Thank you for purchasing FNNEMGE FG601 car jump starter.
Please read the user manual carefully before you start to use
the product.
A Powerful Jump Starter: Car Jump Starter with 2500 amps peak
current can jump starts 12V cars, SUV, truck or van (all gasoline and
8L diesel) in seconds.
To ensure the faster charging efficiency, this external battery
charger is equipped with two USB Output including USB1 (QC3.0 5V
3A/9V 2A/12V 1.5A),USB2 (5V2.4A) and 5V 2A Type C input.
Safety Protection: High-quality battery pack,circuitry and safety
features protect you and your device from surge or short circuits.
LED Lights & LCD Screen: LED light that has 3 mode: flashlight/
strobe/ SOS, that could use as emergency tool, extra red warning
light can remind the passing cars if there is an accident. The LCD
screen can exactly show the remaining power and output voltage.
Convenient wireless charging: If you forget brin
g a charging
cable,this jump starter is your best choice.10W quickly wireless
charger or power bank on the go.
EN
EN
1. Please use a 5V2A/9V2A/12V1.5A
adapter to charge the product. (Type C
cable is included, adapter is not
included).
2. Using a 5V/2A adapter, it will take
approximately 5-6 hours to fully charge
the unit. In order to extend the battery
life it is recommended to fully charge
the unit every 3-6 months.
Short press the power switch to boot the jump starter, the display will be
turned on. For energy saving, the jump starter will be turned to standby
mode if there is no operation within 20 seconds.
Turn on the jump starter. Press the power button continuously for 3
seconds to turn on / off the flashlight mode.There are four modes
including illumination, SOS and Strobe, warning light. Short press the
power switch button to change the 3modes(illumination, SOS and
Strobe)or turn off the flashlight mode. Double press the power switch
button to enter the warning light mode or turn off the warning light
mode.
This portable jump starter is also equipped with two smart USB outputs
(USB1-QC3.0:5V 3A/9V 2A/12V 1.5A;
USB2-5V 2.4A) that provide
the fastest charging speed for your portable electronic devices, such
as phones,tablets, bluetooth earphones, etc
EN
1. Please make sure that battery level is above
50% before you use it to jump start your car.
2. Insert the plug of the smart clip completely
into the jump starter, the green and red lights
flash alternately.
3. Connect the red clip to the positive electrode
of the car battery and the black clip to the negative
electrode. The green light is always on.
4. Start the vehicle.
LED status
Discharge preparation
The (traffic)red/green
light flash alternately
Working condition
5. When the vehicle is started, remove the jumper
cable from the vehicle battery immediately.
EN
The green light is always on Jump starter is quickly discharging
• Please confirm whether both red and black
clips are connected well (short circuit).
• Please check if the positive (red) electrode
and negative (black) electrode connection
are reversed.
• The jumper starter is in low power and needs
to be charged in time.
• Back charge protection, the voltage of the
car battery is higher than 12.6V.
• No jump starter needed, the car battery is
enough to star
your car.
• The temperature of the clamp exceeds
65(+/-5)degrees.
• Rem
ove
the clamp untill the red green
led flash.
The red light is always on
(warning)
The red light flashes
1. Use the original smart clip to start the car.
2. DO NOT use this unit if any cable clamp or cord is damaged.
3. Start only for 12V vehicles,or it will cause serious damages to the unit.
4. Do not jump start your car when the battery capacity is lower than 50%.
5. Do not connect two clamps toget
her when the starter is powered on.And
do not connect both cable clamps to the same piece of metal.
6. If the engine does not start on the first try, disconnect the jumper from the
car battery and wait for at least 20 seconds before reconnecting. Maximize
three attempts in two minutes.
7. Once the engine is successfully started,disconnect the clamps within 30
seconds.
EN
Q: How to turn off this power pack?
A: This power pack will power off automatically when no load or charging
is complete.
Q: What kind of adapter should l use?
A: You can use the adapter of your phone or tablet.
Q: How long does the FNNEMGE FG601 jump starter fully charged?
A: About 5-6 hours through the 5V2A AC adapter.
Q: How many times can this product start the vehicle with full capacity?
A: Up to 30 times.
Please read the manu
al before using this product. If the product is not used
properly, It may cause product damage, overheating, toxic diffusion,fire or
explosion, and our company will not responsible for it.
EN
• Please don’t immerse the jump starter in water or put in rain or humid place.
• Do not disassemble the equipment, it may cause damage.
• Do not contact with fire, hot or flammable liquids.
• It can be used in hot summers and cold winters. The working temperature
is -20 ° C to + 70 ° C.
• Do not reverse the positive and negative electrode.Otherwise, the product
and car may damaged.
• After use, please disconnect the cable from the jump starter.
• Please confirm that the battery capacity of the jump starter exceeds 75%
before starting the car.
• Please keep it out of the children's reach.
• Do not insert foreign things into the input or output port.
• Please do not let the red and black clips touched, it will leads to short circuit.
• The product storage time is more than 3 months. If it is not used for a long
time, please full charge it at least one time within 3 months.
Warranty& Contact US
Our company provides customers with warranty of 24 months from the date
of purchase.
For additional assistance or warranty cover claim,please contact us:
E-Mail: [email protected]
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
·
Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
· Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
