Operating Instructions
Cordless Telephone
Model No. KX-TGB810
KX-TGB812
Model shown is KX-TGB810.
Before initial use, see “Getting Started”
on page 11.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them
for future reference.
®
Consulte “Guía Rápida Española”, página 37.
For assistance, visit our Web site: http://shop.panasonic.com/support
for customers in the U.S.A.
Please register your product: http://shop.panasonic.com/support
Table of Contents
2
Introduction
Model composition......................... 3
Accessory information ................... 3
Graphical symbols for use on
equipment and their descriptions... 5
Important Information
For your safety............................... 6
Important safety instructions.......... 8
For best performance .................... 8
Other information ........................... 9
Specications ................................ 10
Getting Started
Setting up ...................................... 11
Note when setting up ..................... 12
Navigating the menus .................... 13
Date and time ................................ 13
Other settings ................................ 13
Controls ......................................... 14
Display icons ................................. 15
Menu map...................................... 16
Making/Answering Calls
Making calls ................................... 17
Answering calls.............................. 17
Useful features during a call .......... 17
Intercom, transferring calls and
conference calls ............................ 18
Redial ............................................ 19
Handset locator ............................. 19
Phonebook
Phonebook .................................... 20
Speed dial...................................... 21
Caller ID service
Using Caller ID service .................. 23
Programming
Call block ....................................... 26
Flash time ...................................... 27
Dial mode ...................................... 27
Auto clock ...................................... 27
Clock and alarm............................. 27
Personal settings ........................... 28
Useful Information
Voicemail ....................................... 31
Wall mounting ................................ 31
Troubleshooting ............................. 31
FCC and other information ............ 34
Guía Rápida Española
Guía Rápida Española .................. 37
Appendix
Customer services ......................... 42
Limited Warranty
(ONLY FOR U.S.A.) ....................... 43
Index
Index .............................................. 45
3
For assistance, please visit http://shop.panasonic.com/support
Model composition
Series Model No.
Base unit Handset
Part No. Part No. Quantity
KX-TGB810
series
KX-TGB810 KX-TGB810 KX-TGBA81 1
KX-TGB812 KX-TGB810 KX-TGBA81 2
Accessory information
Supplied accessories
No. Accessory item/Part number
Quantity
KX-TGB810 KX-TGB812
AC adaptor/PNWYAB810S00 1 2
Telephone line cord/PNJA1186Z 1 1
Rechargeable batteries
*1
2 4
Handset cover
*2
/PNWYAB810S01 1 2
Charger/PNWYAB810S02 - 1
*1
See page 4 for replacement battery information.
*2
The handset cover comes attached to the handset.
Introduction
1
2
3
4
2 3 4
5
5
1
For assistance, please visit http://shop.panasonic.com/support
4
Introduction
Additional/replacement accessories
Please contact your nearest Panasonic dealer for sales information (page 42).
Accessory item Model number/Specications
Rechargeable
batteries
HHR-4DPA*
1
● To order, please visit http://shop.panasonic.com/support
Battery type:
– Nickel metal hydride (Ni-MH)
– 2 x AAA (R03) size for each handset
*1
Replacement batteries may have a different capacity from that of the
supplied batteries.
Other information
● Design and specications are subject to change without notice.
● The illustrations in these instructions may vary slightly from the actual
product.
5
For assistance, please visit http://shop.panasonic.com/support
Graphical symbols for use on equipment and
their descriptions
Symbol Explanation Symbol Explanation
Alternating current (A.C.)
Class II equipment
(equipment in which
protection against
electric shock relies on
Double Insulation or
Reinforced Insulation)
Direct current (D.C.) “ON” (power)
Protective earth “OFF” (power)
Protective bonding earth Stand-by (power)
Caution: risk caused by
visible radiation
“ON”/“OFF” (power;
push-push)
For indoor use only Caution, risk of electric
shock
Introduction
6
For assistance, please visit http://shop.panasonic.com/support
Important Information
● Never touch the plug with wet
hands. Danger of electric shock
exists.
Installation
● To prevent the risk of re or
electrical shock, do not expose
the product to rain or any type of
moisture.
● Do not place or use this product
near automatically controlled
devices such as automatic doors
and re alarms. Radio waves
emitted from this product may
cause such devices to malfunction
resulting in an accident.
● Do not allow the AC adaptor
or telephone line cord to be
excessively pulled, bent or placed
under heavy objects.
Operating safeguards
● Unplug the product from power
outlets before cleaning. Do not
use liquid or aerosol cleaners.
● Do not disassemble the product.
● Do not spill liquids (detergents,
cleansers, etc.) onto the telephone
line cord plug, or allow it to
become wet at all. This may cause
a re. If the telephone line cord
plug becomes wet, immediately
pull it from the telephone wall jack,
and do not use.
● Do not place the corded or
cordless handset in the base unit
when battery cover is removed.
Medical
● Consult the manufacturer of any
For your safety
To prevent severe injury and loss
of life/property, read this section
carefully before using the product to
ensure proper and safe operation of
your product.
WARNING
Power connection
● Use only the power source marked
on the product.
● Do not overload power outlets and
extension cords. This can result in
the risk of re or electric shock.
● Completely insert the AC adaptor/
power plug into the power outlet.
Failure to do so may cause electric
shock and/or excessive heat
resulting in a re.
● Regularly remove any dust, etc.
from the AC adaptor/power plug
by pulling it from the power outlet,
then wiping with a dry cloth.
Accumulated dust may cause an
insulation defect from moisture,
etc. resulting in a re.
● Unplug the product from power
outlets if it emits smoke, an
abnormal smell, or makes an
unusual noise. These conditions
can cause re or electric shock.
Conrm that smoke has stopped
emitting and contact us at
http://shop.panasonic.com/support
● Unplug from power outlets and
never touch the inside of the
product if its casing has been
broken open.
7
For assistance, please visit http://shop.panasonic.com/support
Important Information
Note:
● This height is not guaranteed
for product reliability.
● To prevent serious injuries due
to the product unexpectedly
falling, the product must be
installed at a height of 1.5 m
or lower.
● This product is unable to make
calls when:
– the handset batteries need
recharging or have failed.
– there is a power failure.
Battery
● We recommend using the
batteries noted on page 4.
USE ONLY rechargeable Ni-MH
batteries AAA (R03) size.
● Do not mix old and new batteries.
● Do not open or damage the
batteries. Released electrolyte
from the batteries is corrosive
and may cause burns or injury to
the eyes or skin. The electrolyte
is toxic and may be harmful if
swallowed.
● Exercise care when handling the
batteries. Do not allow conductive
materials such as rings, bracelets,
or keys to touch the batteries,
otherwise a short circuit may
cause the batteries and/or the
conductive material to overheat
and cause burns.
● Charge the batteries provided
with or identied for use with this
product only, in accordance with
the instructions and limitations
specied in this manual.
personal medical devices, such
as pacemakers or hearing aids, to
determine if they are adequately
shielded from external RF (radio
frequency) energy. (The product
operates in the frequency range
of 1.92 GHz to 1.93 GHz, and the
RF transmission power is 115 mW
(max.).)
● Do not use the product in health
care facilities if any regulations
posted in the area instruct you not
to do so. Hospitals or health care
facilities may be using equipment
that could be sensitive to external
RF energy.
CAUTION
Installation and location
● Never install telephone wiring
during an electrical storm.
● Never install telephone line jacks
in wet locations unless the jack is
specifically designed for wet
locations.
● Never touch uninsulated
telephone wires or terminals
unless the telephone line has
been disconnected at the
network interface.
● Use caution when installing or
modifying telephone lines.
● The AC adaptor is used as the
main disconnect device. Ensure
that the AC outlet is installed near
the product and is easily
accessible.
● The product is only use for
mounting at heights ≤ 2 m.
8
For assistance, please visit http://shop.panasonic.com/support
Important Information
Important safety
instructions
When using your product, basic
safety precautions should always
be followed to reduce the risk of re,
electric shock, and injury to persons,
including the following:
1. Do not use this product near
water for example, near a
bathtub, washbowl, kitchen sink,
or laundry tub, in a wet basement
or near a swimming pool.
2. Avoid using a telephone (other
than a cordless type) during an
electrical storm. There may be a
remote risk of electric shock from
lightning.
3. Do not use the telephone to
report a gas leak in the vicinity of
the leak.
4. Use only the power cord and
batteries indicated in this manual.
Do not dispose of batteries in a
re. They may explode. Check
with local codes for possible
special disposal instructions.
SAVE THESE INSTRUCTIONS
For best performance
Base unit location/
avoiding noise
The base unit and other compatible
Panasonic units use radio waves to
communicate with each other.
● Only use a compatible base unit
(or charger) to charge the batteries.
Do not tamper with the base unit
(or charger). Failure to follow
these instructions may cause the
batteries to swell or explode.
● Avoid the use in the following
conditions
– High or low extreme
temperatures during use, storage
or transportation.
– Replacement of a battery with
an incorrect type that can defeat a
safeguard.
– Disposal of a battery into re
or a hot oven, or mechanically
crushing or cutting of a battery,
that can result in an explosion.
– Extremely high temperature and/
or extremely low air pressure that
can result in an explosion or the
leakage of ammable liquid or gas.
Attention:
A nickel metal hydride battery that
is recyclable powers the product
you have purchased. Please call
1-800-8-BATTERY (1-800-822-8837)
for information on how to recycle this
battery.
9
For assistance, please visit http://shop.panasonic.com/support
Important Information
● When you leave the product
unused for a long period of time,
unplug the product from the power
outlet.
● The product should be kept away
from heat sources such as heating
devices, cooking appliances, etc.
It should not be placed in rooms
where the temperature is less than
0°C (32°F) or greater than 40°C
(104 °F). Damp basements should
also be avoided.
● The maximum calling distance
may be shortened when the
product is used in the following
places: Near obstacles such as
hills, tunnels, underground, near
metal objects such as wire
fences, etc.
● Operating the product near
electrical appliances may cause
interference. Move away from the
electrical appliances.
Routine care
● Wipe the outer surface of the
product with a soft moist cloth.
● Do not use benzine, thinner, or
any abrasive powder.
Other information
● The applied nameplate is located at
the bottom or rear of the product.
● CAUTION: Risk of explosion if
battery is replaced by an incorrect
type. Dispose of used batteries
according to the instructions.
● For maximum coverage and
noise-free communications, place
your base unit:
– at a convenient, high, and central
location with no obstructions
between the handset and base unit
in an indoor environment.
– away from electronic appliances
such as TVs, radios, personal
computers, wireless devices, or
other phones.
– facing away from radio
frequency transmitters, such as
external antennas of mobile phone
cell stations. (Avoid putting the
base unit on a bay window or near
a window.)
● Coverage and voice quality
depends on the local
environmental conditions.
● If the reception for a base unit
location is not satisfactory, move
the base unit to another location
for better reception.
Environment
● Keep the product away from
electrical noise generating
devices, such as uorescent
lamps and motors.
● The product should be kept free
from excessive smoke, dust, high
temperature, and vibration.
● The product should not be
exposed to direct sunlight.
● Do not place heavy objects on top
of the product.
10
For assistance, please visit http://shop.panasonic.com/support
Important Information
Specications
● Frequency range:
1.92 GHz to 1.93 GHz
● RF transmission power:
115 mW (max.)
● Power source:
100–240 V AC, 50/60 Hz
● Power consumption:
Base unit:
Standby: 0.39 W
Maximum: 1.2 W
Charger:
Standby: 0.03 W
Maximum: 0.6 W
● Operating conditions:
0°C (32 °F) – 40°C (104°F), 20 %
– 80 % relative air humidity (dry)
Notice for product disposal,
transfer, or return
● This product can store your
private/condential information. To
protect your privacy/condentiality,
we recommend that you erase
information such as phonebook or
caller list entries from the memory
before you dispose of, transfer, or
return the product.
Notice
11
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Note:
● Use only the supplied AC adaptor
MN0063-L060040.
Battery installation
1 Press down at
1
.
2 Slide the handset cover
2
.
3 Insert the batteries, then close
the handset cover.
● USE ONLY rechargeable Ni-MH
batteries AAA (R03) size(
A
).
● Do NOT use alkaline/manganese/
Ni-Cd batteries.
● Conrm correct polarities.
Setting up
Connections
■ Base unit
Connect the telephone line cord
to the unit until you hear a click.
Connect the AC adaptor to the
unit by pressing the plug rmly.
Fasten the cord by hooking it.
Connect the AC adaptor to the
power outlet.
Connect the telephone line cord
to the single-line telephone jack
(RJ11) until you hear a click.
A DSL/ADSL lter (not supplied)
is required if you have a DSL/
ADSL service.
Note:
● Use only the supplied AC adaptor
MN0063-L060040.
■ Charger
Connect the AC adaptor to the
unit by pressing the plug rmly.
Fasten the cord by hooking it.
Connect the AC adaptor to the
power outlet.
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
1
2
A
+
–
+
–
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
Hook
Hook
12
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Power failure
The unit cannot be used to make or
receive calls during a power failure.
We recommend connecting a corded-
type telephone that does not use an
AC adaptor to your telephone line.
Note for battery installation
● Use the supplied rechargeable
batteries. For replacement,
we recommend using the
rechargeable batteries noted
on page 4 and 7.
Note for battery charging
● It is normal for the handset to feel
warm during charging.
● Clean the charge contacts of the
handset, base unit and charger
with a soft and dry cloth once a
month. Before cleaning the unit,
disconnect from power outlets and
any telephone line cords. Clean
more often if the unit is exposed to
grease, dust, or high humidity.
Battery charging
Charge for at least 8 hours.
When the handset needs charging,
the display shows “Low battery”
and there is a warning beep every
2 minutes during a call, recharge
the handset before using it again.
When charging, will scroll on
the display.
Note when setting up
Note for connections
● The AC adaptor must remain
connected at all times. (It is normal
for the adaptor to feel warm during
use.)
● The AC adaptor should be
connected to a vertically oriented
or oor-mounted AC outlet. Do
not connect the AC adaptor to a
horizontally oriented AC outlet
that faces the oor, such as an
AC outlet installed on a ceiling or
under a table, as the weight of the
adaptor may cause it to become
disconnected.
MENU
OK
REDIAL MUTE
BACK
13
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Note:
If no buttons are pressed for 30
seconds, the handset returns to
standby automatically.
Date and time
1
L
MENU/OK
R
,
L
d
R
“Clock/
Alarm”, press
L
MENU/OK
R
.
2 “Date & time”.
3
L
MENU/OK
R
to select.
4 Enter the date using the keypad
(e.g. 08-12-20 for August 12th
2020) and press
L
MENU/OK
R
to
conrm.
5 Enter the time (12-hour clock
format) using the keypad (e.g.
09:00) then press
L
u
R
or
L
d
R
to select
“AM”
or
“PM”
and press
L
MENU/OK
R
to save.
Other settings
Dial mode
If you cannot make calls, change this
setting according to your telephone
line service. the default setting is
"Tone", to change this setting, see
page 27.
"Tone": For tone dial service.
"Pulse": For rotary/pulse dial
service.
Battery level
Battery is fully charged
Battery is partially charged
Battery is running low
Flashes when battery is
almost fully discharged
Ni-MH battery performance
(supplied batteries)
Operation Operating time
In continuous use 9 hours max.
Not in use (standby) 180 hours max.
Note:
● Actual battery performance
depends on usage and ambient
environment.
Navigating the menus
The phone has an easy to use menu
system. Each menu has a list of
options, which can be seen on the
menu map on page 16.
When the handset is in standby:
1
L
MENU/OK
R
to open the main
menu.
2
L
u
R
or
L
d
R
: available
options.
3
L
MENU/OK
R
to select an option.
4 To return to the previous menu
level, press
L
MUTE/BACK
R
.
5 To exit the menu and return to
standby, press
L
OFF
R
.
14
For assistance, please visit http://shop.panasonic.com/support
Getting Started
1 Receiver
2 Redial
Press to view the last 10 entries
dialed.
3 Menu/Ok
Press to open the Menu.
Select the option displayed
on screen.
Conrm menu option.
4 Phonebook/Scroll up/
Volume up
Open the phonebook list.
Scroll up through lists
and menus.
Increase the receiver or speaker
volume during a call.
Increase the ringer volume
while ringing.
5 Intercom
Press to make intercom call and
transfer calls to another handset.
This feature is not available for
single handset model.
6 Talk/Speakerphone
Press to make and receive calls.
During a call, press to turn
speakerphone on and off.
7 Speed dial buttons
Press and hold to show the
stored entry, page 21.
8 Dial keypad
9
/Pulse to Tone dialing
Dial a star, page 21.
During a call, press to switch
from pulse dialing to tone dialing,
page 18.
10 Display
See page 15 for an overview
of the display icons.
Controls
Handset
MENU
OK
REDIAL MUTE
BACK
7
10
2
3
4
5
6
8
9
1
11
12
13
14
16
17
15
15
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Base unit
1 Charge contacts
2 Locator button
Use to locate a misplaced
handset.
Display icons
Signal icon
Steady when registered
and in range.
11 Mute/Back
In editing mode, press to delete
characters and digits.
Go back to the previous
menu level.
During a call, press to turn mute
on/off, page 17.
12 Flash
Press to use with switchboard/
PBX services and some
network services.
13 Off
Press to end a call.
14 Caller list/Scroll down/
Volume down
Press to enter the caller list.
Scroll down through lists
and menus.
Decrease the receiver or
speaker volume during a call.
Decrease the ringer volume
while ringing.
15
/Change case/Pause
Dial a .
Press and hold to change the
case from Abc to abc or ABC
mode when entering or editing
letters, page 20.
Press and hold to enter a pause
when pre-dialling or storing
numbers, page 17.
16 Microphone
17 Charge contacts
2
1
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
16
For assistance, please visit http://shop.panasonic.com/support
Handset ringer is off
Flashes to indicate a new
missed call and when
viewing a new missed call
in the caller list.
Steady when viewing a
missed call in the caller list
Steady when making an
outgoing call
Flashes to indicate an
incoming or intercom call
Indicates an answered call
when viewing the caller list
Indicates an outgoing call
when viewing the redial list
Speakerphone is activated
Alarm is set
Flashes when the alarm
is ringing
Flashes to indicate
new voicemail
messages received
Steady when the entry has
been viewed in the call log
Time
Date
Indicates you can scroll
through a list or adjust the
volume while talking
More text after
Menu map
Phonebook - View
- Add new
- Edit
- Delete
*1
- Delete all
*1
Clock/Alarm - Date & time
- Set alarm
Personal setting - Handset tone
- Ring volume
- Ring tones
- Key tone
- Docking tone
- Battery tone
- Phone name
- Language
- Auto answer
- Auto hang-up
Advanced
setting
- Call list type
- Call block
-Anonymous call
-Block list
-
Block mode
-
Block number
- Area code
- Flash time
- Dial mode
- Auto clock
- Register
- Deregister
*2
- Reset
*1
Only available if a phonebook entry
is stored.
*2
This feature is not available for
single handset model.
Getting Started
17
For assistance, please visit http://shop.panasonic.com/support
Making/Answering Calls
1
L
9
R
. Press and hold
L R
. “P”
(Pause) will be displayed.
2 Dial the phone number
L
TALK/SP-PHONE
R
.
Note:
A 3.5 second pause is inserted each
time you press and hold
L R
(Pause)
on the handset.
Answering calls
When an outside call is received,
the phone rings and
ashes on the
display.
1 Lift the handset and press
L
TALK/SP-PHONE
R
when the
unit rings.
2 When you nish talking, press
L
OFF
R
or place the handset on the
base unit or charger.
Auto answer: You can answer calls
simply by lifting the handset (page 29).
Temporary ringer off: You can turn
the ringer off temporarily by pressing
L
MUTE/BACK
R
.
Adjusting the ringer volume
Press
L
u
R
or
L
d
R
to select the
desired volume while ringing.
Useful features during
a call
Mute
1 Press
L
MUTE/BACK
R
. The display
shows
“Mute on”
.
2 To return to the call, press
L
MUTE/BACK
R
.
Making calls
1 Lift the handset and then dial the
phone number. To correct a digit,
press
L
MUTE/BACK
R
.
2 Press
L
TALK/SP-PHONE
R
to
make a call. To make the call
using the speakerphone, press
L
TALK/SP-PHONE
R
.
3 When you nish talking, press
L
OFF
R
or place the handset on the
base unit or charger.
Note:
While talking, you can switch between
the receiver and the speakerphone
by pressing
L
TALK/SP-PHONE
R
.
In step 1, you can store the dialed
phone number to the phonebook
by pressing
L
MENU/OK
R
.
Auto hang-up: You can end a call
simply by placing the handset on the
base unit or charger (page 29).
Adjusting the receiver or
speaker volume
Press
L
u
R
or
L
d
R
to select the
desired volume while talking.
Pause (for PBX/long distance
service users)
A pause is sometimes required when
making calls using a PBX or long
distance service.
When storing a calling card access
number and/or PIN in the phonebook,
a pause is also needed (page 21).
Example:
If you need to dial the line access
number “9” when making outside
calls with a PBX:
18
For assistance, please visit http://shop.panasonic.com/support
Making/Answering Calls
Intercom, transferring
calls and conference
calls
Available for: KX-TGB812
Making an intercom call
If 2 or more handsets are registered
to the base unit, intercom calls can
be made between two handsets.
ashes and the display shows the
handset number you are calling.
1 Press
L
INTERCOM
R
and the other
handset rings automatically.
Receiving an intercom call
When an intercom call is received,
ashes and the handset number that
is calling is displayed.
1
L
TALK/SP-PHONE
R
to answer
the call.
Transferring calls
Outside calls can be transferred or a
conference call with an outside party
can be made between 2 handsets.
During an outside call:
1 Press
L
INTERCOM
R
and the other
handset rings automatically.
2 When the other handset answers,
press
L
OFF
R
to complete the transfer.
Note:
If there is no answer from the
other handset, press
L
MUTE/BACK
R
to return to the outside caller. The
outside call resumes automatically
after 60 seconds if there is no answer.
L
FLASH
R
allows you to use the
special features of your host PBX
such as transferring an extension
call, or accessing optional telephone
services.
Note:
To change the ash time, see
page 27.
For call waiting or Call Waiting
Caller ID service users
To use call waiting or Call Waiting
Caller ID, you must rst subscribe
with your phone service provider.
This feature allows you to receive
calls while you are already talking on
the phone. If you receive a call while
on the phone, you will hear a call
waiting tone.
If you subscribe to both Caller ID
and Call Waiting with Caller ID
services, the 2nd caller’s information
is displayed on the handset that is
in use after you hear the call waiting
tone.
1 Press
L
FLASH
R
to answer the
2nd call.
2 To switch between calls,
press
L
FLASH
R
.
Temporary tone dialing (for
rotary/pulse service users)
Press
L R
before entering access
numbers which require tone dialing.
Flash
19
For assistance, please visit http://shop.panasonic.com/support
Making/Answering Calls
5 Enter the name and press
L
MENU/OK
R
. The number is
displayed.
6 Edit the number if necessary,
then press
L
MENU/OK
R
. The
number is stored.
Note:
See ‘Entering names and writing tips’
on page 20.
Deleting an entry
1
L
REDIAL
R
.
2
L
u
R
or
L
d
R
: Select the desired
entry.
3
L
MENU/OK
R
“Delete”,
press
L
MENU/OK
R
.
4
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to cancel.
Deleting the entire redial list
1
L
REDIAL
R
, press
L
MENU/OK
R
.
2
L
d
R
“Delete all”, press
L
MENU/OK
R
.
3
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to cancel.
Handset locator
The handset locator can be used to
alert a handset user that they are
wanted or locate a missing handset.
Locator calls cannot be answered by
a handset.
1
L
p
R
on the base unit.
The handset will ring.
2 To stop the ringing, press
any button.
3-way conference call
To hold a 3-way conference call
between 2 intercom callers and 1
outside caller.
During a call with an outside caller:
1 Press
L
INTERCOM
R
and the other
handset rings automatically.
2 Once the second handset
answers, press
L
MENU/OK
R
to
join all 3 callers.
3 Press
L
OFF
R
to end the call.
Redial
Making a call using the
redial list
The last 10 phone numbers dialed are
stored in the redial list (each 24 digits
max.)
1
L
REDIAL
R
.
2
L
u
R
or
L
d
R
: Select the desired
entry.
3
L
TALK/SP-PHONE
R
.
Note:
If the caller’s number exactly matches
an entry stored in the phonebook, the
name is displayed.
Copying a redial list number to
the phonebook
1
L
REDIAL
R
.
2
L
u
R
or
L
d
R
: Select the desired
entry.
3
L
MENU/OK
R
“Save number”
.
4
L
MENU/OK
R
“Enter name”
.
20
For assistance, please visit http://shop.panasonic.com/support
Phonebook
Press and hold
L
MUTE/BACK
R
for
1 second to delete all characters or
digits.
L
u
R
or
L
d
R
to move between
characters/digits.
L0R
to insert a space.
Viewing or dialling an entry
1 Press
L
u
R
.
2
L
u
R
or
L
d
R
: Select the required
entry.
OR
Enter the rst letter of the name
to search alphabetically. The rst
name that starts with this letter or
the nearest letter in the alphabet
will be displayed.
L
u
R
or
L
d
R
: Select the required
entry.
3
L
TALK/SP-PHONE
R
to dial or
L
OFF
R
to return to standby.
Editing a name and number
1
L
MENU/OK
R
“Phonebook”
.
2
L
MENU/OK
R
,
L
d
R
“Edit”
,
press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select the entry
that needs to be edited, or search
alphabetically, press
L
MENU/OK
R
.
4
L
MUTE/BACK
R
to delete the
name if required, then enter the
new name and press
L
MENU/OK
R
. The existing number
is displayed.
5
L
MUTE/BACK
R
to delete the
number if required, then enter
the new number and press
L
MENU/OK
R
. The entry is saved.
Phonebook
The phonebook can store up to 50
names and numbers. Names can
be up to 16 characters long and
numbers up to 24 digits.
Storing a name and number
When subscribed to Caller ID,
to display the name of the caller
instead of the number, save the full
telephone number including the area
code to the phonebook.
Multiple entries can be stored with
the same name. However, to prevent
unnecessary duplicated entries, the
number can be stored only once.
1
L
MENU/OK
R
“Phonebook”.
2
L
MENU/OK
R
,
L
d
R
“Add new”.
3
L
MENU/OK
R
. “Enter name”.
4 Enter the name and press
L
MENU/OK
R
. “Enter number” is
displayed.
5 Enter the number and press
L
MENU/OK
R
. The entry is saved.
6
L
OFF
R
to return to standby.
Entering names and writing tips
Use the keypad letters to enter
names, e.g. to store Tom:
L
8
R
once to enter T.
L
6
R
three times to enter o.
L
6
R
once to enter m.
Press and hold
L R
to change the
case from Abc to abc or ABC mode.
L
MUTE/BACK
R
to delete the last
character or digit.
21
For assistance, please visit http://shop.panasonic.com/support
Phonebook
pauses after the number and PIN
as necessary (page 17).
● If you have rotary/pulse service,
you need to press
L R
before
pressing
L
MENU/OK
R
in step
1 to change the dialing mode
temporarily to tone. When adding
entries to the phonebook, we
recommend adding
L R
to the
beginning of phone numbers you
wish to chain dial.
Speed dial
You can assign 1 phone number to
each of the dial keys (1 and 2). The
speed dial number can be up to 24
digits. If a number is stored in the
phonebook, it cannot be stored as a
speed dial number.
Storing phone numbers to
speed dial keys
1
L
MENU/OK
R
“Phonebook”
.
Press
L
MENU/OK
R
.
2
L
d
R
:
“Edit”
and press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select the “Speed
dial 1” or “Speed dial 2” you
want to store the number under,
press
L
MENU/OK
R
.
4 Enter the number, press
L
MENU/OK
R
.
Note:
If you want to change/delete the
speed dial number follow the rst 3
steps above. Delete the number by
pressing
L
MUTE/BACK
R
and either
press
L
MENU/OK
R
to save no number
or enter the new number and press
L
MENU/OK
R
to save.
Deleting an entry
1
L
MENU/OK
R
“Phonebook”
.
2
L
MENU/OK
R
,
L
d
R
“Delete”
,
press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select the entry
that needs to be deleted, or
search alphabetically, press
L
MENU/OK
R
.
4
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to cancel.
Deleting all entries
1
L
MENU/OK
R
“Phonebook
”.
2
L
MENU/OK
R
,
L
d
R
“Delete all”
,
press
L
MENU/OK
R
.
3
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to cancel.
Chain dial
This feature allows you to dial phone
numbers in the phonebook while you
are on a call. This feature can be
used, for example, to dial a calling
card access number or bank account
PIN that you have stored in the
phonebook, without having to dial
manually.
1 During an outside call, press
L
MENU/OK
R
.
2
L
u
R
or
L
d
R
: Select the desired
entry.
3 Press
L
TALK/SP-PHONE
R
to dial
the number.
Note:
● When storing a calling card
access number and your PIN in
the phonebook as one phonebook
entry, press and hold
L R
to add
22
For assistance, please visit http://shop.panasonic.com/support
Phonebook
Dialing a speed dial number
Press and hold the relevant key
(
L
1
R
or
L
2
R
) until the number is
displayed and dialed.
23
For assistance, please visit http://shop.panasonic.com/support
Caller ID service
Phonebook name display
When caller information is received
and it matches a phone number
stored in the phonebook, the stored
name in the phonebook is displayed
and logged in the caller list.
To ensure that the caller’s name
is displayed, make sure the full
telephone number, including the area
code is stored in the phonebook.
Area code
Phone numbers stored automatically
in the caller list will include area
codes. If you do not want to dial the
area code when making calls from
the caller list, you can store the area
code which you want the unit to
delete automatically. The area code
must be 3-digit long.
1
L
MENU/OK
R
,
L
d
R
"Advanced
setting", press
L
MENU/OK
R
.
2
L
d
R
"Area code", press
L
MENU/OK
R
.
3 Enter the 3-digit area code, press
L
MENU/OK
R
to conrm.
Setting the call list type
You can set the caller list to show All
calls or Missed calls only.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting
”
, press
L
MENU/OK
R
.
2 "Call list type" is displayed,
press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select “
All calls”
or
“
Missed calls”
, press
L
MENU/OK
R
to conrm.
Using Caller ID service
IMPORTANT
● This unit is Caller ID compatible.
To use Caller ID features, you
must subscribe to a Caller ID
service. Contact your phone
service provider for details.
Caller ID features
When an outside call is being
received, the caller’s phone number
is displayed. Caller information for
the last 20 callers is logged in the
caller list from the most recent call to
the oldest.
● If the unit cannot receive caller
information, the following is
displayed:
–
“Out of area”
: The caller dials from
an area which does not provide a
Caller ID service.
–
“Private”
: The caller requests not
to send caller information.
If the unit is connected to a PBX
system, caller information may not be
properly received. Contact your PBX
supplier.
Missed calls
If a call is not answered, the unit
treats it as a missed call. The display
shows "X missed call(s)"
*1
and
ashes . This lets you know if you
should view the calls list to see who
called while you were away.
*1
"X" depends on the number of new missed calls.
24
For assistance, please visit http://shop.panasonic.com/support
Caller ID service
Note:
See ‘Entering names and writing tips’
on page 20.
Editing a caller's phone number
You can edit a phone number in the
caller list by removing its area code
and/or the long distance code "1".
Important:
To edit a number, you need to store
the area code (page 23).
1
L
d
R
CID
.
2
L
u
R
or
L
d
R
: To select the required
entry.
3 Press
L
#
R
repeatedly until the
phone number is shown in the
desired format.
4
L
TALK/SP-PHONE
R
.
Deleting an entry
1
L
d
R
CID
.
2
L
u
R
or
L
d
R
: To select the required
entry.
3
L
MENU/OK
R
.
4
L
d
R
“Delete”
, press
L
MENU/OK
R
.
5
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to cancel.
Deleting all caller information
1
L
d
R
CID
.
2
L
MENU/OK
R
.
3
L
d
R
“Delete all”
, press
L
MENU/OK
R
.
4
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to cancel.
Viewing the caller list
1
L
d
R
CID
. If there are no calls
in the list, the display shows
“List empty”
.
2
L
u
R
or
L
d
R
: To select the
required entry.
3
L
MENU/OK
R
“View”
.
4 Press
L
MENU/OK
R
to view the call
name and time and date of the
call, press
L
MENU/OK
R
to switch
between the name and number.
Note:
disappears after viewing all
missed call.
Dialing a number in the
caller list
1
L
d
R
CID
.
2
L
u
R
or
L
d
R
: To select the
required entry.
3
L
TALK/SP-PHONE
R
to dial the
displayed entry.
Copying a caller list number to
the phonebook
1
L
d
R
CID
.
2
L
u
R
or
L
d
R
: To select the required
entry.
3
L
MENU/OK
R
.
4
L
d
R
“Save number”
, press
L
MENU/OK
R
.
5 Enter the name if necessary, then
press
L
MENU/OK
R
. The number is
displayed.
6 Edit the number if necessary,
then press
L
MENU/OK
R
to save.
25
For assistance, please visit http://shop.panasonic.com/support
Caller ID service
Storing a number to the
block list
1
L
d
R
CID
.
2
L
u
R
or
L
d
R
: To select the
required entry.
3
L
MENU/OK
R
.
4
L
d
R
“Block number”
, press
L
MENU/OK
R
.
5
L
d
R
: To select next available slot,
press
L
MENU/OK
R
, number is
displayed, press
L
MENU/OK
R
to
conrm.
Note:
To activate the call block feature,
you must turn the block mode on
(page 26).
26
For assistance, please visit http://shop.panasonic.com/support
Programming
Setting a number to be
blocked
You can store up to 20 phone
numbers in the block list.
To activate this feature, you must turn
the block mode on (page 26).
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Call block”
, press
L
MENU/OK
R
.
3
L
d
R
“Block list”
, press
L
MENU/OK
R
.
4
L
d
R
“Block number”
,
press
L
MENU/OK
R
.
5 If required, press
L
u
R
or
L
d
R
to
the next available slot.
6
L
MENU/OK
R
, enter the number
you want to block, press
L
MENU/OK
R
to save.
Note:
When you store a phone number in
the block list, you will need to store
the full number including the area
code for the number to be blocked.
If you want to change/delete the
block list number follow the first 4
steps in ‘Setting a number to be
blocked’ above, and then press
L
u
R
or
L
d
R
to the slot where the number
is stored, press
L
MENU/OK
R
.
To delete the number, press
MUTE/BACK
R
, either press
MENU/OK
R
to delete, or enter a new
number and press
L
MENU/OK
R
.
Call block
This feature allows the unit to block
calls from specied phone numbers
that you do not want to answer such
as junk calls. When a call is received,
the unit does not ring while the caller
is being identied. If the caller’s
phone number matches an entry in
the block list, the unit emits no sound
to the caller and "Blocked caller" is
displayed for about 7 seconds, then
disconnects the call.
Switching anonymous
call on/off
You can block calls when no phone
number is provided, such as Private,
or Out of area calls.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Call block”
, press
L
MENU/
OK
R
“Anonymous call”
is
displayed.
3
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”
, press
L
MENU/OK
R
to conrm.
Turning block mode on/off
1
L
MENU/OK
R
,
L
d
R
,
“Advanced
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Call block”
, press
L
MENU/OK
R
.
3
L
d
R
“Block list”
, press
L
MENU/OK
R
“
Block mode”
is displayed.
4
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”
, press
L
MENU/OK
R
to conrm.
L
L
27
For assistance, please visit http://shop.panasonic.com/support
Programming
Auto clock
If you have subscribed to Caller ID
Service, the date and time will be set
on all your handsets whenever a call
is received. This feature can be set
to On or Off.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Auto clock”
, press
L
MENU/OK
R
.
3
L
d
R
: To select
“On”
or
“Off”
,
press
L
MENU/OK
R
to conrm.
Clock and alarm
Setting the date and time
1
L
MENU/OK
R
,
L
d
R
“Clock/
Alarm”, press
L
MENU/OK
R
.
2 “Date & time”.
3
L
MENU/OK
R
to select.
4 Enter the date using the keypad
(e.g. 08-12-20 for August 12th
2020) and press
L
MENU/OK
R
to conrm.
5 Enter the time (12-hour clock
format) using the keypad (e.g.
09:00) then press
L
u
R
or
L
d
R
to select
“AM”
or
“PM”
and press
L
MENU/OK
R
to save.
Setting the alarm
1
L
MENU/OK
R
,
L
d
R
“Clock/
Alarm”
, press
L
MENU/OK
R
.
2
L
d
R
“Set alarm”
, press
L
MENU/OK
R
.
Flash time
Flash allows you to use the special
features of your host PBX such
as transferring an extension call,
or accessing optional telephone
services.
It is unlikely that you need to change
this setting unless advised to do so.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Flash time”
, press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select "80ms",
"90ms", "100ms", "110ms",
"160ms", "200ms", "250ms",
"300ms", "400ms", "600ms",
"700ms" or "900ms", press
L
MENU/OK
R
to conrm.
Dial mode
Your phone is set to tone dialing.
You should only need to change
this if connected to an older type of
switchboard / PBX which requires
pulse dialing.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Dial mode”
, press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select
“Tone”
or
“Pulse”
, press
L
MENU/OK
R
to conrm.
28
For assistance, please visit http://shop.panasonic.com/support
Programming
Handset ringer tone
Different ringer melodies can be
set. Choose from 10 different ringer
melodies. While scrolling a sample
ring will be heard for each melody.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
“Handset tone”
, press
L
MENU/OK
R
.
3
L
d
R
“Ring tones”
, press
L
MENU/OK
R
.
4
L
u
R
or
L
d
R
: Select the melody
(1 – 10).
5
L
MENU/OK
R
to save or
L
MUTE/BACK
R
to return to
the previous menu.
Key tones
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
“Handset tone”
, press
L
MENU/OK
R
.
3
L
d
R
“Key tone”
.
4
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”
, press
L
MENU/OK
R
to conrm.
Docking tone
When you place the handset on the
base unit or charger, you will hear
a double beep. You can switch this
beep On or Off.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
“Handset tone”
, press
L
MENU/OK
R
.
3
L
d
R
“Docking tone”
.
3
L
u
R
or
L
d
R
: To select
“On”
or
“Off”
, press
L
MENU/OK
R
to
conrm.
4 If you select "On" enter the time
using 12 hour format (e.g 09:00)
then press
L
u
R
or
L
d
R
to select
“AM”
or
“PM”
and press
L
MENU/OK
R
to save.
Note:
Once the alarm is set to on, is
displayed and the alarm will sound
for 30 seconds every day until it is
turned off again. When the alarm
sounds ashes and
“Alarm on”
is displayed. Press any key to stop
the sound.
Personal settings
Handset ringer volume
The handset ring volume can be set
to different volume level. Choose
from 5 volume levels or Off.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
“Handset tone”
, press
L
MENU/OK
R
.
3
“Ring volume”
, press
L
MENU/OK
R
.
4
L
u
R
or
L
d
R
: Select the volume
(1 – 5 or
“Off”
).
5
L
MENU/OK
R
to save or
L
MUTE/BACK
R
to return to the
previous menu.
29
For assistance, please visit http://shop.panasonic.com/support
Programming
4
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”
, press
L
MENU/OK
R
to conrm.
Battery tones
When your batteries are running low
on charge you will hear a beep. You
can switch this beep On or Off.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
“Handset tone”
, press
L
MENU/OK
R
.
3
L
d
R
“Battery tone”
.
4
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”
, press
L
MENU/OK
R
to conrm.
Handset name
A personalized name can be set for
each handset. A name can be up to
14 characters long.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Phone name”
, press
L
MENU/OK
R
.
3 Enter the new handset name,
press
L
MENU/OK
R
to save.
To delete the current name or
if a mistake is made, press
L
MUTE/BACK
R
to delete the
last character or digit.
Note:
See ‘Entering names and writing tips’
on page 20.
Language
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Language”
, press
L
MENU/OK
R
.
3
L
u
R
or
L
d
R
: To select the required
language and press
L
MENU/OK
R
to conrm.
Note:
Languages available are English,
Spanish and French.
Auto answer
The phone is set to answer calls by
lifting the handset off the base unit or
charger. This feature can be switched
off so that calls can only be answered
by pressing
L
TALK/SP-PHONE
R
.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Auto answer”
.
3
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”
, press
L
MENU/OK
R
to conrm.
Auto hang-up
The phone is set to end calls by
pressing
L
OFF
R
. This feature can
be switched on so that calls can be
ended by placing the handset on the
base unit or charger.
1
L
MENU/OK
R
,
L
d
R
“Personal
setting”
, press
L
MENU/OK
R
.
2
L
d
R
“Auto hang-up”
.
3
L
MENU/OK
R
,
L
u
R
or
L
d
R
:
To select
“On”
or
“Off”,
press
L
MENU/OK
R
to conrm.
Restore default settings
The phone can be restored to its
default (original) settings. The
handset that is registered to the base
unit will be retained.
30
For assistance, please visit http://shop.panasonic.com/support
Programming
Dial mode Tone
Auto clock On
Caller list Empty
Redial list Empty
Receiver volume 4
Speaker volume 3
IMPORTANT
Resetting the phone to its default
settings will delete all entries in the
caller list. Current handset and base
settings will also be reset. Entries
stored in the phonebook are retained.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”, press
L
MENU/OK
R
.
2
L
u
R
“Reset”, press
L
MENU/OK
R
.
3 The display shows “Conrm?”.
4
L
MENU/OK
R
to conrm or
L
MUTE/BACK
R
to return to the
previous menu. The phone will
restart automatically.
Note:
Once reset the handset will prompt
you to reset the date and time, see
page 27.
Default settings by reset
Phonebook Unchanged
Speed dial Unchanged
Alarm Off
Ringer volume 5
Ringer tone 1
Key tone On
Docking tone On
Battery tone On
Handset name HANDSET
Language English
Auto answer Off
Auto hang-up On
Call list type All calls
Anonymous call Off
Block mode Off
Block list Empty
Area code Empty
Flash time 700ms
31
For assistance, please visit http://shop.panasonic.com/support
Useful information
Troubleshooting
No dial tone
● Use only the telephone line cord
supplied.
● Check that the telephone line cord
is connected properly.
● Check that the mains power is
connected properly.
No display
● Check that the batteries are
inserted correctly and fully
charged. Use only approved
rechargeable batteries supplied.
● Reset the unit by removing the
batteries and disconnecting the
mains power. Wait for around
15 seconds before connecting
it again. Allow up to one minute
for the handset and base unit to
synchronize.
is not displayed
● Handset is out of range. Move
closer to the base unit.
● The handset registration is
cancelled. Register the handset to
the base unit, see page 32.
● Check that the mains power is
connected properly.
is not scrolling during
charge
● Adjust the handset slightly on the
base unit.
Voicemail
Voicemail is an automatic answering
service offered by your phone service
provider. This service can also record
calls when you are unavailable to
answer the phone or when your line
is busy. Messages are recorded on
the phone company system. When
you have new messages is
displayed if message indication
service is available. Please contact
your phone service provider for
details of this service.
To listen to your voice mail
messages, you have to dial your
voicemail access number manually.
Important:
If still remains on the display
even after you have listened to new
messages, turn it off by pressing and
holding
L
5
R
while viewing all voicemail
entries of caller list .
Wall mounting
Note:
● Make sure that the wall and the
xing method are strong enough
to support the weight of the unit.
Drive the screws (
A
) (not supplied)
into the wall.
B
25.4mm (1 inch)
B
A
32
For assistance, please visit http://shop.panasonic.com/support
Useful information
Handset does not ring
● The handset ringer volume may
be set to Off, see page 28.
Noise interference on my
phone or on other electrical
equipment nearby
● Place the phone at least one
metre away from electrical
appliances or any metal
obstructions to avoid any risk of
interference.
Registering a handset
On the base unit:
1 Press and hold
L
p
R
for 5
seconds. The base unit will
remain in registration mode for
120 seconds.
On the handset:
2 If “Unregistered” is displayed,
press
L
MENU/OK
R
and then enter
the 4 digit PIN code (0000) and
press
L
MENU/OK
R
.
3 If “Searching” or “Unavailable”
is displayed, press
L
MENU/OK
R
,
L
d
R
“Advanced setting”,
press
L
MENU/OK
R
.
4
L
d
R
“Register”, press
L
MENU/OK
R
.
5 Enter the 4 digit PIN code (0000)
and press
L
MENU/OK
R
.
A beep will be heard if the registration
is successful. The handset is
automatically assigned an available
handset number.
● Clean the charge contacts with a
dry cloth.
● Check that the mains power is
connected properly.
● The battery is full. When the
handset is fully charged, will
appear steadily on the display.
I cannot enter the time when
setting the date and time
● You need to use 12-hour clock
format, but invalid time may be
displayed. Enter the time between
01:00 and 12:59.
No Caller Display
● You must subscribe to Caller
ID service. Contact your phone
service provider for details.
● The caller may have withheld their
number.
● The record cannot be found in the
phonebook. Check that the correct
name/number is stored in the
phonebook, with the full area code.
Cannot register a handset to the
base unit
● Check that correct PIN code
(0000) has been entered.
● Check that the handset and base
unit are at least one metre away
from other electrical equipment
to avoid interference when
registering.
33
For assistance, please visit http://shop.panasonic.com/support
Useful information
Liquid damage
Liquid or other form of
moisture has entered the
handset/base unit
● Disconnect the AC adaptor
and telephone line cord from
the base unit. Remove the
batteries from the handset and
leave to dry for at least 3 days.
After the handset/ base unit
are completely dry, reconnect
the AC adaptor and telephone
line cord. Insert the batteries
and charge fully before use. If
the unit does not work properly,
contact an authorized service
center.
Caution:
● To avoid permanent damage,
do not use a microwave oven to
speed up the drying process.
Note:
If registration is not successful the
rst time, please repeat the process
again in case the base registration
period ran out of time. If the base unit
is not found after about 120 seconds,
the handset returns to standby. Try
registering again.
De-register a handset (Available
for: KX-TGB812)
Use one handset to de-register
another. The handset being used
cannot de-register itself.
1
L
MENU/OK
R
,
L
d
R
“Advanced
setting”, press
L
MENU/OK
R
.
2
L
d
R
“Deregister”, press
L
MENU/OK
R
.
3 Enter the 4 digit PIN code (0000),
press
L
MENU/OK
R
.
4
L
u
R
or
L
d
R
to select the handset
that needs to be de-registered,
press
L
MENU/OK
R
. A conrmation
beep will be heard and the
display will return to standby.
34
For assistance, please visit http://shop.panasonic.com/support
Useful information
FCC and other
information
This equipment complies with
Part 68 of the FCC rules and the
requirements adopted by the ACTA.
On the bottom of this equipment is
a label that contains, among other
information, a product identier in the
format US:ACJ----------.
If requested, this number must be
provided to the telephone company.
● Registration No.............(found on
the bottom of the unit)
● Ringer Equivalence No.
(REN) .....................................0.9A
A plug and jack used to connect this
equipment to the premises wiring
and telephone network must comply
with the applicable FCC Part 68
rules and requirements adopted by
the ACTA. A compliant telephone
cord and modular plug is provided
with the product. It is designed to be
connected to a compatible modular
jack that is also compliant.
The REN is used to determine
the number of devices that may
be connected to a telephone line.
Excessive RENs on a telephone
line may result in the devices not
ringing in response to an incoming
call. In most but not all areas, the
sum of RENs should not exceed
ve (5.0). To be certain of the
number of devices that may be
connected to a line, as determined
by the total RENs, contact the local
telephone company. For products
approved after July 23, 2001, the
REN for the product is part of the
product identier that has the format
US:AAAEQ##TXXXX. The digits
represented by ## are the REN
without a decimal point (e.g., 03 is a
REN of 0.3).
If this equipment causes harm to the
telephone network, the telephone
company will notify you in advance
that temporary discontinuance of
service may be required. But if
advance notice isn’t practical, the
telephone company will notify the
customer as soon as possible. Also,
you will be advised of your right to
le a complaint with the FCC if you
believe it is necessary.
The telephone company may make
changes in its facilities, equipment,
operations or procedures that could
affect the operation of the equipment.
If this happens the telephone
company will provide advance
notice in order for you to make
necessary modications to maintain
uninterrupted service.
If trouble is experienced with this
equipment, for repair or warranty
information, please contact a Factory
Service Center or other Authorized
Servicer. If the equipment is causing
harm to the telephone network, the
telephone company may request that
you disconnect the equipment until
the problem is resolved.
Connection to party line service is
subject to state tariffs. Contact the
state public utility commission, public
service commission or corporation
commission for information.
35
For assistance, please visit http://shop.panasonic.com/support
Useful information
(1) This device may not cause
harmful interference, and (2) this
device must accept any interference
received, including interference that
may cause undesired operation.
Privacy of communications may not
be ensured when using this phone.
CAUTION:
Any changes or modications not
expressly approved by the party
responsible for compliance could
void the user’s authority to operate
this device.
NOTE:
This equipment has been tested and
found to comply with the limits for
a Class B digital device, pursuant
to Part 15 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses, and can radiate
radio frequency energy and, if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving
antenna.
If your home has specially wired
alarm equipment connected to the
telephone line, ensure the installation
of this equipment does not disable
your alarm equipment. If you have
questions about what will disable
alarm equipment, consult your
telephone company or a qualied
installer.
This equipment is hearing aid
compatible as dened by the FCC in
47 CFR Section 68.316.
When you hold the phone to your
ear, noise might be heard in your
Hearing Aid. Some Hearing Aids are
not adequately shielded from external
RF (radio frequency) energy. If noise
occurs, use an optional headset
accessory or the speakerphone
option (if applicable) when using this
phone. Consult with your audiologist
or Hearing Aid manufacturer about
the availability of Hearing Aids which
provide adequate shielding to RF
energy commonly emitted by digital
devices.
WHEN PROGRAMMING
EMERGENCY NUMBERS AND(OR)
MAKING TEST CALLS TO
EMERGENCY NUMBERS:
1 Remain on the line and briey
explain to the dispatcher the
reason for the call.
2 Perform such activities in the
off-peak hours, such as early
morning or late evenings.
This device complies with Part 15 of
the FCC Rules. Operation is subject
to the following two conditions:
36
For assistance, please visit http://shop.panasonic.com/support
Useful information
Notice:
● FCC ID can be found inside the
battery compartment or on the
bottom of the units.
– Increase the separation between
the equipment and receiver.
– Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an
experienced radio/TV technician for
help.
Some cordless telephones operate
at frequencies that may cause
interference to nearby TVs and
VCRs. To minimize or prevent such
interference, the base of the cordless
telephone should not be placed
near or on top of a TV or VCR. If
interference is experienced, move
the cordless telephone further away
from the TV or VCR.This will often
reduce or eliminate interference.
FCC RF Exposure Warning:
● This product complies with FCC
radiation exposure limits set forth
for an uncontrolled environment.
● To comply with FCC RF exposure
requirements, the base unit must
be installed and operated 20 cm
(8 inches) or more between the
product and all person’s body.
● This product may not be
collocated or operated in
conjunction with any other antenna
or transmitter.
● For body-worn operation, the
handset must be used only with
a non-metallic accessory. Use of
other accessories may not ensure
compliance with FCC RF exposure
requirements.
37
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
37
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
Guía Rápida Española
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
Gancho
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
Gancho
Guía rápida
Unidad base
Conecte el cable de la línea telefónica a la unidad hasta que escuche un clic.
Conecte el adaptador de corriente alterna a la unidad presionán
dolo rmemente.
Enganche el cable para jarlo.
Conecte el adaptador de corriente a la toma de corriente.
Conecte el cable de la línea telefónica a la toma de una sola línea telefónica (RJ11)
hasta que escuche un clic.
Requiere un ltro DSL/ADSL (no incluido) si dispone de este tipo de servicio.
Nota:
Use solo el adaptador de corriente MN0063-L060040 que se incluye.
Cargador
Conecte el adaptador de corriente alterna a la unidad presionán
dolo rmemente.
Enganche el cable para jarlo.
Conecte el adaptador de corriente a la toma de corriente.
Nota:
Use solo el adaptador de corriente MN0063-L060040 que se incluye.
38
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
38
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
MENU
OK
REDIAL MUTE
BACK
Guía Rápida Española
1
2
A
+
–
+
–
1 Presione
1
hacia abajo.
2 Deslice la tapa del auricular
2
.
3 Inserte las baterías y, a continuación,
cierre la tapa del auricular.
Instalación y carga de la batería
Cargue durante al menos 8 horas.
Cuando el auricular necesite carga, la pantalla mostrará el men
saje “Batería baja”
y se emitirá un pitido de advertencia cada 2 minutos durante una llamada. Recargue
el auricular antes de usarlo nuevamente. Cuando se esté cargando el dispositivo, se
mostrará el icono
con sus barras en movimiento.
Nota
USE SOLO baterías recargables de Ni-MH tamaño AAA (R03) (
A
).
NO utilice baterías alcalinas, de manganeso ni de Ni-Cd.
Conrme que las polaridades estén correctas.
Cambie el idioma de la pantalla.
39
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
39
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Sugerencias de operación
1
L
MENU/OK
R
para abrir el menú principal.
2
L
u
R
o
L
d
R
: opciones disponibles.
3
L
MENU/OK
R
para seleccionar una opción.
4
Para volver al nivel de menú anterior, oprima
L
MUTE/BACK
R
.
5
Para salir del menú y regresar a espera, oprima
L
OFF
R
.
Cambio de idiomas (predeterminado: “English”)
1
L
MENU/OK
R
,
L
d
R
“Personal setting” (Ajustes pers.), oprima
L
MENU/OK
R
.
2
L
d
R
“Language” (Idioma),
L
MENU/OK
R
.
3
L
u
R
o
L
d
R
: Para seleccionar el idioma deseado, oprima
L
MENU/OK
R
.
Fecha y hora
1
L
MENU/OK
R
,
L
d
R
“Reloj/Alarma”,
L
MENU/OK
R
.
2
“Fecha y hora”,
L
MENU/OK
R
.
3
Introduzca la fecha con el teclado,
L
MENU/OK
R
.
4
Introduzca la hora con el teclado,
L
MENU/OK
R
.
Operaciones básicas
Cómo hacer y contestar llamadas
Para hacer llamadas Marque el número telefónico.
L
TALK/SP-PHONE
R
.
Para contestar llamadas
L
TALK/SP-PHONE
R
.
Para colgar
L
OFF
R
.
Para ajustar el volumen del
receptor o del altavoz
Oprima repetidamente
L
u
R
o
L
d
R
durante la
llamada.
Para hacer una llamada
usando la lista de
remarcación
1
L
REDIAL
R
.
2
L
u
R
o
L
d
R
: Seleccione la entrada deseada.
3
L
TALK/SP-PHONE
R
.
Para ajustar el volumen del
timbre
Oprima repetidamente
L
u
R
o
L
d
R
para elegir el
volumen deseado mientras el teléfono suena.
Guía Rápida Española
4040
Guía Rápida Española
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
40
For assistance, please visit http://shop.panasonic.com/support
Directorio telefónico
Para añadir entradas 1
L
MENU/OK
R
“Directorio”.
2
L
MENU/OK
R
,
L
d
R
“Agregar nueva”.
3
L
MENU/OK
R
“Introd. nombre”.
4 Introduzca el nombre,
L
MENU/OK
R
se muestra la opción “Introd. número”.
5 Introduzca el nombre,
L
MENU/OK
R
.
Para hacer llamadas
1
L
u
R
.
2
L
u
R
o
L
d
R
: Seleccione la entrada deseada.
O
Introduzca la primera letra del nombre deseado
para realizar una búsqueda en orden alfabético.
Se mostrará el primer nombre que comience
con dicha letra o con la letra más cercana del
alfabeto.
L
u
R
o
L
d
R
: Seleccione la entrada deseada.
3
L
TALK/SP-PHONE
R
.
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
40
Guía Rápida Española
41
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
41
Preguntas frecuentes
Preguntas Causa/Solución
¿Por qué no se muestra
?
El auricular está demasiado lejos de la unidad
base. Acérquelo.
El adaptador para corriente de la unidad base no
está conectado correctamente. Conecte de nuevo
el adaptador para corriente a la unidad base.
El registro del auricular está cancelado. Registre
el auricular a la unidad base.
En la unidad base:
1 Mantenga oprimido
L R
durante 5 segundos.
En el auricular:
2 Si se muestra “No registrado”,
L
MENU/OK
R
. Introduzca el código PIN de 4
dígitos (0000),
L
MENU/OK
R
.
3 Si se muestra “Buscando…” o
“No disponible”,
L
MENU/OK
R
,
L
d
R
“Ajuste avanz.”,
L
MENU/OK
R
.
4
L
d
R
“Registrar”,
L
MENU/OK
R
. Introduzca el
código PIN de 4 dígitos (0000),
L
MENU/OK
R
.
¿Cómo se incrementa el nivel
de volumen del auricular?
Oprima repetidamente la tecla de volumen
L
u
R
mientras habla.
¿Por qué hay ruido o se corta
la conversación?
Trate de reubicar la unidad base de forma que se
minimice la distancia al auricular.
Si ocurre el mismo problema incluso con el
auricular junto a la unidad base, visite:
http://shop.panasonic.com/support
¿Es posible mantener
cargando las baterías todo el
tiempo?
Puede dejar el auricular en la unidad base o el
cargador en cualquier momento.
¿Cómo se contestan las
llamadas en espera (2a
llamada)?
Oprima
L
FLASH
R
cuando escuche el tono de
llamada en espera.
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
42
For assistance, please visit http://shop.panasonic.com/support
Customer services
Appendix
Accessories!
hp://shop.panasonic.com/support
Customer Services Directory
Shop
for all your Panasonic gear
Go to
Get everything you need to get the most out of
your Panasonic products
Accessories & Parts for your Camera, Phone, A/V
products, TV, Computers & Networking, Personal
Care, Home Appliances, Headphones, Baeries,
Backup Chargers & more…
For Product Informaon, Operang Assistance,
Parts, Owner’s Manuals, Dealer and Service info
go to
hp://shop.panasonic.com/support
For the hearing or speech impaired TTY: 1- 877-833-8855
As of June 2015
For assistance, please visit http://shop.panasonic.com/support
43
Appendix
Limited Warranty (ONLY FOR U.S.A.)
Limited Warranty Coverage (For USA Only)
Labor
One (1) Year
Parts
One (1) Year
To submit a new repair request and for quick repair status visit our Web Site at
http://shop.panasonic.com/support
Panasonic Products Limited Warranty
Online Repair Request
Mail-In Service--Online Repair Request
If your product does not work properly because of a defect in materials or workmanship,
Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length
of the period indicated on the chart below, which starts with the date of original purchase
(“warranty period”), at its option either (a) repair your product with new or refurbished parts,
(b) replace it with a new or a refurbished equivalent value product, or (c) refund your
purchase price. The decision to repair, replace or refund will be made by the warrantor.
During the “Labor” warranty period there will be no charge for labor. During the “Parts”
warranty period, there will be no charge for parts. This Limited Warranty excludes both
parts and labor for non-rechargeable batteries, antennas, and cosmetic parts (cabinet).
This warranty only applies to products purchased and serviced in the United States.
This warranty is extended only to the original purchaser of a new product which was
not sold “as is”.
Telephone
When shipping the unit, carefully pack, include all supplied accessories listed in the
Owner’s Manual, and send it prepaid, adequately insured and packed well in a carton box.
When shipping Lithium Ion batteries please visit our Web Site at
http://shop.panasonic.com/support as Panasonic is committed to providing the most up to
date information. Include a letter detailing the complaint, a return address and provide a
daytime phone number where you can be reached. A valid registered receipt is required
under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER WILL
BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING
DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL
BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF
OF PURCHASE.
Product or Part Name
44
For assistance, please visit http://shop.panasonic.com/support
Limited Warranty Limits and Exclusions
(As examples, this excludes damages for lost time, travel to and from the servicer,
loss of or damage to media or images, data or other memory or recorded content.
The items listed are not exclusive, but for illustration only.)
This warranty ONLY COVERS failures due to defects in materials or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which
are caused by products not supplied by the warrantor, or failures which result from
accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or other business
or rental use of the product, or service by anyone other than a Factory Service Center
or other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY.
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY,
ARE YOUR RESPONSIBILITY.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state. If a problem with this product develops during or after the warranty period,
you may contact your dealer or Service Center. If the problem is not handled to your
satisfaction, then write to:
Panasonic Corporation of North America
Consumer Affairs Department 8th FI.
Two Riverfront Plaza
Newark NJ 07102-5490
As of January 2020
Appendix
Index
Index
A Alarm: 27
Answering calls: 17
Area code: 23
Auto answer: 29
Auto clock: 27
Auto hang-up: 29
B Base unit:
Controls: 15
Locator: 19
Battery: 4, 7
Battery charging: 12
Battery installation: 11, 12
Battery level: 13
Battery performance: 13
C Call block: 26
Caller ID: 23
Call waiting: 18
Call Waiting Caller ID: 18
Chain dial: 21
Conference call: 19
Connections: 11
D Date and time: 13, 27
Default settings: 30
De-register a handset: 33
Dial mode: 13, 27
Display icons: 15
F FCC and other information: 34
Flash: 18
Flash time: 27
H Handset:
Battery tones: 29
Controls: 14
Docking tone: 28
Key tones: 28
Name: 29
Ringer tone: 28
I Intercom: 18
L Language: 29
M Making calls: 17
Menu map: 16
Mute: 17
N Navigating the menus: 13
P Pause: 17
Phonebook: 20
Power failure: 12
R Redial: 19
Restore default settings: 29
Rotary/pulse service: 18
S Safety instructions: 8
Setting up: 11
SP-PHONE (Speakerphone): 17
Specications: 10
Speed dial: 21
T Temporary tone dialing: 18
Transferring calls: 18
Troubleshooting: 31
TTY: 42
V Voicemail: 31
Volume
Receiver: 17
Ringer: 17, 28
Speaker: 17
W Wall mounting: 31
Warranty: 43
45
46
Notes
47
Notes
© Panasonic Corporation 2020
Printed in China
PNQE1137ZA SS0120MU0
1 Reconnect AC adaptor to the base unit.
2 Check if telephone line cord is connected.
3 Use rechargeable Ni-MH batteries.
(Alkaline/Manganese/Ni-Cd batteries CANNOT be used.)
4 Read troubleshooting page in the Operating Instructions.
IMPORTANT!
If your product is not working properly. . .
Visit our Web site: http://shop.panasonic.com/support
LFAQ and troubleshooting hints are available.
Two Riverfront Plaza, Newark, NJ 07102-5490
For your future reference
We recommend keeping a record of the following information to assist with
any repair under warranty.
Serial No. Date of purchase
(found on the bottom of the base unit)
Name and address of dealer
Attach your purchase receipt here.
