Thank you for purchasing this Combination Smoke/CO alarm GS886. This
model is powered by two 1.5V AA batteries. It also contains a voice message
system and SMART Silence Control to temporarily silence nuisance alarms.
THIS EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THE
NATIONAL FIRE PROTECTION ASSOCIATION'S STANDARD 72
(National Fire Protection Association, Battery march Park, Quincy, MA 02269).
Typical installation drawing layouts for the unit(s), indicating recommended
locations, which shall be in accordance with the applicable requirements
outlined in the following:
1)C22.1-12, Canadian Electrical Code, Part I, Safety Standard for Electrical
Installations;
2)CAN/ULC-S553, Standard for Installation of Smoke Alarms.
3) National Electrical Code, NFPA 70, Wiring Methods and Materials;
4) National Fire Alarm and Signaling Code, NFPA 72, Single- and
Multiple-Station Alarms and Household Fire Alarm Systems for US require-
ment.
The National Fire Protection Association (NFPA) and the manufacturer
recommend replacing this alarm ten years from the date code on back of
alarm. Beyond which the device might no longer detect smoke accurately and
should be immediately replaced. This instruction manual contains important
information on starting operation and using the device.
Table of Contents
Ref: 358-8386
RD-886-39-001 Rev E
Model No.: GS886
1.What to do if the smoke alarm sounds.................................. 1
2.What to do if the CO alarm sounds........................................ 1
3.Product important information............................................... 1
4.Installation instructions.......................................................... 2-3
5.Understanding your combo smoke/CO alarm ...................... 4
6.General maintenance .............................................................. 4
7.Carbon monoxide overview ................................................... 5
8.Battery information ................................................................. 5
9.Product specifications............................................................ 6
10.Recognizing nuisance alarms.............................................. 6
11.Good safety habits ............................................................... 6
12.Service information............................................................... 6
13.Warranty information ............................................................ 6
14.Warranty card ........................................................................ 6
3. Product important information
WARNING! -THIS PRODUCT IS INTENDED FOR USE IN ORDINARY INDOOR
RESIDENTIAL AREAS.
IT IS NOT DESIGNED TO MEASURE COMPLIANCE WITH
COMMERCIAL AND INDUSTRIAL STANDARDS.
1)The TEST/SILENCE button accurately tests the device functions. Do not
use any other test method. Test the device weekly to ensure proper
operation. Do not install in non-residential buildings. And the device is not a
substitute for a complete alarm system.
2)If you're sure it isn't a real alarm, open windows or fan the air around the
device to silence it.
3)Observe and follow all local and national electrical and building codes for
installation.
4)This Combo Smoke/CO alarm is designed to be used inside a single family
only. In multifamily buildings, each individual living unit should have its own
smoke alarm devices.
5)Install a Combo Smoke/CO alarm in every room and on every level of the
home. Smoke may not reach the smoke alarm for many reasons. For
example, if a fire starts in a remote part of the home, on another level, in a
chimney, wall, roof, or on the other side of a closed door, smoke may not
reach the device in time to alert household members. This Combo
Smoke/CO alarm will not promptly detect a fire or CO danger except in the
area or room in which it is installed.
6)This Combo Smoke/CO alarm may not alert every household member
every time. The alarm horn is loud in order to alert individuals to a potential
danger. However, there may be some circumstances where a household
member may not hear the alarm (i.e. outdoor or indoor noise, sound
sleepers, drug or alcohol usage, the hard of hearing, etc.). If you suspect
that this device may not alert a household member, should install and
maintain other specialty smoke alarm or/and CO alarm devices. Household
member must hear the alarm’s warning sound and quickly respond to it to
reduce the risk of damage, injury, or death that may result from fire. If a
household member is hard of hearing, install other special smoke alarm
or/and CO alarm with lights or vibrating devices to alert occupants.
7)This Combo Smoke/CO alarm can only sound their alarms when they
detect smoke or detect combustion particles or dangerous level of CO in
the air. They do not sense heat, flame, or other gas. The device is designed
to give audible warning of a developing fire. However, many fires are fast -
burning, explosive, or intentional, and others are caused by carelessness or
safety hazards. In these cases, smoke may not remake the unit alarm
QUICKLY ENOUGH to ensure safe escape.
8)This Combo Smoke/CO alarm have limitations. The device is not foolproof
and is not warranted to protect lives or property from fire. Smoke alarm
or/and CO alarm are not a substitute for insurance. Homeowners and
renters should insure their lives and property. In addition, it is possible for
the device to fail at any time. For this reason, you must test the device
weekly and replace every 10 years.
4. Installation instructions
1)In all sleeping rooms and guest rooms.
2)Outside of each separate dwelling unit sleeping area, within 21 feet (6.4 m)
of any door to a sleeping room, the distance measured along a path of travel.
3)On every level of a dwelling unit, including basements.
4)On every level of a residential board and care occupancy (small facility),
including basements and excluding crawl spaces and unfinished attics.
5)In the living area(s) of a guest suite.
6)In the living area(s) of a residential board and care occupancy.
7)Smoke, heat, and combustion products rise to the ceiling and spread
horizontally. Mounting the smoke alarm on the ceiling in the center of the room
places it closest to all points in the room. Ceiling mounting is preferred in
ordinary residential construction.
8)The device should be at least 6 feet (1.8 m ) above the floor level.
9)When mounting a device on the
ceiling, locate it at a minimum of 4 inch
(10 cm) from the side wall.
10)When mounting the device on the
wall, use an inside wall with top edge
the alarm at a minimum of 4 inch (10
cm) and maximum of 12 inch (30.5 cm)
below the ceiling.
11)Put the device at both ends of a
bedroom hallway or large room if the
hallway or room is more than 30 feet
(9.1 m) long.
12)Install the device on sloped, peaked
or cathedral ceilings at or within 3 feet
(0.9 m) of the highest point (measured
horizontally).
DINING
ROOM
LIVING
ROOM
BEDROOM BEDROOM
BEDROOM
KITCHEN
Single floor plan
LIVING
ROOM
BEDROOM
HALL
BEDROOM
KITCHEN
Multiple floor plan
4.2 Locations to avoid
To ensure the combo smoke/CO Alarm work properly and provide detection
performance, do not install the device in the following places:
1)Near appliances or areas where normal combustion regularly occurs
(kitchens, near furnaces, hot water heaters). Install at least 10 feet(3m)way
from these areas. Use specialized smoke alarm device with unwanted alarm
control for this areas.
2)In areas with high humidity, like bathrooms or areas near dishwashers or
washing machines or directly above a sink. Install at least 10 feet (3m)away
WARNING!- To prevent injury, this device must be securely attached
to the ceiling/wall in accordance with the installation instructions.
4.1 Recommended location for alarms
The following suggestions are intended to
help you with the placement and installation
of your combo smoke/CO alarm.
If you install only one device in your
home, install the device near
bedrooms, not in the basement or
furnace room.
1). Drilling two φ5.0mm holes in the
ceiling or wall, the distance between
two holes center is 75mm ( 2.95
inch), then inserting two plastic plugs
provided into the holes.
2). Attach the bracket to the plastic
plugs and fix tightly the screws into
the plastic plugs. Do NOT over-tight-
en screws.
3). Install the battery, see 'Battery
information'.
4). Install and rotate the alarm body
on the bracket.
5). Test the device by using the
TEST/SILENCE button. Ensure the
device sound is alarm pattern.
5. Understanding your combo smoke/CO alarm
5.1 Product overview
GREEN=POWER
YELLOW=FAULT
RED=ALARM
Voice
Tricolor indicator
TEST/SILENCE button
Sounder
1.POWER indicator(green)
The green indicator is used to indicate power status of the device.
2.FAULT indicator(yellow)
The yellow indicator is used to indicate malfunctions or low battery warning
status of the device.
3.ALARM indicator (red)
The red indicator is used to indicate alarm status of the smoke alarm or CO
alarm.
4.TEST/SILENCE button
The TEST/SILENCE button is used to test the device and to silence the unit
during a smoke alarm/carbon monoxide alarm. Press to keep it longer than 1
second to enable test function, or press to enable silence function.
5.Sounder/Speaker
The sounder/speaker is used to send out smoke alarm, CO alarm warning
and abnormal warning information.
5.2 Operation and testing
1)Operation
The alarm is operating once it is power on and testing is complete. When the
product alarms, the unit sounds a loud alarm with voice messages. See
sections 1 and 2 for alarm signal descriptions.
Smoke/CO alarms for required protection
Smoke/CO alarms for additional protection
Smoke alarms with silence control for additional protection
1. What to do if the smoke alarm sounds
2. What to do if the CO alarm sounds
Smoke alarm pattern is three long beeps with voice 'Fire!','Incendie!',
three long beeps, 1.5 seconds pause, repeating.
The smoke alarm takes precedence when both smoke and carbon monoxide
are present.
What to do in case of fire.
1.Do not be panic, stay calm.
2.While leaving, don't open any inside door without first feeling its surface. lf
hot, or if you see smoke seeping through cracks, don't open that door!
Instead, use your alternate exit. lf the inside of the door is cool, place your
shoulder against it, open it slightly and be ready to slam it shut if heat and
smoke rush in.
3. Meet at a pre-arranged meeting place outside the building.
4.Call the fire department or 911 from outside the building.
5.Do not go back inside a burning building. Wait for the fire department to
arrive.
NOTE: These guidelines will assist you in the event of a fire, however, to
reduce the chance that fires will start, practice fire safety rules and prevent
hazardous situations.
WARNING:
ACTUATION OF YOUR
CO ALARM INDICATES THE PRESENCE OF
CARBON MONOXIDE (CO) WHICH CAN KILL
IF ALARM SIGNAL SOUNDS :
1.Operate Test/Silence button; NOTE: Pressing the button on
the alarming unit will silence the alarm notification. If the unit
goes into alarm mode again within six minutes, it is sensing
high levels of CO which can quickly become a dangerous
situation.
2.Call your emergency services [Fire Department or 911]；
Telephone Number#：_____________________________
3.Immediately move to fresh air-outdoors or by an open
door/window. Do a head count to check that all persons are
accounted for. Do not reenter the premises nor move away
from the open door/window until the emergency services
responders have arrived, the premises have been aired out,
and your alarm remains in its normal condition.
4.After following steps 1-3, if your alarm reactivates within a
24 hour period, repeat steps 1-3 and call a qualified appliance
technician to investigate sources of CO from fuel burning
equipment and appliances, and inspect for proper operation
of equipment.
Telephone Number#：_____________________________
If problems are identified during this inspection have the
equipment serviced immediately. Note any combustion
equipment not inspected by the technician and consult the
manufacturers’ instructions, or contact the manufacturers
Carbon monoxide (CO) alarm pattern is four quick beeps with voice
'Warning! Carbon Monoxide', 'Attention! monoxyde de carbone!', four
quick beeps, 5 seconds pause, repeating. The ALARM indicator (red) will
flash the same pattern.
ATTENTION!- Please take a few minutes to thoroughly read the instruction
manual and familiarize yourself and your family with its operation. And save it
for future reference.
Images are representative only. Actual product may vary slightly.
Installation
Remove
holes of ceiling or wall
plastic plugs
two screws
alarm body
Before clipping
Button
3. To remove the alarm unit, press the button on the bracket while rotating the
bare unit counterclockwise.
1. Cut off the small triangular structure protruding from the bracket to enable
the locking feature.
2. Rotate the alarm clockwise to install the product.
4.5 Optional locking feature
The locking feature is designed to discourage unauthorized removal of the
Alarm. It is not necessary to activate the locks in single-family households
where unauthorized battery or Alarm removal is not a concern.
4.4 Installation of the alarm
Rotate clockwise (right) to install the alarm.
Rotate counterclockwise (left) to remove the alarm.
WARNING! -ACTION OF THIS DEVICE INDICATES THE PRESENCE OF
DANGEROUS LEVELS OF CO! CO CAN BE FATAL!
CAUTION! -This Combo Smoke/CO alarm is designed to detect carbon
monoxide gas from any source of combustion. It is not designed to detect
any other gas.
CAUTION! -This Combo Smoke/CO alarm will not protect against the
risk of smoke or carbon monoxide poisoning when the battery has been
drained.
WARNING! -Installation of the alarm should not be used as a
substitute for proper installation, use and maintenance of fuel burning
appliances including appropriate ventilation and exhaust systems.
CAUTION! -This device should be installed by a competent person.
CAUTION! -THIS DEVICE WILL ONLY INDICATE THE PRESENCE OF
CARBON MONOXIDE GAS AT THE SENSOR. CARBON MONOXIDE GAS
MIGHT BE PERSENT IN OTHER AREAS.
WARNING! -Individuals with medical problems may consider using
warning devices which provide audible and visual signals for carbon
monoxide concentrations under 30 ppm. This alarm has not been investi-
gated for carbon monoxide detection below 70 PPM.
There are situations where a smoke alarm may not be effective to protect
against fire as stated in the NFPA Standard 72. For instance: a) Fires
where the victim is intimate with a flaming initiated fire; for example, when
a person’s clothes catch fire while cooking; b) Fires where the smoke is
prevented from reaching the smoke alarm due to a closed door or other
obstruction; c) Incendiary fires where the fire grows so rapidly that an
occupants egress is blocked even with properly located smoke alarms.
WARNING!-Smoke alarms are not to be used with smoke alarm
guards unless the combination has been evaluated and found suitable
for that purpose.
WARNING!-This combo smoke/CO alarm requires a continuous
supply of electrical power – it will not work without power.
WARNING!-THIS DEVICE IS DESIGNED TO PROTECT INDIVIDUALS
FROM THE ACUTE EFFECTS OF CARBON MONOXIDE EXPOSURE. IT
WILL NOT FULLY SAFEGUARD INDIVIDUALS WITH SPECIFIC MEDICAL
CONDITIONS. IF IN DOUBT CONSULT A MEDICAL PRACTITIONER.
WARNING!-This product is intended for use in ordinary indoor
locations of family living units. It is not designed to measure compliance
with Occupational Safety and Health Administration (OSHA) commercial
or industrial standards.
WARNING!- IT IS NOT DESIGNED FOR USE IN A RECREATIONAL
VEHICLE (RV) OR BOAT.
from these areas.
3)Avoid spraying aerosols near the device.
4)Next to a door or window, an extractor fan, air returns or heating and cooling
supply vents. Install at least 3 feet(0.9m) away from these areas. The air
could blow smoke away from the device, interrupting its alarm.
5)In rooms where temperatures may fall below 0°C or rise above 40°C, or in
humidity higher than 95%. These conditions will reduce battery life or cause a
fault alarm.
6)In extremely dusty, dirty, or insect - infested areas influence particles
interfere with the device operation.
7)In the garage. Products of combustion are present when you start your
automobile.
8)In an enclosed space (for example in a cupboard or behind a curtain).
9)Where it can be obstructed (for example by furniture).
10)Less than 4 inch (10 cm) from the peak of an 'A' frame type ceiling.
11)Near fluorescent lights. Electronic 'noise' may cause nuisance alarms.
12)Place out of the reach of children. Under no circumstance should children
be allowed to handle the device.
13)Normal cooking may cause nuisance alarms. If a kitchen alarm is desired,
it should have an alarm silence feature and should not be installed within 6
feet(1.8m) of cooking appliances.
After the cut out
4.3 Installation instructions
CAUTION! -This device should be installed by a competent person.
WARNING! -This device should be located in an open and unobstructed
area and shall not be located behind furniture, drapes, or any other object
where it might not be seen or heard. The alarm shall be heard from all
sleeping areas.
WARNING! -Alarm users should add the phone numbers of their
emergency service providers and qualified technicians on the two self-adhe-
sive labels provided by the alarm manufacturer. Users should place one label
next to the alarm and another near the source of fresh air they plan to gather.
When the alarm indicates the presence of carbon monoxide, the user can
escape as planned.
04 05 06
To keep your combo smoke/CO alarm in good working order, please follow these
simple steps:
1.Verify the unit
’s
alarm sound and indictors operation by enable the
TEST/SILENCE button once a week.
2.Remove the unit from the ceiling and clean the alarm cover and vents with a
soft brush attachment once a month to remove dust and dirt.
3.Never use detergents or other solvents to clean the unit.
4.Avoid spraying air fresheners, hair spray, or other aerosols near the device.
5.Do not paint the device. Paint will seal the vents and interfere with the
sensor’s ability to detect CO. Never attempt to disassemble the unit or clean
inside. This action will void your warranty.
6.As soon as possible, place the combo smoke/CO alarm back in its proper
location to assure continuous protection from fire and carbon monoxide
poisoning.
7.When household cleaning supplies or similar contaminants are used, the area
should be ventilated.
WARNING! -The following substances can affect the sensor and may
cause false actions: methane, propane, isobutene, isopropanol, ethylene,
benzene, toluene, ethyl acetate, hydrogen sulfide, sulfur dioxides, alcohol
based products, paints, thinner, solvents, adhesives, hair sprays, after
shaves, perfumes and some cleaning agents.
WARNING! -Your combo smoke/CO alarm will not be operational and will
not monitor for smoke and CO levels without battery.
WARNING! -This apparatus is designed to protect individuals from the
acute effects of carbon monoxide exposure. It may not however, prevent the
chronic effects of carbon monoxide exposure and will not fully safeguard
individuals at special risk or with specific medical conditions. If in doubt
consult a medical practitioner.
8.1 Battery type
This alarm is powered by 2 replaceable 1,5V(AA) batteries located in a battery
compartment. Under normal conditions, a fresh battery should last at least one
year.
NOTE: Battery installation or replacement is necessary for the life of the
device.
WARNING: Constant exposure to low or high temperature or high humidity
may reduce battery life.
NOTE: Data comes from Siterwell labs. Actual battery life may vary
depending on product differences, usage habits, and environmental factors.
8.2 Battery deactivation
This alarm is equipped with a low battery monitor circuit. If the battery capacity
is near the point where it can no longer provide adequate power for all alarm
functions, the low battery condition will occur. See Troubleshooting Guide. The
battery must be replaced within 7 days of the first occurrence of the ‘Low
Battery Warning’ to provide continuous alarm protection.
Replace battery with one of the following approved brands:
ENERGIZER, Alkaline battery, 1.5V, E91,
Gold peak, Alkaline battery, 1.5V, GN15A,
These batteries can be purchased at your local retailer.
8.3 Battery disposal
WARNING!-Fire, explosion, and severe burn hazard. Do not recharge,
7. Carbon monoxide (CO) overview
6. General maintenance
11. Good safety habits
Prepare and practice a home escape plan twice a year, including drills at night.
Know two ways out of every room(door & window) and identify a meeting place
outside the home where everyone will gather once they have exited the
residence. When two people have reached the meeting place, one should leave
to call the fire department's telephone number while the second person stay to
account for additional family members. Establish a rule that once you're out,
you never reenter under any circumstance!
■Make a floor plan indicating all doors and windows and least two escape
routes from each room. Second story windows may need a rope or chain ladder.
■Have a family meeting and discuss your escape plan, showing everyone what
to do in case of fire and where to meet after they leave the house.
■Ensure that small children hear the alarm and wake when it sounds. They
must wake up on order to execute the escape plan. Practice allows all
occupants to test your plan before an emergency. You may not be able to reach
your children. It is important they know what to do.
■Familiarize everyone with the sound of the smoke/CO alarm and train them to
leave you home when they hear it.
■Current studies have shown smoke/CO alarms may not awaken all sleeping
individuals, and that it is the responsibility of individuals in the household that
are capable of assisting other to provide assistance to those who may not be
awakened by the alarm sound, or to those who may be incapable of safely
evacuating the area unassisted.
■Install and maintain fire extinguishers on every level of the home and in the
kitchen, basement and garage. Know how to use a fire extinguisher prior to an
emergency.
12. Service information
13. Warranty Information
Last Name:
First Name:
Phone:
Address:
City:
Country:
Zip Code:
Fault description:
Date of purchase:
Signature:
14. Warranty Card
Model: GS886
Product standards:
Conf. to UL STD 217 & 2034
Cert. to CAN/ULC STD S531-19 & CSA STD 6.19-17
Power Supply: 3VDC ( Energizer,E91,Gold peak,GN15A ) (replaceable)
Sensor of Smoke: Multi-Criteria Optical
Smoke Alarm Sensitivity: 2.08%/ft +/-25% OBS
Smoke alarm silence: About 8 minutes
CO silence: About 5 minutes
Sensor of CO: Electrochemical
Voice message system
CO alarm sensitivity Setting (Conforms to UL2034):
70PPM Between 60 to 240 minutes
150PPM Between 10 to 50 minutes
400PPM Between 4 to 15 minutes
Product life: 10 years after manufacture
Temperature Operating Range: 40°F (4.4°C) to 100°F (37.8°C)
Humidity Operating range: 10~95% RH non-condensing
Audible Alarm: ≥85dB at 10ft@ 3.0 to 3.5 KHz pulsing alarm, with voice
messages 'Fire!','Incendie!'and/or'Warning! Carbon Monoxide','Attention!
monoxyde de carbone!'.
Storage/Transport Ambient Condition: -20~+50°C, 10~95% RH non-con-
densing
Low Battery warning silence: About 10 hours
Installation Location: Ceiling or wall
Detection range: Max. 40 m² within a room.
Size: About φ155*41.8mm
Weight: 320±10g
NOTE: This combo smoke/CO alarm is designed to detect carbon
monoxide gas from any source of combustion. It is not designed to
detect any other gas.
9. Product Specifications
Smoke Nuisance
SILENCE: If you know why the alarm is sounding, and you can verify that it is
not a life threatening situation, you can push the button silence the alarm for
about 8 minutes. If the smoke is not too dense, that unit will be silenced. After
the SILENCE period, the smoke alarm will automatically reset and sound the
alarm if particles of combustion are still present. You can use SILENCE
repeatedly until the air has been cleared of the condition causing the alarm.
NOTE: Dense smoke will override SILENCE and sound a continuous alarm. If
no fire is present, check to see if one of the reasons listed in 'Locations to
avoid' may have caused the alarm. If a fire is discovered, get out and call the
fire department or 911.
This alarm is designed to minimize nuisance alarms. Cigarette smoke will not
normally cause the unit to alarm, unless the smoke is blown directly into the
alarm. Combustion particles from cooking may set off the alarm if it is located
too close to a cooking appliance. Large quantities of combustible particles are
generated from spills or when broiling. Using the fan on a range hood which
vents to the outside (non-recirculating type) will also help prevent nuisance
alarms from occurring by removing these combustible products from the
kitchen.
Carbon Monoxide (CO) Nuisance
RESET: Pushing the button during CO alarm allows the unit to reset
calculations and double check for the presence of CO. If the unit re-alarms
within 5 minutes, it is sensing high levels of CO which can quickly become a
dangerous situation. Exit to fresh air and call 911.
WARNING! - lt is impossible to determine the source of a CO alarm using
sight or smell. Always consider a CO alarm event as dangerous.
10. Recognizing Nuisance Alarms
3) Chirping
When End-of-Life or low battery chirping begins, you can temporarily silence
these chirps by pressing the TEST/SILENCE button. See Troubleshooting
Guide.
WARNING!-
Replace unit as soon as possible when in End-of-Life mode.
Carbon monoxide (CO) is a colorless, odorless, and tasteless poisonous
gas that can be fatal when inhaled. CO inhibits the bloods ability to carry
oxygen.
7.1 Possible Sources of CO
Inside your home, appliances used for heating and cooking are the most likely
sources of CO. Vehicles and other combustion engines running in an attached
garage and using a charcoal/gas grill or hibachi in an enclosed area are all
possible sources of CO. Generators running in enclosed areas, such as
garages or living spaces, will create CO. CO can be produced when burning
any fossil fuel: gasoline diesel, propane, natural gas, oil and wood. lt can be
produced by any fuel-burning appliance that is malfunctioning, improperly
installed, or not ventilated correctly, such as: Furnaces/boilers, gas ranges
stoves, gas clothes dryers, water heaters, portable fuel burning space heaters,
fireplaces, wood-burning stoves and certain swimming pool heaters. Blocked
chimneys or flues, back drafting and changes in air pressure, corroded or
disconnected vent pipes, or a loose or cracked furnace heat exchanger can
also release CO into your building.
7.2 The Following Conditions Can Result In Transient CO Situations
1) Excessive spillage or reverse venting of fuel-burning appliances may be
caused by:
i) Outdoor ambient conditions such as wind direction and/or velocity,
including high gusts of wind; heavy air in the vent pipes (cold/humid air
with extended periods between cycles).
ii) Negative pressure differential resulting from the use of exhaust fans.
iii) Simultaneous operation of several fuel-burning appliances competing for
limited internal air.
iv) Vent pipe connection vibrating loose from clothes dryers, furnaces, or
water heaters.
v) Obstructions in or unconventional vent pipe designs which amplify the
above situations.
vi) Poorly designed or maintained chimneys and/or vents.
2) Extended operation of unvented fuel-burning devices (such as ranges,
ovens, or fireplaces).
3) Temperature inversions that can trap exhaust gases near the ground.
4) Car idling in an open or closed attached garage, or near a home.
7.3 Symptoms of CO Poisoning
Initial carbon monoxide poisoning symptoms are similar to the flu with no fever
and can include dizziness, severe headaches, nausea, vomiting and disorien-
tation. Everyone is susceptible but experts agree that unborn babies, pregnant
women, senior citizensand people with heart or respiratory problems are
especially vulnerable. If symptoms of carbon monoxide poisoning are
experienced seek medical attention immediately. CO poisoning can be
determined by a carboxyhemoglobin test.
The following symptoms are related to CARBON MONOXIDE POISONING
and should be discussed with ALL members of the household:
1. MILD EXPOSURE: Slight headache, nausea, vomiting, fatigue (often
described as “Flu-like” symptoms).
2. MEDIUM EXPOSURE: Severe throbbing headache, drowsiness,
confusion, rapid heart rate.
3. EXTREME EXPOSURE: Unconsciousness, convulsions, cardiorespiratory
failure, and death.
The above levels of exposure relate to healthy adults. Levels may vary for
those at high risk. Many cases of reported carbon monoxide poisoning
indicate that while victims are aware they are not feeling well, they become
so disoriented they are unable to save themselves by either exiting the
building or calling for assistance. Additionally, young children and household
pets may be the first to be affected.
7.4 CO Safety Tips
Every year, have the heating system, vents, chimney and flue inspected and
cleaned by a qualified technician. Always install appliances according to
manufacturer's instructions and adhere to local building codes. Most
appliances should be installed by professionals and inspected after
installation.
Regularly examine vents and chimneys for improper connections, visible rust,
or stains, and check for cracks in furnace heat exchangers. Verify that the
color of flame is blue on pilot lights and burners. An amber or orange flame is
a sign that the fuel is not burning completely and may be releasing CO.
Teach all household members what the alarm sounds like and how to
respond. Fire Departments, most utility companies and HVAC contractors will
perform CO inspections. Some contractors may charge for this service. lt's
advisable to inquire about any applicable fees prior to having the service
performed. Siterwell will not pay for, or reimburse the owner or user of this
product, for any repair or dispatch calls related to the alarm sounding.
Install or replace battery:
1) Install or replace the battery:
Open the battery cover and Install or replace with new battery. (See Diagram
1-2)
2) After you Installed or replaced the battery:
Close the battery cover, then test smoke alarm using TEST/ SILENCE
button.(See Diagram 3)
2)Testing
Test your alarm weekly by pressing more than 1 second and
releasing the TEST/SILENCE button. See Other Alarm Visual and Audible
Indicators table. The alarm and voice will sound if the electronic circuitry, horn,
speaker, and battery are working. If the alarm or voice does not sound, or
gives erratic or low volume sound, the unit must be replaced.
5.3 Other Alarm Visual and Audible Indicators
5.4 Troubleshooting Guide
RED LED
flashes every
8 seconds
RED LED
flashes every
8 seconds
This feature is
to be used only
when a known
alarm condition,
such as smoke
from cooking,
activates the
alarm.
This feature can
help users
confirm whether
there is a CO
leak
Mute time for eight minutes
Mute time for five
minutes
Voice'Too much smoke,
cannot be silenced', 'Trop
de fumée, mode
silencieux impossible'.
Smoke
Alarm
Silent
Mode
High
smoke
levels
cannot be
silenced
CO Alarm
Silent
Mode
None None
RED LED
flashes every
40 seconds
This feature will
help the user
determine
which alarm
went off. This
status can
maintain 72
hours.
You can exit the
visual indicator
by pressing the
button 3 times
in succession.
The voice will
always exist.
Alarm
memory
mode
Operate
mode
Visual
(flash)
Audible
(beep/voice)
Description
mode
Power
on
Preheat 60
seconds, with
POWER
indicator
(Green LED)
flashes every 2
seconds
RED LED
flashes in time
with alarm
pattern.
Long press Test/Silence
button;Three long beeps,
Voice 'Fire!', 'Incendie!'.
Three long beeps; Pause
for a second, four quick
beeps, Voice 'Warning,car-
bon monoxide', 'Attention!
monoxyde de carbone!',
four quick beeps.
Press
Test/Silence
button once a
week to verify
proper alarm
operation
Standby Green LED
flashes every
40 seconds
Test
RED LED
flashes once a
second.
RED LED
flashes in time
with alarm
pattern.
Smoke
Alarm
CO
Alarm
None None
None None
None
None
Three long beeps with
voice 'Fire!','Incendie!',
three long beeps, 1.5
seconds pause, repeating.
Four quick beeps with
voice 'Warning! Carbon
Monoxide', 'Attention!
monoxyde de carbone!',
four quick beeps, 5
seconds pause, repeating.
End-of-
Life
Low
battery
warning
Yellow LED
flashes every
40 seconds
Yellow LED
flashes every
40 seconds
Yellow LED
flashes every
40 seconds
Review Cleaning Your
Alarm section. Remove
and dispose your unit, and
replace as soon as
possible
Review Alarm section.
Press Test/Silence button
once to attempt to reset
unit.
If error continues, remove,
dispose unit, and replace
as soon as possible
Voice'Smoke
sensor
error','Erreur du
capteur de
fumée'.
Voice'Low
battery', 'Pile
faible'.
After beep,
Voice ‘CO
sensor error’,
‘Erreur du
capteur de
CO’.
Voice ‘End of
life’, ‘Fin de
vie’.
Yellow LED
flashes twice
every 40
seconds
Smoke
Sensor
Fault
warning
CO
Sensor
Fault
warning
Trouble
Condition
Visual
(flash)
Audible
(beep/voice)
Description
mode/Action
Press Test/Silence button
once to silence for 10h.
Replace batteries as soon
as possible.
Press Test/Silence
button once to silence for
10 hours. Note:After 30
days of the first occurrence
of end of life signal, can
not be silenced anymore .
Remove and dispose your
unit, and replace as soon
as possible.
WARNING! - Exposure to high levels of carbon monoxide can be fatal or
cause permanent damage or disabilities.
WARNING! - This device may not prevent chronic effects of carbon
monoxide exposure or fully safeguard individuals at special risk.
Diagram 1 Diagram 2 Diagram 3
8. Battery information
crush, disassemble, heat above 100°C, incinerate or expose contents to
water.
1, Do not dispose of battery (or the device) as unsorted municipai waste, but
collect it separately.
2, Dispose of in accordance with all applicable federal, state and local
regulations.
WARNING!
-Due to the loudness of the alarm, always stand about 2.5 feet
away from the unit or use ear protection when testing.
WARNING!
-Do not use an open flame to test your alarm, you could
damage the alarm or ignite combustible materials and start a structure fire.
CAUTION!- Test the alarm for correct operation using the test facility
whenever the battery is replaced.
NOTE: A missing or improperly installed battery will prevent the battery door
from closing and result in improper alarm operation
WARNING! -Use only the batteries specified. Use of different batteries
may have a detrimental effect on the alarm.
NOTE: Do not use lithium batteries in this unit. A good safety measure is to
replace the battery at least once a year.
Develop and practice a plan of escape
After button pressed, “Fire
alarm before, The total
number of historical alarms
is X”，“Alarme incendie
avant, Le nombre total
d'alarmes en mémoire est
de X”；“Carbon monoxide
alarm before, XXX PPM”
The total number of
historical alarms is“ X”，
“détection de monoxyde de
carbone avant, XXX PPM”，
Le nombre total d'alarmes
en mémoire est de X”.
Manufactured by:
SITERWELL ELECTRONICS CO.,LIMITED
No.666 Qingfeng Road, Jiangbei District, Ningbo, Zhejiang, China.
Distributed by:
Menard, Inc.
Eau Claire, WI 54703 U.S.A.
Visit MENARDS.COM
10-YEAR LIMITED WARRANTY
If this PERFORMAXTM product fails to perform to your satisfaction under normal
use within the 10-year limited warranty period, return the product to a Menards®
retail store for a replacement of the same or similar PERFORMAXTM product.
