SPECIFICATION SHEET
WESTINGHOUSE LIGHTING
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
^ Based on typical use, excluding lights
* Based on 12 cents per kWh and 6.4 hours use per day
† Values are per lamp
** Based on 3hrs./day
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
Item Number 74005B00
52 in. Black-Bronze Finish
Reversible Blades (Dark Walnut/Wengue) Amber Frosted Glass
Smart Wi Technology
Specications
Size ............................................................... 52”
Blades .......................................................... Reversible Plywood Blades
(Dark Walnut/Wengue)
Blade Pitch ................................................ 12°
Approved Location ............................... Indoor Only
Suggested Room Size .......................... Large Room (up to 15x15)
Down Rod .................................................. 3/4 x 4”
Installation ................................................. Combo
Max. Ceiling Angle ................................. N/A
Lead Wire .................................................. 54”
Light Bulb Usage .................................... Includes (1) Medium (E26) Base,
9 Watt Omni LED Lamps
Remote Control ....................................... Remote Control Included
Motor Finish .............................................. Black-Bronze
Motor Material ......................................... Silicon Steel Motor 153mm
x 15mm
Reverse Airow ....................................... Yes
Capacitor ................................................... Single
Switch Housing Cap........................... Not Included
Energy Information
Airow (CFM) when operated at high speed..... 4307 3579
Energy Use (Excludes lights)^......................... 42 42
Airow (CFM)^.................................................... 3223 2264
Airow Eciency (CFM/W)^........................... 78 54
Estimated Yearly Energy Cost^....................... $12 $12
RPM (High)........................................................... 176
Amp (High).......................................................... 0.52
Watts (High)........................................................ 61
Light Source
Number of Lamps........................... 1
Energy Use (Watts)†....................... 9
Equiv. Incand. Wattage†................ 60
Light Appearance (Kelvin)............ 3000
Lumens†............................................. 800
CRI...................................................... 80
Average Rated Hours..................... 25000
Life in Years**†................................. 22.80
Estimated Yearly Energy Cost..... $1.08
Porto Ceiling Fan
Smart Wi Technology
Hugger/
With down rod Without down rod
DIMMABLE
2022
Reversible Wengue
Finish Blades
Compatible with
Amazon Alexa and
Google Assistant
A. Top of Canopy to Bottom of Blades ...................................10.8”
B. Top of Canopy to Bottom of Switch House ....... ............12.8”
C. Top of Canopy to Bottom of Canopy ............................. .....2.7”
D. Width of Motor Housing ............................................................. 7.9”
E. Width of Canopy ............................................................................. 5.2”
F. Top of Canopy to Bottom of Glass .......................................20.1”
Warranty
Ceiling fans backed by our Limited Lifetime Warranty have a lifetime motor warranty and a 2-year warranty on all other parts.
SPECIFICATION SHEET
If a Combo Style Fan with a 4” Down Rod is installed without the Down Rod, Subtract 3” from the Dimensions Listed (A, B, F).
If a Combo Style Fan with a 6” Down Rod is installed without the Down Rod, Subtract 5” from the Dimensions Listed (A, B, F)
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
2022
WESTINGHOUSE LIGHTING
Item Number 74005B00
52 in. Black-Bronze Finish
Reversible Blades (Dark Walnut/Wengue) Amber Frosted Glass
Smart Wi Technology
Porto Ceiling Fan
Smart Wi Technology
