QUICK REFERENCE GUIDE > OS24NDLX1 Date: 28.04.2023 > 1
Combination Steam Oven, 24",
18 Function
Series 7 | Contemporary
Stainless Steel
Designed to be the cornerstone of any kitchen solution, our
Combination Steam Oven is engineered for the home chef. In
compact size, this oven can be placed almost anywhere.
18 oven functions including Steam, Sous Vide, Air Fry and Vent
Bake
With steam cooking, convection cooking, or a combination of
both
Pair with our Vacuum Seal Drawer companion product for
effortless Sous Vide preperation
DIMENSIONS
Height
18"
Width
23 7/16"
Depth
22 1/4"
FEATURES & BENEFITS
COMBINATION COOKING
Give every ingredient the respect it deserves with combination
steam cooking. Using a fusion of dry convection heat with
variable amounts of steam, you can easily retain the delicate
texture of ingredients like salmon and snapper, the vitamins and
minerals of greens, or the depth of flavor of a perfect cut of
meat.
MASTERY OF TEMPERATURE
Elevate your meals with the precise temperature and humidity
control of steam cooking. Steam cooking has a gentler heat
transfer into the food, so you get nutritious and delicious results
that are moist and tender on the inside, crisp and flaky on the
outside, all with minimal effort.
PRESERVE FLAVOR AND NUTRIENTS
Cooking with steam creates dishes that are full of flavor, while
preserving all the vitamins, minerals and textures of delicate
ingredients, like fish and seafood. With five steam-only cooking
functions, including Sous vide, Steam and Steam Proof, you can
use steam to create healthier dishes that get the best out of each
component on the plate.
MULTI-FUNCTION FLEXIBILITY
A truly multiple function oven where both steam-only and
convection-only cooking mediums can stand on their own merits.
You have the freedom to choose – whether it's dry heat or moist
heat, or a combination of the two – each delivering different
cooking results. A Wireless Temperature Sensor precisely
monitors cooking in real time, giving you complete control.
DESIGN FREEDOM
This Contemporary style oven has a stylish black finish with
stainless steel contrasts, designed to help you achieve a kitchen
aesthetic that suits your design style. Pair with a Vacuum Seal
Drawer for the ultimate kitchen solution.
SIZED TO SUIT
This compact 24” Steam Oven can be placed almost anywhere.
All Companion products can be installed at a convenient height
to suit your kitchen design and preference.
SPECIFICATIONS
Accessories
Broil pan 1
Broil rack 1
Chromed shelf runners •
Descale solution 2 sachets, Part 580925
Large solid dish 1
Perforated large dish 1
Step down wire shelf 1
Telescopic sliding runners 1 set
Wire shelf 1
Wired temperature sensor 1
Capacity
Shelf positions 4
Total capacity 1.9cu ft
Usable capacity 1.6L
Cleaning
Acid resistant graphite enamel •
QUICK REFERENCE GUIDE > OS24NDLX1 Date: 28.04.2023 > 2
Descale cycle •
Drying cycle •
Removable oven door •
Removable oven door inner
•
Removable shelf runners •
Removable water tank •
Steam clean (oven) •
Controls
Adjustable audio and display
•
Audio feedback •
Automatic cooking/minute
•
Automatic pre-set
•
Delay start •
Electronic clock •
Electronic oven control •
Food probe •
Guided cooking by food types •
Halogen lights •
Multi-language display
UK English, US English,
Sabbath mode •
Soft close doors •
True convection oven •
Turned stainless steel dials
•
Wi-Fi connectivity •
Wireless temperature sensor
•
Functions
Aero Bake •
Aero Broil •
Air fry •
Bake •
Maxi Broil •
Number of functions 18
Pizza bake •
Roast •
Slow cook •
Sous vide •
Steam •
Steam clean (oven) •
Steam defrost •
Steam proof •
True Aero •
True Aero + High steam •
True Aero + Low steam •
True Aero + Medium steam •
Vent bake •
Performance
ActiveVent™ system •
AeroTech™ technology •
Automatic rapid pre-heat •
SteamTechnology •
Temperature range 95 °F - 445 °F
Whisper quiet cooking •
Power requirements
Amperage 16.6-19.4A
Supply frequency 60Hz
Supply voltage 208-240VV
Product dimensions
Depth 22 1/4"
Height 18"
Width 23 7/16"
Safety
ADA compliant •
Balanced oven door •
Control panel key lock •
CoolTouch door •
Non-tip shelves •
Safety thermostat •
Warranty
Parts and labor 2 years
SKU 82640
The product dimensions and specifications in this page apply to the specific product
and model. Under our policy of continuous improvement, these dimensions and
specifications may change at any time. You should therefore check with Fisher &
Paykel's Customer Care Centre to ensure this page correctly describes the model
currently available. ? Fisher & Paykel Appliances Ltd 2020
