Company: Remote Tech LLC
Address: 310 ALDER RD,Dover,DE 19904,USA
Name: Remote Key
Model: RT-13D012
Operation instructions
1.把钥匙匹配到车子上之后，按开锁键 2 秒可打开车门，按闭锁键 2 秒可关车门，
按警报键可用于寻车，按尾箱键可用于开启尾箱。
2.点火钥匙用于手动开锁以及启动汽车
1. After matching the key to the car, press the unlock key for 2 seconds to open
the door and press the lock key for 2 seconds to close the door.
2. The ignition key is used to manually unlock and start the car.
产品参数
Product parameters
额定电压 Rated voltage
DC 3V
工作电流 Working current
<5mA
工作电压 Operating voltage
1.8V~3.6V
发射功率 Transmit power
>-20dbm
按键操作力 Key operation force
200±50g
工作温度 Operating
temperature
-5°C +45°C
待机电流 Stand-by current
<1uA
发射频率 transmitting frequency
315M±75KHZ
调制方式 Modulation
ASK
电池 Battery
CR2032
开锁键
Unlock key
闭锁键
Lock
警报
Panic
按键耐久次数 Key durability
100,000 次以上
More than 100,000 times
FCC warning statements:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement.
