WARNING
Repair Mode
Repair Mode. An advanced battery recovery mode for repairing
old, idle, damaged, stratified and sulfated batteries. The maximum
repair time is 24 hours. Not for Lithium and LiFePO4 batteries.
Can not repair badly damaged batteries.
Wrong polarity, please change the connection
of the clamps.
Defect battery, please let the battery be
checked by a mechanic and if necessary
change the battery.
Bad connection, please check the connection
between the charger and the battery.
1. Don not charge for the lithium battery without battery protection
board(BMS).
2. Charge the battery below 20AH with the minimum current.
3. The charger is designed for 36V and 48V Lithium,Lead-acid,
LiFePO4 batteries.
4. Check battery specifications before using.
5. Provide ventilation to prevent flames and sparks.
6. Do not expose charger to the sun, or under high temperature
environment.
7. Battery acid is corrosive. Rinse immediately with water if acid
comes into contact with skin or eyes.
8. Do not charge a frozen or damaged battery.
9. Do not charge non-rechargeable batteries.
10. Do not place the charger on the battery while charging.
11. Be extra cautious to reduce risk of dropping a metal tool on
the battery. It might spark or short-circuit battery or other
electrical part that may cause explosion.
12. When working with a lead-acid battery, remove personal
metalitems such as rings, bracelets, necklaces, watch...
13. Do not smoke or allow a spark or flame while charging.
14. In order to reduce risk of electric shock, unplug charger from
AC outlet before doing any maintenance or cleaning .
15. Not intended for children and anyone unable to follow the user
manual.
16. Do not over-charge your battery even it is kept connecting in
any mode.
Charging Current：
Max 18A(36V),Max 13A(48V)
Battery Chemistries：
Lithium, LiFePO4, Lead-acid (AGM, GEL,
EFB,MF, FLOODED, VRLA, SLA, WET, etc.)
Type of Batteries: 36V,48V
Minimum Start Volt: 26V
Dimension: 230*125*70mm
Net weight: 1000g
100-240V~50/60Hz
AC Input Voltage:
Choose an appropriate
charging current.
Connect the charger to
the AC power
Connect the charger
and battery.
Choose the appropriate gear
according to your battery
voltage. (Left: 36V, Right: 48V)
Voltage selection switch. Choose the voltage according to the
battery voltage, choose 36V for 36V batteries, and choose 48V
for 48V batteries.
Used to select a mode
Charge current level. 5A charging current for 36V and 48V batteries.
Charge current level. 10A for 36V battery, 8A for 48V battery.
Charge current level. 18A for 36V battery, 13A for 48V battery.
For activation and repair of weak, old and idle batteries. Can not
repair severely damaged batteries. Not for Lithium and LiFePO4
batteries.
Note :
1. Don not charge for the lithium battery without battery protection
board(BMS).
2. Charge the battery below 20AH with the minimum current.
- 1EN - - 2EN - - 3EN - - 4EN - - 5EN -
AC:100-240V 50~60Hz
18A 13A
36V
48V
Current selection
18A 13A
36V
48V
5A/5A 10A/8A 18A/13A REPAIR
36V/48V Battery Charger and Maintainer
battery voltage
Lithium,LiFePO4,
Lead-acid(AGM/Gel/SLA..)
36V
48V
36V
48V
36V
48V
18A 13A
36V
48V
5A/5A 10A/8A 18A/13A REPAIR
36V/48V Battery Charger and Maintainer
battery voltage
Lithium,LiFePO4,
Lead-acid(AGM/Gel/SLA..)
36V 48V
36
9-stage charging process optimizing battery
power precisely and gently.
1:Battery desulfation
2:Soft start charging
3:Bulk charging
4:Absorption charging
5:Trickle charge
6:Battery test
7:Recondition charging
8:Float & maintenance charging
9:Small current to maintain charging
Battery
Capacity
(Ah)
50(Ah)
120(Ah)
150(Ah)
400(Ah)
1000(Ah)
36V 5A
6.5 H 3.1 H / 6.5 H 4 H /
7.2 H 4.1H 15 H 9.3 H 5.7 H
9.5 H 5.5 H 19 H 12 H 7.5 H
25 H 14 H / 31 H 19.5 H
/ 42 H / / 58 H
15 H
19 H
200(Ah)
12.5 H 7 H 25 H 15.5 H 9.5 H25 H
/
/
Charging Time(H)
36V 10A 36V 18A 48V 5A 48V 8A 48V 13A
The estimated charging time is for reference only,
please refer to the actual time.
Full Voltage of Different Batteries
USER MANUAL
Screen Icon Description
Estimated Charging Time For Different Battery Capacities.
How to charge the battery?
1. Supports Lithium,Lead-acid(AGM,GEL,SLA,Flooded,WET,EFB,etc.)
and LiFePo4 battery.
2. Fully automatic microprocessor control. 9-stage charging program provides the
best and most efficient battery charging.
3. Charging voltage automatically adapts to temperature to prevent over-or
under-charging.
4. With repair function to repair old, weak and idle batteries.
5. With overcharge protection, reverse polarity protection, short circuit protection,
sparks free contact, etc.
6. With LCD screen showing voltage, current, battery power,temperature etc.
7. Charge current can be selected.
8. The charger has auto-memory function and will return to the last mode when
connected.
Features
V
Battery Real-time Voltage
