PrepareCabinetRoughOpening:

Preparetheroughopeningusingthedimensionsinthefollowingtable.Theopeningshouldbeplumb,levelandsquare.



 LowerDoorsPro

VGC30AD

LowerDoorsElite

VGC42AD

RoughOpeningHeight 11‐1‐2” 11‐1/2”

RoughOpeningWidth 27‐3/8” 39‐3/4”



RemoveDoors:

Removethedoorsforeaseofinstallation.Openthedoorsandreleasethemfromthecabinetwiththesmallcliponthe

insideportionofthehinge.Setthedoorsaside.



1)Opendoors   2)ReleaseHinges  3)Removedoors.



  





InstallCabinet:

Installthecabinetintothepreparedroughopening.Ensurethatthecabinetisplumb,levelandsquareintheopeningand

fastenthecabinettothestructure.Useaminimumoffourfastenersthatareappropriateforthestructure’smaterial.Once

installed,doublecheckthatthecabinetisstillplumb,levelandsquare.Reinstallthedoorsbyclippingthehingesonthe

doorontothehingeplatesonthecabinet.Cliponehingeatatime.Closethedoorsandusethehingealignment

mechanismstoalignthedoorsinthecabinet.





4)Fastencabinettostructure5)Reinstalldoors6)CloseDoors



  

Buil

‐inAccessDoor InstallationInstructions
