Remote Control Outlet
[Instruction Manual]
Please pay attention to the warning signs
Read the instructions with caution before operating
and keep it properly
Warning:
To reduce the risk of fire, electric shock, or personal injury,please
strictly follow the instructions.
1. Indoor use only. Avoid high humidity, high temperature, and areas with
a high magnetic field.
2. Always be sure to cut off the power before installing the receiver.
3. Don't connect any device that may exceed the performance limits of the
receiver.
4. Don't install or repair the product Only authorized service personnel
should undertake such installation and repairs.
5. If the remote is not in use for an extended period time, remove
batteries.
6. Used batteries should be disposed of safely and properly.
7. To prevent a choking hazard, keep packing materials away from children.
8. Do not use the battery again if it is dropped or knocked out of shape.
Product Illustration
Programming the Outlets
Note: The transmitter and receiver have been pre-programmed for immediate
use, but the configuration can be customized to meet your needs.
To program a remote transmitter and receiver:
1. Plug the receiver into the socket.
2. Press and hold the program button on the receiver until the indicator
ON/OFF & Program Button
Receiving Terminal
Indicator
Transmitting Terminal
EUT
PMN: Remote control
HVIN: JZ-2603
light starts to blink slowly.
3. Release the program button, then press the “ON” or “OFF” button
corresponding to the number on the transmitter.
4. When the indicator light stops flashing, the program is paired
successfully.
Repeat Step 1-4 to pair multiple transmitters and receivers.
Cancel All Programming:
Cancel all the programs so that no remote transmitter can control it.
1. Press and hold the program button on the receiver until the indicator
light starts to blink rapidly.
Note: The indicator light blinks from slow to fast.
2. Release the program button, then press it again, the indicator light
will go
off, which means cancel the program successfully.
No Interference
Remote control outlets adopt variable learning codes technology.The codes
will be changed each time after re-programming. If this remote control
outlet happens to be in the same channels with other RF remote devices,
just re-program it and the interference will be eliminated.
Battery Replacement
If you find the receiver works abnormally or the indicator on the remote transmitter
becomes dim, please replace the remote battery with a new DC 12V (type 23A )
battery, making sure the polarity +/- of the battery is correct.
- Low battery power may decrease readable wireless remote range.
- Remove batteries if the remote is not in use for an extended period of time.
Troubleshooting
In the case that one receiver is unresponsive to the remote control, pleas follow
the steps below to resolve the issue:
1. If the wire switch receiver is unresponsive to the remote control, please
refer to the "Canceling Programming" and "Programming the Receiver" sections in the
manual to reprogram the receiver.
2. Make sure the receiver and appliance are properly connected and powered on.
3. Replace the remote battery with a new DC 12V (type 23A ) battery.
4. The remote transmitter may be too far away to control the receiver.
5. Make sure not to exceed the maximum load.
6. "Canceling Program" is always prior to "Programming the Receiver" when you would
like to make changes.
Specifications
- Input Voltage: 125VAC,60Hz
- Max Power Rating: 15A /1875W (Resistive), 10A /1250W (Tungsten)
- Transmission Frequency: 433.92MHz
- Remote Control Distance:100 Feet (Free Area)
- Remote Battery: 23A，12V
One Year Limited Warranty
Supported by our professional R&D team and QC team, we provide One
Year Warranty for materials and workmanship from the purchase date.
Please note that the warranty does not cover damage caused by personal
misuse or improper installation.
Please attach your Order ID and Name so that our dedicated customer
service team can help you better.
FCC Warning Statement
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment. This
equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
FCC ID: 2A4G9-IT104B
ISED Warning
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
This device may not cause interference.
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
Under Innovation, Science and Economic Development Canada regulations, this radio
transmitter may only operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Innovation, Science and Economic Development Canada.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
This device complies with Canadian ICES-003 and RSS-GEN and RSS-210.
Radiation Exposure: This equipment complies with Canada radiation exposure limits
set forth for an uncontrolled environment.
ISED Radiation Exposure Statement: The device has been evaluated to meet general
RF exposure requirement. The device can be used in portable exposure condition
without restriction.
Avertissement ISED
Cet appareil contient un émetteur/récepteur exempté de licence qui est conforme au
RSS exempté de licence d'Innovation, Sciences et Développement économique Canada.
Les opérations sont soumises aux deux conditions suivantes:
1.Cet appareil ne peut pas causer d’interférences.
2. Cet appareil doit accepter toute interférence, y compris les interférences qui
peuvent causer un fonctionnement indésirable de l’appareil.
En vertu des règlements d’innovation, sciences et développement économique Canada,
cet émetteur radio ne peut être exploité qu’à l’aide d’une antenne d’un type
et d’un gain maximal (ou inférieur) approuvés pour l’émetteur par Industrie Canada.
Pour réduire le brouillage radio potentiel pour d’autres utilisateurs, le type
d’antenne et son gain devraient être choisis de manière à ce que la puissance
isotrope rayonnée équivalente (p.i.r.e.) ne soit pas supérieure à celle nécessaire
pour une communication réussie.
Cet appareil est conforme aux ICES-003 et RSS-GEN et RSS-210 du Canada.
Exposition au rayonnement: Cet équipement est conforme aux limites d’exposition
au rayonnement du Canada établies pour un environnement non contrôlé.
Déclaration d'exposition aux rayonnements ISED: L'appareil a été évalué pour
répondre aux exigences générales d'exposition aux RF. L'appareil peut être utilisé
sans restriction dans des conditions d'exposition portables.
PMN: Remote control
HVIN: JZ-2603
IC: 26865-IT104B
