PH01-T Digital Wall Clock User Manual
ThreeDucksDirect@outlook.com
1. Installation -------------------------------------------------- 1
2. First use ------------------------------------------------------ 2
3. Overview ----------------------------------------------------- 3-4
4. Time Set ------------------------------------------------------ 5-7
5. Alarm Set ----------------------------------------------------- 8-9
6. Temperature --------------------------------------------------- 9
7. Screen brightness, Font Colors, Night light -------------- 10
8. Countdown, Volume Setting -------------------------------- 11
9. Daylight saving time ----------------------------------------- 12
10. Settings with device buttons -------------------------------- 13-14
11. FAQ ---------------------------------------------------------- 15
12. Warranty ---------------------------------------------------- 16
Contents
ThreeDucksDirect@outlook.com
Installation
2 * hanging nails
1. Align the positioning hole to nail the hanging nail to the wall.
2. Hang the alarm clock on the nail.
3. Installation completed
ThreeDucksDirect@outlook.com
1
Start to power on
Power on for the first time
Connect the DC power plug to the back connector of the alarm clock, and the USB plug
at the other end is connected to the charging head to plug into the 100V-240V home
socket. As shown in the following figure:
This alarm clock must work with power adapter. We provide lifetime warranty for
every customer. We strongly recommend you to contact us with your order ID to
activate the warranty. You can also visit www.jall-us.com to activate lifetime
warranty. If missing any accessories, please contact us for replacements.
ThreeDucksDirect@outlook.com
2
Device Overview
Time display area
Night Light
Alarm setting
Time setting
+
-
DC input
ThreeDucksDirect@outlook.com
3
Remote Control Overview
Alarm 1 setting
Alarm 1 switch
DOWN “ - ”
Time setting
12H / 24H
Night light switch
Screen Brightness
Volume up / down
Auto Brightness
C° / F° unit
Alarm 2 setting
Alarm 2 switch
UP “ + ”
Auto Daylight
Saving Time
Display letter color
Countdown setting
Confirm and Next
ThreeDucksDirect@outlook.com
4
Auto Bluetooth
Manual Bluetooth
3. After choosing the 12H/24H and DST mode, you have 2 ways for time setting.
They’re Bluetooth Method and Manually Method.
Time Setting (by remote control)
Note: we strongly recommend to set with remote control for the whole setting.
1. Press to select 12-Hour or 24-Hour mode according to your habits.
2. Press to turn on AUTO DST, it’s for daylight saving time area.
If you don’t need it, just ignore this step.
5
Bluetooth Time Setting
4.1. Press to switch on Bluetooth mode. The “BT” icon will flash on the
clock screen, waiting for connecting your cellphone in 10 minutes.
4.2. Switch on your cellphone Bluetooth, find the Bluetooth signal “PH01 Clock”
and connect it. Accept and allow the clock to access to your cellphone.
4.3. When it’s connected successfully, the “BT” icon will stay on for 3-5 seconds
and it will automatically synchronize your cellphone’s time with the clock.
4.4. <Notice> : If you don’t allow the clock to access to your phone, it can’t
synchronize the time and will fail to finish time setting.
4.5. Now time setting is finished and the clock will auto disconnect Bluetooth.
You may see the “BT” icon disappear on the screen and the time of the clock
is already correctly set.
4.6. To keep the time always correct, you can press button to turn ON / OFF
Auto Bluetooth mode. When it’s ON, the clock will automatically switch on
Bluetooth by 10:00 a.m. and 10:00 p.m. every day for 10 minutes, to connect
cellphone and synchronize the time, then disconnect Bluetooth automatically.
The process of connection will be very short. You can’t even realize it’s finished.
In this way, it can keep the time always the same with your phone.
Notice: You just need to pair with the clock once, and it will remember.
If the clock can’t connect to any phones in 10 minutes, it will also
quit Bluetooth mode automatically.
Tips: Sometimes the Bluetooth signal is not strong enough, makes it stuck on a
certain step. To solve this problem, we recommend you to unpair your
phone’s Bluetooth connection with the clock. Press button on the
clock’s remote to turn off Bluetooth mode, then turn on again and retry.
6
5.4. Then “Minute” is flashing, press to select value. Press and next.
Time Setting (by remote control)
5.3. The “Hour” is flashing, press to select value. Press and next.
5.5. Then “Year” is flashing, press to select value. Press and next.
5.6. Then “Month” is flashing, press to select value. Press and next.
5.7. Then “Date” is flashing, press to select value.
Press to finish time setting.
Note: You don’t have to set the day of the week. It’s calculated automatically.
If you find the day is wrong, it’s most likely you’ve set a wrong “YEAR”.
When you turn on Auto DST, time will auto adjust on March and November.
If you don’t need auto DST, please turn if off.
7
Manually Time Setting
5.1. Ignore step.5 if you’ve finished time setting by Bluetooth method.
5.2. After choosing the 12H/24H and DST mode, press to enter time setting.
You will set in sequence for Hour > Minute > Year > Month > Date
4. Then “Minute” is flashing, press to select value. Press and next.
2. Press to enter the alarm #1 setting, you will set in sequence for
Alarm Hour > Minute > Alarm Mode (MON-SUN, MON-FRI, SAT-SUN).
Alarm Setting (by remote control)
1. Press to activate / inactivate alarm #1. You will see the icon appears,
that means alarm #1 is activated, while disappears means alarm #1 is inactivated.
3. The “Hour” is flashing, press to select value. Press and next.
5. Then select your alarm mode. There’re 3 modes to choose from.
1-7 means alarm works for Monday to Sunday (every day).
1-5 means alarm only works for Monday to Friday.
6-7 means alarm only works for Saturday to Sunday.
Then press to finish alarm setting. Alarm #2 is the same.
6. You can press to adjust alarm volume from OFF and V01 to V05.
Attention: If you find the alarm turned on unexpectedly and you don’t
need it, please set the volume to “OFF”. Sometimes other home device
remote signal, like TV will influence the clock alarm.
ThreeDucksDirect@outlook.com
8
How to stop alarm?
1. When the alarm goes off, press any buttons on remote control to
stop the alarm. It will go off the next day.
2. Without any operation, the alarm will ring for 20 minutes and stop
automatically. It will still go off the next day.
Note: If you want to disable the alarm permanently,
press or to turn it off so that it won’t go off the next day.
You will see the alarm icon disappear on the screen.
Temperature Unit
Press to change temperature from C° to F°.
Note: The temperature is detected by the sensor inside the clock. You
can’t set it manually.
ThreeDucksDirect@outlook.com
9
Font Displaying Colors & Night Light
1. Press to change letter colors. If you want to freeze
certain color, you can hold the button and release it when you
find your favorite.
1. In the time display state, press to adjust the screen brightness
from High -> Low -> High.
2. You can also press auto-dimmer button to auto adjust the
screen brightness. In this mode, the brightness will auto change
according to the environment light, makes it dimmer at night and
brighter at daytime. It shows “ON”, which means it’s turned ON,
while “OFF” means it’s turned OFF.
Screen Brightness
2. Press to turn ON / OFF the night light at the bottom.
3. When the light is on, press to adjust the brightness of
the light (range: L01-L10)
10
1. Countdown switch
In the time display screen, press to set countdown time,
Press to set your desired time (range from 1~30MIN).
Press to start counting down. If you want to stop it and return to
time display screen. Just hold for 2s to quit.
2. How to stop the bell ringing?
1) Press any buttons to stop it.
2) The bell will ring for 60 seconds and stop automatically.
Countdown Setting
Volume Setting
In the time display screen, press to set alarm volume
range from (OFF - V01-V05). If you find the alarm is turned on
unexpectedly and you don’t need it, please set the volume to “OFF”
ThreeDucksDirect@outlook.com
11
Daylight Saving Time
1. Press to turn ON / OFF AUTO DST, it’s for daylight saving time area.
It will automatically adjust displaying time on the 2
nd
Sunday of March and
1
st
Sunday of November. When it’s ON, the screen will show “AUTO DST”.
2. If your area doesn’t apply to daylight saving time, please turn DST OFF.
Tips for remote control
Please aim at the product when using the remote control.
12
We recommend users to set by remote control.
For any reasons, if missing remote control, you can set up basic settings
by pressing buttons on the device. However, functions like “Night light”,
“DST”, “Countdown”, “Brightness setting”, “Display Colors”, “Volume”
can only set by remote control.
Settings without remote control
Alarm setting
Time setting
+
-
13
3. Then do the same for “Hour”, “Minute”, “Year”, “Month” and “Date”.
Time Setting (by device buttons)
Note: we strongly recommend to set with remote control for the whole setting.
1. Press button on the right of device to enter time setting. You will
set in sequence for 12/24H mode > Hour > Minute > Year > Month > Date
2. The “12H / 24H” is flashing, press to select value.
Press to confirm and next.
Note: You don’t have to set the day of the week. It’s calculated automatically.
Auto DST can only set by remote control.
Alarm Setting (by device buttons)
2. Hold button for 2 seconds to enter the alarm #1 setting, you will set in
sequence for Alarm Hour > Minute > Alarm Mode (MON-SUN,
MON -FRI , SAT-SUN). Press button to confirm and next.
1. Press to activate / inactivate alarm #1. You will see the icon appears,
that means alarm #1 is activated, while disappears means alarm #1 is inactivated.
5. After setting Hour, Minute, you will need to choose alarm mode:
1-7 = Monday to Sunday, 1-5 = Monday to Friday, 6-7 = Saturday to Sunday
6. Alarm #2 can only set by remote control.
14
FAQ
Q1: The day of the week is wrong.
This section summarizes the most common issues you may have. If you’re unable to
solve the issue, please feel free to contact ThreeDucksDirect@outlook.com.
The day of the week is calculated automatically. Please check if the “Year”,
“Month”, “Date” are set correctly. Many customers may have set a wrong “Year”.
Please press “Time Set” button to enter time setting, pay attention to something like
“2023” or “2024”. That’s the year value, you have to set a correct year so that the
day of the week will calculate correctly.
The temperature is detected by the inside sensor. The LED circuit may produce heat,
making it not so accurate as professional thermometer. It’s normal. We need your
understanding. If it has a huge difference with actual temperature, please contact us.
Q3: The temperature is inaccurate
The remote control is powered by CR2032 battery. If it doesn’t work, it may be run
out of battery. Please try to replace CR2032 battery.
Q4: The remote control doesn’t work.
15
Sometimes other home device remote signal, like TV will influence the clock alarm.
If you find the alarm turned on unexpectedly and you don’t need it, please press the
“Volume Down” button to set the volume “OFF”.
Q2: The alarm goes off unexpectedly. How can I turn it off permanently?
We provide lifetime warranty to every customer.
Contact us to activate your lifetime warranty Now!
Don’t forget to include your order ID when contact.
FAQ
Email
Visit
ThreeDucksDirect@outlook.com
www.jall-us.com
Missing any accessories or any questions during usage, please contact us.
Q5: The BT mode doesn’t work.
1. Make sure you have allowed the clock’s Bluetooth to access your phone.
2. Sometimes the Bluetooth signal is not strong enough, makes it stuck on a certain
step. We recommend you to unpair your phone's Bluetooth connection with the
clock. Press BT button on the clock's remote to turn off Bluetooth mode, then turn
on again and retry.
Warranty
