WYBOT C1 Pro/Max(OS7010/OS7010 Max)
Robotic Pool Cleaner
User Manual
Read through the entire manual before running your new
robotic pool cleaner, and keep this manual handy
for your reference.
Copyright© 2024 WYBOTICS Co., Ltd. All Rights Reserved.
www.wybotpool.com
Email: [email protected]
Facebook: @WybotPool
WYBOTICS CO.,LTD
No.30, Zhongnan 4th Street West Zone, TEDA Tianjin, China
All trade names are registered trademarks of respective manufacturers listed.
Thank you for choosing WYBOT products, your support means a lot to us. Continu-
ous providing the best solution to free you up from pool cleaning and enjoy your
family time is always our pursuit.
WYBOT Robotic Pool Cleaner is dedicated to serving you high efficiency, low power
consumption, easy operation and thorough pool cleaning work.
Its unique appearance and reliable functions as one-button activation, powerful
suction and scrubbing, fine filtration, smart navigation, remote control, and high
compatibility with various pool shapes and constructions materials assure you a
convenient, intelligent, and optimal pool cleaning.
Feel free to contact us by Email or visit our website with any questions. We are very
glad to hear your advice on our continuous improvement.
01
01
02
02
03
03
04
04
05
05
06
08
09
10
10
10
12
12
WYBOT C1 PRO/MAX(OS7010/OS7010 Max) AT A GLANCE
Product External Overview
Product Internal Overview
Packing List
GET STARTED
Charge your new WYBOT C1 Pro/max(OS7010/OS7010 Max)
Setup your new WYBOT C1 Pro/max(OS7010/OS7010 Max)
Connect to your App
Choose your cleaning mode
Preset your cleaning cycle via the app
Run your new WYBOT C1 Pro/max(OS7010/OS7010 Max)
DO A FILTER CLEANING
DEVICE SPECIFICATION
LIMITED WARRANTY
HOW TO MAINTAIN YOUR DEVICE
FAQ & TROUBLE SHOOTING
CERTIFICATION
WYBOT CUSTOMER CARE
CONTENTS
Caution
Failure to operate the device as per the cautions can cause a damage to the device
or personal injury.
1. Charge the unit before first use.
2. Do not over charge the cleaner, which will reduce the battery life.
3. Charge the cleaner prior to being stored for a long time (over 6 months) to main-
tain an optimal battery life.
4. Remember to wash and clean the filter basket after each use.
5. Store the cleaner in a cool and ventilated place, away from direct sunshine or
any heat source.
6. Use only the pool cleaner in the following water conditions:
Chlorine
pH
Temperature
NaCl
Max 4mg/L
7.0 - 7.8
41 - 95 ˭ (5 - 35 ℃)
Maximum 5000 PPM
Read the manual carefully before you use the cleaner. Your safety is the most
important thing. Please read through and operate the device as per instructions,
WYBOTICS Co., Ltd. is not held liable for any loss or injury caused by improper use.
Warning
Failure to operate the device as per the warnings can result in serious injury,
electrocution or death.
1. Use only the accessories recommended or sold by WYBOTICS Co., Ltd.
2. Dry the charging port after each cleaning. Humidity charging socket may cause a
electric shock.
3. Do not charge the cleaner when it is running (the indicator is on).
4. Use only the original and authorized power charger, Avoid charging any other
devices with this charger. Improper use may result in overheating or corrosive
liquid leakage from the battery.
5. Make sure the electrical outlet is protected by a ground fault circuit interrupter
(GFCI) and an earth leakage interrupter (ELI).
6. Do not use a cord-damaged charger to avoid any electrical shock.
7. Do not try to use extension cord to connect the charger.
8. Never allow children to ride on the cleaner or play with it as a toy.
9. Do not allow child to operate or maintain the device.
10. Do not enter the pool when the cleaner is working in it.
11. Never expose or charge the device in flammable environments.
12. Only licensed professionals can disassemble the sealing parts of the cleaner.
13. Do not operate the cleaner while pool filter is running.
01
01
02
02
03
03
04
04
05
05
06
08
09
10
10
10
12
12
WYBOT C1 PRO/MAX(OS7010/OS7010 Max) AT A GLANCE
Product External Overview
Product Internal Overview
Packing List
GET STARTED
Charge your new WYBOT C1 Pro/max(OS7010/OS7010 Max)
Setup your new WYBOT C1 Pro/max(OS7010/OS7010 Max)
Connect to your App
Choose your cleaning mode
Preset your cleaning cycle via the app
Run your new WYBOT C1 Pro/max(OS7010/OS7010 Max)
DO A FILTER CLEANING
DEVICE SPECIFICATION
LIMITED WARRANTY
HOW TO MAINTAIN YOUR DEVICE
FAQ & TROUBLE SHOOTING
CERTIFICATION
WYBOT CUSTOMER CARE
CONTENTS
Caution
Failure to operate the device as per the cautions can cause a damage to the device
or personal injury.
1. Charge the unit before first use.
2. Do not over charge the cleaner, which will reduce the battery life.
3. Charge the cleaner prior to being stored for a long time (over 6 months) to main-
tain an optimal battery life.
4. Remember to wash and clean the filter basket after each use.
5. Store the cleaner in a cool and ventilated place, away from direct sunshine or
any heat source.
6. Use only the pool cleaner in the following water conditions:
Chlorine
pH
Temperature
NaCl
Max 4mg/L
7.0 - 7.8
41 - 95 ˭ (5 - 35 ℃)
Maximum 5000 PPM
Read the manual carefully before you use the cleaner. Your safety is the most
important thing. Please read through and operate the device as per instructions,
WYBOTICS Co., Ltd. is not held liable for any loss or injury caused by improper use.
Warning
Failure to operate the device as per the warnings can result in serious injury,
electrocution or death.
1. Use only the accessories recommended or sold by WYBOTICS Co., Ltd.
2. Dry the charging port after each cleaning. Humidity charging socket may cause a
electric shock.
3. Do not charge the cleaner when it is running (the indicator is on).
4. Use only the original and authorized power charger, Avoid charging any other
devices with this charger. Improper use may result in overheating or corrosive
liquid leakage from the battery.
5. Make sure the electrical outlet is protected by a ground fault circuit interrupter
(GFCI) and an earth leakage interrupter (ELI).
6. Do not use a cord-damaged charger to avoid any electrical shock.
7. Do not try to use extension cord to connect the charger.
8. Never allow children to ride on the cleaner or play with it as a toy.
9. Do not allow child to operate or maintain the device.
10. Do not enter the pool when the cleaner is working in it.
11. Never expose or charge the device in flammable environments.
12. Only licensed professionals can disassemble the sealing parts of the cleaner.
13. Do not operate the cleaner while pool filter is running.
01
02
Packing List
WYBOT C1 PRO/MAX(OS7010/OS7010 Max) AT A GLANCE
Filter Basket
Store collected dirt and debris, need to
be washed after each use.
j
Sealed Part
Important components are sealed there.
For your safety, do not try to disassemble it
without authorization.
k
Product External Overview
Product Internal Overview
Do not operate the device when the top cover or scrubbing brushes are broken.
If there is any liquid leakage from the sealing part, stop charging or running
the device.
d
f
e
g
b
c
a
h
j
Handle
Remove and transport the device with it
on/off Button
Turn on/ turn off the device
a
b
d
LED Indicator
Different light colors to indicate device status
f
Pump
Suck debris and pump out water through
the window
c
Cleaning Mode Indicator
The chosen cleaning mode will be shown here
g
Top Cover Open Handle
Open the top cover to take out filter basket
Charging Port
Connect the charging cable
h
j
Track
Enhance device’s capability in climbing walls
and various obstacles
e
Scrubbing Brush
Knock loose all dirt and roll them all into the
device
Device x 1
Filter Basket x 1
Charger x 1
Quick Start Guide x 1
Hook x 1
Floating Parts
j
k
User Manual x 1
01
02
Packing List
WYBOT C1 PRO/MAX(OS7010/OS7010 Max) AT A GLANCE
Filter Basket
Store collected dirt and debris, need to
be washed after each use.
j
Sealed Part
Important components are sealed there.
For your safety, do not try to disassemble it
without authorization.
k
Product External Overview
Product Internal Overview
Do not operate the device when the top cover or scrubbing brushes are broken.
If there is any liquid leakage from the sealing part, stop charging or running
the device.
d
f
e
g
b
c
a
h
j
Handle
Remove and transport the device with it
on/off Button
Turn on/ turn off the device
a
b
d
LED Indicator
Different light colors to indicate device status
f
Pump
Suck debris and pump out water through
the window
c
Cleaning Mode Indicator
The chosen cleaning mode will be shown here
g
Top Cover Open Handle
Open the top cover to take out filter basket
Charging Port
Connect the charging cable
h
j
Track
Enhance device’s capability in climbing walls
and various obstacles
e
Scrubbing Brush
Knock loose all dirt and roll them all into the
device
Device x 1
Filter Basket x 1
Charger x 1
Quick Start Guide x 1
Hook x 1
Floating Parts
j
k
User Manual x 1
03
04
The device has a lithium-ion rechargeable battery, and you need to charge the batte-
ry before first use and when the battery is low.
Connect your device to a power outlet using the included cable and adaptor.
GET STARTED
Charge your new WYBOT C1 Pro/Max(OS7010/OS7010 Max)
You can download the WYBOT App to your smart mobile device by scanning QR code
below, or from Google Play or App Store.
Connect to your App
Setup your new WYBOT C1 Pro/Max(OS7010/OS7010 Max)
Note:
1. When yellow light flashing, you should remove your device out of water and
charge it.
2. If red LED light is on, you can find solution from trouble shooting in this manual
or call for service.
You can turn on the device by pressing the on/off button. The LED indicator on the
front will display a solid blue when the device is on.
The adaptor has an indicator, Which will display blue light indicating the power
supply status.
Below is the indication of the LED lights when running, you may refer it to know
different device status.
LED Color Indication
Solid
Flashing
Solid
Flashing
Solid or flashing
Status
Power On
Under working
Connecting to App
Charging in progess, low battery
or under self-parking in the pool
Fault
Flashing
Solid
Charging in progress
Fully charged/ battery level
Note:
1. When charging ,you should ensure your device at least 3m (appr. 10ft) away from
the edge of the pool.
2. For reducing fire risk, keep your device and adaptor away from direct
sunshine or water when charging.
3. For your important safety, you need to double check the device is powered off
and the charging port is dry before charging.
4. The best charging environment is temperature at 32℉ -95℉ (0℃ -35℃ ), RH at
5%-95%.
The LED indicator in the front of the device will turn starting from a flashing light
to a flashing light during charging, and turn a solid light when fully charged.
Solid : fully charged!
The LED will continue a flashing indicating low battery when powering on the
device, and you should charge it immediately.
Note:
03
04
The device has a lithium-ion rechargeable battery, and you need to charge the batte-
ry before first use and when the battery is low.
Connect your device to a power outlet using the included cable and adaptor.
GET STARTED
Charge your new WYBOT C1 Pro/Max(OS7010/OS7010 Max)
You can download the WYBOT App to your smart mobile device by scanning QR code
below, or from Google Play or App Store.
Connect to your App
Setup your new WYBOT C1 Pro/Max(OS7010/OS7010 Max)
Note:
1. When yellow light flashing, you should remove your device out of water and
charge it.
2. If red LED light is on, you can find solution from trouble shooting in this manual
or call for service.
You can turn on the device by pressing the on/off button. The LED indicator on the
front will display a solid blue when the device is on.
The adaptor has an indicator, Which will display blue light indicating the power
supply status.
Below is the indication of the LED lights when running, you may refer it to know
different device status.
LED Color Indication
Solid
Flashing
Solid
Flashing
Solid or flashing
Status
Power On
Under working
Connecting to App
Charging in progess, low battery
or under self-parking in the pool
Fault
Flashing
Solid
Charging in progress
Fully charged/ battery level
Note:
1. When charging ,you should ensure your device at least 3m (appr. 10ft) away from
the edge of the pool.
2. For reducing fire risk, keep your device and adaptor away from direct
sunshine or water when charging.
3. For your important safety, you need to double check the device is powered off
and the charging port is dry before charging.
4. The best charging environment is temperature at 32℉ -95℉ (0℃ -35℃ ), RH at
5%-95%.
The LED indicator in the front of the device will turn starting from a flashing light
to a flashing light during charging, and turn a solid light when fully charged.
Solid : fully charged!
The LED will continue a flashing indicating low battery when powering on the
device, and you should charge it immediately.
Note:
05 06
Choose your cleaning mode
iOS Android
iOS 15.0 or later Android 8.0 or later
Note:
1. You can preset your cleaning mode before putting the device into the pool.
The default mode is full pool cleaning.
2. If the device restarts, it will automatically enter the cleaning mode you set last
time
Hold the handle of the cleaner and submerge it into the pool within 3 minutes, other-
wise the device will be turned off. Additionally, you should not release it until no bubble
comes out.
Run your new WYBOT C1 Pro/Max(OS7010/OS7010 Max)
Cleaning Range
Mode
Wall+ Floor+Waterline/Wall then floor
Floor only/Turbo floor/ECO floor
Full pool cleaning
Floor cleaning
Wall cleaning
Wall only
Preset your cleaning cycle via the app
You can start to schedule your cleaning cycle through clicking the “cycle timer” on
the app, and select the one you prefer. You may refer to below for a better under-
standing of the working principle.
Note:
1. If you have selected a cycle cleaning mode, you should ensure the cleaner is fully
charged before.
2. The default cleaning cycle of WYBOT C1 Pro(OS7010) is one time cleaning for 2 hours,
and WYBOT C1 Max(OS7010 Max) is one time cleaning for 3 hours.
3. If your select other cleaning cycles, you should keep the cleaner in the pool to
complete whole cycles.
There are 3 cleaning modes on the device, and you can see details below.
You can preset a suitable cleaning mode for your device on the device through press-
ing the on/off button. You can also select one cleaning mode via the app.
eg WYBOT C1 Pro(OS7010/OS7010 Max) cycle timer
Cycle 1 120min*1
Cycle 2 60min*2
Cycle 3 40min*3
Cycle 4 30min*4
(default)
24 hours
60min.
60min.
1st day
2nd day
24 hours
40min.
24 hours
40min.
1st day
2nd day
40min.
3rd day
120min.
1st day
48 hours
30min.
48 hours
30min.
1st day
3rd day
30min.
5th day
48 hours
30min.
7th day
*You can define a specific mode from the app
*You can define a specific mode from the app
05 06
Choose your cleaning mode
iOS Android
iOS 15.0 or later Android 8.0 or later
Note:
1. You can preset your cleaning mode before putting the device into the pool.
The default mode is full pool cleaning.
2. If the device restarts, it will automatically enter the cleaning mode you set last
time
Hold the handle of the cleaner and submerge it into the pool within 3 minutes, other-
wise the device will be turned off. Additionally, you should not release it until no bubble
comes out.
Run your new WYBOT C1 Pro/Max(OS7010/OS7010 Max)
Cleaning Range
Mode
Wall+ Floor+Waterline/Wall then floor
Floor only/Turbo floor/ECO floor
Full pool cleaning
Floor cleaning
Wall cleaning
Wall only
Preset your cleaning cycle via the app
You can start to schedule your cleaning cycle through clicking the “cycle timer” on
the app, and select the one you prefer. You may refer to below for a better under-
standing of the working principle.
Note:
1. If you have selected a cycle cleaning mode, you should ensure the cleaner is fully
charged before.
2. The default cleaning cycle of WYBOT C1 Pro(OS7010) is one time cleaning for 2 hours,
and WYBOT C1 Max(OS7010 Max) is one time cleaning for 3 hours.
3. If your select other cleaning cycles, you should keep the cleaner in the pool to
complete whole cycles.
There are 3 cleaning modes on the device, and you can see details below.
You can preset a suitable cleaning mode for your device on the device through press-
ing the on/off button. You can also select one cleaning mode via the app.
eg WYBOT C1 Pro(OS7010/OS7010 Max) cycle timer
Cycle 1 120min*1
Cycle 2 60min*2
Cycle 3 40min*3
Cycle 4 30min*4
(default)
24 hours
60min.
60min.
1st day
2nd day
24 hours
40min.
24 hours
40min.
1st day
2nd day
40min.
3rd day
120min.
1st day
48 hours
30min.
48 hours
30min.
1st day
3rd day
30min.
5th day
48 hours
30min.
7th day
*You can define a specific mode from the app
*You can define a specific mode from the app
DO A FILTER CLEANING
07 08
Let it sink down to the floor.
Note:
To achieve an optimal cleaning performance, you should ensure the water depth
of the pool is at least 19.5 in (50 cm) high from the top of the device.
Take out the filter basket. Empty all debris and rinse it with clean
water.
Hold the filter cover handle, press and open it.
The cleaner begins to clean walls, floor
and waterline as default or your set.
About 20 seconds of auto calibration
on the floor, the indicator light will turn
flashing blue. The cleaner is ready to
clean.
The device will automatically move to
stop by the edge of wall when finishing
cleaning or battery low.
You can insert the included hook into
a pool rod and lift the cleaner out of
the pool.
You should take the cleaner out verti-
cally to drain inside water out quickly.
Note:
1. You should ensure the device is powered off when open the top cover.
2. You need to clean the filter basket before being dry.
Note:
If you have preset a cleaning cycle other than the default one, you should leave the
cleaner in the pool to complete the whole cycle.
1
2
3
4
5
3
4
1
2
DO A FILTER CLEANING
07 08
Let it sink down to the floor.
Note:
To achieve an optimal cleaning performance, you should ensure the water depth
of the pool is at least 19.5 in (50 cm) high from the top of the device.
Take out the filter basket. Empty all debris and rinse it with clean
water.
Hold the filter cover handle, press and open it.
The cleaner begins to clean walls, floor
and waterline as default or your set.
About 20 seconds of auto calibration
on the floor, the indicator light will turn
flashing blue. The cleaner is ready to
clean.
The device will automatically move to
stop by the edge of wall when finishing
cleaning or battery low.
You can insert the included hook into
a pool rod and lift the cleaner out of
the pool.
You should take the cleaner out verti-
cally to drain inside water out quickly.
Note:
1. You should ensure the device is powered off when open the top cover.
2. You need to clean the filter basket before being dry.
Note:
If you have preset a cleaning cycle other than the default one, you should leave the
cleaner in the pool to complete the whole cycle.
1
2
3
4
5
3
4
1
2
09 10
1. All WYBOT pool cleaners in the market have been inspected and licensed to be
sold as per local laws.
2. The warranty duration for battery, motor and PCB is two (2) years from the purchas
ing date. Consumable parts, including filter basket, brush, wheels etc., are beyond
warranty.
3. The warranty apply only to original buyers, and not valid to resale and any other
kinds of transfer.
4. Any damages to the unit caused by improper use, unauthorized repair or disas-
sembly are not covered by WYBOTICS Co., Ltd.’s warranty.
5.The order number or record must be presented for any claim or repair within the
warranty period.
LIMITED WARRANTY
Note:
If your device do not work after a long-term low battery life or being off, please
contact after-sale team for help. For your safety, do not try to disassemble it
without authorization.
Note:
If you can not find a solution from the table, please contact after-sale team.
After rinsing, put the filter basket into
the cleaner and close the cover.
DEVICE SPECIFICATION
You should follow the steps to store your cleaner to maintain good performance.
a) Ensure the device is powered off
b) Dry out the cleaner and filter basket
c) Fully charge the battery
d) Store the cleaner in a cool and ventilated place, away from direct sunshine,
heat source, frost and squeezing with an ambient temperature between 5℃/ 41
℉ and 45℃ / 113℉.
e) Charge the cleaner every three months to ensure an optimal battery life.
HOW TO MAINTAIN YOUR DEVICE
Q: What pool shapes and construction materials is the cleaner suitable for?
A: The machine can be applied to rectangle, oval, or irregular shapes of in-ground
swimming pools. Applicable construction materials include PVC, gunite and other
high friction materials. (Slippery materials such as tiles, mosaics, and acrylic may
not work well, and you need to do some modification.)
Q: Will obstacles such as steps, shallow water areas, drains, slopes etc. in the swim-
ming pool affect the running?
A: The machine can climb steps, drains, and shallow water areas.
FAQ & TROUBLE SHOOTING
If you encounter the following situations when using the cleaner, you can check
the table and solve them by yourself.
5
13ft (4m)
25.2V/2.6A
65W
100-240V, 50-60Hz
180µm
7.8kg
WYBOT C1 Pro(OS7010)
7800mAh
App Connection
OTA Update
Available
Available
Max. 150㎡
Name
Pool Size
Depth
Device Dimension
Weight
Runtime
Charging Time
Power
Charger Input
Charger Output
Battery Capacity
Filter
Flow Rate
Moving Speed
Water Resistance
WYBOT C1 Max(OS7010 Max)
Max. 200㎡
13ft (4m)
372(L)*360(W)*240(H) mm
372(L)*360(W)*240(H) mm
120min.~150min.
2.5 hours
180min.~
21
0
min.
3.5 hours
65W
100-240V, 50-60Hz
25.2V/2.6A
4600mAh
180µm
11.5 m³/H
11m/min
IPX8
11.5 m³/H
11m/min
IPX8
Available
Available
7.8kg
09 10
1. All WYBOT pool cleaners in the market have been inspected and licensed to be
sold as per local laws.
2. The warranty duration for battery, motor and PCB is two (2) years from the purchas
ing date. Consumable parts, including filter basket, brush, wheels etc., are beyond
warranty.
3. The warranty apply only to original buyers, and not valid to resale and any other
kinds of transfer.
4. Any damages to the unit caused by improper use, unauthorized repair or disas-
sembly are not covered by WYBOTICS Co., Ltd.’s warranty.
5.The order number or record must be presented for any claim or repair within the
warranty period.
LIMITED WARRANTY
Note:
If your device do not work after a long-term low battery life or being off, please
contact after-sale team for help. For your safety, do not try to disassemble it
without authorization.
Note:
If you can not find a solution from the table, please contact after-sale team.
After rinsing, put the filter basket into
the cleaner and close the cover.
DEVICE SPECIFICATION
You should follow the steps to store your cleaner to maintain good performance.
a) Ensure the device is powered off
b) Dry out the cleaner and filter basket
c) Fully charge the battery
d) Store the cleaner in a cool and ventilated place, away from direct sunshine,
heat source, frost and squeezing with an ambient temperature between 5℃/ 41
℉ and 45℃ / 113℉.
e) Charge the cleaner every three months to ensure an optimal battery life.
HOW TO MAINTAIN YOUR DEVICE
Q: What pool shapes and construction materials is the cleaner suitable for?
A: The machine can be applied to rectangle, oval, or irregular shapes of in-ground
swimming pools. Applicable construction materials include PVC, gunite and other
high friction materials. (Slippery materials such as tiles, mosaics, and acrylic may
not work well, and you need to do some modification.)
Q: Will obstacles such as steps, shallow water areas, drains, slopes etc. in the swim-
ming pool affect the running?
A: The machine can climb steps, drains, and shallow water areas.
FAQ & TROUBLE SHOOTING
If you encounter the following situations when using the cleaner, you can check
the table and solve them by yourself.
5
13ft (4m)
25.2V/2.6A
65W
100-240V, 50-60Hz
180µm
7.8kg
WYBOT C1 Pro(OS7010)
7800mAh
App Connection
OTA Update
Available
Available
Max. 150㎡
Name
Pool Size
Depth
Device Dimension
Weight
Runtime
Charging Time
Power
Charger Input
Charger Output
Battery Capacity
Filter
Flow Rate
Moving Speed
Water Resistance
WYBOT C1 Max(OS7010 Max)
Max. 200㎡
13ft (4m)
372(L)*360(W)*240(H) mm
372(L)*360(W)*240(H) mm
120min.~150min.
2.5 hours
180min.~
21
0
min.
3.5 hours
65W
100-240V, 50-60Hz
25.2V/2.6A
4600mAh
180µm
11.5 m³/H
11m/min
IPX8
11.5 m³/H
11m/min
IPX8
Available
Available
7.8kg
11 12
CERTIFICATION
5
6
only clean part area and cannot
clean the entire pool
Sinking down
away from wall
or floating on
the water
Filter basket blo-
cked
Filter basket blo-
cked
front side up when on the floor
Encounter Obst-
acles
The APP cannot be connected
when the device is in the pool
Wrong cleaning
mode
Firmware not the
latest
Connect to the App and
update the firmware
Clean the filter basket
7
8
Do not clean as set cleaning
path
Clean the filter basket
Device power off
Not available
Unable to connect to the App
Restart
Connect the device
on the shore
Connect to the App
and re-choose a suit-
able cleaning mode
Clean the filter basket
Intake air
No.
1
2
Issues
Device does
not work
A flashing red
light
A flashing red
light
A flashing yel-
low light
Battery low
Fully charge the device
and restart
Charger light
flashes
Unable to ch-
arge
Poor contact
Re-plug the charger
3
4
Do not climb walls
Abnormal wall
climbing
Climbing slowly
Filter basket blo-
cked
Clean the filter basket
Slippery constru-
ction materials
Stick floating parts (Con-
tact service team for ins-
truction.)
Too dirty water
Clean the filter basket
Possible Causes
A solid red light
Motor protection
Not put the device
into the water or
the pool water is
too shallow
Restart and put it into
the pool immediately.
Be sure the water dep-
th is over 0.5m.
Restart
Impeller is stuck
Suggested Solution
Check the impeller
and clean foreign
Details
WYBOT robotic pool cleaners have passed all performance and reliability tests
and also has obtained relevant certifications from the countries in which they are
sold. you can rest assured.
WYBOT CUSTOMER CARE
Wybot Customer Service:
Email: [email protected]
Facebook: @WybotPool
Tel: 1-866-777-6655
Due to the need for continuous products improvement, the products in the
manual are subject to the real products, and WYBOTICS Co., Ltd. reserves the
right to update products.
If you encounter any problems during use, please contact after-sale team.
For more details, please contact WYBOTICS website www.wybotpool.com
Stick floating parts (Con-
tact service team for ins-
truction.)
CERTIFICATION
C
US
CM
Document No. A2024701001
11 12
CERTIFICATION
5
6
only clean part area and cannot
clean the entire pool
Sinking down
away from wall
or floating on
the water
Filter basket blo-
cked
Filter basket blo-
cked
front side up when on the floor
Encounter Obst-
acles
The APP cannot be connected
when the device is in the pool
Wrong cleaning
mode
Firmware not the
latest
Connect to the App and
update the firmware
Clean the filter basket
7
8
Do not clean as set cleaning
path
Clean the filter basket
Device power off
Not available
Unable to connect to the App
Restart
Connect the device
on the shore
Connect to the App
and re-choose a suit-
able cleaning mode
Clean the filter basket
Intake air
No.
1
2
Issues
Device does
not work
A flashing red
light
A flashing red
light
A flashing yel-
low light
Battery low
Fully charge the device
and restart
Charger light
flashes
Unable to ch-
arge
Poor contact
Re-plug the charger
3
4
Do not climb walls
Abnormal wall
climbing
Climbing slowly
Filter basket blo-
cked
Clean the filter basket
Slippery constru-
ction materials
Stick floating parts (Con-
tact service team for ins-
truction.)
Too dirty water
Clean the filter basket
Possible Causes
A solid red light
Motor protection
Not put the device
into the water or
the pool water is
too shallow
Restart and put it into
the pool immediately.
Be sure the water dep-
th is over 0.5m.
Restart
Impeller is stuck
Suggested Solution
Check the impeller
and clean foreign
Details
WYBOT robotic pool cleaners have passed all performance and reliability tests
and also has obtained relevant certifications from the countries in which they are
sold. you can rest assured.
WYBOT CUSTOMER CARE
Wybot Customer Service:
Email: [email protected]
Facebook: @WybotPool
Tel: 1-866-777-6655
Due to the need for continuous products improvement, the products in the
manual are subject to the real products, and WYBOTICS Co., Ltd. reserves the
right to update products.
If you encounter any problems during use, please contact after-sale team.
For more details, please contact WYBOTICS website www.wybotpool.com
Stick floating parts (Con-
tact service team for ins-
truction.)
CERTIFICATION
C
US
CM
Document No. A2024701001
WYBOT C1 Pro/Max(OS7010/OS7010 Max)
Robotic Pool Cleaner
User Manual
Read through the entire manual before running your new
robotic pool cleaner, and keep this manual handy
for your reference.
Copyright© 2024 WYBOTICS Co., Ltd. All Rights Reserved.
www.wybotpool.com
Email: [email protected]
Facebook: @WybotPool
WYBOTICS CO.,LTD
No.30, Zhongnan 4th Street West Zone, TEDA Tianjin, China
All trade names are registered trademarks of respective manufacturers listed.
