Item Number 74001B00
48 in. Barnwood Finish
Reversible Blades (Reclaimed Hickory/Pewter Ash) Cage Shade
Smart Wi Technology
Specications
Size ............................................................... 48”
Blades .......................................................... Reversible Plywood Blades
(Reclaimed Hickory/Pewter Ash)
Blade Pitch ................................................ 11.5°
Approved Location ............................... Indoor
Suggested Room Size .......................... Large Room (up to 15x15)
Down Rod .................................................. 3/4 x 4”
Installation ................................................. Down Rod Only
Max. Ceiling Angle ................................. N/A
Lead Wire .................................................. 54”
Light Bulb Usage .................................... Includes (3) Medium (E26) Base, 4.5 Watt
Filament ST15 LED Lamps
Remote Control ....................................... Remote Control Included
Motor Finish .............................................. Barnwood
Motor Material ......................................... Silicon Steel Motor 153mm
x 15mm
Reverse Airow ....................................... Yes
Capacitor ................................................... Dual
Switch Housing Cap........................... Not Included
Energy Information
Airow (CFM) when operated at high speed..... 4637
Energy Use (Excludes lights)^......................... 37
Airow (CFM)^.................................................... 3264
Airow Eciency (CFM/W)^........................... 89
Estimated Yearly Energy Cost^....................... $10
RPM (High)........................................................... 200
Amp (High).......................................................... 0.49
Watts (High)........................................................ 57
Light Source
Number of Lamps........................... 3
Energy Use (Watts)†....................... 4.50
Equiv. Incand. Wattage†................ 40
Light Appearance (Kelvin)............ 2700
Lumens†............................................. 470
CRI...................................................... 80
Average Rated Hours..................... 15000
Life in Years**†................................. 13.60
Estimated Yearly Energy Cost..... $0.54
Barnett Ceiling Fan
Smart Wi Technology
With down rod
Reversible Pewter Ash
Finish Blades
DIMMABLE
2022
Compatible with
Amazon Alexa and
Google Assistant
A. Top of Canopy to Bottom of Blades ................................... .11.8”
B. Top of Canopy to Bottom of Switch House ....................12.6”
C. Top of Canopy to Bottom of Canopy ..................................2.2”
D. Width of Motor Housing ............................................................ 11.4”
E. Width of Canopy .................................................................................6”
F. Top of Canopy to Bottom of Glass ....................................... 21.3”
Item Number 74001B00
48 in. Barnwood Finish
Reversible Blades (Reclaimed Hickory/Pewter Ash) Cage Shade
Smart Wi Technology
Warranty
Ceiling fans backed by our Limited Lifetime Warranty have a lifetime motor warranty and a 2-year warranty on all other parts.
