Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
1.7 Cu. Ft. Compact
Refrigerator
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Main components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting up your refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting the thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Reversing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Before you begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Removing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Reinstalling the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Maintaining your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Defrosting your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Shutting down your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Moving your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your NS-CF17BK26
or NS-CF17BK26-C represents the state of the art in refrigerator design and is designed
for reliable and trouble-free performance.
3
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Important Safety Instructions
Read all instructions before use.
Keep these instructions.
For your safety and correct usage, please read these instructions carefully before using
your new appliance to avoid unnecessary mistakes and accidents. Please ensure that all
people using this appliance are familiar with its operation and safety features. Keep these
instructions in a safe place for future reference and be sure that they are kept with the
appliance in the event that it is moved or sold, so that everyone using it through its life
will be properly informed on its correct usage and safety. The manufacturer is not
responsible for damages caused by misuse. The appliance is for indoor and domestic use
only.
WARNING: Risk of fire or explosion/flammable materials
• Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage compartments of the
• appliance, unless they are of the type recommended by the manufacturer.
• If the SUPPLY CORD is damaged, it must be replaced by the manufacturer, its
service agent, or a similarly qualified person in order to avoid a hazard.
• Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
• Do not use extension cords or ungrounded (two prong) adapters.
• Unplug the cooler before carrying out user maintenance on it.
WARNING: Safety for children and others who are
vulnerable
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
• Keep all packaging away from children to avoid risk of suffocation.
• Never allow children to play with, operate, or crawl inside the refrigerators.
Risk of child entrapment. Before you throw away your old refrigerator:
1) Take off the door
2) Leave the shelves in place so that children may not easily climb inside
3) Have the refrigerant removed by a qualified service technician.
4
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
WARNING: General safety and daily use
• This appliance is intended to be used in household and similar applications
such as:
1) Staff kitchen areas in shops, offices, and other working environments
2)Farm houses and by clients in hotels, motels, and other residential
type environments
3)Bed and breakfast environments
4)Catering and similar non-retail applications
• Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
• Do not place the appliance in direct sunlight.
• Do not operate any electrical appliances within the appliance (such as
electric ice cream makers, mixers, etc.).
• Do not store flammable gases or liquids inside the refrigerator. There is a risk
of an explosion.
• Unplug this appliance during lightning storms or when it will not be used for
long periods of time.
• Unplug the power cord by holding the plug, never by pulling the cord.
WARNING: Disposal of appliance
• It is prohibited to dispose of this appliance as household waste.
• Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
gases must be disposed of professionally as they may cause eye injuries or a
fire hazard. Make sure that the refrigerant tubing is not damaged prior to
proper disposal.
• Packaging materials with the recycle symbol are recyclable. Dispose of the
packaging into a suitable waste collection container to recycle it.
• Before disposing of this appliance:
1) Unplug it.
2) Cut off and discard the power cord.
5
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Features
• 1.7 cu. ft. (.05 cu. m) refrigerator suits small areas
• Tempered glass shelf safely holds your foods
• Door racks hold your soda cans and a 2-liter bottle (bottom rack only)
• Reversible door hinge adjusts to fit your space
• Recessed handle takes up no additional space
• Mechanical dial makes it easy to adjust to your chosen temperature
Package contents
• 1.7 cu. ft. compact refrigerator
• User Guide
Main components
Setting up your refrigerator
WARNING
• Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
CAUTION
Flammable refrigerant used! When handling, moving, and using your
refrigerator, avoid damaging the refrigerant tubing, which may increase the risk
of a leak.
Thermostat
knob
Leveling foot
Door rack
Glass shelf
Bottle rack
6
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
Before using your refrigerator
• Remove the exterior and interior packing.
• Let your refrigerator stand upright for approximately two hours before connecting it
to power. This reduces the possibility of a malfunction in the cooling system from
improper handling during transportation.
• Clean the interior surface with lukewarm water using a soft cloth. See Cleaning your
refrigerator on page 12 for more information.
Finding a suitable location
• This refrigerator is designed to be free standing only, and should not be recessed or
built-in.
• Place your refrigerator on a floor that is strong enough to support your refrigerator
when it is fully loaded.
WARNING
The foam pad above the compressor is only suitable for transport and must be
removed before use.
7
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
• Allow at least 4 in. (10 cm) of space between your refrigerator and the side and back
walls, 10 in. (25 cm) above the top, and a clear space at the front to open the door.
This allows for proper air ventilation.
• Place your refrigerator away from direct sunlight and sources of heat (stove, heater,
radiator, and so on). Direct sunlight may affect the acrylic coating and heat sources
may increase electrical consumption. Ambient temperature below 50° F (10° C) or
above 110° F (43.3° C) will hinder the performance of your refrigerator. This
refrigerator is not designed for use in a garage or any other outside installation.
• Avoid placing your refrigerator in wet or moist areas.
Leveling your refrigerator
• It is very important for your refrigerator to be level in order to function properly. If
your refrigerator is not leveled during installation, the doors may not close or seal
properly, causing cooling, frost, or moisture problems. Also, if the ground is uneven,
the door will rub against the ground.
Providing a proper power supply
Check your local power source. This refrigerator requires a 115V AC at 60Hz power supply.
WARNING
Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
4 in. (10 cm)
4 in. (10 cm)
10 in. (25 cm)
8
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
Use a receptacle that accepts the grounding prong. The power cord is equipped with a
three-prong (grounding) plug which mates with a standard 3-prong (grounding) wall
outlet to minimize the possibility of electric shock hazard from this refrigerator.
Setting the thermostat
Adjust the thermostat to set your refrigerator’s temperature from 32° to 50° F (0° to 10° C).
1 The first time you turn your refrigerator on, adjust the temperature setting to MAX
and let your refrigerator cool completely before putting food in. You can adjust it to a
warmer or cooler setting, as needed.
2 Rotate the thermostat to adjust the temperature:
• OFF: Turns your refrigerator off
• MIN: Warmest temperature setting
• MED: Moderate temperature - recommended
• MAX: Coldest temperature setting
Notes:
• Your refrigerator should always be plugged into its own individual electrical outlet
which has a voltage rating that matches the rating plate.
• Never unplug your refrigerator by pulling on the power cord. Always grip the plug
firmly and pull straight out from the outlet.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet
Using a grounding adapter
9
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Reversing the door
You can change the side that the door opens on from the right side (as shipped) to the
left side.
You will need: An 8 mm (5/16”) socket wrench or Phillips screwdriver, and a flathead
screwdriver
Before you begin
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
Removing the door
1 Lay your refrigerator on its back to gain access to the base. You should rest your
refrigerator on soft foam packaging or similar material to avoid damage to the
cooling pipes on the back of your refrigerator.
2 Open your refrigerator door and remove all the shelves inside the door.
3 Remove the upper hinge cover with flathead screwdriver.
4 Using a Phillips screwdriver or 8 mm socket wrench remove the two screws that hold
the upper hinge to the right side of the cabinet top.
5 Carefully lift the door off and place it on a padded surface to prevent scratches.
Notes:
• The recommended temperature setting is “MED.”
• Though your refrigerator is energy efficient, it is more efficient at lower
temperature settings.
• Keep soda cans away from the refrigerator wall because the cans could freeze at
the coldest temperature setting.
• If the thermostat is set to “MAX” when the ambient temperature is high (such as
on hot summer days), the compressor may run continuously. To properly defrost,
the compressor needs to turn on and off periodically. Therefore, we advise you to
set the refrigerator to a more moderate setting.
8 mm socket wrench
Phillips screwdriver
Flathead screwdriver
OR
Upper hinge cover
Screws
Upper hinge
10
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
6 Remove the screw hole covers and push them firmly into the uncovered holes on the
right side of your refrigerator.
7 Using a Phillips screwdriver, remove the two screws that hold the lower hinge to the
right side of the cabinet. Keep the lower hinge and screws to reuse.
8 Remove the foot and transfer it to the right side of the cabinet.
Reinstalling the door
1 Install the hinge you removed from the right side in step 7 to the left side, with the
two screws you saved.
2 Replace the door, making sure the pin enters the bushing at the lower frame hole.
Screw hole covers
Lower hinge
Screws
Foot
11
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
3 Loosely secure the lower hinge, but do not fully tighten the screws until the door is in
the closed position and leveled. Make sure that the space between the door and the
refrigerator body is approximately 1/2 in. (12.5 mm).
4 Secure the upper hinge (removed in step 4) to the left side of your refrigerator. Make
sure that the pin enters the hole on the upper frame.
5 Replace the upper hinge cover (removed in step 3).
6 Lift your refrigerator upright again.
7 Open the door and attach all shelves.
CAUTION
Let your refrigerator stand upright for approximately two hours before
connecting it to power. This reduces the possibility of a malfunction in the
cooling system.
1/2 in. (12.5 mm)
Screws
Upper hinge
Upper hinge cover
12
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
Maintaining your refrigerator
Your refrigerator is designed for year-round use with only minimal cleaning and
maintenance.
When you first receive it, wipe the case with a mild detergent and warm water, then wipe
dry with a dry cloth. Do this periodically to keep your refrigerator looking new.
Cleaning your refrigerator
For hygienic reasons, the inside of your refrigerator and its accessories should be cleaned
every two months.
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food and store in a cool place.
3 Wash your refrigerator’s interior and exterior with mild detergent and warm water,
then wipe dry.
4 Wipe the door gasket (seal) clean to keep the unit running efficiently.
5 Once a year, carefully clean the condenser on the back of your refrigerator with a soft
brush or vacuum cleaner to remove dust and debris that increases energy usage.
6 Check the water drain hole on the back wall inside your refrigerator compartment. If
it’s blocked, clear the drain hole with something like a pipe cleaner. Be careful not to
damage the cabinet with sharp objects.
7 Dry the interior and exterior with a soft cloth.
8 Plug in the refrigerator’s power cord and turn it back on.
WARNING
Danger of electric shock.
WARNING
Flammable refrigerant used. Do not damage the refrigerant circuit.
CAUTION
• Do not use harsh or abrasive cleaners.
• Do not use gasoline, benzine, thinner, or other similar solvents.
• Ethereal oils and organic solvents can attack plastic parts, such as lemon juice
or the juice from orange peel, butyric acid, and cleansers that contain acetic
acid. Do not allow such substances to come into contact with appliance
parts.
• Do not use razor blades or other sharp instruments, which can scratch the
appliance surface when removing adhesive labels. Any glue left from the
tape can be removed with a mixture of warm water and mild detergent, or
touch the residue with the sticky side of tape already removed. Do not
remove the serial plate.
• Do not clean your refrigerator with a steam cleaner. Moisture could
accumulate in electrical components and hot vapors can damage plastic
parts.
13
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Defrosting your refrigerator
Turn the temperature control knob to OFF, and remove all food from your refrigerator.
The defrost water is discharged to the water pan at the back of your refrigerator. Allow
your refrigerator to defrost until there is no moisture on the back side liner.
Shutting down your refrigerator
To prepare your refrigerator for long term storage or a long vacation:
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Clean and dry your refrigerator.
4 Leave the door open slightly to avoid possible formation of condensation, mold, or
odor.
Moving your refrigerator
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Securely tape down all loose items inside your refrigerator.
4 Tape the doors shut. Make sure that your refrigerator stays in the upright position
during transportation.
Tips on saving energy
• Do not open and close the door too often or leave the door open any longer than
necessary.
• Do not set the temperature any colder than necessary.
• The Features
illustration on page 5 shows the most energy efficient arrangement of
shelves in your refrigerator. If you change this arrangement, you may sacrifice
efficiency.
• Do not exceed the recommended storage period for your food.
• Locate your refrigerator in the coolest area of the room, away from heat producing
appliances or heating ducts and out of the direct sunlight.
• Let hot foods cool before placing them in your refrigerator.
• Overloading your refrigerator forces the compressor to run longer. Foods that freeze
too slowly may lose quality or spoil.
• Wrap foods properly and wipe containers dry before placing them in your
refrigerator. This cuts down on frost build-up inside your refrigerator.
• Organize and label food to reduce door openings and extended searches.
CAUTION
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING
Use extreme caution with children. The unit should not be accessible to child's
play.
14
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
Troubleshooting
Note: Minor malfunctions may be caused by a fault that you can rectify yourself,
using the following instructions. Do not perform any other work on your
refrigerator if this troubleshooting table does not fix the problem.
CAUTION
It is our recommendation that repairs only be performed by qualified service
personnel. Improper repairs can result in significant hazards for the user. If your
refrigerator requires repair, contact your dealer or your local service center.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
My refrigerator
does not operate.
Your refrigerator is turned off. Make sure that the thermostat knob is
not set to “OFF”. If it is, change to the
appropriate setting.
Your refrigerator is unplugged. Make sure that your refrigerator is
plugged in and that the plug is
pushed completely into the outlet.
The fuse for the refrigerator
circuit is blown or the breaker
has tripped.
Make sure that the fuse is good or the
circuit breaker is turned on.
Power failure. If a power failure occurs, your
refrigerator turns off. Wait until the
power is restored.
The electrical outlet is defective. Make sure that the electrical outlet is
“live.” If not, have an electrician correct
the problem.
Food in my
refrigerator
compartment is
not cold.
The door has been opened too
often or was not closed properly.
Make sure that the door is closed
properly.
You have just added a large
amount of food to your
refrigerator.
Allow time for the new food to cool,
then check again. Let hot foods cool
before placing them inside your
refrigerator.
The thermostat is set too warm. Adjust the thermostat to a colder
setting.
The door gasket does not seal
properly.
Clean the gasket.
Your refrigerator has recently
been disconnected for a period
of time.
Allow up to four hours for your
refrigerator to cool completely.
Your refrigerator is too close to a
heat source.
See Finding a suitable location
on
page 6
.
15
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
The compressor
turns on and off
frequently or
runs
continuously.
The door has been opened too
often or was not closed properly.
The door seal may be dirty.
Make sure that the door is closed
properly. Clean the door seal if
necessary.
The room temperature is hotter
than normal.
This is normal, under the
circumstances. Because the
compressor needs to turn off
occasionally to defrost, make sure not
to set your refrigerator’s temperature
too low. If your refrigerator has an
issue with frost, try a warmer
temperature setting.
A large amount of food was
recently added to your
refrigerator.
This is normal, under the
circumstances. Let hot food cool
before placing it inside your
refrigerator.
The thermostat is set too cold. Set the thermostat to a warmer
temperature.
Your refrigerator does not have
the correct clearances.
Leave at least 4 in. (10 cm) of space
between the wall and the back and
sides of your refrigerator, and 10 in.
(20 cm) at the top for heat dissipation.
Your refrigerator has recently
been disconnected for a period
of time.
Allow up to four hours for your
refrigerator to cool down completely.
Food in my
refrigerator
compartment is
freezing.
The thermostat is set too cold. Set the thermostat to a warmer
setting.
My refrigerator
makes unusual
noises or
vibrations.
Your refrigerator may not be
level on the floor.
Level your refrigerator with the
leveling foot.
The body of your refrigerator is
touching a wall.
Move your refrigerator out from the
wall.
The compressor buzzes during
operation (louder when turning
on or off).
This is normal.
The refrigerant is creaking or
moaning.
This is a normal noise as the
refrigerant passes through the cooling
system.
Accessories are misplaced. Make sure that your refrigerator
accessories are placed properly.
The sound of ice cracking is
caused by thermal expansion
and cold contraction.
This is normal. You can manually
adjust the thermostat to “OFF,” then
adjust to the appropriate setting until
there is no water beading on the back
side liner.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
16
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
Moisture is
building up in
the interior of my
refrigerator.
The door has been opened too
often or was not closed properly.
Make sure that the door is closed
properly.
Your refrigerator is in a location
that is very humid.
Move your refrigerator to a dryer
location.
The food in your refrigerator is
not packaged properly.
Repackage the food in your
refrigerator to make sure that it is
sealed.
Moisture is
building up on
the exterior of my
refrigerator.
The door may be slightly open. Make sure that the door closes
completely.
The humidity is high. This is normal. Just wipe the
condensation with a clean towel.
My refrigerator
door does not
close completely.
Food packages are interfering
with the door.
Move the food packages or remove
some food.
The shelves are out of position. Adjust the shelves properly.
The door gaskets are dirty. Clean the door gaskets.
Your refrigerator is not level. Level your refrigerator with the
leveling foot.
The exterior of
my refrigerator is
warm.
In the insulated walls of your
refrigerator there is a heat
exchanger coil. This produces
heat.
This is normal. The longer your
refrigerator runs the warmer the sides
and top will get.
The ambient temperature is too
high.
Move your refrigerator to a cooler
location.
Too much food is being stored. Remove some food from your
refrigerator.
Your refrigerator does not have
the correct clearances.
Leave at least 4 in. (10 cm) of space
between the wall and the back and
sides of your refrigerator, and 10 in.
(20 cm) at the top for heat dissipation.
The drip tray
overflows.
There is too much food in your
refrigerator, or the stored food
contains too much water,
causing heavy defrosting.
Remove excess food from your
refrigerator.
The doors are not properly
closed.
Make sure that the door closes
completely.
The door gasket
(seal) is not tight.
The gasket is dirty. Clean the door gaskets.
Your refrigerator is not level. Use the front leveling feet to level your
refrigerator.
The door seal (gasket) is aging. Replace the door gasket.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
17
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Specifications
My refrigerator
has a bad odor.
Odorous foods are not wrapped
properly.
Make sure that you seal your food
properly.
Food is rotting. Remove rotten food from your
refrigerator.
Your refrigerator is dirty. Clean your refrigerator.
The compressor
does not start
immediately after
changing the
temperature
setting.
This is normal. The compressor will start after a set
period of time.
Dimensions (H × W × D) 19.29 × 18.58 × 17.56 in.
(49 × 47.2 × 44.6 cm)
Weight 31.42 lbs. (14.25 kg)
Capacity 1.7 cu. ft. (.05 cu. m)
Temperature range 32° to 50° F (0° to 10° C)
Ambient temperature range 50° to 110° F (10° to 43.3° C)
Power cord length 65 in. (1.65 m)
Noise 40dB (A)
Power requirements 115V AC at 60Hz
Current .85A
Power consumption (annual) 246 kWh/year
Refrigerant type R600a
Garage ready No
Energy Star certified Yes
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
18
NS-CF17BK26/NS-CF17BK26-C
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY
Best Buy, or its Authorized Partner of Insignia branded products, warrants to you, the original
purchaser of this new Insignia branded product (“Product”), that the Product shall be free of defects
in the original manufacture of the material or workmanship for a period of one (1) year from the date
of your purchase of the Product or the date of delivery (if later than the date of purchase) (“Warranty
Period”).
For this warranty to apply, your Product must be (i) purchased in the United States or Canada from a
Best Buy branded retail store, online at www.bestbuy.com or www.bestbuy.ca, or from Best Buy’s
Authorized Partner, and (ii) packaged or sold with this warranty statement.
The term “Best Buy”, as used in this warranty, refers to Best Buy branded retail stores,
www.bestbuy.com
, www.bestbuy.ca, and Best Buy’s Authorized Partner.
Because Insignia cannot control the quality of products sold by unauthorized sellers, this warranty
applies only to Products that were purchased from Best Buy or an Insignia Authorized Partner, unless
otherwise prohibited by law. Insignia reserves the right to reject warranty claims for Products
purchased from unauthorized sellers, including unauthorized websites.
REPAIR OR REPLACEMENT, AS PROVIDED UNDER THIS WARRANTY, IS YOUR EXCLUSIVE REMEDY FOR
BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR THE BREACH OF ANY EXPRESSED OR IMPLIED WARRANTY ON THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS, OR
LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO
THE PRODUCT. ALL EXPRESSED AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT
NOT LIMITED TO ANY IMPLIED WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET
FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESSED OR IMPLIED, WILL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES, PROVINCES, AND JURISDICTIONS DO NOT ALLOW LIMITATIONS
ON (i) HOW LONG AN IMPLIED WARRANTY LASTS, (ii) EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, or (iii) LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO
STATE OR PROVINCE TO PROVINCE.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product or the date
of delivery (if later than the date of purchase). Your purchase date is printed on the receipt you
received with the Product. In the event that Authorized Partner ceases to sell the covered Insignia
branded product, this warranty shall terminate for that product and there shall be no repair or
replacement of the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the
Product is determined to be defective by an authorized Insignia repair center or store personnel,
Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the
Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced
under this warranty become the property of Insignia and are not returned to you. If service of
Products or parts are required after the Warranty Period expires, you must pay all labor and parts
charges. This warranty lasts as long as you own your Insignia Product during the Warranty Period.
Warranty coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or from a Best Buy online website
(www.bestbuy.com
or www.bestbuy.ca), please take your original receipt and the Product to any
Best Buy store. Make sure that you place the Product in its original packaging or packaging that
provides the same amount of protection as the original packaging. If you purchased your Product
from an Authorized Partner, call Insignia at 1-877-467-4289.
To obtain warranty service, in the United States and Canada call 1-877-467-4289. Call agents may
diagnose and correct the issue over the phone.
19
1.7 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
If you purchased the Product from an Authorized Partner other than Best Buy, please call
1-888-BESTBUY in the United States or 1-866-BESTBUY in Canada. You will be asked to provide proof
of purchase and to return your Product to Best Buy. Make sure that you put the Product in its original
packaging or packaging that provides the same amount of protection as the original packaging.
Where is the warranty valid?
This warranty is valid only in the United States and Canada to the original purchaser of the product
from an Authorized Partner, in the country where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Food, beverage, and or medicine loss/spoilage.
• Damage to other products caused by a power surge or other similar issue while connected
to the Product.
• Customer instruction/education.
• Installation.
• Set up adjustments.
• Cosmetic damage.
• Damage due to weather, lightning, and other acts of God, such as power surges.
• Accidental damage.
• Misuse.
• Abuse.
• Negligence.
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or otherwise
used in a place of other than a private home.
• Modification of any part of the Product, including the antenna.
• Display panel damaged by static (non-moving) images applied for lengthy periods
(burn-in).
• Damage due to incorrect operation or maintenance.
• Connection to an incorrect voltage or power supply.
• Damage due to attempted repair by any person not authorized by Insignia to service the
Product.
• Products sold “as is” or “with all faults”.
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.).
• Products where the factory applied serial number has been altered or removed.
• Loss or Theft of this product or any part of the product.
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly
illuminated) grouped in an area smaller than one tenth (1/10) of the display size or up to
five (5) pixel failures throughout the display. (Pixel based displays may contain a limited
number of pixels that may not function normally.).
• Failures or Damage caused by any contact including but not limited to liquids, gels or
pastes.
Contact Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A
©2025 Best Buy. All rights reserved.
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2025 Best Buy. All rights reserved.
V3 ENGLISH
25-0444
