Sen sitivity Setting: C o nforms to U L S td.UL2034 4th Ed
Keep the CO alarm away from excessively dusty, dirty, or greasy areas such as kitchens,
Do not install in areas where the temperature is below -10 or hotter than
Do not place behind curtains or furniture. CO must be able to reach the sensor for the
Keep out of damp and humid areas such as the bath room. Avoid spraying aerosols
2.1 POWER INDICATOR
The power indicator (green LED) is used to indicate power status of the CO alarm. The
power indicator will flash every 40 seconds.
2.2 FAULT INDICATOR
The fault indicator (yellow LED) is used to indicate fault or warning status of the CO alarm.
2.3 ALARM INDICATOR
The alarm indicator (red LED) is used to indicate alarm status of the CO alarm.
2.4 TEST/SILENCE BUTTON
The TEST/SILECNE button is used to test the unit. Press and hold to enable test function.
2.5 ALARM SOUNDER
The alarm sounder is used to send out CO alarm warning and fault warning information.
2.6 LCD SCREEN
Indicates CO concentration and alarm status.
S
The power indicator (green LED) blink once every 40 seconds.
fault
fault
fault
fault
fault
fault
Press the TEST/SILENCE button within 1 second, the LCD displays a maximum
concentration as detected before press, LCD will display as following figure 3.11.1, and
restores the current concentration after 10 seconds. LCD will display as follow figure
3.11.2.
Once chirps with corresponding fault indicator (yellow LED) flashing once every 40
seconds indicates that the battery is low battery, you must to replace the battery with
battery specified, please see "8. Specification" To install or replace the battery in unit,
please perform the following steps:
WARNING!
- Use only the
battery specified. Use of different
battery may have a detrimental effect
on the CO alarm. A good safety mea-
sure is to replace the battery at least
once a year,or at the same time as you
change your clocks for daylight saving
time.
CAUTION: Please replace new 2pcs
same type batteries in the meantime.
CAUTION: Test the alarm for correct
operation using the TEST/SILENCE
distance : 52mm
holes of the wall
plastic stopper
Ref: 358-8402
Sen sitivity Setting: Confo rms to U L S td.UL2034 4th Ed
Sen sitivity Setting: Confo rms to U L S td.UL2034 4th Ed
WARNING!
- The following
substances can affect the sensor and
may cause false actions: methane,
propane, isobutene, isopropanol, eth-
ylene, benzene, toluene, ethyl acetate,
hydrogen sulfide, sulfur dioxides,
alcohol based products, paints, thin-
ner, solvents, adhesives, hair sprays,
after shaves , perfumes and some
cleaning agents.
WARNING!
- This carbon
monoxide alarm requires a continuous
supply of electrical power - it will not
work without power. Models without
battery backup will not operate during
power failure.
WARNING!
- This apparatus is
designed to protect individuals from
the acute effects of carbon monoxide
exposure. It will not fully safeguard
individuals with specific medical con-
ditions. If in doubt consult a medical
practitioner.
IMPORTANTZ:
This carbon mon-
oxide alarm is designed to detect
carbon monoxide from ANY source of
combustion. It is NOT designed to
detect smoke, fire, or any other gas.
WARNING!
- The installation
of this device should not be used as a
substitute for proper installation, use
and maintenance of fuel burning appli-
ances, including appropriate ventila-
tion and exhaust systems. It does not
prevent CO from occurring, nor can it
solve an existing CO problem.
Individuals with medical problems
may consider using warning devices
which provide audible and visual sig-
nals for carbon monoxide concentra-
tions under 30 PPM.
This alarm has not been investigated
for carbon monoxide detection below
70 PPM.
WARNING!
- This product is
intended for use in ordinary indoor
locations of family living units. It is not
designed to measure compliance with
Occupational Safety and Health Admin-
istration (OSHA), commercial or indus-
trial standards. It is not suitable for
installation in hazardous locations as
defined in the National Electric Code.
WARNING!
- Carbon monoxide
alarms are not smoke alarms. This
carbon monoxide alarm is not a substi-
tute for installing and maintaining an
appropriate number of smoke alarms in
your home. This carbon monoxide
alarm will not sense smoke, fire, or any
poisonous gas other than carbon mon-
oxide even though carbon monoxide
can be generated by fire. For this
reason you must install smoke alarms
to provide early warning of fire and to
protect you and your family from fire
and its related hazards.
CAUTION:
This alarm will only
indicate the presence of carbon monox-
ide at the sensor. Carbon monoxide
may be present in other areas.
WARNING! - This product is intended
for use in ordinary indoor locations of
family living units, not for use in boats
or recreational vehicles. It is not
designed to measure compliance with
commercial or industrial standards. It is
carbon monoxide poisoning
all
7.2.4 Many cases of reported carbon monoxide poisoning indicate that while victims are
aware they are not well, they become so disoriented they are unable to save themselves by
either exiting the building or asking for assistance. Young children and household pets are
typically the first affected. The above levels of exposure relate to healthy adults. Levels
differ for those at high risk. Exposure to high levels *of carbon monoxide can be fatal or
cause permanent damage and disabilities. Many cases of reported carbon monoxide
poisoning indicate that while victims are aware they are not well, they become so
disoriented they are unable to save themselves by either exiting the building, or calling for
assistance. Also, young children and household pets may be the first effected. Familiar with
the effects of each level is important.
WARNING!
- Exposure to high
levels of carbon monoxide can be fatal or
cause permanent damage and disabilities.
WARNING!
- The device may not
prevent the chronic effects of carbon
monoxide exposure, and that the device
will not fully safeguard individuals at
special risk.
A
W
Operation Ambient Condition: 40°F(4.4°C)~100°F(+37.8°C), 30 ~ 95%RH noncondensing
Storage/Transport Ambient Condition: -20°C~+50°C,10 ~ 95%RH non-condensing
Alarm sound: 85dB@3m; with 3.08±0.5KHz pulsing alarm
Manufactured by:
SITERWELL ELECTRONICS CO.,LIMITED
No.666 Qingfeng Road, Jiangbei District, Ningbo, Zhejiang, China.
Distributed by:
Menard, Inc.
Eau Claire, WI 54703 U.S.A.
Visit MENARDS.COM
10-YEAR LIMITED WARRANTY
If this PERFORMAX
TM
product fails to perform to your satisfaction under normal use within the
10-year limited warranty period, return the product to a Menards® retail store for a replacement of
the same or similar PERFORMAX
TM
product.
