as needed.
The shelves have mounting brackets that
attach to slotted supports at the rear of
each compartment.
Change the Position of a Shelf
1. Remove all food from shelf.
2. Lift the front edge up and pull the
shelf out.
3. Replace by inserting the mounting
bracket hooks into the desired
support slots.
4. Lower the shelf and lock into position.
Removing CrispSeal Drawer
CrispSeal Drawer
The refrigerator includes a crisper
designed for storing fruits, vegetables,
and other fresh produce.
To remove the CrispSeal drawer for cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove
the drawer.
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to
sudden temperature change. Allow
the glass shelves to stabilize to room
temperature before cleaning. Do not
wash in dishwasher.
19
Doors
Storage bins
The doors to the fresh food compartment
use a system of modular storage bins.
All of these bins are removable for easy
cleaning. Adjust bins as needed.
Door bins are ideal for storing jars, bottles,
cans, and large drink containers. They
also enable quick selection of frequently
used items.
Adjustable door bins
Adjustable door bins can be moved to suit
individual needs.
STORAGE FEATURES
To remove upper freezer drawer:
1. Open freezer compartment completely.
2. Lift up and out to remove upper
freezer drawer.
Reverse the steps to reinstall drawer.
Freezer Drawer
Freezer Features
NOTE
If basket is not resting on stabilizer
bar retainer clips, the drawer will not
close properly.
To remove freezer basket:
1. Open freezer compartment completely.
2. Lift the basket up and remove.
Reverse the steps to reinstall freezer basket.
IMPORTANT
There are wheels on the bottom of
the drawer. Make sure all wheels are
aligned on their respective tracks for
proper function. If drawer is not aligned
properly, it will cause problems with the
door operation.
Adjustable Door Bins
To move door bin side-to-side:
1. Tilt bin up so the back of the
bin is o the door but the hook is
still engaged.
2. Slide bin along rail to desired position.
3. Lower bin back into place.
To move door bin up or down:
1. Lift bin up disengaging the hook.
2. Move bin to desired rail location.
3. Push bin hook into rail engaging
the hook.
20
STORING FOOD AND SAVING ENERGY
Ideas for storing foods
Fresh food storage
• Keep the fresh food compartment
between 34°F and 44°F with an opti-
mum temperature of 37°F.
• Avoid overcrowding the refrigerator
shelves, which reduces air circulation
and causes uneven cooling.
• Avoid placing food in front of air
ports. (See CONTROLS AND SET-
TINGS for illustration.)
Fruits and vegetables
• Store fruits and vegetables in crisper
drawers, where trapped moisture
helps preserve food quality for longer
time periods.
• Do not wash items until ready to use.
Remove excess water before placing
inside unit.
• Wrap any items that have strong
odors or high moisture content.
Meat
Wrap raw meat and poultry separately
and securely to prevent leaks and con-
tamination of other foods or surfaces.
Frozen food storage
• Keep the freezer compartment at 0°F
or lower.
• A freezer operates most eciently
when it is at least ⅔ full.
Packaging foods for freezing
• To minimize food dehydration and
quality deterioration, use aluminum foil,
freezer wrap, freezer bags, or airtight
containers. Force as much air out of
the packages as possible and seal them
tightly. Trapped air can cause food to
dry out, change color, and develop an
o-flavor (freezer burn).
• Wrap fresh meats and poultry with
suitable freezer wrap prior to freezing.
• Do not refreeze meat that has com-
pletely thawed.
Loading the freezer
• Prior to grocery shopping, we
recommend you activate Freeze
Boost to freeze your food faster It will
remain active for up to 24 hours
• Activating Freeze Boost will help the
freezer more eciently maintain the
selected temperature after placing
new purchases with pre-existing
frozen foods.
• Avoid adding too much warm food to
the freezer at one time. This over-
loads the freezer, slows the rate of
freezing, and can raise the tempera-
ture of frozen foods.
• Leave a space between packages, so
cold air can circulate freely, allowing
food to freeze as quickly as possible.
Ideas for saving energy
Installation
• Locate the refrigerator in the coolest
part of the room, out of direct
sunlight, and away from heating
ducts or registers.
• Do not place the refrigerator next to
heat-producing appliances such as a
range, oven, or dishwasher. If this is
not possible, a section of cabinetry or
an added layer of insulation between
the two appliances will help the re-
frigerator operate more eciently.
• Level the refrigerator so that the
doors close tightly.
Temperature settings
Refer to the CONTROLS AND SETTINGS
for procedures on temperature settings.
Food storage
• Avoid overcrowding the refrigerator
or blocking cold air vents. Doing so
causes the refrigerator to run longer
and use more energy.
• Cover foods and wipe containers dry
before placing them in the refrig-
erator. This cuts down on moisture
build-up inside the unit.
• Organize the refrigerator to reduce
door openings. Remove as many
items as needed at one time and
close the door as soon as possible.
• Do not place a hot container directly
on a cold shelf. Remember, such an
extreme temperature change may
damage the glass.
21
NORMAL OPERATING SOUNDS
Understanding the sounds
coming from the refrigerator
High-eciency refrigerators may
introduce unfamiliar sounds. These
sounds normally indicate the refrigerator
is operating correctly. Some surfaces on
floors, walls, and kitchen cabinets may
make these sounds more noticeable.
The following is a list of major
components in the refrigerator and the
sounds they can cause:
A Evaporator Refrigerant through
the evaporator may create a
boiling or gurgling sound.
B Evaporator fan Sounds of air
being forced through the
refrigerator by the evaporator
fan may be heard.
C Defrost heaters During defrost
cycles, water dripping onto the
defrost heaters may cause a
hissing or sizzling sound. After
defrosting, a popping sound
may occur.
D Automatic ice maker When
ice has been produced, sounds
of ice cubes falling into the
ice bin may be heard. The ice
maker fan, water valve
activation, and refrigerant
gas fluid may create sounds
from its operation.
E Electronic control & automatic
defrost control These parts can
produce a snapping or clicking
sound when turning the cooling
system on and o.
F Compressor Modern, high-
eciency compressors run much
faster than older models. The
compressor may have a high-
pitched hum or pulsating sound.
G Water valves Make a buzzing
sound each time they open to fill
the ice maker.
H Drain pan (not removable)
Sounds of water dripping into
the drain pan during the defrost
cycle may be heard.
I Condenser May create minimal
sounds from forced air.
J Motorized damper May produce
a light humming during operation.
NOTE
Energy ecient foam in the refrigerator
is not a sound insulator.
NOTE
During automatic defrost cycle, a red
glow in the back wall vents of the freez-
er compartment is normal.
Features vary by model
A
B
C
D
E
FG
H
I
J
22
FILTER REPLACEMENT
Ordering Replacement Air Filters
Order replacement filters online at
Frigidaire.com, by calling 1-800-374-
4432
(Frigidaire.ca or 1-800-265-8352 in
Canada)
or through the dealer from which
the refrigerator was purchased. Frigidaire
recommends replacing filters at least once
every 6 months.
Here is the product number to request
when ordering:
Pure
Air Ultra II™ Air Filter
PAULTRA2
Air Filter
The air filter is located in the top center of
the fresh food compartment.
Replacing the PureAir Ultra II
TM
Air Filter
To ensure optimal filtering of refrigerator
odors, change the air filter every 6 months
(Replace Air Filter on the Display indicates
replacing the filter after 6 months).
1. Remove the air filter cover by
squeezing the top and bottom of
the cover together and removing
from liner.
2. Remove the old filter and discard it.
3. Unpack the new filter and snap it
into the filter cover. The open face
(carbon media) of the filter should be
installed facing outward in the cover.
4. Replace the air filter cover by
squeezing the sides and snapping it
back into place.
5. Press and hold the Reset Air Filter
button on the Display for 3 seconds.
When the indicator turns o, the
status has been reset.
Ordering Replacement Water Filters
Order replacement filters online at
Frigidaire.com, by calling 1-800-374-
4432
(Frigidaire.ca or 1-800-265-8352 in
Canada)
or through the dealer from which
the refrigerator was purchased. Frigidaire
recommends replacing filters at least once
every 6 months.
Here is the product number to request
when ordering:
PureSource Ultra II
TM
Water Filter
Part #EPTWFU01
Water Filter
The refrigerator is equipped with a water
filtering system. The water filtering
system filters water used to produce ice.
The water filter is located at the top left
side of the fresh food compartment.
Replacing the PureSource
Ultra II
TM
Water Filter
Change the water filter every 6 months to
ensure the highest possible water quality.
Replace Water Filter on the display
indicates when to replace the filter
after a standard amount of water (125
gallons/473 liters for PureSource UltraII
TM
)
has flowed through the system.
If the refrigerator has not been used
for a period of time (during moving
for example), change the filter before
reinstalling the refrigerator.
NOTE
When ordering replacement filters,
please reorder the same filter type that
is currently in the refrigerator.
23
Do not use with water that is
microbiologically unsafe or of unknown
quality without adequate disinfection
before or after the system. Systems
certified for cyst reduction may be used
on disinfected waters that may contain
filterable cysts.
Test & certification results:
• Rated Capacity - 125 gallons/473
liters for PureSource Ultra II
TM
ice
and water filter
• Rated service flow - .65 gallons
per minute
• Operating Temp: Min. 33°F,
Max. 100°F
• Maximum Rated Pressure - 100
pounds per square inch
• Recommended Minimum Operating
Pressure: 30pounds per square inch
The PureSource Ultra II
TM
ice and water filter system is
tested and certified to NSF/
ANSI Standards 43, 53 and
401 for the reduction of claims
specified on the performance
data sheet.
More about the Advanced
Water Filter
FILTER REPLACEMENT
To replace the PureSource Ultra II
TM
water filter:
It is not necessary to turn the water
supply o to change the filter. Be ready
to wipe up any small amounts of water
released during the filter replacement.
(Instructional video of procedure can be
found on Frigidaire.com.)
1. Turn o Ice Maker on the appliance
control display.
2. Remove the old filter by rotating it
counterclockwise (to the left) 90
degrees to release it.
3. Slide the old filter cartridge straight
out of the housing and discard it.
4. Unpackage the new filter cartridge.
Slide it into the filter housing
as far as it will go with the grip
end horizontal.
5. Push lightly inward on the filter
while rotating it clockwise (to the
right). The filter will then pull itself
inward as it is rotated. Rotate the
filter 90 degrees until it stops and
the grip end is vertical. A very light
click may be heard as the filter locks
into place.
6. Press and hold the Reset Water
Filter button on the appliance
control display for 3 seconds.
When the indicator is no longer
illuminated, the water filter status
has been reset.
7. Turn on Ice Maker on the appliance
control display.
8. In order for the ice maker to work
properly, clear air from the water
filter tubing by filling the ice bucket
completely twice. Discard the ice
produced.
24
IMPORTANT
When storing or moving refrigerator in freezing temperatures, be sure to complete-
ly drain the water supply system. Failure to do so could result in water leaks when
the refrigerator is put back into service. Contact a service representative to perform
this operation.
CAUTION
• Pull the refrigerator straight out to move it. Shifting it from side to side may damage
flooring. Be careful not to move the refrigerator beyond the plumbing connections.
• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces
with wet or damp hands.
NOTE
Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable
fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing
petroleum products on plastic parts, interior doors, gaskets, or cabinet liners. Do
not use scouring pads or other abrasive cleaning materials.
NOTE
When setting temperature controls to turn o cooling, power to lights and other elec-
trical components will continue until the power cord is unplugged from the wall outlet.
CARE AND CLEANING
Care & Cleaning Tips
Keeping the refrigerator clean maintains its appearance and prevents odor build-up.
Wipe up any spills immediately and clean the freezer and fresh food compartments at
least twice a year.
• Always unplug the electrical power cord from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do not use razor blades or other sharp
instruments which can scratch the appliance surface.
• Do not remove the serial plate. Removal of the serial plate voids the warranty.
• Before moving refrigerator, raise the anti-tip brackets so the rollers will work
correctly. This will prevent the floor from being damaged.
Refer to the guide on the next page for details on caring and cleaning specific areas
of refrigerator.
• Never use metallic scouring pads, brushes, abrasive cleaners, or strong alkaline
solutions on any surface.
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
25
Vacation and moving tips
Occasion Tips
Short
Vacations
• Leave the refrigerator operating during vacations of 3 weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn the automatic ice maker o and empty the ice bucket, even if
only away a few days.
Long
Vacations
• Remove all food and ice if leaving for 1 month or more.
• Turn the cooling system o (see “Controls” section for location of On/
O button) and disconnect power cord.
• Turn the water supply valve to the closed position.
• Clean the interior thoroughly.
• Leave both doors open to prevent odors and mold build-up. Block the
doors open if necessary.
Moving
• Unplug the unit.
• Remove all food and ice.
• We reommend If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad the cabinet to avoid scratching the surface.
CARE AND CLEANING
Care & Cleaning Tips
Part What To Use Tips and Precautions
Interior &
Door Liners
• Soap and water
• Baking soda and
water
Use two tablespoons of baking soda in
one quart of warm water. Be sure to wring
excess water out of sponge or cloth
before cleaning around controls, light
bulb or any electrical part.
Door Gaskets
• Soap and water Wipe gaskets with a clean soft cloth.
Drawers & Bins
• Soap and water Use a soft cloth to clean drawer runners
and tracks.
Glass Shelves
• Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature
before immersing in warm water.
Exterior &
Handles
• Soap and water
• Non Abrasive Glass
Cleaner
Do not use commercial household cleaners
containing ammonia, bleach or alcohol to
clean handles. Use a soft cloth to clean
smooth handles or exterior. DO NOT use a
dry cloth to clean smooth doors.
26
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
TROUBLESHOOTING
Concern Potential Cause Common Solution
Automatic Ice Maker
Ice maker is
not making
any ice.
• Ice maker is turned o.
• Refrigerator is not
connected to water line or
water valve is not open.
• The water supply line is
kinked.
• The water filter is not
seated properly.
• Turn on ice maker on the appliance
control display.
• Connect the unit to the household
water supply and ensure the water
valve is open.
• Ensure that the supply line does not
kink when the refrigerator is pushed
into place against the wall.
• Remove and reinstall the water
filter. Be sure to seat it fully into the
locked position.
Ice maker is
not making
enough ice.
• Ice maker is producing
less ice than expected.
• The water supply line is
kinked.
• Water pressure is
extremely low. Cut-o and
cut-on pressures are too
low (well systems only).
• Reverse osmosis system
is in regenerative phase.
• The ice maker will produce approxi-
mately 2 to 2.5 pounds of ice every 24
hours depending on usage conditions.
• Ensure that the supply line does not
kink when the refrigerator is pushed
into place against the wall.
• Have someone turn up the cut-o
and cut-on pressure on the water
pump system (well systems only).
• It is normal for a reverse osmosis
system to be below 20 psi during
the regenerative phase.
Ice cubes
are freezing
together.
• Ice cubes are not being
used frequently enough
or interruption of power
for prolonged time.
• Ice cubes are hollow
(shells of ice with water
inside). The hollow cubes
break open in the bin
and leak their water onto
existing ice, which causes
it to freeze together.
• Remove ice container and discard
ice. The ice maker will produce
fresh supply. Ice should be used
at least twice weekly to keep the
cubes separated.
• This generally occurs when the
ice maker does not get enough
water. This is usually the result of
a clogged water filter or restricted
water supply. Replace the water
filter and if the condition still occurs,
check to see if the water valve is not
turned on all the way or if there is a
kinked water supply line.
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
27
TROUBLESHOOTING
Concern Potential Cause Common Solution
Opening/Closing Of Doors/Drawers
Door(s) will
not close.
• Door was closed too
hard, causing other door
to open slightly.
• Refrigerator is not level.
It rocks on the floor
when moved slightly.
• Refrigerator is touching
a wall or cabinet.
• Food/packaging is
obstructing the door
from closing.
• Flipper mullion on left
fresh food door is not in
the correct position.
• Close both doors gently.
• Ensure floor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Ensure floor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Make sure there is no food/
packaging blocking the doorway.
• Ensure the flipper mullion is in the
correct position to allow the door
to close. (See “Flipper Mullion” in
INSTALLATION.)
Drawers are
dicult to
move.
• Food is touching shelf
on top of drawer.
• Track that drawers slide
on is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly installed
on track.
• Clean drawer, rollers, and track. See
CARE & CLEANING.
Running of Refrigerator
Compressor
does not run.
• Refrigerator is in
defrost cycle.
• Plug at electrical outlet
is disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• This is normal for a fully automatic
defrost refrigerator. The defrost
cycle occurs periodically, lasting
about 30 minutes.
• Ensure plug is tightly pushed
into outlet.
• Check/replace fuse with a 15 amp
time-delay fuse. Reset circuit breaker.
• Check house lights. Call local
electric company.
Refrigerator
seems to
run too
much or
too long.
• The variable speed
compressor is designed
to run 100% of the
time except during the
defrost cycle. At times
it will run faster, such as
after a defrost cycle.
• It is normal for the compressor to
run continuously except during
defrost mode.
Digital Temperature Setting Display
Digital
temperature
displays an
error.
• Electronic control
system has detected a
performance problem.
• Contact Electrolux Customer Care
for assistance with any errors or
codes flashing in the display by
calling 1-800-374-4432.
28
Concern Potential Cause Common Solution
Water/Moisture/Frost Inside Refrigerator
Moisture
collects on
inside of
refrigerator
walls.
• Weather is hot and humid.
• Flipper mullion
• The rate of frost buildup and
internal sweating increases.
• Adjust flipper mullion. (See “Flipper
Mullion” in INSTALLATION.)
Water
collects on
bottom side
of drawer
cover.
• Vegetables contain and
give o moisture.
• It is not unusual to have moisture on
the bottom side of the cover.
• Both crispers contain an automatic
humidity control, which should
adjust automatically to the varying
levels of moisture inside the
drawer without creating additional
condensation or drying out the air
inside the crisper drawer, works with
various types of produce. If excess
moisture is noticed, check to verify
humidity membrane is not damaged
and replace as necessary.
Water
collects in
bottom of
drawer.
• Washed vegetables
and fruit drain while
in the drawer.
• Dry items before putting them in
the drawer. Water collecting in
bottom of drawer is normal.
Water/Moisture/Frost Outside Refrigerator
Moisture
collects on
outside of
refrigerator
or between
doors.
• Weather is humid. • This is normal in humid weather.
When humidity is lower, the
moisture should disappear.
Food/Drinks in Fresh Food Compartment
Food is
freezing.
• Temperature setting is
too low.
• Temperature sensor is
covered by food (right
side of fresh food area).
• Food is covering the
air ports.
• Move the setting to a higher degree.
• Allow space for air flow to the sensor.
• Allow space between the air ports
and the food.
TROUBLESHOOTING
29
LIMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that
prove to be defective in materials or workmanship when such appliance is installed, used and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily
determined.
2. Product that has been transferred from its original owner to another party or removed
outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or
for appliances not in ordinary household use or used other than in accordance with the
provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your
appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other
consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls,
tolls, ferry trip charges, or mileage expense for service calls to remote areas, including the
state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not
limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts
other than genuine Electrolux parts or parts obtained from persons other than authorized
service companies; or external causes such as abuse, misuse, inadequate power supply,
accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED
WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT
LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY
BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND
PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by
Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada,
your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to change or
add to any obligations under this warranty. Obligations for service and parts under this warranty must
be performed by Electrolux or an authorized service company. Product features or specifications as
described or illustrated are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
