Instruction Manual
Handy Cordless Vacuum
Cleaner Manual
Make Your Daily Cleaning Easy
Model Number: L7
Important Safety Instructions
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
Personal Safety:
1. Store indoors in a dry place out reach of children;
2. The device CANNOT be used by children, physically and mentally
fragile people and people lack of related experience and knowledge,
unless they are supervised by others and they fully understand the
possible potential hazards.
3. Keep children away from the device. Otherwise, children must be
supervised when using or maintaining the appliance.
4. Use the manufacturer’s recommended attachments and accessories
only. Using other accessories may have a risk of safety hazard.
5. Take extra care when cleaning stairs;
6. Keep the appliance and accessories away from hot surface;
7. Do not block the outlet of the appliance or hinder the airflow. Keep
dust, lint, clothing or fingers away from the outlet.
8. Do not block the outlet and attachments of the device.
Do not use the device or leave it outdoors when it
’
s raining.
Basic safety precautions should always be observed when
using an electrical appliance, including the following to reduce the risk
of fire, electrical shock, or injury.
WARNING:
1
Electrical Safety:
1. Only use batteries and chargers supplied by the manufacturer;
2. Never modify the charger in any way;
3. The charger has been designed at a specific voltage. Always make
sure the main voltage is the same as the specific voltage.
4. There is a risk of fire when a charger that is designed for a specific
battery type is used with another type of batteries.
5. Check if there is damage or tear and wear on the charging cable.
A damaged or entangled charging cable may increase the risk of fire
and electric shock.
6. Do not abuse the charger;
7. Never carry the charger by the cord;
8. Do not pull the charging cable when the charge is plugged into an
outlet.
9. Do not wrap the charger with the charging cable when you store the
charger.
10. Keep the charger away from hot surfaces and sharp edges;
11. The included charging cable is not replaceable. If the charging cable
is damaged, please change another charger directly.
12. Do not operate the charger or the appliance with wet hands;
13. Do not store or charge the appliance outdoors;
14. The charger must be removed from the socket before removing
the battery, cleaning or maintaining the appliance.
Battery Safety:
1. This appliance included Li-ion batteries. Please do not expose the
appliance to high-temperature environments as the batteries may
explode.
2. Liquid from the battery may cause irritation or burns;
2
3. For any emergency, please contact professional staff for help
immediately.
4. Li-ion batteries may leak corrosive fluid under extreme conditions.
Do no touch the liquid. If the liquid splashes on your skin, wash your
skin immediately with soap and water. If the liquid splashes in the eye,
flush your eye with clean water for at least 10 minutes and seek medical
attention. Wear gloves to handle and dispose of the battery based on
local regulations.
5. A short circuit may cause a fire.
6. When the battery is not in use, keep it away from clips, coins, keys, nails,
screws or other small metal objects;
7. When you dispose of the appliance, remove the battery and dispose
of the battery safely in accordance with local regulations.
Attention:
1. If the appliance hits an object, please check if there is any damage.
2. Do not use the appliance if any part is damaged or defective;
3. Repairs should be carried out by a service agent or a suitably
qualified person in accordance with relevant safety regulations;
Repairs by unqualified persons may have a risk of damaging the
appliance;
4. Never modify the appliance in any way as this may increase the
risk of personal injury;
5. Only use replacement parts or accessories provided or
recommended by the manufacturer.
3
Intended Use:
1. The appliance is designed for use in dry environments for vacuum
cleaning only;
2. Do not use the appliance on any wet surface or to clean any liquid;
3. Do not use the appliance to clean flammable or burning objects;
4. Use the appliance properly based on this user manual;
5. Don’t use the appliance on concrete, tarmacadam or other rough
surfaces.
WARNING:
1. Do not use water, solvents, or polishes to clean the outside of the
appliance; Clean it with a dry cloth;
2. Never immerse the unit in water and do not clean it in a dish washer.
4
5
PRODUCT INSTRUCTIONS
Battery Release Button
Switch Button(On/Off)
Main Screen
Retractable Metal Tube
Floor Brush Release Button
Floor Brush
Dustbin Release Button
Extend-Retract Tube Button
Battery Pack
Soft Dusting Brush Power Adapter Wall Bracket HEPA FilterCleaning ToolLong Suction Nozzle
6
Multi-Task Roller Brush with LED
The roller brush increases the cleaning efficiency, ideal for removing
stubborn dirt in the carpets, dust and debris on hard floors.
Long Suction Nozzle
The crevice tool is used for corners, niches and other hard-to-reach
places, such as car seat and mat, picture frame, etc.
Soft Dusting Brush
Angled bristles on slender and the oval shape provide anti-static
cushioned contact, suitable for cleaning dust on sofa, curtain or other
fabric furniture or delicate surfaces, electronics and more.
Cleaning Tool
Use the end with small blade to remove the hair and debris wrapped
around the roller brush. Use the end with little brush to clean the the
dustbin and the HEPA filter.
Power Adapter
Charge the battery of the vacuum cleaner with the power adapter.
HEPA Filter
The HEPA filter increases the cleaning efficiency and removes up to
99.8% of ultrafine dust particles down to 0.3 microns.
Accessory Instructions
On Screen Display
7
Speed Button
1. Speed adjustment:
2. Fault indication:
When the roller brush is clogged, the red light of the roller brush clog
indicator will flash, and then the floor brush will stop working.After
cleaning the dust or dirt, restart the machine, and it will work normally.
click the Speed button to change the suction power.
Note:
Battery Indicator Light
Three-speed Indicator
Ring Light
Speed Indicatorring
Light
Roller Brush Clog
Reminder
Low Battery Indicator
Air Duct Clog Reminder
When the machine is powered on, it is in the small mode by default,
and the green circular indicator will light up.
Click the ""Speed"" button to switch the machine to the medium mode,
then the blue circular indicator ring will light up.
Click the ""Speed"" button again to switch the machine to the maximum mode,
and the red circular indicator ring will light up.
When the machine is clogged, the red light of the dust blocking indicator
light will flash. After clean the dust or dirt, restart the machine, and it will
work normally.
8
Assemble and Disassemble the Retractable Metal Tube
Insert the retractable metal tube
into the main motor.
Press the release button and then
remove the retractable metal tube.
Assembly
Assemble and Disassemble the Motorized Floor Brush
Insert the motorized floor brush
to the retractable metal tube.
Press the release button and then
remove the motorized floor brush.
Assemble and Disassemble the Roller Brush
Press the roller brush release
button according to the diagram.
Open it to 90°, and then pull it out
to remove the roller brush.
9
Disassemble the Dustbin
1. Press the dustbin release button to clean it
2. Press the dust cup release button and use upward force to remove the dust cup
3. Remove the sponge and filter assembly from the dust cup, then rotate the cone
counterclockwise to disassemble it
4. Pull the Hepa outwards
1
2
3
4
Assemble and Disassemble the Battery
Press the battery release button and
remove the battery.
Slide the battery into place.
PRODUCT OPERATION
How to Operate the Vacuum
Press the switch button and then
the vacuum will start to work.
Press the switch button again and then
the vacuum will stop working.
1
10
11
Press the extend-retract tube button with one hand, extending or retracting to
choose the suitable vacuum cleaner height for more comfortable cleaning
with the other hand;
Three Ways to charge the Vacuum cleaner:
2. Remove the battery from the vacuum cleaner and charge it separately by
power adapter;
1. Charge the vacuum cleaner head by power adapter;
3. Charge the whole vacuum cleaner by power adapter.
Charging mode : directly insert into the charging socket of the battery
to charge.
2
Battery Charging:
1. When the battery power is low to one bar, the low battery indicator flashes,
indicating that the machine's battery power is low;
3. When the battery is fully charged, the battery indicator lights on constantly and
shows five bars on the screen.
2. When the battery is in the charging state, the blue battery indicator light flashing;
Battery Indicator Light:
3
1
2
3
Press the Dustbin Release Button
1. Please clean the dustbin when the dust reaches the MAX level;
2. We suggest to clean the dustbin each week even the dust
doesn't reach its MAX level.
Note:
Note:
How to Empty the Dustbin
Disassemble the filter system as above, then clean it.
1. Cleaning the dustbin: wipe with a brush or dry cloth.
2. Cleaning the stainless steel filter: wipe with a brush or dry cloth.
If it is too dirty, wash it and dry it in the sun.
3. HEPA cleaning: clean the HEPA 2-3 months, if it is too dirty, please replace
the HEPA in time.
It is recommended to clean the HEPA filter 2-3 months for better cleaning efficienc y.
Please make sure dry the filter completely before use. Otherwise, it will affect the life
of the machine.
Clean the Filter Components
Maintenance
12
13
Remove the roller brush and clean the hair and other dirt tangled on the roller
brush with the cleaning tool. If the roller brush is too dirty, please wash it and
dry it completely in a well-ventilated place under the sun.
Clean the Roller Brush
Assemble the rack against the wall and place the machine on the rack. Place
the accessories in the charging station slot.
Product Storage
14
• Do not carry out any maintenance or repair work beyond this user manual.
• Store the machine indoors. Do not use or store it below 37.4°F (3°C).
Ensure the machine is at room temperature before operating.
• Clean the machine only with a dry cloth. Do not use any lubricants, cleaning
agents, polishes or air fresheners on any part of the machine.
Maintenance
When using the Lubluelu vacuum cleaner, basic precautions should always
be followed. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
1. Please use the original parts for the machine. Do not use non-original parts
without the permission of the manufacturer. If there is any malfunction due
to using non-original parts, the warranty will be automatically ended. The
manufacturer is not responsible for any loss of life or property.
2. Please check if the product is damaged or the accessories are completely
received after you have received the package.
3. Do not use the vacuum with any damaged cord or plug. If the appliance
has been dropped, damaged, left outdoors, dropped into water, or is not
working, return it to the manufacturer.
4. Children below 15 years old and incapacitated persons should use this
machine under the supervision of their guardians.
5. When a fault occurs, the power adapter should be pulled out immediately
and the defective product should not be in working status.
6. Please do not disassemble and repair all the electric parts including but not
limited to motors, battery and power adapter, which is easy to damage the
machine and cause other insecurity.
Any content with the logo means being prohibited.
Otherwise, it may cause damage to the product or
endanger the personal safety of the user.
Prohibited sign
15
All contents with the logo mean it must be handled in
strict accordance with the requirements. Otherwise, it
may cause damage to the product or endanger
personal safety of the user.
This product is for household use
only. Do not use this product
outdoors.
Children below 15 years old are not
allowed to use the device alone to
avoid dangers like electric shock.
Please do not let the vacuum cleaner
too close to the heat source and
other high temperature objects, lest
plastic deformation. It will affect the
use of the vacuum cleaner.
When using the vacuum cleaner,
please pay attention to the installation
of various filter parts. Do not use the
vacuum cleaner when there are no
filter accessories.
Please don't use the vacuum cleaner
to suck up burning cigarette butts,
so as to avoid danger. Please do not
suck up detergent, kerosene, gasoline,
paint, sewage and other liquids, in
case the liquid enters the motor and
causes motor failure.
Warning sign
When cleaning the vacuum cleaner,
please use the wet cloth with water
or neutral detergent. Do not use
gasoline, banana oil, etc., or it will
cause shell crack and fade.
16
Troubleshooting
Problem Possible Cause Solution
Please do not suck up hair group,
paper group and other objects that
are easy to block the suction port
and air duct.
Please do not place heavy objects
on the machine or tread on the
machine.
After 5-6 hours of charging time,
please unplug the power adapter
from the socket and keep it properly.
Keep the power adapter out of reach
of children.
Please do not use the vacuum cleaner
to suck up cement, gypsum powder,
wall powder, starch and other small
particles. Otherwise, it will cause
vacuum cleaner filter part blockage,
motor burnout and other faults. If the
vacuum cleaner sucks up the above
small particles, please clean all filter
parts in time.
1. Low battery
2. Pipe is blocked
Product stops
working
1. Use the device after it is fully
charged
2. Clean the pipe and restart
the device
1. Low battery
2. Run with MAX mode
all the time
Working time is too
short
1. Use the device after it is fully
charged
2. Select the appropriate
suction speed according to
different floor conditions
17
Problem Possible cause Solution
1. The dust fills the
dustbin up to the MAX
line
2. The roller brush is
blocked by objects such
as hair
3. HEPA is dirty or
missing
The suction power
of the product is
reduced
1. Clean the dustbin on time
2. Clean the roller brush on
time
3. Clean HEPA in time or use it
after HEPA installation
1. The power outlet is
damaged
2. The power adapt-
er/charging port is not
properly inserted into
the charging port of
the socket/rack
3. The original power
adapter is not used
4. Overheating
protection
Battery is not
charging
1. Replace the power outlet
2. Insert the power adapt-
er/charging port into the
charging port of the
socket/rack correctly
3. Use the original power
adapter to charge the appli-
ance
4. Wait for a few minutes until
the appliance cools down
before charging.
Roller brush is blocked
by objects such as hair
Roller brush does
not turn/floor
brush light does
not turn on/roller
brush blockage
light is on
Clean roller brush in time and
restart the machine
Pipe is blocked
Abnormal motor
noise
Clean the pipe in time
Insufficient battery
power
Battery indicator is
flashing
Charge the appliance in time
Dust detection sensor
is clogged/dirty
Automatic mode
does not work
Clean the trash/dirt from the
dustbin port in time
18
The 2-Year Limited Warranty
Applies to purchases made from authorized retailers of Lubluelu. According
to the requirements outlined in this instruction manual, subject to the
following conditions and exclusions.
WHAT IS COVERED?
Your Lubluelu machine has a 2-year warranty against original defects in
material and workmanship.
when used for private household purposes in accordance with the
Lubluelu Instruction Manual.
This warranty provides, at no extra cost to you, all labor and parts necessarily
to ensure your machine is in proper operating condition during
the warranty period.
This warranty will only be valid if the machine is used in the country in which
it was sold.
Warranty
Note:
If the above solutions cannot solve the problems, please contact us via support
@lubluelu.com or visit our website lubluelu.com for further support.
19
WHAT IS NOT COVERED?
Lubluelu shall not be liable for costs, damages or repairs
incurred as a result of:
• Machines purchased from an unauthorized dealer.
• Careless operation or handling, misuse, abuse and/or lack of maintenance
or use not in accordance with the Lubluelu Instruction Manual.
• Use of the machine other than for normal domestic purposes, e.g.
for commercial or rental purposes.
• Use of parts not in accordance with the Lubluelu Instruction Manual.
• Use of parts and accessories other than those produced or recommended
by Lubluelu.
• External factors unrelated to product quality and use, like accidental
water damage.
• Repairs or alterations carried out by unauthorized parties or agents.
• Failing to clear blockage and other hazardous material from the machine.
• Normal wear and tear, including normal wearing parts, such as dustbin, filter,
HEPA, and power adapter (or where external damage or abuse is diagnosed),
carpet or floor damage due to use not in accordance with manufacturer's
instructions or failure to turn the brush bar off when necessary.
• Reduction in battery discharge time due to battery age or use.
WARRANTY SERVICE
We highly recommend you register your machine on Lubluelu official website
and enjoy exclusive benefits.
Failure to register your product won't diminish your warranty rights.
How to Claim: Please keep your proof of purchase. To make a claim under our
limited warranty, you need to provide your original purchase receipt with the
purchase date and order number on it.
All work will be carried out by Lubluelu or its authorized agency.
Any replaced defective parts will become the property of Lubluelu.
Service under this warranty will not extend the period of this warranty.
If your machine is not functioning properly, please email us:
suppor[email protected]
Customer Service
Please contact us if you need any help as following:
Email: suppor[email protected]
Website: lubluelu.com
Made in China
- Technical Support
- Package is NOT in perfect condition
- Parts missing
- Any other quality issues
Tiger-Zhou UG (haftungsbeschränkt)
Handelsregister: Leipzig HRB 37896
Shukowstr. 6 04347 Leipzig, Deutschland
Email: Tiger-Zhou@web.de
EC REP
UK REP
HAIWAI CONSULTING LTD
113, GloucesterPlace, Fly, London, England, W1U 6JR
Email: haiwaiconsultingltd@gmail.com
