SPECIFICATION SHEET
WESTINGHOUSE LIGHTING
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
^ Based on typical use, excluding lights
* Based on 12 cents per kWh and 6.4 hours use per day
† Values are per lamp
** Based on 3hrs./day
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
Item Number 74002B00
60 in. Black-Bronze Finish
Reversible Blades (Applewood/Cherry) Frosted Opal Glass
Smart Wi Technology
Specications
Size ............................................................... 60”
Blades .......................................................... Reversible Plywood Blades
(Applewood/Cherry)
Blade Pitch ................................................ 11°
Approved Location ............................... Indoor
Suggested Room Size .......................... Great Room (up to 20x20)
Down Rod .................................................. 3/4 x 6”
Installation ................................................. Down Rod Only
Max. Ceiling Angle ................................. N/A
Lead Wire .................................................. 54”
Light Bulb Usage .................................... Includes (2) Medium (E26) Base,
8 Watt T7 LED Lamps
Remote Control ....................................... Remote Control Included
Motor Finish .............................................. Black-Bronze
Motor Material ......................................... Silicon Steel Motor 188mm
x 22mm
Reverse Airow ....................................... Yes
Capacitor ................................................... Single
Switch Housing Cap........................... Not Included
Energy Information
Airow (CFM) when operated at high speed..... 6573
Energy Use (Excludes lights)^......................... 52
Airow (CFM)^.................................................... 4383
Airow Eciency (CFM/W)^........................... 85
Estimated Yearly Energy Cost^....................... $14
RPM (High)........................................................... 141
Amp (High).......................................................... 0.72
Watts (High)........................................................ 84
Light Source
Number of Lamps........................... 2
Energy Use (Watts)†....................... 8
Equiv. Incand. Wattage†................ 60
Light Appearance (Kelvin)............ 3000
Lumens†............................................. 800
CRI...................................................... 80
Average Rated Hours..................... 25000
Life in Years**†................................. 22.80
Estimated Yearly Energy Cost..... $0.96
Cayuga Ceiling Fan
Smart Wi Technology
With down rod
Reversible Cherry
Finish Blades
DIMMABLE
2022
Compatible with
Amazon Alexa and
Google Assistant
A. Top of Canopy to Bottom of Blades .................................. .13.8”
B. Top of Canopy to Bottom of Switch House .....................11.5”
C. Top of Canopy to Bottom of Canopy ..................................2.6”
D. Width of Motor Housing ...........................................................10.6”
E. Width of Canopy ..............................................................................5.1”
F. Top of Canopy to Bottom of Glass .........................................17.1 ”
Warranty
Ceiling fans backed by our Limited Lifetime Warranty have a lifetime motor warranty and a 2-year warranty on all other parts.
SPECIFICATION SHEET
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by Westinghouse Lighting. All Rights Reserved.
Specifications are subject to change without notice, please visit www.westinghouselighting.com for latest information.
2022
WESTINGHOUSE LIGHTING
Item Number 74002B00
60 in. Black-Bronze Finish
Reversible Blades (Applewood/Cherry) Frosted Opal Glass
Smart Wi Technology
Cayuga Ceiling Fan
Smart Wi Technology
