Hotpoint HTX8015DNF Piano cottura a induzione Ariston User Manual

750 mm

R = Max. 10 mm

Min. 35 mm

750 mm

R = 11.5 mm

513 mm

Min. 490 mm

Max. 492 mm

50 mm

Min. 490 mm

Max. 492 mm

4 mm

741 mm

510 mm

489 mm

800 mm

R = Max. 10 mm

R = 11.5 mm

803 mm

6mm

OCTOSEAL S70

min. 45 mm

min. 550 mm

A-A

min. 35 mm

min. 400 mm

min.100 mm

min.

12 mm

min. 10 mm

min. 12 mm

min. 10 mm

min. 20 mm

min. 64 mm

min. 12 mm

min. 10 mm

min. 20 mm

A-A

min. 20 mm

min. 12 mm

min. 64 mm

A-A

min. 64 mm

min.

28 mm

min. 28 mm

20 mm

min. 10 mm

A-A

min. 64 mm

90°C

XX 1234X XX

XXXX XXXX XXXX

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings to be observed at all times.

The manufacturer declines any liability for failure to

observe these safety instructions, for inappropriate use

of the appliance or incorrect setting of controls.

WARNING: If the hob surface is cracked, do not use

the appliance - risk of electric shock.

WARNING: Danger of re: Do not store items on the

cooking surfaces.

CAUTION: The cooking process has to be supervised.

A short cooking process has to be supervised

continuously.

WARNING: Unattended cooking on a hob with fat or

oil can be dangerous - risk of re. NEVER try to extinguish

a re with water: instead, switch o the appliance and

then cover ame e.g. with a lid or a re blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away from

the appliance, until all the components have cooled

down completely - risk of re.

Metallic objects such as knives, forks, spoons and

lids should not be placed on the hob surface since they

can get hot.

Very young children (0-3 years) should be kept away

from the appliance. Young children (3-8years) should

be kept away from the appliance unless continuously

supervised. Children from 8years old and above and

persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge can

use this appliance only if they are supervised or have

been given instructions on safe use and understand

the hazards involved. Children must not play with the

appliance. Cleaning and user maintenance must not be

carried out by children without supervision.

After use, switch o the hob element by its control

and do not rely on the pan detector.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid

touching heating elements. Children less than 8 years

of age shall be kept away unless continuously

supervised.

The food must not be left in or on the product for

more than one hour before or after cooking.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: sta kitchen areas in

shops, oces and other working environments; farm

houses; by clients in hotels, motels, bed & breakfast and

other residential environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not use

the appliance outdoors.

WARNING: Induction hob may generate the acoustic

sound when something is left on the control panel.

Switch o the cooktop through the ON/OFF button.

INSTALLATION

The appliance must be handled and installed by two

or more persons - risk of injury. Use protective gloves to

unpack and install - risk of cuts.

Installation, including water supply (if any), electrical

connections and repairs must be carried out by a

qualied technician. Do not repair or replace any part

of the appliance unless specically stated in the user

manual. Keep children away from the installation site.

After unpacking the appliance, make sure that it has

not been damaged during transport. In the event of

problems, contact the dealer or your nearest After-sales

Service. Once installed, packaging waste (plastic,

styrofoam parts etc.) must be stored out of reach of

children - risk of suocation. The appliance must be

disconnected from the power supply before any

installation operation - risk of electric shock. During

installation, make sure the appliance does not damage

the power cable - risk of re or electric shock. Only

activate the appliance when the installation has been

completed.

Carry out all cabinet cutting operations before tting

the appliance and remove all wood chips and sawdust.

ELECTRICAL WARNINGS

It must be possible to disconnect the appliance from

the power supply by unplugging it if plug is accessible,

or by a multi-pole switch installed upstream of the

socket in accordance with the wiring rules and the

appliance must be earthed in conformity with national

electrical safety standards.

Do not use extension leads, multiple sockets or

adapters. The electrical components must not be

accessible to the user after installation. Do not use the

appliance when you are wet or barefoot. Do not operate

this appliance if it has a damaged power cable or plug,

if it is not working properly, or if it has been damaged or

dropped.

Installation using a power cable plug is not allowed

unless the product is already equipped with the one

provided by the Manufacturer.

If the supply cord is damaged, it must be replaced

with an identical one by the manufacturer, its service

agent or similarly qualied persons in order to avoid a

hazard - risk of electric shock.

CLEANING AND MAINTENANCE

WARNING: Ensure that the appliance is switched o

and disconnected from the power supply before

performing any maintenance operation; never use

steam cleaning equipment - risk of electric shock.

SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

Do not use abrasive or corrosive products, chlorine-

based cleaners or pan scourers.

DISPOSAL OF PACKAGING MATERIALS

The packaging material is 100% recyclable and is marked with the recycle

symbol

The various parts of the packaging must therefore be disposed of responsibly

and in full compliance with local authority regulations governing waste

disposal.

DISPOSAL OF HOUSEHOLD APPLIANCES

This appliance is manufactured with recyclable or reusable materials.

Dispose of it in accordance with local waste disposal regulations. For further

information on the treatment, recovery and recycling of household electrical

appliances, contact your local authority, the collection service for household

waste or the store where you purchased the appliance. This appliance is

marked in compliance with European Directive 2012/19/EU, Waste Electrical

and Electronic Equipment (WEEE) and with the Waste Electrical and Electronic

Equipment regulations 2013 (as amended).

By ensuring this product is disposed of correctly, you will help prevent

negative consequences for the environment and human health.

The symbol

on the product or on the accompanying documentation

indicates that it should not be treated as domestic waste but must be taken to

an appropriate collection center for the recycling of electrical and electronic

equipment.

ENERGY SAVING TIPS

Make the most of your hot plate’s residual heat by switching it o a few

minutes before you nish cooking.

The base of your pot or pan should cover the hot plate completely; a container

that is smaller than the hot plate will cause energy to be wasted.

Cover your pots and pans with tight-tting lids while cooking and use as

little water as possible. Cooking with the lid o will greatly increase energy

consumption.

Use only at-bottomed pots and pans.

DECLARATION OF CONFORMITY

This appliance meets Ecodesign requirements of European Regulation

66/2014 and The Ecodesign for Energy-Related Products and Energy

Information (Amendment) (EU Exit) Regulations 2019 in compliance with the

European standard EN 60350-2.

The information related to low power mode of the appliance in accordance

with Regulation (EU) 2023/826 can be found in the following link: https://docs.

emeaappliance-docs.eu.

NOTE

People with a pacemaker or similar medical device should use care when

standing near this induction cooktop while it is on. The electromagnetic

eld may aect the pacemaker or similar device. Consult your doctor, or

the manufacturer of the pacemaker or similar medical device for additional

information about its eects with electromagnetic elds of the induction

cooktop.

ELECTRICAL CONNECTION

Electrical connection must be made before connecting the appliance to the electricity supply.

Installation must be carried out by qualied personnel familiar with the current safety and installation regulations. Specically, installation must be carried out in

compliance with the regulations of the local electricity supply company.

Make sure the voltage specied on the data plate located on the bottom of the appliance is the same as that of the home.

Regulations require that the appliance be earthed; use conductors (including the earth conductor) of the appropriate size only.

220-240 V

220-240 V 3

230V 2 Phase 2N

380-415 V 2 N ~

380-415 V 3 N ~

blue-blu-azul-azul-μπλε-sinine-zila-mėlyna-niebieski-blau-bleu-blauw-albastru-синьо-плава-modro-

plava-синий-синій-көк-modrý-modrý-kék-blå-sininen-blå-blåt-mavi-gorm- blár-כחול

blue (gray)-blu (grigio)-azul (gris)-azul (cinza)-μπλε (γκρι)-sinine (hall)-zila (pelēka)-mėlyna (pilkas)-

niebieski (szary)-blau (grau)-bleu (gris)-blauw (grijs)-albastru (gri)-синьо (сиво)-плава (сива)-

modro (sivo)-plava (siva)-синий (серый)-синій (сірий)-көк (сұр)-modrý (šedá)-modrý (sivá)-

kék (szürke)-blå (grå)-sininen (harmaa)-blå (grå)-blåt (gråt)-mavi (gri)-gorm (liath)- blár (grár)-כחול (אפור)

yellow/green-giallo/verde-amarillo/verde-amarelo/verdeκίτρινο/πράσινο-kollane/roheline-dzeltens/zaļš-

geltona/žalia-żółty/zielony-gelb/grün-jaune/vert-geel/groen-galben/verde-жълто/зелено-жуто/зелена-

rumeno/zeleno-žuto/zelena-желтый/зеленый-жовтий/зелений-жасыл/сары-žlutá/zelená-žltá/zelená-

sárga/zöld-gul/grønn-keltainen/vihreä-gul/grön-gul/grøn-sarı/yeşil-buí/glas- gulur/grænn-צהוב/ירוק

black-nero-negro-preto-μαύροσ-must-melns-juodas-czarny-schwarz-noir-zwart-negru-черно-црн-

črna-crno-черный-чорний-қара-černá-čierna-fekete-svart-musta-svart-sort-siyah-dubh-svartur-שחור

brown-marrone-marrón-marrom-καφέ-pruun-brūns-rudas-brązowy-braunen-brun-bruin-maro-кaфяв-

браон-rjava-smeđ-коричневый-коричневий-қоңыр-hnědý-hnedý-barna-brunt-ruskea-brunt-brun-

kahverengi-donn-brúnn-חום

PRODUCT DESCRIPTION

1. Cooktop

2. Control panel

CONTROL PANEL

11 12 16 1914

1. Flexi Zone button

2. Cooking zone OFF button

3. Scroll keypad

4. Arrows to set Temperature/Timer

5. Fast heating button (Booster)

6. Preheat/Cool down indicator

7. Cooking zone display

8. Indicator light – function active

9. Timer button

10. On/O button

11. Assisted Boil (Boil&Cook) button

12. Wipe function button

13. Key lock button – 3 seconds

14. Symbols/Activation of special functions

15. Temperature indicator (degrees Celsius)

16. Minutes indicator

17. Timer indicator symbol

18. Heat control button

19. Special function button

NOTE: Press the ON/OFF button (10); all the available functions will become visible for a few moments, after which only the main ones will remain active. The

others can be used, and will be activated, during the subsequent use of the device.

IMPORTANT: All the available functions will be illuminated in dim light intensity, which will become more intense only when they are activated.

THANK YOU FOR BUYING A HOTPOINT/ARISTON PRODUCT

In order to receive a more complete assistance, please register

your product on www.

register10.eu.

PLEASE SCAN THE QR CODE ON

YOUR APPLIANCE IN ORDER TO

REACH MORE INFORMATION

Before using the appliance carefully read the Safety

Instruction.

Owner's manual

ACCESSORIES

Only use pots and pans made from ferromagnetic material suitable for induction

hobs. Check for the

symbol (generally stamped on the bottom) to determine

whether a pot is suitable. A magnet may also be used to check whether the

cookware base is magnetic.

COOKWARE MATERIAL PROPERTIES

Recommended

cookware

Base made of stainless steel with

a sandwich design, enamelled

steel, cast iron.

Ensures optimum efficiency,

heats up quickly, and distributes

heat evenly.

Suitable cookware

Base not fully ferromagnetic

(magnet sticks only on part of the

cookware base).

Only the ferromagnetic area

heats up. As a result, may heat

up less quickly and heat may be

distributed less evenly.

Suitable cookware

Ferromagnetic base contains

areas with aluminium, or has a

recessed area in the centre.

The ferromagnetic area is smaller

than the actual cookware base

area. As a result, less power may

be delivered and cookware may

not heat suciently. Cookware

may not be detected.

Not suitable Normal thin steel, glass, clay,

copper, aluminium and other

non-ferromagnetic materials,

cookware with rubber feet.

Cookware is not detected and

will not heat up.

NOTE: All cookware must have a at base. Periodically check the base for any

sign of warping, as some cookware may undergo deformation due to high heat.

Using cookware that does not match the recommended sizes and properties

may signicantly aect cooking performance and cause unsatisfactory results.

ADAPTERS FOR POTS/PANS UNSUITABLE FOR INDUCTION

The use of adapter plates aects eciency and therefore increases the time

required to heat water or food. Make sure the ferromagnetic diameter of the

cookware base aligns with both the diameter of the adapter plate and the

diameter of the cooking zone. If these measurements don't match, eciency

and performance may be signicantly reduced. If these guidelines are not

followed, there may be a heat build-up that is not eectively transferred to the

pot or pan, potentially causing blackening of the plate and hob.

EMPTY POTS AND PANS

The hob is equipped with an internal safety system that activates the “Automatic

o” function when an over-high temperature is detected. The use of empty

pots and pans with a thin base is not recommended but, if they are used, the

temperature might rise quicker than the time needed for the “Automatic o” to

be triggered promptly, with the risk of damaging the pan or the hob surface. If

this happens, do not touch the pan or the hob surface. Wait for all components

to cool down. If any error message is displayed, call the Service Centre.

SUITABLE SIZE OF PAN/POT BASE FOR THE DIFFERENT COOKING

ZONES

To ensure that the hob works properly, use pots of a suitable base diameter for

each zone (refer to the table below). Please note that cookware manufacturers

often provide the size of the upper diameter of the cookware, rather than the

base diameter.

To ensure that the hob works as expected, always use a cooking zone with a size

matching the ferromagnetic size of the cookware base.

Centre the pan/pot correctly on the cooking zone in use. It is recommended

not to use pots larger than the size of the cooking zone.

COOKWARE USAGE BY ZONE

Zone Suitable cookware

shape

Suitable ferromagnetic

base (cm)

1 or 2 Round or Square 16 - 21

3 Round 16 - 21

4 Round 10 - 15

1+2

(Flexi Zone)

Oval or Rectangular

Short side 16 - 21

Long side 24 - 38

FIRST TIME USE

POWER MANAGEMENT

At the time of purchase, the hob is set to the maximum power. Adjust the

setting on the basis of the limits of your domestic electrical system, as explained

in the following paragraph.

NOTE: Depending on the power selected for the hob, some of the cooking

zone power levels and functions (e.g. boil or fast heating) may be automatically

limited to prevent the selected limit from being exceeded.

The table below shows the power used by each zone for each function, to help

you understand the possible usage limitations based on the chosen power

setting.

ZONE 1 or 2 1 + 2 3 4

POWER LEVEL 18 (KW) 2.2 2.2 2.5 1.5

BOOSTER (KW) 3.7 3.7 3.7 2.2

HEAT CONTROL (KW) 1.4 NA 1.4 NA

ASSISTED BOIL (BOIL&COOK) (KW) 3.0 NA 3.0 NA

MELTING (KW) NA NA NA 0.045

KEEP WARM (KW) NA NA NA 0.145

Examples with reference to the values in the table above:

If you set the “Power management setting” at 4 kW and activate multiple

cooking zones simultaneously, the hob will automatically adjust the power

levels not to exceed the overall power limit (e.g. 4 kW).

For example, with the “Power management setting” set at 4 kW, if you set zone

3 at “Booster” (=3.7 kW) and then try to activate zone 1 at level 18 (2.2 kW), the

overall power supplied would exceed the limit of 4 kW (3.7 + 2.2 = 5.9 kW). For

this reason, the hob will automatically adjust the power levels as follows: the

cooking zone set to “Booster” will be set at level 18 (=2.2 kW), while the second

cooking zone at level 15 (=1.6 kW, the maximum power level not to exceed

the 4 kW limitation).

Setting Menu: Changing the basic settings

Once you have connected the device to the main power supply, you can

change the default settings by entering the Setting menu within 60 seconds:

1. After connecting the hob to the main power supply, wait until all the LEDs

turn on and o consecutively.

2. Press and hold the On/O button (

)

to turn on the hob.

3. Press the Key-lock button (

) for at least 6 seconds to enter the Setting

menu. Ignore the key-lock activation sound that you will hear after 3 seconds

of pressing.

4. The setting type (eg."PL") will be shown on the top-left cooking zone

display, and its default (or current) value (eg."2_5") will appear on the

bottom-left cooking zone display.

5. You can select the setting type by using up (

) and down ( ) arrows of

the top-left cooking zone. You can change its value by using up (

) and

down (

) arrows of the bottom-left cooking zone. See the table below for

the setting types, default values and possible values.

6. Press the On/O button to conrm.

7. Without the conrmation, the hob will quit the Setting menu and return to

the previous values within 30 seconds.

ORDER

SETTING

TYPE

TOP-LEFT

BOTTOM-LEFT

(DEFAULT)

POSSIBLE VALUES

Power

Limitation

PL 7_4

2_5 kW ; 4_0 kW ;

6_0 kW ; 7_4 kW

2 Audio tone Aud On On/O

3 Demo mode dE O O/On

NOTE: once the demo mode function has been activated, it will remain ON

even if the main power supply is interrupted.

DAILY USE

SWITCHING THE HOB ON/OFF

To turn on the hob, press and hold the power button. The LED above the button

will turn on, and you will hear an acoustic signal. After a few seconds, you can

interact with the hob. To turn the hob o, press the same button again; all the

cooking zones will be deactivated.

POSITIONING

Do not cover the control panel symbols with the cooking pot.

Note: In the cooking zones close to the control panel, it is advisable to keep

pots and pans inside the markings (taking into consideration both the bottom

of the pan and its upper edge, as this tends to be larger).

This prevents excessive overheating of the keypad. When grilling or frying, use

the rear cooking zones if possible.

ACTIVATING/DEACTIVATING COOKING ZONES AND ADJUSTING

POWER LEVELS

OFF

To activate the cooking zones:

When the hob is turned ON, the scroll keypad (SLIDER) of all available cooking

zones will turn ON in low luminosity. Place your nger on the scroll keypad

(SLIDER) of the zone you want to activate, and gently slide it to the right if you

want to increase the power level or to the left to decrease it. You will notice that

the control keypad segments will shift to high luminosity based on the selected

power level, and the display digits will show the number corresponding to the

power level selected (from 1 to 18).

The ”P” button can be used to select the fast heating function (Booster) to quickly

boil water.

To deactivate the cooking zones:

Select the “OFF“ button at the beginning of the scroll keypad.

NOTE: Water spillage, food overow and/or an object positioned on the

control panel buttons can mimic your nger and accidentally activate or

deactivate any of the hob buttons. If such elements are not removed within 8

seconds, the hob makes two short acoustic sounds and switches OFF by itself

while showing the "OFF" message.

CONTROL PANEL LOCK

The control panel lock function is designed to lock the hob settings, to prevent

accidental changes to the settings or the unintentional activation/deactivation

of the functions. You may need to use this function for example in case of

possible liquid or food spillage, or for safety reasons (children's accidental

interaction with the hob) to prevent any risk of the hob turning on by accident.

To use the control panel lock function press and hold the

button for 3 seconds.

The button switches to high luminosity and a beep and a light above the symbol

indicate that this function has been activated. To unlock the controls, repeat the

activation procedure.

NOTE: The control panel is locked except for the switching o function. If you

turn your hob o with the control panel lock active, press the ON/OFF button

and then press the lock button for 3 sec to unlock the hob.

WIPE FUNCTION

The wipe function temporarily locks the buttons of the user interface to prevent

accidental changes to the settings during the cleaning process. The function

doesn’t interrupt the cooking process.

Wipe function helps to prevent any sounds if water spills on the user interface

during the cooking process or during your habitual cleaning.

For safety reasons, the ON/OFF button can be activated, even involuntarily,

during cleaning.

To activate the Wipe function:

1. Press Wipe function button (

)

. You will hear an acoustic sound when

the function is active.

2. The LED above the button will turn on and stay on while the button itself

ashes for the entire duration of the function activity.

3. The control panel remains locked for 30 seconds.

TIMER

The timer controls all the active cooking zones.

To activate the timer:

1. Select the cooking zone and set the required power level.

2. The timer button will turn on approximately 5 seconds after the cookware

has been recognised. Press it until an indicator light turns on in line with

the specic symbol on the chosen cooking zone.

3. Use the up (

) and down ( ) arrows to set the time (don't press and

hold them for more than 8 seconds, otherwise the hob shows OFF. For more

information, refer to the "Troubleshooting" section). The time will change

from 000 seconds to 30 minutes, increasing by 1 minute each time; from 30

to 150 minutes, the time will increase in steps of 5 minutes. If you need to

change the time by 10 minutes, use the side dashes. The dash on the left

will subtract 10 minutes, while the dash on the right will add 10 minutes (see

following image).

4. To conrm the time set, you can press the clock button (

)

. Otherwise, the

time will be automatically conrmed after 5 seconds without any action.

5. You can change the time at any point and activate multiple timers

simultaneously.

6. During the countdown, tap with your nger on the slider to see the power

level. Tap the up (

) or down ( ) arrow to see the set temperature.

After 3 seconds, the countdown will reappear.

7. Once the timer has elapsed, a beep will sound, and the cooking zone will

switch o automatically.

To deactivate the timer:

Press the down arrow (

) until it shows 000, and it will be deactivated after 5

seconds.

TIMER INDICATOR

This LED (when ON) indicates that the timer has been set for the cooking zone.

MAXIMUM WORKING TIME OF COOKING ZONES AND FUNCTIONS

Power level or function OFF 1-3 4-6 7-9 10-12 13-15 16-18 Booster * Booster ** Melting Keep warm

Maximum working time - 8 h 6 h 4 h 3 h 2 h 1.5 h 10 min. 5 min. 8 h 8 h

Power level after time-out - 0 0 0 0 0 0 18 18 0 0

* Cooking Zone 1, 2, 3

** Cooking Zone 4

Examples regarding the values in the table above:

If you turn on a cooking zone and set its power to level 14, the cooking zone will continue working for a maximum of 2 hours. After 2 hours, the power level will drop to level

0 and the cooking zone will turn off automatically. If there are no other active cooking zones and there is no interaction with the control panel buttons within 30 seconds,

the hob will turn off automatically.

If you activate the Booster function on cooking zone 4, it will automatically drop to power level 18 after 5 minutes. On the other hand, if you activate the Booster function

on cooking zone 1, 2 or 3, it will automatically drop to power level 18 after 10 minutes. After 1.5 hours, the power level will drop to level 0 and the cooking zone will turn off

automatically. If there are no other active cooking zones, and there is no interaction with the control panel buttons within 30 seconds, the hob will turn off automatically.

Owner's manual

FUNCTIONS

P BOOSTER FUNCTION

Booster is a special mode with a power level higher than level 18, for the fastest

heating. This mode can have a dierent duration depending on the zone used

(refer to table below). After the Booster time has elapsed, the power will be

automatically reduced to level 18.

IMPORTANT: Do not use with an empty pan or oil/butter. This function is ideal

for boiling water.

NOTE: Depending on the Power Management setting, the Booster function

may not be available for certain cooking zones. Furthermore, if you set one

cooking zone to Booster and then activate another zone, the rst one will

be reduced to the maximum level available (even much lower than level 18)

to allow the second one to be used. The second cooking zone will be set or

limited based on the remaining power available on that side of the hob.

Please bear in mind as well that the power delivery may vary according to the

size and material of the cookware being used.

ZONE DESCRIPTION

Zone Nominal power

(Level 18, kW)

Power

Booster (kW)

Booster

Duration (min.)

1 or 2 2.2 3.7 10

3 2.5 3.7 10

4 1.5 2.2 5

1+2

(Flexi Zone)

2.2 3.7 10

NOTE: the values in the table refer to testing conditions as described in the normative standard for

evaluating the performance of cooking appliances.

The power shown may vary depending on the size or material of the cookware used.

FLEXIBLE COOKING ZONE (FLEXI ZONE)

With this function you can combine two cooking zones into a single, longer one

to accommodate rectangular, oval or elongated cookware, and use a single

setting for the whole combined zone.

To ensure the correct results, use only pots and pans with a ferromagnetic base

long enough to cover the two zones at the same time. Place the cookware in the

centre of the exible cooking rectangular area.

Refer to the gure below for examples of correct and incorrect usage.

NOTE: A large round pot used in the middle may heat up less quickly and heat

may be distributed less evenly.

IMPORTANT: With pots and pans with a ferromagnetic base of 21 cm or smaller,

it is recommended to use the single cooking zones without activating the

exible cooking mode (Flexi Zone). Place the cookware on either the front or

rear zone, then activate that zone.

If the Flexi Zone is active, the Heat Control function will not be available or

displayed on the control panel.

Refer to the gure below for examples of correct and incorrect usage.

Flexi Zone used as two individual zones

When used with two pots or pans at the same time, it is advisable to place the

rst one on the rear zone and the second on the front zone (refer to gure

below). In this case, the zones should be activated without using the exible

cooking mode (Flexi Zone).

For optimal performance, make sure both pans are centred in their respective

zones. Do not move one pot/pan o-centre to make space for the other one.

When positioning the cookware, do not go outside the cooking zone area or on

top of the control panel.

Refer to the gure below for examples of correct and incorrect usage.

AUTOMATIC FUNCTIONS

This hob provides you with some automatic functions to assist you in the cooking

process. Please note that they may not be available, depending on the power

management setting (see "Power Management" section). For example, if power

management has been set at 2.5 kW and some zones are already being used, the

remaining power might not be enough to activate an automatic function. The

hob will notify you with an acoustic signal.

MELTING

The function automatically sets the ideal power for melting. It allows

you to melt delicate food such as chocolate or butter, and keep it melted

without the risk of it burning or sticking to the pot/pan.

KEEP WARM

The function automatically sets the ideal power for keeping food warm after

cooking and before serving. Note that liquids are reduced over time when food

is kept warm.

These automatic functions are only available on standard cooking zones

(zones with the icon

How to activate automatic functions:

To activate the automatic functions, press the icon

The display will show two dimly lit icons:

(keep warm) on the top and

(melting) on the bottom.

Use the up (

) and down ( ) arrows to select the required function.

The display will show “A1” for melting and “A2” for keep warm and the

corresponding icon will become brighter.

HEAT CONTROL - ASSISTED COOKING WITH TEMPERATURE

This function allows you to select and cook at the temperature you want (as you

would do with an oven), rather than using standard power levels.

With this feature, the hob will automatically adjust the heat and maintain a

stable cookware temperature, eliminating the need for constant adjustments.

This function is available only on cooking zones with the

icon .

NOTE: The displayed temperature refers to the centre of the empty cookware.

Depending on the specic cookware you are using, the temperature shown might

be dierent from the actual cookware temperature. For optimal performance, it is

advisable to place the cookware in the centre of the cooking zone and to activate

the function when there is no 'residual heat' indicator (

) active.

IMPORTANT: This function is not meant to be used for boiling water or deep-

frying. For this reason, the water won't boil even if a temperature higher than

100°C is selected. Refer to "Assisted Boil" section or use the Booster function

for quick boiling.

How to activate Heat Control:

1. Place the cookware on the zone with the

icon.

2. Press the

icon.

3. Use the up arrow (

) to select the required temperature. The default

setting is 45° C. You can increase the temperature up to 200°C, according

to your needs (refer to the table below for cooking tips). Use the down

arrow (

) to reduce the temperature.

4. During the heat-up phase, an up arrow (

) will ash next to the selected

temperature.

5. When the cookware has reached the set temperature, the hob will notify

you with an acoustic signal and the up arrow (

) will stop ashing. Now

you can add food.

6. Once the set point has been reached, you can use the up (

) and down

(

)arrows to adjust the selected temperature in steps of 5°C.

7. If the new selected temperature is lower than current one, a down arrow

(

) will ash next to the selected temperature until the new set point has

been reached. If the new selected temperature is higher than the current

one, an up arrow (

) will ash next to the selected temperature until the

new set point has been reached.

8. If you set a timer on a zone where the Heat Control function is active,

the timer will start only after the set point has been reached. The display

will show the timer countdown instead of the temperature. During

the countdown, tap the up (

) or down ( ) arrow to see the set

temperature. After 3 seconds, the countdown will reappear.

HEAT CONTROL - COOKING TIPS

The table below gives some suggestions on cooking techniques for each

temperature.

LOW HEAT MEDIUM HEAT HIGH HEAT

45°C 80°C 130°C 150°C 180°C 200°C

Melt

(chocolate,

butter)

Keep Warm

Gentle fry

(vegetable

base mix)

Scramble

(eggs)

Sauté

Stir-fry

Grill

(beef,

vegetables)

Defrost

(meat, sh)

Thickening,

Creaming

(risotto)

Cont

(vegetables)

Deglaze

Caramelise

(sugar,

vegetables)

Brown

(Pancakes,

Toast)

Sear

(steak, roast)

Simmer

(120°C)

Refer to "Assisted Boil" section or use the Booster function for quick boiling.

NOTE:

• The system is able to monitor the cooking temperature, but it is always

advisable to stay nearby when the hob is in use.

• Depending on the cooking zone activation sequence, the Heat Control

function might not be available. The hob will notify you with an acoustic signal.

Scan the QR code to unlock the secrets of cooking with

Heat Control. Discover how easy and rewarding it is to

cook with temperature by visiting our website, where

you can nd guidance on a variety of cooking techniques,

everyday meals and exciting new dishes through step-by-

step recipes.

ASSISTED BOIL (BOIL&COOK)

This function brings water to the boil and automatically adjusts the power to keep

it simmering until you are ready to add your food. This function also helps prevent

overboiling and wasted energy when compared to Booster mode. To save energy

and speed up the boiling process, we recommend covering the pan with a lid.

Assisted Boil is available only on cooking zones with the

icon.

NOTE: When using this function, the pot must have a base diameter of 160 - 210

mm and be lled with water to between 1/2 an d 3/4 of its volume. Consider that

the maximum volume that can be used with this function is about 4 lt. Do not

add salt to the water before it has reached the boil, as this will prevent the system

from working as expected.

For optimal performance, it is advisable to place the cookware in the centre of

the cooking zone, use water at room temperature, and activate the function

when there is no 'residual heat' indicator present.

IMPORTANT: This function is meant to be used for boiling water only, not for

milk or other types of liquid.

Based on the cookware available on the market, the function might not perform

as expected.

How to activate Assisted Boil:

1. Fill the pot with water (see the notes above).

2. Place the cookware on a cooking zone with the

icon.

3. Select the Assisted Boil button ( ).

4. Press the Assisted Boil button ( ) one time if Heat Control is available on

one cooking zone only. If Heat Control is available on more than one cooking

zone, press the

button several times until you reach the cooking zone

where you want to use the Assisted Boil function. A “-b-” indication will

appear in the display to guide you through the zones.

5. When the zone is selected, you will see -b- ashing on the zone display for a

few seconds and then the function will start automatically.

6. When the Assisted Boil function starts, an animation will appear in the

display during the heat-up phase.

7. Within 90 seconds from when the water starts boiling, the function will notify

you of the fact with an acoustic signal. The animation will disappear, and the

hob automatically sets the power level at 15 to maintain a gentle boil.

8. Depending on the cookware used, the power level may automatically

drop to level 15 without reaching the boiling point of the water. In order to

reach boiling point, you can increase the power level of the cooking zone

in use. Alternatively, you can try using another pan that is compatible with

induction cooking. If the conditions described above do not occur, we

suggest switching the Boil&Cook function o and setting the power levels

manually to continue cooking.

9. Add your food and, if necessary, change the power level to adjust the

strength of the boil as required. The power selection will be limited to

those levels suitable for boil maintenance (i.e. levels 10 - 18).

NOTE:

• Whether the water is boiling or not, after about 15 minutes from the

activation of the function the hob automatically sets the power level to 15

and the animation disappears.

• Depending on the Power Management setting or the cooking zone

activation sequence, the Assisted Boil function might not be available. The

hob will notify you with an acoustic signal.

• When using this function, you will not be able to set a timer during the

water heat-up phase. The timer can only be enabled after receiving the

acoustic notication that the water has reached boiling point.

• The system is able to monitor the boiling process, but it is always advisable

to stay nearby when the hob is in use.

• If the hob oers the possibility of using Boil&Cook in multiple zones, only

one Boil&Cook function can be activated on each side. During the selection

process, the animation (snake) will still be displayed on the same side for a

few seconds without the function being able to be activated.

INDICATORS

RESIDUAL HEAT

If “Hot“ appears on the display, this means that the cooking zone is hot. The

indicator lights up even if the zone has not been activated but has been heated

(due to the use of adjacent zones or because a hot pot has been placed on it).

When the cooking zone has cooled down, the ”Hot” message disappears.

POT INCORRECTLY POSITIONED OR MISSING

This symbol appears if the pot is not suitable for induction cooking, is not

positioned correctly or is not of an appropriate size for the cooking zone

selected. If no pot is detected within 30seconds of making the selection, the

cooking zone switches o.

Owner's manual

COOKING TABLE

The cooking table oers cooking tips for each power level. The actual power delivered for each power level depends on the cooking zone dimension and on the

cookware used.

POWER LEVEL COOKING TIPS

Maximum power (P) Booster* - Bring water to a boil as quickly as possible. Do not use with an empty pan or oil/butter.

17 − 18 Bring water to a boil, deep fry** frozen products.

15 − 16 Maintain a lively boil, sear, blister, stir-fry, brown.

10 − 14 Maintain a gentle boil, preheat, grill (for a long period of time), stir-fry, sauté, caramelise, brown, pancakes.

5 − 9 Simmer, stew, thicken, slow cook.

3 − 4 Keep warm, defrost.

1 − 2 Melting, creaming (risotto).

Zero power (OFF) Hob is in stand-by or o mode (possible end-of-cooking residual heat, indicated by “Hot“).

*Booster is a special mode that uses a power level higher than 18, to heat up water faster. This mode can be maintained for a maximum time of 10 min. depending

on the zone used. After this time, the power will be automatically reduced to level 18.

** For deep frying frozen products such as French fries, it is recommended to use non Flexi Zone cooking zones. If you want to deep fry using Flexi Zone cooking

zones, it is recommended to use the front one.

CLEANING AND MAINTENANCE

Important:

• Before cleaning, make sure the cooking zones are switched off and that

the residual heat indicator (“Hot“) is not displayed.

• Do not use abrasive sponges or scouring pads as they may damage the glass.

• After each use, clean the hob (when it is cool) to remove any food residue

deposits or stains.

• A surface that is not kept suitably clean may reduce the sensitivity of control

panel buttons.

• Only use a scraper if residue is stuck to the hob. Follow the scraper manufacturer's

instructions to avoid scratching the glass.

• Sugar or foods with a high sugar content can damage the hob and must be

removed immediately.

• Salt, sugar and sand might scratch the glass surface.

• Use a soft cloth, absorbent kitchen paper or a special hob cleaner (follow the

manufacturer’s instructions).

• Liquid spills in the cooking zones can cause the pots to move or vibrate.

• After cleaning the hob, dry thoroughly.

TROUBLESHOOTING

• Check that the electricity supply has not been shut o.

• If you cannot to turn the hob o after using it, disconnect it from the power

supply.

• If alphanumeric codes appear on the display when the hob is switched on,

consult the following table for instructions.

Please note: The presence of water, or liquid spilled from pots or any objects

resting on a hob button, can accidentally activate or deactivate the control

panel lock function.

DISPLAY CODE/ISSUE

DETECTED

DESCRIPTION POSSIBLE CAUSES SOLUTION

F9E0 Wrong power cord connection.

The power supply connection is not exactly

as indicated in “Electrical connection“

section.

Make the power supply connection according to

the “Electrical connection“ section.

F0EA

The control panel switches off because of

excessively high temperatures.

The internal temperature of electronic parts

is too high.

Wait for the hob to cool down before using it

again.

F0E9

The power level

is automatically

decreased.

A cooking zone turns

OFF automatically.

The hob turns OFF

automatically.

The cooking zone turns off when the

temperatures are too high.

The power level is decreased, or the cooking

zone turns off or the hob turns off when the

temperatures are too high.

The internal temperature of electronic parts

is too high.

Hob ventilation may not be adequate to

ensure the proper functioning of the hob.

Wait for the cooking area to cool down before

using it again.

To ensure the appliance works properly, the

hob must receive adequate ventilation from a

sufficient fresh air supply. Check the hob has been

installed respecting the indications described in

the "Installation" section. Ensure that no object

is obstructing the rear and lower rear part of the

hob.

F0E2, F0E4, F0E6, F0E8,

F1E1, F2E1, F6E1, F6E2,

F7E5, F7E6, FCE1, FCE2,

FCE3

Disconnect the hob from the power supply.

Wait a few seconds (more than 10), then reconnect the hob to the power supply.

If the problem persists, call the service centre and specify the error code that appears on the display.

d E

[when the hob is off]

The hob does not heat up.

The functions do not come on.

DEMO MODE on.

Follow the instructions in the “First time use“

section.

DISPLAY CODE/ISSUE

DETECTED

DESCRIPTION POSSIBLE CAUSES SOLUTION

A special function does

not turn on and the hob

produces an acoustic

signal.

The hob does not allow a special function to

be activated.

The power regulator limits the special

function activation in accordance with the

power management setting selected for the

hob (e.g. 2.5 kW).

See the “Power management“ section.

When you choose

a power level or

use the Booster

function, the power

level automatically

decreases.

The hob automatically sets the maximum

available power level (even lower than the

set one) to ensure that the cooking zone

can be used.

The power regulator limits the special

function activation in accordance with the

power management setting selected for the

hob (e.g. 2.5 kW).

The Booster function can have a different

duration depending on the zone used. After

the Booster time has elapsed, the power will

be automatically reduced to level 18.

Hob ventilation may not be adequate to

ensure the proper functioning of the hob.

See the “Power management“ or "Booster

function" section.

To ensure the appliance works properly, the

hob must receive adequate ventilation from a

sufficient fresh air supply. Check the hob has been

installed respecting the indications described in

the "Installation" section. Ensure that no object

is obstructing the rear and lower rear part of the

hob.

Cookware is not detected.

Cooking zone switches off after 30 seconds.

This symbol appears if the pot is not suitable

for induction cooking, is not positioned

correctly or is not of an appropriate size

for the cooking zone selected. If no pot is

detected within 30 seconds of making the

selection, the cooking zone switches off.

If your cookware is suitable for induction cooking

(see the "Accessories" section) and correctly

positioned on the required cooking zone, try

using it on a smaller cooking zone. Otherwise,

please use appropriate cookware (See the

"Accessories" section).

The hob makes two short

acoustic sounds and then

switches OFF by itself.

The "OFF" message is

subsequently displayed

for up to 60 seconds,

during which time the

hob cannot be turned

back on and it repeats

the two short acoustic

sounds every 5 seconds.

Water spillage, food overflow and/or an object positioned on the control panel buttons

can mimic your finger and accidentally activate or deactivate any of the hob buttons:

• the ON/OFF button, causing the hob to turn off unintentionally,

• the key-lock button, causing the unwanted activation of the key-lock function if

pressed continuously for more than 3 seconds. The function remains active even after

the hob has switched off, with the key-lock icon and LED on,

• the scroll keypad, causing the unwanted change of power levels.

The hob switches off by itself (showing the "OFF" message) if it is not cleaned within 8

seconds.

Dry and/or clean and/or remove the object so

the hob can be turned back on 60 seconds after

the OFF message appeared.

If the key lock function has been accidentally

activated, press the key-lock button for 3 seconds

to disable it.

Press the ON/OFF button to switch on the hob.

Water does not boil

when Heat Control (

)

is used.

Water does not boil when the temperature

is set using the Heat Control function.

You are using Heat Control to boil water.

Use Assisted Boil (Boil&Cook) or Booster function.

A clicking and/or tick-tack

sound is heard when

cookware is positioned.

These continuous clicking and/or tick-tack noises occur when the pan is not able to receive

the full power delivered for the power level set.

The pan diameter may be lower than the minimum indicated in the user manual for specific

cooking zones. Even if you use a pan with the correct dimensions, some pan models have a

base partially covered by metal inserts (or without an even ferromagnetic distribution), and

they do not always perform as expected.

Use a pan with a diameter larger than the

minimum indicated in the manual for the specific

cooking zones, or use a more high-performing

pan (refer to the "Accessories" section).

The hob is turned o.

The hob will automatically turn off in the following situations:

• In the event of water spillage, food overow, or objects positioned on the control

panel buttons that could accidentally activate the ON/OFF button. If these items

are not removed within 8 seconds, the hob will automatically switch o while

producing a sound.

• If there is no interaction with the control panel for more than 30 seconds, and no

cooking zone is active.

• If no cookware has been detected for more than 30 seconds and there has been

no interaction with the control panel for the same time.

• The maximum working time for a power level or function has elapsed, and there

has been no interaction with the hob for more than 30 seconds.

• Other cases not specied here.

See the "Daily use" section for further information.

Turn on the hob manually.

While using the Assisted

Boil (Boil&Cook) function,

the water does not reach

boiling point.

Depending on the cookware or the amount of water used, boiling point might not be

reached.

Whether the water is boiling or not, the power level may automatically drop to 15 after

about 15 minutes from when the function is activated.

If the water is not boiling, bring it to the boil by

increasing the power level of the cooking zone in

use. Alternatively, you can try using another pan

suitable for induction cooking.

The function does not

indicate that boiling

point has been reached

within about 90 seconds

from when the water

starts to boil.

If the function does not indicate boiling within

about 90 seconds from when the water starts

boiling, we suggest you switch off the Boil&Cook

function and use power levels to continue

cooking.

Owner's manual

AFTER-SALES SERVICE

BEFORE CALLING THE AFTER-SALES SERVICE:

1. See if you can solve the problem by yourself with the help of the

TROUBLESHOOTING suggestions.

2. Switch the appliance o and back on again to see if the fault persists.

IF THE FAULT STILL OCCURS EVEN AFTER THE ABOVE CHECKS, GET IN

TOUCH WITH YOUR NEAREST AFTER-SALES SERVICE.

When contacting our customer after-sales service, always give:

• a brief description of the fault;

• the type and exact model of the appliance;

XXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXXXXXX

Made in X

Type: XXXMod.: XXX

XXXX XXX XXXXXXX XXXX XXXXX

XXXXXXXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX

• Ind. C.

• the serial number (number after the letters SN on the rating plate

located under the appliance). The serial number is also indicated in the

documentation;

Mod.

Ind.C.

SN:

Prod.N.

xxxx xxxx xxxx

xxx xxx

PRODUCT

INFORMATION

• your full address;

• your telephone number;

If any repairs are required, please contact an authorized after-sales service

(to guarantee that original spare parts will be used and repairs carried out

correctly).

400020006780

Induction hobs may whistle or creak during normal operation.

These noises actually come from the cookware and are linked to the

characteristics of the pan bases (e.g. when the bottoms are made from dierent

layers of material, or are uneven).

They may vary according to the type of cookware used and the amount of food

contained, and are not the symptom of something wrong.

Induction hobs may produce continuous clicking and/or tick-tack sounds with a

positioned pot/pan. These sounds may occur when the pan is not able to receive

the full power delivered for the power level set. Use a pan with a diameter larger

than the minimum indicated in the manual for the specic cooking zones, or use

a more high-performing pan (refer to the "Accessories" section).

Water spillage, food overow and/or an object positioned on the control panel

buttons can mimic your nger and accidentally activate or deactivate any

of the hob buttons, as well as producing acoustic signals due to the contact

between the objects and the buttons. If these items are not removed within 8

seconds, the hob will automatically switch o while producing a sound which

will then be repeated every 5 seconds until the object or water is removed from

the control panel, even after switch-o. To avoid switch-o, remove any spilled

liquids from the user interface and thoroughly dry it within 8 seconds, or use the

Wipe function which gives you 30 seconds for cleaning and drying.

Remember that the ON/OFF button will always be active.

SOUNDS PRODUCED DURING OPERATION

Policies, standard documentation and additional product information can be found by:

• Using QR code in your appliance;

• Visiting our website docs. hotpoint.eu;

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product's identication plate.

Prima di utilizzare l’apparecchio, leggere le seguenti

norme di sicurezza. Conservarle per eventuali

consultazioni successive.

Queste istruzioni e l’apparecchio sono corredati da

importanti avvertenze di sicurezza, da leggere e

osservare sempre. Il fabbricante declina qualsiasi

responsabilità che derivi dalla mancata osservanza

delle presenti istruzioni di sicurezza, da usi impropri

dell’apparecchio o da errate impostazioni dei comandi.

AVVERTENZA: Se la supercie del piano cottura è

incrinata, non utilizzare l’apparecchio per evitare il

rischio di folgorazione.

AVVERTENZA: Pericolo di incendio: non appoggiare

oggetti sulle superci di cottura.

ATTENZIONE: Il processo di cottura deve essere

sorvegliato. I processi di cottura brevi richiedono una

supervisione continua.

AVVERTENZA: La cottura non sorvegliata su un

piano di cottura con grasso e olio può essere pericolosa

e generare incendi. Non tentare MAI di spegnere le

amme con acqua: piuttosto, spegnere l’apparecchio e

soocare le amme, ad esempio con un coperchio o

una coperta antincendio.

Non utilizzare il piano di cottura come supercie di

lavoro o appoggio. Non avvicinare all’apparecchio

stoe o altri materiali inammabili no a che tutti i

componenti non si siano completamente rareddati

per evitare il rischio di incendi.

Non poggiare oggetti metallici come coltelli,

forchette, cucchiai e coperchi sulla supercie del piano

di cottura perché potrebbero surriscaldarsi.

Tenere i bambini di età inferiore a 3 anni lontani

dall’apparecchio. Senza la sorveglianza costante di un

adulto tenere anche l’apparecchio fuori dalla portata

dei bambini di età compresa tra 3 e 8 anni. I bambini di

età superiore agli 8 anni, le persone con ridotte capacità

siche, sensoriali o mentali e le persone che non

abbiano esperienza o conoscenza dell’apparecchio

potranno utilizzarlo solo sotto sorveglianza, o quando

siano state istruite sull’utilizzo sicuro dell’apparecchio e

siano consapevoli dei rischi del suo utilizzo. Vietare ai

bambini di giocare con l’apparecchio. I bambini non

devono eseguire operazioni di pulizia e manutenzione

dell’apparecchio senza la sorveglianza di un adulto.

Dopo l’uso, spegnere l’elemento del piano di cottura

mediante il rispettivo comando e non fare adamento

sul rilevatore di tegami.

ATTENZIONE: L'apparecchio e i suoi componenti

accessibili possono diventare molto caldi durante l'uso.

Fare attenzione a non toccare gli elementi riscaldanti.

Tenere lontani i bambini di età inferiore agli 8 anni, a

meno che non siano costantemente sorvegliati.

L'alimento non deve essere lasciato nel o sul prodotto

per più di un'ora prima o dopo la cottura.

USO CONSENTITO

ATTENZIONE: l’apparecchio non è destinato ad

essere messo in funzione mediante un dispositivo di

commutazione esterno, ad esempio un temporizzatore,

o attraverso un sistema di comando a distanza separato.

L’apparecchio è destinato all’uso domestico e ad

applicazioni analoghe, quali: aree di cucina per il

personale di negozi, uci e altri contesti lavorativi;

agriturismi; camere di hotel, motel, bed & breakfast e

altri ambienti residenziali.

Non sono consentiti altri usi (ad es., il riscaldamento

di ambienti).

Questo apparecchio non è destinato ad applicazioni

professionali. Non utilizzare l’apparecchio all’aperto.

AVVERTENZA: Il piano di cottura a induzione può

generare un segnale acustico quando viene lasciato

qualcosa sul pannello di controllo. Spegnere il piano

cottura tramite il pulsante ON/OFF.

INSTALLAZIONE

Per evitare il rischio di lesioni personali, l’apparecchio

deve essere movimentato e installato da due o più

persone. Per le operazioni di disimballaggio e

installazione utilizzare i guanti protettivi per non

procurarsi tagli.

L’installazione, comprendente anche eventuali

raccordi per l’alimentazione idrica e i collegamenti

elettrici, e gli interventi di riparazione devono essere

eseguiti da personale qualicato. Non riparare o

sostituire qualsiasi parte dell’apparecchio se non

specicatamente richiesto nel manuale d’uso. Tenere i

bambini a distanza dal luogo dell’installazione. Dopo

aver disimballato l’apparecchio, controllare che

l’apparecchio non sia stato danneggiato durante il

trasporto. In caso di problemi, contattare il rivenditore

o il Servizio Assistenza Clienti. A installazione

completata, conservare il materiale di imballaggio

(parti in plastica, polistirolo, ecc.) fuori della portata dei

bambini per evitare il rischio di soocamento. Per

evitare rischi di scosse elettriche, prima di procedere

all’installazione scollegare l’apparecchio dalla rete

elettrica. Durante l’installazione, accertarsi che

l’apparecchio non possa danneggiare il cavo di

alimentazione e causare così rischi di scosse elettriche.

Attivare l’apparecchio solo dopo avere completato la

procedura di installazione.

Eseguire tutte le operazioni di taglio del mobile

prima di inserire l’apparecchio, avendo cura di rimuovere

trucioli o residui di segatura.

AVVERTENZE ELETTRICHE

Deve essere possibile scollegare l’apparecchio dalla

rete elettrica disinserendo la spina, se questa è

accessibile, o tramite un interruttore multipolare

installato a monte della presa nel rispetto dei

regolamenti elettrici vigenti; inoltre, la messa a terra

NORME DI SICUREZZA

IMPORTANTE: DA LEGGERE E OSSERVARE

dell’apparecchio deve essere conforme alle norme di

sicurezza elettrica nazionali.

Non utilizzare cavi di prolunga, prese multiple o

adattatori. Una volta terminata l’installazione, i

componenti elettrici non devono più essere accessibili.

Non utilizzare l’apparecchio quando si è bagnati oppure

a piedi nudi. Non accendere l’apparecchio se il cavo di

alimentazione o la spina sono danneggiati, se si

osservano anomalie di funzionamento o se

l’apparecchio è caduto o è stato danneggiato.

L'installazione tramite spina del cavo di alimentazione

non è consentita a meno che il prodotto non sia già

dotato di quella fornita dal Produttore.

Se il cavo di alimentazione è danneggiato, deve

essere sostituito con uno dello stesso tipo dal

produttore, da un centro di assistenza autorizzato o

da un tecnico qualicato per evitare situazioni di

pericolo o rischi di scosse elettriche.

PULIZIA E MANUTENZIONE

AVVERTENZA: Per evitare rischi di folgorazione,

prima di qualsiasi intervento di manutenzione accertarsi

che l’apparecchio sia spento e scollegato

dall’alimentazione elettrica; inoltre, non usare in nessun

caso pulitrici a getto di vapore.

Non utilizzare prodotti abrasivi o corrosivi, prodotti a

base di cloro o pagliette.

SMALTIMENTO DEL MATERIALE DI IMBALLAGGIO

Il materiale di imballaggio è riciclabile al 100% ed è contrassegnato dal simbolo

del riciclaggio

Le varie parti dell’imballaggio devono pertanto essere smaltite

responsabilmente e in stretta osservanza delle norme stabilite dalle autorità

locali.

SMALTIMENTO DEGLI ELETTRODOMESTICI

Questo prodotto è stato fabbricato con materiale riciclabile o riutilizzabile.

Smaltire il prodotto rispettando le normative locali in materia. Per ulteriori

informazioni sul trattamento, il recupero e il riciclaggio degli elettrodomestici,

contattare l’ucio locale competente, il servizio di raccolta dei riuti domestici

o il negozio presso il quale il prodotto è stato acquistato. Questo apparecchio

è contrassegnato in conformità alla direttiva europea 2012/19/UE, Riuti di

apparecchiature elettriche ed elettroniche (RAEE) e alle norme sui riuti di

apparecchiature elettriche ed elettroniche 2013 (e successive modiche).

Assicurandosi che questo prodotto sia smaltito in modo corretto, l’utente

contribuisce a prevenire le conseguenze negative per l’ambiente e la salute.

Il simbolo

sul prodotto o sulla documentazione di accompagnamento

indica che questo apparecchio non deve essere smaltito come riuto

domestico, bensì conferito presso un centro di raccolta preposto al ritiro delle

apparecchiature elettriche ed elettroniche.

CONSIGLI PER IL RISPARMIO ENERGETICO

Per sfruttare al meglio il calore residuo delle piastre, spegnerle alcuni minuti

prima del termine della cottura.

La base della pentola o del tegame dovrebbe coprire completamente la piastra

di cottura; un recipiente con la base più piccola del diametro della piastra

causerà uno spreco di energia.

Durante la cottura, coprire pentole e tegami con un coperchio che chiuda bene

il recipiente e usare la minima quantità d’acqua possibile. La cottura senza

coperchio comporta un consumo di energia notevolmente superiore.

Utilizzare solo pentole e padelle con fondo piatto.

DICHIARAZIONE DI CONFORMITÀ

Questo apparecchio soddisfa i requisiti di Ecodesign del regolamento europeo

66/2014 e l'Ecodesign per i prodotti connessi all'energia e le informazioni

sull'energia (emendamento) (Uscita UE) Regolamenti 2019 in conformità con

la norma europea EN 60350-2.

Le informazioni relative alla modalità a basso consumo dell'apparecchio in

conformità con il Regolamento (UE) 2023/826 sono disponibili al seguente link:

https://docs.emeaappliance-docs.eu.

NOTA

Le persone con un pacemaker o un dispositivo medico simile devono prestare

attenzione quando si trovano in prossimità di questo piano di cottura a

induzione mentre è acceso. Il campo elettromagnetico può inuenzare il

pacemaker o un dispositivo simile. Consultare il proprio medico o il produttore

del pacemaker o un dispositivo medico simile per ulteriori informazioni sui

suoi eetti con i campi elettromagnetici del piano di cottura ad induzione.

COLLEGAMENTO ELETTRICO

Il collegamento elettrico deve essere eseguito prima di collegare l'apparecchio alla rete.

L'installazione deve essere eseguita da personale qualicato a conoscenza delle norme vigenti in materia di sicurezza e installazione. Nella fattispecie, l'installazione

deve essere eseguita in ottemperanza alle direttive della locale società di fornitura elettrica.

Controllare che la tensione indicata sulla targhetta matricola nella parte inferiore dell'apparecchio sia la stessa della rete elettrica domestica.

La messa a terra dell'apparecchio è obbligatoria per legge; utilizzare solo conduttori delle dimensioni appropriate (incluso il conduttore di terra).
